Chiller

DAIKIN Air Cooled Chiller

Condition: new, functionality: fully functional, Comparable to Durma, Baykal, Ermaksan, etc. Bending length 3020 mm Pressing force 220 t Approach speed 140 mm/s Bending speed max. 10 mm/s Return speed 130 mm/s Stroke 350 mm Installation height 600 mm Throat depth 450 mm X-axis travel 750 mm X-axis speed 300 mm/s R-axis travel 250 mm R-axis speed 100 mm/s Clear gap between frames 2555 mm Machine length 3730 mm Machine width 2290 mm Overall height 3055 mm Table height 820 mm Motor power 22 kW Oil tank 300 l Machine weight 11,500 kg (technical data may vary depending on equipment) Standard equipment: - 3 CNC axes (Y1, Y2, X) - Press beam double-guided, stable and precise - Robust backgauge, double-guided - Manual backgauge fingers, double-guided on linear rails - Movable front arms with height adjustment - Side and rear safety guards - Lower die adapter rail 60 mm - Manual upper tool clamping system (Promecam system) - Manual crowning - Foot switch with emergency stop - 380 V, 50-60 Hz, 3 phase - LED lighting Including the following options: - Delem DA 66T CNC controller - Fiessler AKAS 2M laser finger protection - FPSC Safety PLC (manual) - X-R axis with servo motors - CNC crowning for high bending accuracy Gtjdpfx Ajq D Dzloc Aet - 2 additional backgauge fingers - Further bending lengths and capacities available with appropriate accessories! -

Condition: used, Year of construction: 2013, functionality: fully functional, cooling capacity: 113 kW (153.64 HP), type of cooling: water, overall weight: 943 kg, total width: 2,100 mm, total length: 2,270 mm, total height: 1,330 mm, heating capacity: 117 kW (159.08 HP), Equipment: compressor, Used Carrier 30 RQS 120 air cooled chiller / heat pump on R410A. Complete with 3 Copeland ZP182KQE-TFD-604 scroll compressors, braced heat exchanger, Carrier PM 100-110mm fan - 50 Hz - 0,53/0,18 kW - 720/500 RPM, Mecasem OOPSG001171100C receiver with a volume of 23,5 liter and a control cabinet with a Carrier Pro-Dialog+ display. Specifications Brand: Carrier Type: 30 RQS 120 Product type: Water chiller / Heat pump Refrigerant: R410A Weight: 943 kg Dimensions: 2270x2100x1330 mm (LxWxH) Compressors: 3 Copeland ZP182KQE-TFD-604 Display: Carrier Pro-Dialog+ Number of fans: 2 Gedpfxsrlk E No Ac Astt Fan specifications: 50 Hz - 0.53/0.18 kW - 720/500 RPM Year of manufacture: 2013 Quantity in stock: 1

Condition: used, Year of construction: 2015, Brand: Rhoss Model: TCAV Z810 Cooling Capacity kW/h: 800 kW/h Cooling Capacity Kcal/h: 688,000 Kcal/h Evaporator: Shell & Tube Condenser: Al Finned Copper Tube Compressor: Refcomp Compressor Model: 134-S-160-L4 Controller: Carel Dimensions (mm): 2260 x 7680 x 2430 Gtodein N Amspfx Ac Ajt Weight (kg): 6490 kg

Condition: new, Year of construction: 2023, Air-cooled chiller ENR160 130KW at 7/12°C, internal P3 pump, internal 390l buffer tank. The unit is perfectly suited for process applications as it is equipped with a shell-and-tube evaporator, a buffer tank, and an internal P3 pump. Low GWP refrigerant R454B, winter package, RS485. Gtedpfx Aogfvlzoc Aet

Condition: used, functionality: fully functional, cooling capacity: 73.6 kW (100.07 HP), type of cooling: water, total width: 2,000 mm, total length: 6,050 mm, total height: 2,200 mm, Equipment: compressor, Used Copeland ZR19M3E-TWD-570 air cooled chiller on Freon. Complete with 2 Copeland ZR19M3E-TWD-570 scroll compressors, condenser with 2 Ziehl-Abegg FN100-MDS.7M.V5P1 fans - 50 Hz - 0,57/0,34 kW - 550/460 RPM - diameter 1000 mm and 2 Ziehl-Abegg FE100-NDS.6N.6 fans - 50 Hz - 0,86/0,50 kW - 420/310 RPM - diameter 1000 mm, braced heat exchanger as evaporator, water pump, expansion vessel and a control cabinet with a Carel PCO5+ electronic controller. The chiller has a capacity of 76,6 kW at the following temperatures: +0°C/+40°C. Gtodpfxorlk Hfj Ac Ajt
