Universal tool milling machine, universal milling machine, drill-milling machine

DECKEL FP 1

Year of construction: 1990, condition: used, Controls: Heidenhain 3-axis digital readout, without clamping systems, tools and large table, with small table, machine makes noticeable operating noises, an on-site inspection is possible. Lrjdpfjz Ea R Isx Agret

Condition: used, Technical details: x-travel: 600 mm y-travel: 300 mm z-travel: 360 mm range of revolution per miute: max horiz. 40- 2000 U/min spindle taper: vert. / horiz. SK 40/ SK40 Lodpeu U E T Ijfx Agrsrt range of revolution per miute: max zul. 40 - 2000 U/min feed:: 2-3600 mm/min quill travel: 80 mm Table dimensions: 810 x 420 mm total power requirement: 3 KVA machine weight approx.: 1300 kg dimension machine xH: 1,8 x 1,35 x 1,95 m Milling machine with shaping head joint length 32-80mm with 10 x double strokes, 24-285 strokes/min Heidenhain 3-axis displays *

Year of construction: 1972, condition: used, Controls: Heidenhain 2-axis digital readout, without clamping systems or tools, with large table, an on-site inspection is possible. Lrsdjz Ea R Ujpfx Agrst

Condition: used, Year of construction: 1970, Deckel FP1 Tool and Cutter Grinding Machine Tool and Cutter Grinding Machine Deckel Type/Model FP1 Condition: Used, geometrically overhauled in 2026 Year of manufacture: approx. 1970 The machine was completely disassembled, thoroughly cleaned, geometrically overhauled, and repainted. Subsequently, it was professionally reassembled, and a comprehensive functional test was carried out. The machine geometry was checked and adjusted. A test report according to DIN 8615 is available. During the work, the gibs were also adjusted, and the coolant pump was overhauled. Technical data Travel ranges X/Y/Z: 300 / 150 / 340 mm Lrsdpfx Agsz A Tn Ierjt Spindle stroke: 60 mm vertical Tool holder: MK 4 Speed range: 40 to 2,000 rpm, two-stage motor, gear stages Speed stages: 16 speeds Feed: 16 stages, 10 to 500 mm/min Drive power: Two-stage motor, approx. 1.0 / 1.4 kW Operating voltage: 380 V / 50 Hz Total connected load: approx. 1.9 kW Clamping area: 600 x 210 mm Max. table load: approx. 150 kg Space requirement (W x H x D): approx. 1,100 x 1,000 x 1,500 mm Weight approx.: 750 kg Inquiry item: Shipping costs in a customized offer.

Condition: reconditioned (used), Year of construction: 1976, Universal tool milling machine Make: DECKEL Model: FP 1 Year of manufacture: 1976 - overhauled, repainted, RAL7035 light gray / RAL7012 basalt gray / RAL5008 gray-blue Mach. No.: 52860/08 Milling head number: 7296/80 Guarantee: 12 months single shift from delivery on the mechanics overhauled by us. The electrics and electronics are excluded from this, as they have only been subjected to a functional test. For machines located outside of our northern Bavarian sales area, the travel costs must be borne by the customer. geometric acceptance with test report Accessories: - 3-axis digital display FAGOR Innova 30i-M, new Lodpfx Ajmhfrregrort - Fixed table 600 x 210 (T-slot: 12 mm) - Vertical milling head SK 40 with tightening thread S 20 x 2 - Coolant system - Operating instructions Used as seen The machine corresponds technically to the state of the year of manufacture.

Condition: good (used), functionality: fully functional, overall weight: 700 kg, For sale is a used Deckel FP1 milling machine in good working condition. The machine has feed in the X and Z axes. Travel ranges XYZ: 300x150x340mm Tool holder: SK40 S20x2 Spindle speeds: 40-2000 rpm Quill with 60mm stroke Ideal machine for toolmaking or prototype production. Already the new version of the FP1 with selector dials for speed and feed selection. Included: - High-quality hydraulic vise - Chip tray Milling cutters and tool holders can also be included upon request. Lsdpfxjz Aa Ids Agrert Loading options (forklift) are available. Shipping is also possible upon agreement. Inspection under power and collection in 5023 Salzburg.

Condition: used, Year of construction: 1984, x-travel 300 mm y-travel 160 mm z-travel 340 mm spindle taper ISO 40 digital readout 3 Achsen HEIDENHAIN spindle turning speed range 40 - 2000 U/min quill stroke 60 mm feeds -stepless- 5 - 500 mm/min table-size 600 x 210 mm rapid traverse 1200 mm/min power capacity 1,6 - 2,0 kW table load 200 kg voltage 400 V weight of the machine ca. 800 kg Lrodozz S Dujpfx Agrot dimensions of the machine ca. 1,15 x 1,15 x 1,65 m electric cabinet 0,60 x 0,35 x 0,90 m !!! ATTENTION !!! EXCELLENT CONDITION !!! This machine comes from a vocational school! - Serialä-No.: 2102-2445 - 3-axis active digital display HEIDENHAIN TNC 116 - Rapid traverse - Machine light

Condition: used, Univ. universal tool milling machine DECKEL, Type FP 1 Machine No. 51265, Year of manufacture approx. 1967 Travel distances X: 300 mm, Y: 150 mm, Z: 340 mm Table size 600 x 200 mm Spindle mounting SK 40 - S20 x 2 Spindle speed 40-2000 rpm, 16 speeds Motor power 1.0 and 1.6 kW, pole-changing Mains connection 380 volts, 50 Hz - Feed in the X and Z axes - Spindle speed via 2 motor speeds and 8 gear stages - Quill movement on the vertical milling head 60 mm - Swivel, rotary, and tilting angle table - Coolant pump in the machine base - Adjacent control cabinet Space required L x W x H 1100 x 1100 x 1600 mm Weight 690 kg Ljdpsghtvasfx Agrort Good condition

Condition: excellent (used), Used Deckel FP 1 Aktiv tool milling machine. The machine is in good technical condition and ready for operation. It has a robust construction and the necessary functions for performing precise milling operations. The machine is equipped with manual and automatic feeds, as well as automatic feeds controlled by a simple NC system. Net price: 23,000 + VAT Lredpszy Rwwofx Agrjt Spindle taper: 40 Travel: X: 300 Y: 160 Z: 340 Spindle speed: 63-2000 rpm Extendable quill

Condition: used, Universal Milling Machine DECKEL FP1 Travel X: 300 mm Travel Y: 150 mm Travel Z: 300 mm Horizontal + vertical spindle Cone SA40 DECKEL Spindle speed: from 40 to 2000 RPM Table size: 600 x 210 mm Horizontally tiltable head Straight table Spindle motor: 2 speeds Ledpfjzy Rfuox Agrort Motor: 1,3 kW Feeds: X - Z auto / Y manual Voltage: 380 V Width: 1200 mm Depth with electrical panel: 1200 mm Height:1600 mm Weight: approx 900 kg

Condition: not inspected (used), Please see technical details on photo. Ledpfjhvzxzex Agrsrt

Condition: used, Universal Milling Machine DECKEL FP1 Travel X: 300 mm Travel Y: 150 mm Travel Z: 300 mm Ljdpjzy Rfhsfx Agrjrt Horizontal + vertical spindle Cone CM4 DECKEL Spindle speed: from 40 to 2000 RPM Horizontally tiltable head Spindle motor: 2 speeds Motor: 1,5 kW Feeds: X - Z auto / Y manual Supplied without table only with one 4 concentric jaws Ø 140 mm Voltage: 380 V Width: 1200 mm Depth: 1200 mm Total height: 1600 mm Weight: approx 900 KG

Condition: good (used), Deckel FP1 milling machine with 3-axis Heidenhain digital display, fixed angular table, and SK 40 spindle mount. Accessories: counter supports, various collets. In good, operational condition. Can be demonstrated under power by arrangement. Lrjdpfx Agszy Hnljrot

Condition: good (used), machine/vehicle number: 85382, UNIVERSAL MACHINING CENTER MAHO MH 800 C, series: 85382 X axis stroke 800 mm Y axis stroke 500 mm Z axis stroke 600 mm Work table dimensions: 900x625 mm Maximum weight allowed on the table: 600 kg Spindle rotation speed: from 20 to 5.000 rpm, 15 kW Tool taper: ISO 40 cone Tool shop with 30 positions MAHO numerical command Machine dimensions: 3,350mm x 2,520mm X 2,500mm; Lrsdpfx Aeldgf Hogret Car weight: 6,200 kg Good technical condition Price EURO 7.000 + VAT Irrtum, Anderungen und Zwischenverkauf vorbehalten / Subject to errors, changes and prior sale / Ne rezervăm dreptul la greșeli, modificări și vânzare We speak English. /Wir sprechen Deutsch./ Beszélünk magyarul. /Nous parlons français/Vorbim romana

Condition: ready for operation (used), Cover FP 1 Milling machine Traverse path X-axis: 300mm Y-axis travel: 160mm Z-axis travel: 340mm Mounting: SK 40 with tightening thread Feed X-axis: 290mm Weight: approx. 940 kg (with pallet) Space requirement: 1300mm x 1200mm x 1800mm ( L x W x H ) Dimensions with pallet: 1400mm x 1400mm x 2000mm ( L x W x H ) You are welcome to come by for a viewing. We are happy to arrange a cost-effective forwarding agent for you. organize! You will receive a proper invoice. A net invoice can also be issued for foreign customers. Prerequisite is a valid VAT number. Subject to prior sale. Visit our store and have a look at our other offers. Lsdpfx Aeuvih Hegrert Company names and trademarks are the property of their owners and are used only to identify and describe the products. Deviations from technical data and errors in the description of the article may occur and are reserved.
