Engraving machine

Deckel G L 1

Condition: ready for operation (used), functionality: fully functional, Engraving machine Deckel G1 L Fodpeyl U Hnjfx Ag Tepd Accessories: character set

Year of construction: 1969, condition: good (used), Work table Clamping surface 500 x 200 mm distance milling spindle - work table 300 mm longitudinal movement of the table by hand 300 mm transversal movement of the table by hand 160 mm template table stencil table 550 x 324 mm distance pantograph arm - clamping surface 20 mm Rotatable 360 stencil grooves 7 pcs., distance 45 mm Milling spindle spindle speed 1.900 - 15.000 rpm cutting speed 1 - 226 m/min Fpedpfxjidckfs Ag Tod motor speed 2.800 rpm Internal taper of the graver spindle 1:5 Gr. bore of the collet 6 mm Adjustability of the spindle 1 mm fine, 3 mm coarse Pantograph Transmission ratio 1 : 1 to 1 : 50 driving power 0,2 kW Dimensions Required area L x W x H 1400 x 1000 x 1420 mm Weight 260 kg Accessories / special features: - 1 set of fonts with letters and numbers - stylus
