Tool cutter

DECKEL FP2

Condition: good (used), Year of construction: 1982, functionality: fully functional, Tool milling machine with 3D control, manual handwheels, and a universal table adjustable in three axes. Control: Deckel Dialog Control 4: 3D contouring control, including drilling and milling cycles Monitor, electronic handheld control panel Rsdjwid Spepfx Agiol Terminal for program input and output Technical specifications: Travel range X/Y/Z 300 x 220 x 400 mm Speed 31.5 - 3,150 rpm with 21 gear stages Feed rate 4-2,000 mm/min Rapid traverse 4 m/min Drive power 1.6-2.0 kW SK 40 tool holder Hydraulic tool clamping Universal milling table with digital display: Clamping area 600 mm x 320 mm Table load 180 kg C-axis rotation range 360° A-axis tilt range 15°/45° B-axis swivel range +/- 45° Vertical milling head: Manual quill stroke - horizontally 65 mm, vertically 60 mm Additional equipment: Manual machine handwheels with scale Direct travel measurement of the NC axes Cooling water system Special accessories: Approx. 33 tool holders (without tools) - see photo High-speed milling spindle Machine data: Machine weight approx. 1,380 kg Space requirement including accessories L approx. 2,940 mm, W approx. 1,900 mm, H approx. 1,960 mm Power supply: 380 V, 50 Hz, 12 kVA The machine is in good, fully functional condition. It can be inspected with power and chippings by appointment.

Condition: used, Year of construction: 1989, x-travel 300 mm y-travel 300 mm z-travel 400 mm CNC-control DIALOG 11 spindle taper ISO 40 spindle turning speed range 31 - 5.000 U/min table-size 620 x 390 mm table load 250 kg power capacity 5,5 kW feeds -stepless- 2 - 6.000 mm/min quill stroke 80 mm Rjdjx Ndbqspfx Agiel voltage 380 V total power requirement 11,0 kVA weight of the machine ca. 1,65 t dimensions of the machine ca. 1,85 x 1,90 x 1,80 m electric cabinet 1,35 x 0,70 x 1,70 m - Serial-No.: 2836-0175 - control: DIALOG 11 - electrical hand wheel - horizontal milling spindle - coolant equipment

Year of construction: 1968, condition: good (used), For sale is a milling machine Deckel brand from 1968 The machine is in a good to very good condition and fully functional (No digital display but can be mounted additionally on request) Technical data: Tool holder: SK 40 Travel X/Y/Z: 400 / 200 / 400 mm speed range: 40 - 2000 rpm spindle travel vertical: 60 mm spindle travel horizontal: 100 mm feeds: 8 - 400 mm/rev table size: 700 x 330 mm motor power: 2,2 kW connection: 400 V / 16 A plug Redpfoihf Etox Agisl weight: approx. 1300 kg All prices plus VAT Machines purchase / sale PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES ETC. Do you need a high-quality but inexpensive metalworking machine for your production? Or do you want to sell yours? For more information or to contact us, please visit our website

Condition: ready for operation (used), Year of construction: 1973, Deckel FP2 tool milling machine with 3-axis digital readout. The machine is in operational condition. Rigid table, SK 40 spindle taper. Accessories: various collets and milling arbors, tailstock support, vise, operating manual. Defects: one axis of the digital readout does not count, table has breakouts. Can be demonstrated under power by arrangement. Rjdpfx Agjx Nclhoiol

Condition: used, x-travel 500 mm y-travel 200 mm z-travel 400 mm table surface area 700 x 300 mm tool taper SK 40 - S20 feed 8 - 400 mm/ min Rsdpfx Asx Hay Degiel rapid traverse in X und Z 1200 mm / min turning speeds 40 - 2000 U/min total power requirement 2,2 kW weight of the machine ca. 1400 kg dimensions of the machine ca. 1500 x 1200 x 1600 mm Includes 2-axis digital display Heidenhain

Condition: good (used), Year of construction: 1964, functionality: fully functional, travel distance X-axis: 500 mm, travel distance Y-axis: 200 mm, travel distance Z-axis: 400 mm, spindle speed (max.): 200 rpm, spindle speed (min.): 40 rpm, input frequency: 50 Hz, Machine is in good condition! Tool holder: SK 40 travels X/Y/Z: 500 / 200 / 400 mm speed range: (18 steps) 40 - 2000 rpm spindle stroke vertical: 60 mm spindle stroke horizontal: 100 mm feeds: 8 - 400 mm/rev table size: 700 x 300 mm motor power: 2,2 kW connection: 400 V / 16 A plug weight: approx. 1300 kg space requirement LxWxH, approx.: 1200 x 1250 x 1670 mm head swivels: 90° / 90 Equipment: - 3-axis digital display - Coolant device We would be pleased to demonstrate the machine under power on site. Rodpfeilg H Esx Agisl All data without guarantee. Subject to prior sale. The object of purchase is sold under exclusion of any warranty. The exclusion does not apply to claims for damages arising from grossly negligent or intentional breach of obligations of the seller and for any injury to life, limb and health.

Condition: like new (used), I'm selling the German milling machine Deckel, model FP2A, shown in the photos. The machine is in perfect, like-new condition. It has seals on the controller. It's ready to work. I can provide on-site loading. Machine data -Controller Dialog 11 -Speed ​​0-4000 Rjdpfx Agoxq Rymjijl -X 300 -Y 300 -Z 400 Complete documentation, including: Machine manuals Programming manuals Error log with descriptions Machine data Electrical diagrams The machine comes with a tool kit: -2 150x300 vices -3D workpiece measurement probe -Tool length measuring device -ER 32 tool set -Arbors -Milling head

Condition: good (used), Dimensions: width 2000mm, depth 2000mm, height 1600mm Table: 620mm x 390mm Rsdpfx Ageu A Iuyoisl Machine weight: approx. 1500kg Control: Dialog 4 Equipment: backlash-free ball screws, hydraulic SK40 tool holder, electric handwheel

Condition: excellent (used), feed length X-axis: 400 mm, feed length Y-axis: 200 mm, feed length Z-axis: 400 mm, For sale is a conventional milling machine of the brand Deckel and type FP2 The machine is in very good condition, has been overhauled by the Harich company (date unknown) and is ready for immediate use Technical data Tool holder: SK 40 Travel X/Y/Z: 400 / 200 / 400 mm Speed range: 40 - 2000 rpm Vertical spindle travel: 60 mm Horizontal spindle travel: 100 mm Feed rates: 8 - 400 mm/rev Table size: 700 x 330 mm Motor power: 2.2 kW Connection: 400 V / 16 A plug Weight: approx. 1300 kg Vice and tools are NOT included in the offer, but can be offered. On request, transportation and loading can be organized for an extra charge. can be organized throughout Europe. Prices plus VAT Viewing possible by appointment. Contact us, our team will be happy to help you. Trade-in or exchange possible! Machines purchase / sale PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES AND MUCH MORE. Do you need a high-quality but inexpensive metalworking machine for your production? Or do you want to sell yours? Rsdpju Ti Akefx Agiol For further information or contact options, please visit our website

Condition: used, Year of construction: 1985, functionality: fully functional, table length: 680 mm, table width: 380 mm, table height: 345 mm, For sale is a Deckel milling table, which was installed on an FP2 milling machine. The angle and rotation functions are fully functional, unfortunately there is no longer a crank. Rodpfxjuuh Suo Agiol Signs of use on surface recognizable on pictures Dimensions: 38*68 cm Height: 25 cm
