Milling machining centers - horizontal

DECKEL MAHO DMC 100 H duoBLOCK

Condition: excellent (used), Year of construction: 2007, operating hours: 32,947 h, functionality: fully functional, Deckel Maho DMC 100H duo Block About the machine: Very robust machine. The main spindle was renewed in 2023. Technical Data: - Control: Siemens 840D - Travel range X, Y, Z axis: 1000/1000/1000mm - C-axis travel range: 360° - Clamping surface rotary table: 800x800mm - Rapid traverse: 60 m/min - Spindle speed: 20-12,000 rpm - Tool holder: SK50 - Tool magazine with 60 slots - Network connectivity - Automation interface possible Equipment: - Through-spindle coolant 50 bar with belt filter system - Work area flushing Dksdpfsyhwqmox Akqop - Rinse gun - Chip conveyor An inspection or test under power on site is of course possible. We are happy to offer you transportation, installation, and commissioning of the machine at your site. All from a single source: We, Baumgärtner CNC GmbH, are a company specializing in: - Service - Maintenance - Overhaul - Automation of DMG machines and those of other renowned manufacturers. We support you! From purchasing your machine, through transport and installation, to commissioning and subsequent maintenance or repair work—you can count on us.

Condition: refurbished (used), Year of construction: 2019, functionality: fully functional, GF Machining Solutions FORM X600 Year of manufacture 2019 - Factory revision 2022 C-shaped design, fixed table with lowerable container Travel paths (X/Y/Z): 600 x 400 x 500 mm Distance between table and quill: 200-700 mm Max. workpiece size: L x W x H = 1200 x 800 x 350 mm Max. workpiece weight: 2000 kg Integrated C-axis for rotation, indexing, and erosion (rpm = 0-100 rpm) Pneumatic chuck of your choice (Erowa/3R Systems) 80 amp ISPG generator Best achievable surface finish Ra 0.08 µm Dodpfxewh Sigs Akqjkp AC FORM HMI user interface 15" LCD color screen, mouse or touchscreen, keyboard, and hand control Incl. 3R-Systems Workpartner WPT1+ - 150 electrode positions - 10 pallet positions Net weight of the system: 5504 kg Machine dimensions: 1790 x 2860 x 3100 mm We will clean, service, and test the machine upon receipt of the order. Optional: - Commissioning and instruction - Transport and installation - Cooling unit - Dielectric

Condition: ready for operation (used), Year of construction: 2009, operating hours: 35,295 h, travel distance X-axis: 800 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 800 mm, controller manufacturer: HEIDENHAIN, controller model: iTNC 530, total height: 3,200 mm, total width: 5,400 mm, table width: 900 mm, table length: 700 mm, table load: 1,400 kg, overall weight: 13,000 kg, spindle speed (max.): 12,000 rpm, spindle motor power: 28,000 W, number of slots in tool magazine: 60, product length (max.): 3,400 mm, swivel angle B-axis (min.): -29 °, swivel angle B-axis (max.): 180 °, swivel angle C-axis (max.): 360 °, number of axes: 5, This 5-axis DMG DECKEL MAHO DMU 80P duoBLOCK was manufactured in 2009. It features impressive axis travels with X-axis at 800 mm, Y-axis at 1050 mm, and Z-axis at 850 mm. The machine includes a robust table size of Ø 900 × 700 mm and a maximum workpiece weight capacity of 1800 kg. If you are looking to get high-quality machining capabilities, consider the DMG DECKEL MAHO DMU 80P duoBLOCK vertical machining centre we have for sale. Contact us for further details. • Rotary axes: B-axis (tilting head) -30° to +180°; C-axis (rotary table) 360° continuous • Table size: approx. Ø 900 × 700 mm • Max. workpiece weight: approx. 1400–1800 kg • Spindle type: Vertical milling spindle Djdpfx Aksyvhfmjqjkp • Coolant through spindle (CTS): yes • CE compliant • P-B0052 – 3D control Heidenhain iTNC 530 • P-W0276 – Universal milling head with controlled B-axis • P-D0010 – Tool magazine Horizontal chain magazine with 60 positions • P-K0220 – Infrared measuring probe Renishaw OMP 60 (optical) • 3D quickSET – Tool set for checking and correcting kinematic accuracy • P-K0205 – 4-color signal light • P-G0004 – Wash gun with pump 2 bar / 40 l/min (theoretical pump capacity) • P-L0036 – Power failure safety package • Condition: Very good working condition; full service history available Technical Specification Taper Size SK 40 Through-spindle Coolant Yes

Condition: used, Year of construction: 2010, x-travel 800 mm y-travel 1.050 mm z-travel 800 mm control 840D solutionline Siemens Speed Mainspindle max. 10.000 min/-1 power capacity - main spindel 44 kW max. Torque 288 Nm tool taper HSK-A 100 DIN 69893 Swivel range -10° / +180 ° table surface area dia. 900 x 700 mm max. table load 1.500 kg distance spindlenose - table horizontal 50 - 850 mm distance spindlenose - table vertical 150 - 950 mm table speed 35 min/-1 rotatable C: 360 ° number of toolpositions 120 pos. tool taper HSK-A 100 max. tool diameter 110 mm max. tool-dia with free toolbox 230 mm max. tool length 550 mm max. tool weight 30 kg tool changing time 5,4 sec rapid traverse ( X / Y / Z ) 60 m/min Rapid B-Axis 23 min/-1 Dksdpfozc Rqwox Akqop Accelaration 7 / 6,5 / 6,5 m/s² Feed force ( X / Y / Z ) 13 / 13 / 9 kN weight of the machine ca. 13,0 t dimensions of the machine ca. 6,0 x 5,5 x 3,7 m total power requirement 80 kVA 5 Axis Machining Center - Universal DMG DECKEL MAHO - DMU 80 P duoBLOCK - Spindle replacement: May 2025 - controled Swivel-Milling-Head / Gear-Spindle (B-Axis) - NC-Rotary Table (C-Axis) - Tool identification - 3D machining, 3D tool compensation - TRANSMIT cylindrical surface transformation (milling of cylindrical paths) - CompCad compressor function for high-speed machining - WITHOUT tools

Condition: ready for operation (used), Year of construction: 2021, travel distance X-axis: 1,250 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 600 mm, controller manufacturer: HEIDENHAIN, controller model: TNC 620, table load: 1,500 kg, spindle speed (max.): 20,000 rpm, number of axes: 4, This 4-axis +GF+ Mikron Mill E 1200 was manufactured in 2021. It features a spindle speed of 20,000 rpm, HSK A63 tool magazine, and rapid traverses up to 40 m/min. The work table measures 1450 x 600 mm with a maximum load of 1500 kg. Additional features include a Lehmann 4-axis rotary table and a liftable chip conveyor. Consider the opportunity to buy this +GF+ Mikron Mill E 1200 vertical machining centre. Contact us for more information. • Tool magazine: DT30, HSK-A63 • Rapid traverse: X/Y 40 m/min; Z 35 m/min • Table size: 1450 x 600 mm • T-slots: 5 • Spindle cooling system – 20 kHz • Linear scales: MILL E 1200 linear scales Dkodpfxoyb Sifj Akqop • Machine status light Additional equipment • Liftable chip conveyor • Chip trolley • Washdown system • Oil separator • Remote electronic handwheel • TS35.10 tool presetter (TNC 620) • IRP40.02 HSK63A measuring system • Lehmann 4-axis rotary table Technical Specification Taper Size HSK 63

Condition: ready for operation (used), Year of construction: 2017, operating hours: 6,417 h, travel distance X-axis: 600 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, overall weight: 4,400 kg, number of axes: 4, This 4-axis AgieCharmilles FORM 30 was manufactured in 2017. It features a stroke of 600mm x 400mm x 400mm, with axis speeds up to 6 m/min. The machine can handle workpiece weights up to 1000kg and dimensions of 1000 x 700 x 400 mm. It includes a dielectric unit with a 750l capacity and a robust weight of 4400kg. Consider the opportunity to buy this AgieCharmilles FORM 30 die-sinking EDM machine. Contact us for more information about this machine. • Axis speed (X/Y/Z): 4 / 4 / 6 m/min • Position reading accuracy (X/Y/Z): 0.1 µm • C-axis (standard) rotation speed: 0–100 rpm • Work tank size: 1200 x 800 x 500 mm • Worktable size: 800 x 600 mm Dedpox Nr N Nofx Akqekp • Max electrode weight: 100 kg • Max workpiece weight: 1000 kg • Workpiece dimensions: 1000 x 700 x 400 mm • Dielectric unit capacity: 750 l • Generator type: ISPG • User interface: AC FORM HMI • Power supply: 3 x 380 V, 3-phase, 50 Hz

Condition: refurbished (used), Year of construction: 2014, functionality: fully functional, travel distance X-axis: 600 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 450 mm, workpiece weight (max.): 1,600 kg, total height: 2,780 mm, total width: 2,265 mm, total length: 2,110 mm, quill stroke: 450 mm, workpiece length (max.): 1,220 mm, workpiece width (max.): 870 mm, workpiece height (max.): 470 mm, GF AgieCharmilles FORM 300 Year of manufacture: 2014 Die-sinking EDM machine in C-frame design (fixed table) with automatic lowering tank Travel paths (X/Y/Z): 600 x 400 x 450 mm Maximum workpiece size: 1220 x 870 x 470 mm Table dimensions: 750 x 600 mm Maximum workpiece weight: 1,600 kg Maximum electrode weight: 50 kg Innovative ISPG Generator (Intelligent Speed Power Generator) for maximum efficiency Maximum working current: 80 amps Surface finish up to Ra 0.08 µm AC FORM HMI with intuitive user interface & touchscreen Intelligent workpiece measurement & 3D correction Reduced electrode wear thanks to iQ technology Adaptive control (ACC & ACO) for optimized spark erosion and reduced electrode wear Pneumatic chuck of your choice (Erowa or 3R Systems) Includes 6-position electrode changer LTC Machine dimensions: 2265 x 2110 x 2780 mm Total weight: 4,500 kg The machine will be cleaned, overhauled and extensively tested prior to sale to ensure the highest quality and reliability. We are also happy to offer you additional services: - Transport - Commissioning - Training - Accessories such as clamping devices Dkedpfxjx Sv E Ho Akqop

Condition: excellent (used), Year of construction: 2011, functionality: fully functional, 5-AXIS MACHINING CENTER MIKRON HPM 1350U TRIPALET, MANUFACTURED IN 2011 EQUIPPED WITH HEIDENHAIN TNC 530 Dkodpfx Aoy Tv Nbekqjp ELECTRONIC HANDWHEEL TRAVEL: Z 1350 AND 1150, Z 895, A +16°/-120°, C ±360° SPINDLE: 24,000 RPM, 38 KW, HSK-A63 (NEW) TABLE: DIAMETER 1100, MAXIMUM LOAD 1600 KG 46-TOOL CHANGER 3-PALLET CHANGER, 1000 x 840 MM RENISHAW OMP60 PART PROBE LASER TOOL MEASUREMENT APS - Advanced Process System APS Extended ITS - Intelligent Thermal Control CINEMATIC OPTIONS CHIP CONVEYOR WITH TSC MACHINE WEIGHT: 19,000 KG

Condition: ready for operation (used), Year of construction: 2010, operating hours: 36,033 h, travel distance X-axis: 800 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 800 mm, controller manufacturer: SIEMENS, controller model: 840D SolutionLine, overall weight: 16,000 kg, spindle speed (max.): 12,000 rpm, number of slots in tool magazine: 60, number of axes: 4, This 4-axis DECKEL MAHO DMC 80 H duoBLOCK was manufactured in 2010. It features a maximum spindle speed of 12,000 rpm and an impressive X, Y, and Z-axis travel of 800 mm each. The machine has a robust weight of 16,000 kg, ensuring stability during operation. If you are looking to get high-quality machining capabilities, consider the DECKEL MAHO DMC 80 H duoBLOCK horizontal machining centre we have for sale. Contact us for further details. • Power capacity: 103 kVA • Current (In max): 148 A Dodpfoy Ryyrsx Akqokp • Voltage: 400 V • Frequency: 50 Hz • Control voltage: 24 V • Measuring system: Direct, absolute, photoelectric • Resolution (X, Y, Z): 0.001 mm • Position tolerance (X, Y, Z): 0.007 mm (Standard) / 0.006 mm (with Accuracy Package) • Position tolerance A-axis: 9 ws (Standard) / 8 ws (with Accuracy Package) • Position tolerance B-axis: 8 ws (Standard) / 6 ws (with Accuracy Package) • Position tolerance C-axis: 7 ws (Standard) / 5 ws (with Accuracy Package) • Table height (top of pallet to floor): 1120 mm • Distance spindle center to table: 150 mm (minimum distance, Motor spindle) / 145 mm (Gear spindle) Technical Specification Taper Size HSK 100

Condition: reconditioned (used), Year of construction: 2008, functionality: fully functional, travel distance X-axis: 1,600 mm, travel distance Y-axis: 1,250 mm, travel distance Z-axis: 1,000 mm, rapid traverse X-axis: 60 m/min, rapid traverse Y-axis: 60 m/min, rapid traverse Z-axis: 60 m/min, feed rate X-axis: 15 m/min, feed rate Y-axis: 15 m/min, feed rate Z-axis: 15 m/min, controller model: HEIDENHAIN TNC 530, workpiece weight (max.): 4,000 kg, overall weight: 35,000 kg, spindle speed (min.): 20 rpm, spindle speed (max.): 12,000 rpm, spindle nose: SK 40 (DIN 69871), number of slots in tool magazine: 60, CNC Machining centre DECKEL MAHO DMU 160 P TECHNICAL CHARACTERISTICS: Year of manufacturing: 2008 CNC control: HEIDENHAIN TNC 530 Number of simultaneous axes: 5 Stroke X axis: 1600 [mm] Stroke Y axis: 1250 [mm] Stroke Z axis: 1000 [mm] Feed rate on X, Y and Z axes: 15000 [mm/min] Traversing feeds X, Y and Z axes: 60000 [mm/min] Table dimensions: Ø1500 x 1250 [mm] Max. load on table: 4000 [Kg] Spindle type: SK 40 (DIN 69871) Min. spindle speed: 20 [rpm] Max. spindle speed 12000: [rpm] Tool changer magazin number of stations: 60 Machine weight: 35000 [Kg] Dodpfx Akezggmbjqskp INCLUDED EQUIPMENT: 1 × HEIDENHAIN part probe 1 × laser measuring system for tool setting and tool monitoring 3 × HEIDENHAIN linear glas scales on the X, Y and Z axes 1 × through-spindle coolant system 1 × chip conveyor 1 × paper-band filtration unit (paper filter system) More information upon request.
