Folding machine

CIDAN

Condition: used, machine/vehicle number: 76271002, sheet width:2040 mm plate thickness:1,2 mm total power requirement:2,5 kW weight of the machine ca.:2,0 t Nwjdpfx Abscxxq Eecjp dimensions of the machine ca.:3,0 x 1,6 x 1,7 m

Condition: good (used), Year of construction: 1978, sheet thickness brass (max.): 3 mm, Motorized folding machine Fab. Lotze Typ. HZ - 2500 x 3mm year 1978 Technical data Make: Lotze Type: HZ-25 Year of construction: 1978 Effective length: 2500 mm Nwjdpfxerc E S Ee Abcop Sheet thickness: max. 3 mm Equipment - Bending angle adjustment via potentiometer - Tool package with focus rail, bending rails, reinforcement rails - Manually adjustable back gauge All specifications without guarantee

Condition: good (used), Year of construction: 1980, machine/vehicle number: 27-3, Offer 23317 Technical data: - max. working width 2040 mm - max. material thickness at 40 kp / mm² strength 3.5 mm - Bending angle setting electronically preselectable 0 - 135 ° - smallest bending radius 1.25 x sheet thickness - Smallest inner flange height 6 x sheet thickness - Automatic sequence control for a complete work process - Operation via hand or foot switch - largest opening width / stroke of the upper beam 200 mm - Height adjustability - of the bending beam 80 mm - of the lower beam 80 mm - Upper beam drive 400 V / 1.1 kW - Bending beam drive 400 V / 1.5 kW - Manual backgauge can be operated from the front Njdpfxorklfre Abcswp - Space requirement approx. W 3300 x H 1350 x D 1500 mm - Weight approx. 2600 kg

Condition: good (used), Year of construction: 1999, machine/vehicle number: 190454, Offer 25290 Technical specifications: - Max. working width: 3040 mm - Max. material thickness at 40 kg / mm² strength: 2 mm - Preselectable bending angle: 6 – 135° - Maximum opening / stroke of the upper beam: 250 mm - Height adjustment: - of the bending beam: 50 mm Nedpfjw Sthdox Abcjwp - of the lower beam: 50 mm - Upper beam drive: 400 V / 0.37 kW - Bending beam drive: 400 V / 0.75 kW - Manual backgauge - Segmented gooseneck bending rail - Space requirement approx. W 4000 x H 1400 x D 1200 mm - Weight approx.: 3500 kg

Condition: used, Year of construction: 2008, machine/vehicle number: 150344, Order No. 25052 Technical Specifications: - Maximum working width: 2020 mm - Maximum material thickness at 40 kg/mm² strength: 2 mm - Bending angle adjustment: 0 - 135° - Upper beam clamping via eccentric lever + foot pedal - Maximum opening width/stroke of the upper beam: 100 mm - Height adjustment of the lower beam: 25 mm - Space requirement: approx. W 2950 x H 1200 x D 800 mm Nwedjv Rbq Tjpfx Abcop - Weight: approx. 1450 kg

Condition: good (used), Year of construction: 1984, machine/vehicle number: 6229, Offer 24483 Nsdpfju Eq Rpox Abcswp Technical data: - max. working width 1020 mm - max. material thickness at 40 kg / mm² strength 4 mm - Bending angle setting preselectable 6 - 135 ° - 6-fold bending angle preselection - Largest opening width / stroke of the upper beam 250 mm - Height adjustability - of the bending beam 50 mm - of the lower beam 50 mm - E. foot switch - Upper beam drive 400 V / 2.2 kW - Bending beam drive 400 V / 2.2 kW - Space requirement approx. W 2100 x H 1400 x D 1100 mm - Weight approx. 2000 kg

Condition: used, Year of construction: 1985, sheet thickness: 2,25total power requirements: 1,1sheet length: 2025 Working length: 2025 mm Kl. Tail width: 5 x s Kl. Inner radius: 1.5 - 2 x s Adjustability of the lower and bending beams: 90 mm for round bends: 90 mm Highest working position of the upper beam: 190 mm large opening width of the upper beam: 290 mm Duration of a workflow: 7.0 sec. External dimensions approx.: 3000 x 1000 x 1650 mm with: - Control panel on the right side of the machine - Simple bending angle adjustment on the control panel - Choice of switching to automatic, semi-automatic or typing mode - Potentiometer for degree adjustment -Foot switch Nwjdpfxevaatfo Abcsp used, in good condition
