Bench drill

CORMAK WS20

The CORMAK WS20 bench drill press is a professional column drill for metal, designed for drilling and tapping operations in industrial environments. Thanks to its robust construction, extended spindle stroke, and automatic tapping function, the machine delivers excellent performance and precision when machining metals, particularly structural steel.

Key Advantages

Tapping function with automatic reverse rotation – fast and safe thread cutting up to M16 in steel

High structural rigidity – 85 mm diameter column and seasoned cast iron head, base, and table ensure stability and vibration damping

135 mm spindle stroke – enables deep drilling without repositioning the workpiece

Belt drive system – five precisely selected speeds ranging from 280 to 1875 rpm

Guards with limit switches – CE compliant, enhanced operator safety

Large 360° rotating worktable with T-slots – flexible and secure workpiece clamping

Design and Technology

The CORMAK WS20 metal drill press is built from high-grade materials for durability and long service life. The spindle and transmission shafts are made of hardened steel to ensure wear resistance. The head, column, and table are manufactured from precisely machined seasoned castings, providing excellent rigidity of the entire structure.
Csdpsrif Trjfx Ah Ijpw

The MK2 Morse taper allows for quick tool changes and compatibility with a wide range of tooling.

Precision and Performance

Thanks to its rigid column, extended spindle travel, and refined belt transmission system, the machine ensures precise and repeatable drilling and tapping operations. The clear control panel simplifies operation, while the powerful 1.1 kW motor enables efficient machining even in more demanding materials.

Applications

The CORMAK WS20 column drill is ideal for use in:

industrial plants

mechanical workshops

maintenance departments

technical schools and training centers

The machine is designed for drilling and tapping in steel, aluminum, and non-ferrous materials.

Standard Equipment

Keyed drill chuck

Drift key for taper removal

U-type spindle guard with safety limit switch

Belt drive cover with limit switch

Technical Specifications
Parameter Value
Max. drilling diameter (steel) 20 mm
Max. tapping diameter (steel) M16
Spindle stroke 135 mm
Spindle taper MK2
Speed range 280–1875 rpm
Number of speeds 5
Column diameter 85 mm
Column wall thickness 12.7 mm
Spindle–column distance 260 mm
Spindle–table distance 366 mm
Spindle–base distance 678 mm
Table dimensions 300 × 320 mm
Base dimensions 376 × 566 mm
Motor power 1.1 kW
Power supply 400 V
Net weight 179 kg
Machine dimensions 800 × 450 × 1250 mm
