Lid cabinet

Deckel

Condition: ready for operation (used), Year of construction: 2001, operating hours: 8,200 h, functionality: fully functional, machine/vehicle number: 28850018432, TECHNICAL DETAILS Tool diameter: max. 140 mm Speed at maximum diameter, max.: 6,500 rpm Guodpfx Aloy Rta Ejxjb Balancing quality according to DIN ISO 1940: G 6.3 Tool Magazine Number of tools: 24 Tool diameter, standard tools: max. 80 mm Tool diameter, special tools with adjacent positions free: max. 140 mm Tool length: max. 300 mm Tool weight: max. 7 kg Magazine load: max. 72 kg Table Clamping surface with T-slots DIN 650-14: 800 x 500 mm Loading height, top of table: 850 mm Workpiece height: max. 240 mm Table load capacity: max. 500 kg Coolant System Tank capacity with standard chip container: 150 l Tank capacity with spindle cooling: 80 l Pump performance standard, flow rate: 30 l/min Pump performance standard, pressure: 1.2 bar Tank capacity with chip conveyor option: 750 l Pump performance, chip conveyor option, flow rate: 40 l/min Pump performance, chip conveyor option, pressure: 3.0 bar Tank capacity including chip conveyor: 750 l Pump performance, internal coolant supply, flow rate: 30 l/min Pump performance, internal coolant supply, pressure: 15 bar Chip Disposal Chip conveyor discharge height: 850 mm Chip conveyor type: scraper belt MACHINE DETAILS Rated power: 30 kVA Rated current: 42 A Delayed main fuse: 3 x 50 A Operating voltage: 400 V Frequency: 50 Hz Compressed air connection: 6 bar Required system delivery rate: 38 Nm³/h Ambient temperature: +5 to +40 °C Average temperature over 24 h: +35 °C Relative humidity: 30–95 % Dimensions & Weight Transport dimensions of the machine with table (L x W x H): 3.1 x 2.1 x 2.4 m Transport weight: approx. 4,200 kg Mounting elements: 4 x BNV 150/4 EQUIPMENT Fixed station coding Vertical tool changer Pick-up system via work spindle Coolant system Spindle cooling Chip conveyor Internal coolant supply Mounting elements BNV 150/4

Condition: ready for operation (used), Year of construction: 2001, operating hours: 18,391 h, functionality: fully functional, machine/vehicle number: 11160000853, travel distance X-axis: 600 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 600 mm, controller manufacturer: Heidenhain, spindle speed (max.): 12,000 rpm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS X-Axis Travel: 600 mm Y-Axis Travel: 700 mm Z-Axis Travel: 600 mm Maximum Spindle Speed: 12,000 rpm X-Axis Feed Rate: 20 – 15,000 mm/min Y-Axis Feed Rate: 20 – 15,000 mm/min Z-Axis Feed Rate: 20 – 15,000 mm/min Rapid Traverse X-Axis: 40 m/min Rapid Traverse Y-Axis: 40 m/min Rapid Traverse Z-Axis: 40 m/min Linear Scale Resolution X-Axis: 0.001 mm Linear Scale Resolution Y-Axis: 0.001 mm Linear Scale Resolution Z-Axis: 0.001 mm Input Increment X-Axis: 0.001 mm Input Increment Y-Axis: 0.001 mm Input Increment Z-Axis: 0.001 mm Positioning Accuracy X-Axis: 0.01 mm Positioning Accuracy Y-Axis: 0.01 mm Positioning Accuracy Z-Axis: 0.01 mm Tool Holder: SK 40 NC Rotary Table Clamping Surface Diameter: 630 mm Max. Table Rotation Speed: 10.7 rpm Table Feed Rate: 3,600 /min Table Scale Resolution: 0.001 MACHINE DETAILS Control Manufacturer: Heidenhain Recorded Spindle Hours: 18,391 h Operating Voltage: 400 V Frequency: 50 Hz Rated Current: 80 A Connected Load: 44 kVA Gjdpfx Aljy Ni Aaoxoub Dimensions & Weight Dimensions (L x W x H): 5,500 x 4,500 x 2,500 mm Machine Weight: 10,000 kg EQUIPMENT 60-station tool changer Chip conveyor Cooling system

Condition: used, Year of construction: 2009, travel distance X-axis: 1,250 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,000 mm, Offered here is a used machining center from the manufacturer Deckel Maho DMG. The machine is powered up and can be inspected at our facility. Free loaded on truck Manufacturer: DMG Deckel Maho Model: DMC 125 H duoBlock Year of manufacture: 2009 Control: Siemens 840 D Solutionline (PCU 50) Technical data: Travel distances X-, Y-, Z-axis: 1250 x 1000 x 1000 mm Feed rate X-, Y-, Z-axis: 20 - 60,000 mm/min Rapid traverse X-, Y-, Z-axis: 60 m/min B-axis travel: 360 x 0.001° B-axis feed rate: 10,800 °/min Max. rotation of table plate: 30 rpm Spindle speed: 20 - 8,000 rpm Guodjw Ew T Sopfx Alxob Gear stages: 2 Max. workpiece diameter: 1250 mm Max. workpiece height: 1580 mm Clamping surface: 800 x 800 mm Max. workpiece weight: 1,500 kg Weight of pallet: 570 kg Max. permissible weight difference for pallet loading: 1,000 kg Tool holder: SK 50 according to DIN 69871 Max. tool length: 650 mm Tool magazine: 120 positions Transport dimensions: 6,500 x 3,000 x 3,200 mm Transport weight of machine (without magazine or other accessories): approx. 20,000 kg Space requirement: approx. 7,000 x 6,000 mm Total machine weight: 24,000 kg Accessories: Chip conveyor with coolant tank Coolant system 4x machine pallets Tool magazine Oil mist extraction Various new spare parts: 1x Length measuring system Y-axis (new) 1x Lubrication unit 230V 0.12 30 bar (new) 1x ZAHNRADP-AGG*MKF1-KW2-20036 (new) 1x Cyclo gearbox *F1C-A25 (new) 1x Conversion kit power module (new) 1x Lifting devices for the machine

Condition: excellent (used), Year of construction: 2006, Travelling-column vertical machining centre with linear motor X-axis Gjdpfx Ajy Skmrjlxoub Control: Heidenhain iTNC 530 (3D path) Travels: X 2,500 mm / Y 920 mm / Z 820 mm Spindle: 20 – 18,000 rpm · HSK taper

Condition: like new (used), Year of construction: 2022, operating hours: 12,719 h, travel distance X-axis: 2,000 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 850 mm, feed length X-axis: 2,000 mm, feed length Y-axis: 800 mm, feed length Z-axis: 850 mm, nominal power (apparent): 21 kVA, controller manufacturer: Heidenhain TNC 640 mit CELOS, workpiece weight (max.): 2,000 kg, total height: 3,200 mm, total length: 4,500 mm, total width: 7,100 mm, table width: 850 mm, table length: 2,350 mm, rotational speed (min.): 15,000 rpm, spindle speed (min.): 15,000 rpm, Year of construction: 2022 CNC controller: Heidenhain TNC 640 mit CELOS Axes X-axis travel mm: 2000 Y-axis travel mm: 800 Z-axis travel mm: 850 C-axis degrees: 360º (0,001) B-axis degrees: ±120 Rapid traverse m/min: 50 Acceleration in the axes m/s2: 5 Worktable Table dimensions mm: 2350x850 Max. workpiece weight kg: 2000 Milling/turning table nc: Table dimensions mm: Ø800 Max. workpiece weight kg: 800 Table rotation speed rpm: 50 Spindle Spindle speed rpm: 15000 Spindle drive power kW: 21/16 (40%ED/cont) Spindle torque Nm: 111/85 (40%ED/cont) Cooling Cooling through the Spindle Center bar: 40 Tank capacity: 600 Tool system Tool holder: SK 40 Tool magazine slots: 40 Tool changer: Double gripper With free neighboring places mm: 130 Godpfx Alsy Shgvsxoub With occupied neighboring places mm: 80 Max. Tool Length mm: 400 Max tool weight kg: 8 Chip-to-chip time s: from 7,5 Equipment Chip conveyor Rigid table with integrated rotary table Infrared probe Internal cooling lubricant supply Rinsing gun blowing air through spindle center selectable via M-function Signal lamp Mist collector NC swivel rotary table Preparation for the use of the 3D quickSET MPC – Machine Protection Control Automatic door Automation interface Machine running times Under power: 18669 Spindle Working: 12719 Basic machine dimensions / weight Length mm: 4500 Width mm: 7100 Height mm: 3200

Condition: used, x-travel 300 mm Godpoy Sbkbefx Alxjub y-travel 160 mm z-travel 330 mm table surface area 600 x 200 mm table load capacity 200 kg Spindle Speed 40-2.000 U/min. tool taper SK40 dimensions 1200 x 1160 x 1800 mm machine weight ab. 800 kg

Condition: used, Year of construction: 2007, x-travel 3.600 mm y-travel 920 mm z-travel 820 mm control iTNC530 Heidenhain B - axis +/- 90 x 1 ° C-axis 360 x 0,001 ° feed X/Y/Z-axis 1 - 20.000 mm/min rapid traverse X-axis 100 m/min rapid traverse Y-axis 60 m/min rapid traverse Z-axis 60 m/min spindle turning speed - stepless 20 - 10.000 U/min tool taper SK50 power capacity at 100 % load 32,00 kW power capacity at 40 % load 48,00 KW max. torque at 40% / 100% load 294 / 196 kW table surface area 4.200 x 900 mm number of T-slots 9 Godey Sbikspfx Alxjub T-slot - distance 100 mm T-slots 1x 18H7 / 8x 18H12 table load capacity - central/maximum 4.200 kg tool magazin: 80 tool diameter 115 mm wotkpiece diameter with 2 vacant positions 160 mm tool length - max. 360 mm weight of tools max. 12,00 kg total power requirement 85,00 kW weight of the machine ca. 32,00 t dimensions of the machine ca. 11,50 x 6,60 x H3,30 m Vertical machining center with HEIDENHAIN iTNC530 control, swivel milling head, partition wall, tool rack magazine with 120 positions, chip conveyor, coolant system, NC extension table (AR1), operating mode 4.

Condition: not inspected (used), Year of construction: 1986, travel distance X-axis: 850 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 600 mm, overall weight: 6,000 kg, Heidenhain TNC 426 900x700 mm universal table Travel: 850x700x600 mm Guodpjyt Nxuofx Alxob Max spindle speed: 6000 rpm Weight: 6000 kg

Condition: ready for operation (used), Year of construction: 2003, Immediately available ex works: 5-axis (3 plus 2) machining centre Deckel Maho Type DMU 35 M Year of manufacture: 2003 Siemens 810 D control Electronic handwheel Universal tilting/rotary table 400 x 290 mm Travel X/Y/Z: 350/240/340 mm Spindle taper SK 40 Spindle speeds: 20 – 6300 rpm Drive: 6.3/10 kW Guedsy R N U Sspfx Alxob Table load: 100 kg Rotation range: 360 degrees Swivel range: plus 105 / minus 15 degrees Distance spindle nose – table: 145/485 mm Feed rates up to 3000 mm/min Weight: 1750 kg Price: Euro 4,500.—plus VAT ex location

Condition: ready for operation (used), Year of construction: 2001, Immediately available ex-site: 5-Axis Machining Centre Deckel Maho Model: DMU 50 M Year of manufacture: 2001 Control system: Heidenhain TNC 124 5 axes (3 + 2) Manual rotary axes with B and C swivel rotary table B and C axes are displayed on the control Table size: 700 x 500 mm Travel paths X/Y/Z: 500 / 400 / 400 mm Table load capacity: 200 kg Spindle taper: SK 40 Spindle speeds: 20 – 4,500 rpm Drive power: 9 / 13 kW C-axis rotation range: 360 degrees Swivel range: plus 95 / minus 10 degrees Feed rate up to 5,000 mm/min Spindle speeds: 20 – 4,500 rpm Weight: 3 tonnes Gsdpfxey R N Uxo Alxeub Coolant system Price: EUR 8,500.— net, ex-site, plus VAT.
