Tool Room Milling Machine - Universal

DECKEL FP 4 A

Condition: reconditioned (used), Year of construction: 1991, functionality: fully functional, travel distance X-axis: 560 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 450 mm, feed rate X-axis: 3,600 m/min, feed rate Y-axis: 3,600 m/min, feed rate Z-axis: 3,600 m/min, quill stroke: 80 mm, spindle speed (max.): 4,000 rpm, spindle speed (min.): 40 rpm, rapid traverse X-axis: 4 m/min, rapid traverse Y-axis: 4 m/min, rapid traverse Z-axis: 4 m/min, table length: 530 mm, table width: 900 mm, rotational speed (max.): 4,000 rpm, rotational speed (min.): 40 rpm, table load: 450 kg, Equipment: rotational speed infinitely variable, The machine is designed and built to be very stable and robust. Thanks to its excellent accessibility, it is extremely user-friendly. The machine can also be moved manually using mechanical handwheels. CNC Path Control DECKEL Dialog 11 Easily programmable 3D path control with color graphic support, dialogue guidance for cycle input, contour path calculator, editor functions, clear program and tool management, and the possibility of parallel programming. Travel paths X / Y / Z: 560 / 500 / 450 mm Tool holder: SK40 DIN 69872 Clamping system: Hydromechanical clamping system SK40 with drawbar according to DIN 2080 or DIN 69872 Working spindle: Vertical and horizontal. Manually retractable quill in vertical direction 80 mm. Milling head: Manually swivels +/- 90° Speed range: 40–4000 rpm, geometrically stepped Direct-drive gearbox for maximum torque / milling performance at the working spindle Feed rate: 2–3600 mm/min, infinitely variable feed Rapid traverse: 4000 mm/min Angle table: 530 x 900 mm, max. load capacity 450 kg Bedpfx Aoyn Dq Ija Hsld

Condition: used, Technical details: x-travel: 700 mm y-travel: 450 mm z-travel: 450 mm spindle cone ISO: 40 (SK 40) table surface area: 760 x 420 mm table feed: längs: 10 - 500 (Eilgang: 1,4 m/min.) mm/min table feed: vertical: 5 - 250 (Eilgang: 1,4 m/min.) mm/min spindle turning speed - continuous: 32 - 1600 / 18 step U/min spindle head swivable left - right: 10 ° links / rechts ° quill stroke vertical: 125 mm feed continuous: 10 - 500 / 8 step mm/min rapid traverse: 1,4 m/min Total power requirement: 6,5 kW weight of the machine ca.: 3,0 t dimension machine xH: 2,3 x 2,0 x 1,85 m Further features: Headstock projection min./max.: 2094 / 2544 mm Bledpfsvc Avhex Aa Hsd Equipment: -cooling water pump with feed -Linear path measuring system - Heidenhain ND750 Accessories: -Machine vice *

Year of construction: 1987, condition: ready for operation (used), Travel X/Y/Z: 560mm/500mm/450mm, tool holder: SK40, speed: 4000rpm, feed rate: 3.6m/min, rapid traverse: 4m/min, table dimensions X/Y: 530mm/900mm, max. table load: 450kg. Machine dimensions X/Y/Z: 2350mm/2200mm/2000mm, weight: approx. 2200kg, control: Deckel Contour 2. An on-site inspection is possible. Blodpfxexvddvo Aa Hod

Year of construction: 1987, condition: ready for operation (used), A CNC universal milling machine Deckel is available. Travel X/Y/Z: 400mm/400mm/400mm, table dimensions X/Y: 700mm/460mm, max. table load: 350kg, tool holder: SK40, quill stroke: 80mm, speed: 4000rpm, feed rate: 3600mm/min, rapid traverse: 4m/min. Machine dimensions X/Y/Z: approx. 1800mm/1800mm/2200mm, weight: approx. 2500kg, control: Contour 3. The tool change magazine is no longer in operation. Documentation available. An on-site inspection is possible. Blsdpfsya Hw Uox Aa Hed

Condition: reconditioned (used), Year of construction: 1984, Universal Tool Milling Machine DECKEL FP 3 With 3-axis active digital display Heidenhain TNC 11 Year of manufacture: 1984 Travel: X 500 / Y 300 / Z 400 mm Speed range: 25 – 2500 rpm Including the following accessories: - Rigid angle table, 850 mm x 400 mm clamping surface - Swiveling rotary table Ø 450 mm with dividing disks - Slotting head - Movable vertical milling head - Extendable quill for drilling - Infinitely variable feed via potentiometer - Various milling arbors SK 40 / S22 x 2 - Chip tray Bedpexuh Rdefx Aa Held - Automatic central lubrication pump for X, Y, Z axis - Machine lamp - Coolant system - 4 machine feet - Operating manual

Condition: used, Technical details: Type: Deckel FP3 / 4A-TC with Contour 3 Bodpjyhwh Tefx Aa Held Year of manufacture: 1987 In 2025, a new power supply unit and a new ballast circuit were installed The tool changer magazine is no longer in operation.

Condition: ready for operation (used), Year of construction: 1994, travel distance X-axis: 565 mm, travel distance Y-axis: 505 mm, travel distance Z-axis: 400 mm, spindle speed (max.): 4,000 rpm, This DECKEL FP4A was manufactured in 1994. A vertical machining centre featuring a travel range of X=565mm, Y=505mm, Z=400mm, SK40 tool holder, and a spindle speed of up to 4000 rpm. Consider the opportunity to buy this DECKEL FP4A vertical machining centre. Contact us for more information. Blodpfxjygxtbj Aa Hjd

Condition: used, Universal tool milling machine Brand: OPTIMUM Model: MT 100 Year of manufacture: 2018 – workshop tested Machine no.: J33021808035 Geometric acceptance with test report Accessories: - 3-axis digital display DPA 2000 - Vertical milling head SK 40 with Bjdpfx Ajw Rlvqsa Hjld drawbar thread M 16 - Fixed table 1,120 x 260 mm (T-slot: 14 mm) - Machine lamp - Coolant system - Manual central lubrication - Operating manual Used as seen, without warranty The machine technically corresponds to the state of the art at the time of manufacture.

Condition: used, Year of construction: 1985, Technical details: x-travel: 485 mm y-travel: 385 mm Blodpfx Aasu Ndcms Hjd z-travel: 380 mm control: Contour 1 Bahnsteuerung spindle taper ISO: SK 40 spindle head swivable left - right: 90° ° quill travel: 80 mm milling head vertical adjustable: 150 ( y-Achse) mm range of revolution per miute: Spindel vertical: 50 - 2.500 / 18 step U/min feed:: X/Y/Z: 2 - 1000 steples mm/min rapid traverse : X/Y/Z: 2000 mm/min revolution per minute: horizontal: bis 1.000 U/min Table dimensions: 460 x 800 mm table load: 0,4 t total power requirement: 9,5 kVA machine weight approx.: 1900 kg dimension machine xH: 2,35 x 2,2 x 2,0 m -Equipment: - Operation via control panel Grundig elektronic with boom - Cooling with pump - machine lighting - Linear interpolation, circular polarization in XY and XZ planes - quick chuck - manual control unit *

Condition: used, Year of construction: 1992, machine/vehicle number: 2821-1444, See pictures for condition. More detailed information about the machine will follow shortly. Bedpjtgkd Refx Aa Hjld

Year of construction: 1981, condition: used, Make cover Type FP 4 Table: dimensions 1000 x 470 mm Bedpsihp U Defx Aa Hold longitudinal movement X - axis 700 mm transversal movement Y - axis 400 mm vertical movement Z - axis 450 mm projection spindle 50 450 mm spindle mounting ISO 40 Number of spindle speeds 18 Spindle speed range 31,5 1600 rpm Number of revolutions horizontal spindle 18 pcs. Speed range horizontal spindle 31,5 1600 rpm Weight machine 2000 kg feeds X Y Z axis 18 pcs 10 500 mm/min Accessories milling head with quill Table 1000 x 470 mm

Condition: like new (used), Year of construction: 1985, functionality: fully functional, travel distance X-axis: 580 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 450 mm, rotational speed (max.): 4,000 rpm, controller model: Contour 1, NC Milling Machine Deckel FP4A We are offering for sale a perfectly maintained Deckel FP4A CNC milling machine (very low operating hours, in as-new condition)! Technical Details: - Travel (X): 580 mm - Travel (Y): 400 mm Bledpfexzpwfex Aa Hsd - Travel (Z): 450 mm (390 mm*) - Table size: 460 x 800 mm - Spindle speed range: 40 – 4000 rpm - Feed rate: 2 – 3600 mm/min - Rapid traverse: 4.0 m/min - Spindle taper: SK 40 - Machine dimensions (LxWxH): approx. 3.0 x 2.10 x 2.10 m - Spindle drive power: 4.0 kW - Control: Contour 1 Description: CNC-controlled tool milling machine, equipped with Contour 2 control. Features include a vertical head rotatable +/- 90° with quill travel of 80 mm, horizontal spindle, power feeds & rapid traverse on all 3 axes, hydraulic tool clamping, flying desk, electronic handwheel, automatic central lubrication, coolant system, safety emergency stop, chip tray, and separate electrical cabinet. The machine is in top working condition. Note: This additional information is standard for this model. Please always verify the exact configuration during inspection. The DECKEL FP4A Universal Tool Milling Machine, built in 1985, is a classic and highly versatile metalworking machine renowned for its precision and flexibility – testament to Deckel’s strong tradition of engineering quality. The FP4A features a robust bed-type construction, delivering the necessary stability for precise milling tasks. Its universal tool milling head is a highlight, enabling a wide spectrum of operations—from basic drilling to complex contouring and profiling. This versatility makes it a valuable asset in tool and die manufacturing, as well as mold making. Key technical features of the 1985 DECKEL FP4A include a generously sized worktable, infinitely variable spindle speed adjustment, and an intuitive control interface for efficient programming and machine operation. The advanced CNC technology contributes to exceptional accuracy and operator convenience. Despite its age, the DECKEL FP4A continues to be a trusted solution for applications requiring flexible tool milling. Its reputation for reliability and precision makes it an essential tool for modern metalworking and manufacturing operations. Deckel’s legacy of quality and innovation in the field of metal machining is clearly evident in this model.

Condition: used, Year of construction: 1987, Deckel FP4-MA Contur 2 with handwheel (universal tool milling machine) year 1987 Bedpoxurkzefx Aa Hjld

Condition: good (used), Year of construction: 1980, Table size 1300 x 355 mm Tool holder, vertical + horizontal ISO 50 Travel X-axis 1000 mm Y-axis 350 mm Z-axis 450 mm Vertical milling head, swiveling R + L Quill stroke 100 mm Speed range 22.4 – 1400 rpm Feed range 6.3 – 630 mm/min Rapid traverse 2.5 m/min Drive power approx. 5 kW Space requirement L x W x H 1900 x 1800 x 2100 mm Weight 3200 kg Accessories / Special features: • 3-axis digital display, make FAGOR Bljdpfjvu Dv Tsx Aa Hod • Swiveling vertical milling head (R-L) with quill adjustment 100 mm • Vertical and horizontal milling spindle ISO 50 • Milling spindle vertical + horizontal • Large Clamping table 1350 x 350 mm • Feed and rapid traverse in all axes • Wide, stable guideways • Central lubrication • Swiveling control panel • Coolant system • EMERGENCY STOP switch Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel

Condition: used, Year of construction: 1985, x-travel 485 mm y-travel 385 mm z-travel 380 mm table surface area 800 x 460 mm spindle taper SK 40 control CONTOUR 1 spindle turning speed range 50 - 2500 U/min feeds 10 - 1000 mm/min rapid traverse 2 m/min Blodpfx Aotqqlloa Hed table load capacity 600 kg quill stroke 80 mm total power requirement 7,5 kW weight of the machine ca. 2,0 t dimensions 2,4 x 1,7 x 1,98 m Acc.: vertical head with hydr. tool clamping and quill retraction, solid table, coolant - movement of X/Y/Z also possible via handwheels -
