Milling machine

DECKEL FP4M

Condition: ready for operation (used), Year of construction: 1984, functionality: fully functional, feed length X-axis: 500 mm, feed length Y-axis: 400 mm, feed length Z-axis: 400 mm, travel distance X-axis: 500 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, rotational speed (max.): 2,500 rpm, rotational speed (min.): 50 rpm, input voltage: 400 V, Deckel FP4M Universal Milling Machine in excellent technical and optical condition. Machine no. 2203-1389 Year of construction: 1984. Technical specifications: - Working travel X/Y/Z: 500/400/400 mm - Spindle speed range: 50 - 2500 RPM - Power: 3.7 / 4.4 KW - Spindle brake - Automatic feed: X-Y-Z, continuously adjustable, 6.3 / 630 mm/min - Rapid traverse X-Y-Z: 1300 mm/min - Fixed angle table - Vertical quill with 90 mm stroke - Tool holder: ISO 40/M16 - Weight approx. 1500 kg Lajdpfeytb Uhsx Akusg Machine options: - 3-axis digital readout Heidenhain - Coolant system - Chip tray - Central lubrication - Automatic pulse lubrication on the milling head - Machine manuals with spare parts list and electrical diagrams - Cabinet with accessories, see photos

Condition: excellent (used), Year of construction: 1992, functionality: fully functional, Universal Milling Machine Deckel FP4M with 3-Axis Active Digital Readout Heidenhain, Excellent Condition, CE Compliant!!! Technical Data: - Year of manufacture: 1992, Machine no. 2203-8449 Laedpsu Tuk Hofx Akujg - Fixed angle table - Spindle speed: 50 - 2500 rpm - Feed rate: 8 – 630 mm/min - Drive power: 3.7 / 4.4 kW - Spindle brake - Rapid traverse: 1300 mm/min - Travel (X/Y/Z): 500/400/400 mm - Vertical milling head traverseable on column - Vertical and horizontal quill - SK40 taper - Vertical quill extendable by 90 mm - Hydraulic drawbar system - Approx. weight: 1600 kg Equipment and Accessories: - 3-axis active Heidenhain digital readout - Coolant system - Chip tray - Central electric lubrication - Operating manual, spare parts drawings About the Machine: For sale is a Deckel FP4M Universal Milling Machine (Active) in very good condition. The machine has minimal backlash, and all slides move smoothly. Even at maximum spindle speeds, the milling machine runs quietly. The machine features hydraulic tool clamping. The FP4M was only occasionally used in a state-run facility for training purposes. On this newer FP4 model, the feed rates are steplessly adjustable in all three axes, and each axis also features a rapid traverse. A major advantage is the active 3-axis digital readout. With the Heidenhain control, you can input measurements that the machine will approach automatically. Oil change has been performed; mechanically and electrically tested. The Heidenhain digital readout makes work easier and even more precise. Take advantage of the opportunity to inspect and test this machine under power on site.

Condition: excellent (used), Year of construction: 1986, functionality: fully functional, Universal milling machine Deckel FP4M with 3-axis digital display Heidenhain ND780 in special light gray paint finish with CE approval!!! Technical data: >> Year of manufacture 1986, machine no. 2203-2471 >> Fixed angular table (newly planed) >> Speed: 50 - 2500 rpm >> Feed rate: 8 – 630 mm/min >> Drive power: 3.7 / 4.4 kW >> Spindle brake >> Rapid traverse rate 1300 mm/min >> Travel ranges X/Y/Z: 500/400/400 mm >> Vertical milling head on spindle support, adjustable by 150 mm >> Vertical quill and horizontal quill - SK40 >> Vertical quill extendable by 90 mm >> Clamping system M16 >> Weight approx. 1500 kg Accessories and equipment: >> 3-axis digital display Heidenhain ND780 >> Coolant system >> Chip tray Ljdpez A S Rnjfx Akueag >> Central lubrication About the machine: Offered is a Deckel FP4M universal milling machine with CE conformity in very good condition. The machine has been partially overhauled, has little backlash, and all spindles move easily and smoothly. Even at maximum speeds, the milling machine runs smoothly. Rapid traverse in all axes, the bellows are all new. The fixed angular table has been newly planed. A reliable and user-friendly machine. An oil change has been performed. Mechanically and electrically inspected. The digital display from Heidenhain makes working easier and even more precise. Take the opportunity to inspect and test the machine on-site while it is powered up.

Condition: ready for operation (used), functionality: fully functional, travel distance X-axis: 500 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, Deckel FP4M universal milling machine in excellent technical and optical condition. Technical specifications: - Working travel X/Y/Z: 500/400/400 mm - Spindle speed range: 50 - 2500 rpm - Power: 3.7 / 4.4 kW - Spindle brake - Automatic feed: X-Y-Z steplessly adjustable 6.3 / 630 mm/min - Rapid traverse X-Y-Z 1300 mm/min - Fixed angle table - Vertical quill, 90 mm travel - Tool holder ISO 40/M16 - Weight approx. 1500 kg Machine options: - 3-axis digital readout Heidenhain - Coolant system - Chip tray Ljdpfx Aez Atxvokuoag - Central lubrication - Automatic pulse lubrication on the milling head Includes cabinet with accessories.

Condition: used, Technical details: x-travel: 600 mm y-travel: 300 mm z-travel: 360 mm range of revolution per miute: max horiz. 40- 2000 U/min spindle taper: vert. / horiz. SK 40/ SK40 range of revolution per miute: max zul. 40 - 2000 U/min feed:: 2-3600 mm/min quill travel: 80 mm Table dimensions: 810 x 420 mm total power requirement: 3 KVA Lsdpfxsu U E T Is Akueag machine weight approx.: 1300 kg dimension machine xH: 1,8 x 1,35 x 1,95 m Milling machine with shaping head joint length 32-80mm with 10 x double strokes, 24-285 strokes/min Heidenhain 3-axis displays *

Condition: good (used), Year of construction: 2021, functionality: fully functional, Internal article number: 26082 Universal milling machine Deckel FP4M Overhauled by FPS in 2021 Ledpfezxgy Sox Akuoag + Hydraulic machine vice, Röhm 135 + Machine lamp / protective cover + Operating manual Dimensions (L x W x H): 140 x 210 x 200 cm Weight: approx. 1500 kg The machine comes from a training workshop and is in very good condition.

Condition: excellent (used), Year of construction: 1986, functionality: fully functional, Universal milling machine Deckel FP4M with 3-axis digital display Heidenhain in special light gray paint!!! Technical data: >> Year of manufacture 1986, machine no. 2203-2308 >> Fixed angular table >> Speed: 50 - 2500 RPM >> Feed rate: 8 – 630 mm/min >> Drive power: 3.7 / 4.4 kW >> Spindle brake >> Rapid traverse rate: 1300 mm/min Ljdpszv Sdqjfx Akusag >> Travels X/Y/Z: 500/400/400 mm >> Vertical milling head on spindle head, adjustable by 150 mm >> Vertical quill and horizontal quill - SK40 >> Vertical quill extendable by 90 mm >> Clamping system M16 >> Weight approx. 1500 kg Accessories and equipment: >> 3-axis digital display Heidenhain >> Coolant system >> Chip tray >> Central lubrication About the machine: Offered is a Deckel FP4M universal milling machine in very good condition. The machine has little backlash and all spindles can be moved easily and smoothly. Even at maximum speeds, the milling machine runs smoothly. Rapid traverse in all axes. A reliable and user-friendly machine. An oil change has been performed. Mechanically and electrically inspected. The Heidenhain digital display makes the work easier and even more precise. Take advantage of the opportunity to inspect and test the machine on site while it is powered up. CE marking available for an additional charge.

Condition: excellent (used), Year of construction: 1990, machine/vehicle number: 30216 & 30277, feed length X-axis: 1,000 mm, travel distance X-axis: 1,000 mm, Universal tool milling machine Make: MAHO Model: MH 1000 2x available! x-way 1000 mm tool holder SK 40 digital display . Head tiltable +/- . Table tilt and swivel +/- . Quill stroke . - 3-axis digital display - Universal table 1.250 x 740 mm (T-slot 16 mm) - Vertical milling head SK 40 with tightening thread S 20 x 2 - 6 autom. quill feeds 0,02/0,03/0,05/0,08/0,12/0,20 mm/Umdr. - central lubrication, manually operated The machine can be inspected with pleasure. Laedpfx Akop S Schsuog Immediately ready for use Free loading, transport no problem.

Condition: used, Year of construction: 1987, FRIEDRICH DECKEL PRECISION MILLING MACHINE MODEL: FP4M YEAR: 1987 approx. HEIDENHAIN DIGITAL READ OUT Ljdpfjzv Eg Sex Akuoag CLEAN

Condition: excellent (used), Year of construction: 1984, functionality: fully functional, feed length X-axis: 500 mm, feed length Y-axis: 400 mm, feed length Z-axis: 400 mm, DECKEL FP4M Universal milling machine (1984) Serial number: 2203-1545 Control: HEIDENHAIN POSITIP 855 Travel distances: X-axis: 500 mm Y-axis: 400 mm Z-axis: 400 mm Rapid traverse rate: 1300 mm/min Feed rate: 8 – 630 mm/min Table dimensions: approx. 800 x 460 mm Ljdpjzmhlfofx Akuoag Max. table load: approx. 600 kg Spindle speed range: 50 - 2500 rpm Tool holder: SK40 Without machine vice.

Condition: used, x-travel 800 mm y-travel 400 mm z-travel 300 mm digital readout Heidenhain table surface area 1000 x 520 mm turning speed range 40 x 2000 U/min spindle taper SK 40 Ljdpfx Akeqpl Uujujag total power requirement 2,2 kW weight of the machine ca. 2,2 t dimensions of the machine ca. 1700 x 1600 x 1800 m

Condition: excellent (used), Year of construction: 1986, X-axis: 500 mm Lajdpfx Akozkhubeuog Y-axis: 400 mm Z-axis: 400 mm Tool holder: SK 40 Drive power: 8.1 kW Includes Heidenhain 3-axis digital display Includes various tools Includes machine vise Includes rotary table Includes additional angled milling head

Condition: like new (used), Year of construction: 2022, functionality: fully functional, Universal milling machine DMG FP4M Special Edition With 3-axis digital display ND7013 by Heidenhain, in new condition, Made in Germany, CE compliant!!! Technical data: Laodpfx Aszung Eokueg >> Year of construction 2022 >> Fixed angular table, clamping area 480x800 mm >> Spindle drive, speed range 25-3000 rpm, stepless adjustment with input on the control panel >> Controlled main drive 6 kW >> Vertical milling head, swiveling +- 90 degrees (180 degrees) >> Linear axes, feed range 6-500 mm/min >> Rapid traverse 1500 mm/min >> Space requirement (W+D) approx. 2.2 x 1.9 meters >> Weight approx. 1600 kg Accessories and equipment: >> Heidenhain digital display ND 7013 >> Coolant system >> Minimum quantity lubrication >> Central lubrication >> Machine feet >> Operating manual, etc. About the machine: Offered is a universal milling machine DMG FP4M Special Edition with a 3-axis digital display by Heidenhain ND 7013, in new condition. A reliable and user-friendly machine, Made in Germany. An oil change has been performed. Mechanically and electrically inspected. Take the opportunity to inspect and test the Deckel machine on-site while it is powered on.

Condition: reconditioned (used), Year of construction: 1984, functionality: fully functional, travel distance X-axis: 300 mm, travel distance Y-axis: 150 mm, travel distance Z-axis: 340 mm, quill stroke: 80 mm, spindle speed (max.): 2,000 rpm, spindle speed (min.): 40 rpm, table length: 210 mm, table width: 600 mm, total height: 1,750 mm, total length: 1,400 mm, total width: 1,600 mm, rotational speed (max.): 2,000 rpm, rotational speed (min.): 40 rpm, overall weight: 850 kg, table load: 200 kg, warranty duration: 3 months, The machine underwent a factory or partial overhaul by us in 2026 and is in top condition. As part of the partial overhaul, a new brake motor was installed. Control System 3-axis – active – digital display HEIDENHAIN TNC 113 Spindle Speed 40–2000 rpm, geometrically stepped direct drive with 18 speed levels for maximum torque and milling performance Feed Rate 5 to 500 mm/min, infinitely adjustable Rapid Traverse 1.2 m/min Quill Extendable quill, vertical 80 mm SK40 with M16 drawbar thread, optionally with DECKEL saw thread S20 x 2 Extendable quill, horizontal approx. 100 mm Axes X/Y/Z 300/150/340 mm Table Fixed angle table 600x210 mm Maximum table load: 200 kg Features • Vertical and horizontal spindle • Milling head manually swivelable +/- 90° • Z-axis bellows Options • Chip tray • Machine lamp • Universal table Lasdpfeyi Amwox Akusg • Rotary table • Slotting head • Dividing head • Steady rest • etc.

Condition: excellent (used), functionality: fully functional, travel distance X-axis: 500 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, spindle speed (max.): 2,500 rpm, spindle speed (min.): 50 rpm, quill stroke: 90 mm, Dear Sir or Madam, We hereby offer you a very well-maintained milling machine of the type Deckel FP4M (K) aktiv, featuring a rotary-tilt-swivel table and a 4-axis digital readout. With its extensive equipment, this model truly stands out among conventional machine tools. The machine has been thoroughly inspected in our workshop, is therefore in excellent condition, and is immediately ready for operation. We look forward to your inquiry! Delivery time: Immediately available Machine No.: xxxx-xxxx Year of manufacture: xxxx Table version: Rotary-tilt-swivel table Ledpfovvtlgsx Akueag Spindle speed: 50 - 2500 rpm Feed rate: 8 - 630 mm/min, infinitely variable Rapid traverse: 1300 mm/min Drive power: 3.7kW / 4.4kW Travel (X/Y/Z): 500/400/400 mm Tool holder: SK40 Clamping system: hydraulic Vertical quill stroke: 90 mm Weight: approx. 1600 kg Further features and accessories include: 4-axis digital readout (Heidenhain), 3-axis active control, hydraulic tool clamping, rotary-tilt-swivel table, coolant system, machine feet, operating manual, and much more upon request... Our service promise to you: - We are a certified master workshop in mechanical engineering - All machines are thoroughly checked - All lubricants and any worn parts are replaced beforehand - Upon request, we can completely or partially overhaul the selected machine - You are free to choose the paint color of your selected machine - If desired, you can order additional accessories such as tools, etc. directly - On request, we can install other accessories such as safety devices - We are happy to take care of shipping and/or installation
