Universal tool milling machine, universal milling machine, drilling-milling machine

DECKEL FP 1

Condition: reconditioned (used), feed length X-axis: 300 mm, feed length Y-axis: 160 mm, feed length Z-axis: 340 mm, Updated Machineseeker description (with travel distances) Deckel FP1 Aktiv – 3 axes – partially overhauled – ready for immediate use Offered for sale is a Deckel FP1 Aktiv in technically inspected and partially overhauled condition. The machine has been professionally refurbished and is in a reliable, operational state. Ideally suited for workshops, toolmaking, training, as well as single part and small batch production. This is not an unchecked used machine but a technically overhauled tool machine with a clearly defined scope of performance and a predictable delivery time. Technical data and features Travel distances: X-axis approx. 300 mm Y-axis approx. 160 mm Z-axis approx. 340 mm 3 axes with Aktiv control and digital readout Stepless feed on all 3 axes Coolant system Brake motor Fixed angle table New LED work lamp New leveling feet Technical documentation in PDF format Scope of refurbishment Workshop tested and partially overhauled Technical inspection of all functions Repair or replacement of defective components Complete basic cleaning Readjustment of all existing adjustment options Renewal of all lubricants Replacement of selected standard and various wear parts New paint finish in RAL 7035 / 7016 Gedpex Tdy Isfx Aa Isil The conscious decision for a partial overhaul provides an optimal compromise between operational reliability, cost-effectiveness, and availability. A complete overhaul of the guideways was not carried out, as there was no technical necessity for this. Scope of delivery Machine loaded free of charge Delivery time approx. 12 weeks

Condition: used, Year of construction: 1980, x-travel 300 mm y-travel 160 mm z-travel 340 mm tool taper SK40 Speed 40-2000 U/min. control Aktiv HEIDENHAIN table-size 600 x 210 mm total power requirement 2 kW weight of the machine ca. 0,73 t dimensions of the machine ca. TBH 1200x1100x1600 m - Active feed in the X and Z axes - Additional swiveling table 600 x 210 mm - Coolant system - Counter bearing for horizontal milling - Several fixtures and clamping devices/milling cutters - Operating instructions Gisdsw A Ap Hjpfx Aa Ijl

Condition: reconditioned (used), Year of construction: 1990, Universal Tool Milling Machine Make: DECKEL Model: FP 1 Aktiv Year of manufacture: 1990 – workshop-inspected Machine no.: 2102-5866 Milling head type: 2171 Milling head no.: 4613 Gijdpfxex S Edlo Aa Iol Geometric inspection with test report Accessories: - 3-axis active digital readout HEIDENHAIN TNC 113 with active function in X, Y, and Z axes - Universal table 590 x 250 mm (T-slot: 12 mm) - Vertical milling head SK 40 with pull stud thread S 20 x 2 - Without coolant system; can be retrofitted if required - Centralized lubrication, electric - Operating manual Used as seen, sold without warranty The machine is technically in the condition of its year of manufacture.

Condition: excellent (used), Year of construction: 1988, functionality: fully functional, Technical details x-travel 300 mm y-travel 160 mm z-travel 290 mm table surface area 210 x 600 mm tool taper SK 40 spindle turning speed range (16) 40 - 2000 U/min feeds -stepless- 5 - 500 mm/min rapid traverse 1,2 m/min spindle motor 1,5 / 1,9 kW total power requirement 9,5 kVA weight of the machine ca. 730 kg dimensions of the machine ca. 2000 x 2200 x 1655 mm Additional information The machine is in very good condition and comes from a training workshop. Equipment: Safety cover and LED lamp retrofitted in 2016 3-axis active digital readout made by Heidenhain Fixed angle table Coolant equipment Giedpfxex S Ec Uo Aa Ijl

Condition: not inspected (used), Please see technical details on photo. Gedpfx Aehvzxzja Ijil

Condition: excellent (used), functionality: fully functional, travel distance X-axis: 300 mm, travel distance Y-axis: 160 mm, travel distance Z-axis: 340 mm, spindle speed (max.): 2,000 rpm, spindle speed (min.): 40 rpm, rotational speed (max.): 2,000 rpm, rotational speed (min.): 40 rpm, 2-axis active digital display (Heidenhain) Spindle mount: SK40 (S20x2) Giodpfx Aovnr Hyea Ijl Travel paths: X 300 / Y 160 / Z 340mm Speed: 40 - 2000 rpm. (2 gear levels) Feed continuously adjustable The machine is in a well-maintained condition and can be inspected on site, with power on. Includes extensive accessories. - Machine vice - Operating instructions / electrical circuit diagram / spare parts list - Collet set (S20x2) including SK40 collet insert - Other accessories on request.

Condition: good (used), Electric motor, three-phase motor, brake motor -Manufacturer: Siemens, electric motor type 1LC3113-4BB23 Z from milling machine Deckel FP4L -Power: 4.0 kW -Speed: 1435 rpm -Design: B14 Giedpfx Ajul H Dwsa Isl -Protection class: IP 44 -Brake: multi-disc brake type EK5dB24 -Dimensions: 575/270/H225mm -Weight: 64 kg

Condition: good (used), Year of construction: 1980, Table size 1300 x 355 mm Tool holder, vertical + horizontal ISO 50 Travel X-axis 1000 mm Y-axis 350 mm Z-axis 450 mm Vertical milling head, swiveling R + L Quill stroke 100 mm Gsdovu Dv Tepfx Aa Ijil Speed range 22.4 – 1400 rpm Feed range 6.3 – 630 mm/min Rapid traverse 2.5 m/min Drive power approx. 5 kW Space requirement L x W x H 1900 x 1800 x 2100 mm Weight 3200 kg Accessories / Special features: • 3-axis digital display, make FAGOR • Swiveling vertical milling head (R-L) with quill adjustment 100 mm • Vertical and horizontal milling spindle ISO 50 • Milling spindle vertical + horizontal • Large Clamping table 1350 x 350 mm • Feed and rapid traverse in all axes • Wide, stable guideways • Central lubrication • Swiveling control panel • Coolant system • EMERGENCY STOP switch Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel

Condition: good (used), 1 used universal tool milling machine Gedpfx Ajrn I Rzoa Ijil make Deckel type FP 1 year 82 Technical data: x-travel: 300 mm y-travel: 160 mm z-travel: 340 mm Spindle holder SK 40 Table size: 600x210 mm Spindle speeds: 40-2000 rpm Machine weight approx.: 1 t Space requirement approx.: 1.6x1.3x1.8 m

Condition: excellent (used), DECKEL Universal Milling Machine FP 1 No. 2101 with HEIDENHAIN 2-axis Digital Readout Travel Paths: X/Y/Z: 300 x 160 x 340 mm Manual Adjustment Milling Head Arm: 100 mm Extension of Working Area to: 300 x 260 mm Spindle Speed Vertical/Horizontal: 40 – 2,000 rpm Gear Steps: 16 Spindle Taper: SK 40 Tool Fixture: S20 x 2 (Deckel Standard) Quill Travel: 60 mm Feed X/Z Axis: 5 – 500 mm/min Feed Control: stepless Rapid Traverse X/Z Axis: 1200 mm/min Feed Y Axis: manual Fixed Angle Table: 600 x 210 mm Tilting Vertical Head: +/- 90 degrees Weight: 710 kg Dimensions: approx. 1250 x 1200 x 1850 mm Technical data not binding! Features: For horizontal machining, the milling head is swivelled 90 degrees and slid to the rear. 2-axis precision digital readout HEIDENHAIN POSITIP VRZ 719 Infinitely variable feed on X/Z axis The machine underwent partial overhaul by a specialized company a few years ago. Equipment: 2-axis HEIDENHAIN digital readout Fixed angle table Chip tray Machine lamp Machine feet Giedexyc N Ejpfx Aa Iel Further accessories on request! Condition: good to very good from training workshop Available from March 2026

Condition: ready for operation (used), travel distance X-axis: 300 mm, travel distance Y-axis: 160 mm, travel distance Z-axis: 340 mm, spindle speed (max.): 2,000 rpm, spindle speed (min.): 40 rpm, position of the milling head: SK40, input voltage: 400 V, Deckel FP1 2 axis Active Gedpfovuzg Aox Aa Isil Displacements: X = 300 mm Y = 160 mm Z = 340 mm Speed 40-2000 Rpm Automatic feed and rapid traverse on the X, Y and Z axes. Continuously adjustable. Table dimensions 600 x 260 mm 2 axes Active control, point-to-point control. 3 axis digital readout from Heidehain. Spindle mounting SK40 Deckel mounting (outside thread)

Condition: excellent (used), functionality: fully functional, travel distance X-axis: 300 mm, travel distance Y-axis: 160 mm, travel distance Z-axis: 340 mm, spindle speed (max.): 2,000 rpm, spindle speed (min.): 40 rpm, rotational speed (max.): 2,000 rpm, rotational speed (min.): 40 rpm, 3-axis active digital display (Heidenhain TNC113) Spindle mount: SK40 (S20x2) Travel paths: X 300 / Y 160 / Z 340mm Speed: 40 - 2000 rpm. (2 gear levels) Giedevnrz Rspfx Aa Isl Feed continuously adjustable The machine is in a well-maintained condition and can be inspected on site, with power on. Includes extensive accessories. - Machine vice - Operating instructions / electrical circuit diagram / spare parts list - Collet set (S20x2) including SK40 collet insert - Other accessories on request.

Condition: good (used), DECKEL Tool Milling Machine FP 1 No. 2101 with HEIDENHAIN 3-axis digital readout Travel: X/Y/Z: 300 x 160 x 340 mm Manual adjustment of milling head arm: 100 mm Expansion of working area to: 300 x 260 mm Spindle speeds, vertical/horizontal: 40 – 2,000 rpm Gear stages: 16 Spindle taper: SK 40 Tool holder: S20 x 2 (Deckel standard) Quill travel: 60 mm Feed X/Z axis: 5 – 500 mm/min Feed adjustment: stepless Rapid traverse X/Z axis: 1,200 mm/min Feed Y axis: manual Fixed angle table: 600 x 210 mm Gijdjxyc Tkspfx Aa Isl Tilting vertical head: +/- 90 degrees Weight: 710 kg Dimensions: approx. 1,250 x 1,200 x 1,850 mm Technical data subject to change! Features: - For horizontal machining, the milling head is swiveled 90 degrees and pushed to the rear. - 3-axis precision digital readout HEIDENHAIN - Stepless feed on X/Z axis - The machine was partially overhauled by a specialist company a few years ago. Equipment: - 3-axis digital readout HEIDENHAIN - Micro coolant spray system - Fixed angle table - Chip tray - Machine lamp - Machine feet Further accessories available on request! Condition: Good to very good, from a training workshop Available from March 2026

Year of construction: 1994, condition: ready for operation (used), Cutting force: 200kN, working width: 2500mm, cylinder width: 2600mm, cylinder diameter: 400mm, opening between the cylinders: 25-100mm, conveying speed: 11-44m/min, connected load: 7.5kW, weight: 3t, with documentation. Godsix Ahbjpfx Aa Isil

Condition: reconditioned (used), Deckel FP1 AKTIV (3-Axis Active) Machine No. 2102-5745 Year of manufacture: approx. 1988 Travel distances: X-axis: 300 mm Y-axis: 150 mm Z-axis: 330 mm Table size: 600 x 210 mm Spindle taper: SK 40 - S20x2 Spindle speed: 40–2000 rpm Motor power: 1.6 and 2 kW Power supply: 380 Volt, 50 Hz Equipment: - HEIDENHAIN 3-axis active digital readout, type TNC 113 - Infinitely variable feed on X, Y, and Z axes - Quill movement on vertical milling head: 60 mm - Vertical milling head swivels and extends horizontally by 100 mm - Coolant system (coolant tank in machine base) - Documentation - Centralized lubrication Space requirements (L x W x H): 1350 x 1100 x 1700 mm Weight: 850 kg The machine has been visually refurbished and technically inspected. Geometry measurement videos can be provided upon request. Backlash Y-axis: 0.15 mm Backlash X-axis: 0.3 mm Backlash Z-axis: 0.2 mm Runout horizontal spindle: 0.002 mm Runout vertical spindle: 0.002 mm Parallelism deviation Y-axis: 0.002 mm (measuring length 150 mm) Parallelism deviation X-axis: 0.002 mm (measuring length 300 mm) The following parts have been renewed: - Centralized lubrication checked Giedpfjxpwfgjx Aa Isl - Heidenhain digital readout overhauled - New wiper set installed - LEDs in the Active display replaced - Oil changed - Vertical milling head fitted with new bearings - Oil sight glass replaced Net price, ex stock, free loaded
