CNC universal traveling column milling machine
DECKEL FP 50 CC

ONO plus VAT
€12,800
Year of construction
1990
Condition
Used
Location
Dortmund Germany
CNC universal traveling column milling machine DECKEL FP 50 CC
CNC universal traveling column milling machine DECKEL FP 50 CC
CNC universal traveling column milling machine DECKEL FP 50 CC
CNC universal traveling column milling machine DECKEL FP 50 CC
CNC universal traveling column milling machine DECKEL FP 50 CC
CNC universal traveling column milling machine DECKEL FP 50 CC
CNC universal traveling column milling machine DECKEL FP 50 CC
CNC universal traveling column milling machine DECKEL FP 50 CC
more Images
DECKEL FP 50 CC
DECKEL FP 50 CC
DECKEL FP 50 CC
DECKEL FP 50 CC
DECKEL FP 50 CC
DECKEL FP 50 CC
DECKEL FP 50 CC
DECKEL FP 50 CC

Machine data

Machine type:
CNC universal traveling column milling machine
Manufacturer:
DECKEL
Model:
FP 50 CC
Year of construction:
1990
Condition:
good (used)

Price & Location

ONO plus VAT
€12,800
Location:
Rüschebrinkstr. 151-153, 44143 Dortmund-Wambel, Deutschland Germany
Call

Details about the offer

Listing ID:
A650-4601
Update:
04.09.2026

Description

1 used, well-maintained CNC tool milling machine, traveling column design, with CNC path control GRUNDIG Dialog 11

Table size 1600 x 675 mm
Tool holder SK / ISO 40
Travel distances X-axis, longitudinal 1200 mm
Y-axis, transverse 600 mm
Z-axis, vertical 500 mm
Table load 2000 kg
Spindle speed range 20 – 6300 rpm
Feed rate range, stepless 2 – 10,000 mm/min
Rapid traverse in all axes 10 m/min
Quill stroke 80 mm
Drive power 100% ED 7.5 kW
40% ED 12 kW
Machine dimensions L x W x H 3600 x 3000 x 2300 mm
Machine weight 6800 kg
Control cabinet dimensions L x W x H 1700 x 900 x 1750 mm
Control cabinet weight 470 kg

Accessories / Special features:
• CNC tool milling machine suitable for tool and fixture manufacturing, training, and mold making
• CNC path control GRUNDIG Dialog 11
• Screen graphics, dialog-guided input, 3D linear interpolation, circular interpolation, helical interpolation, polar coordinate input, numerous drilling and milling cycles, cycle input graphically supported, milling cycles "contour pocket" for automatic free milling of irregular pockets, even with islands, shifting and rotation of the coordinate system
• Electronic handwheel
• RS 232 interface
Nledpfxehhuf Ho Agrsg
• Swiveling vertical milling head +/- 90°
• Hydraulic tool clamping, DIN 2080 with clamping groove, Ott system
• Quill adjustment 80 mm
• Horizontal milling attachment
• Full protection enclosure
• Ball screw spindles in all 3 axes
• Coolant system
• Lighting

Siegfried Volz Werkzeugmaschinen
Rüschebrinkstr. 151-153
D - 44143 Dortmund - Wambel
