DECKEL

Condition: ready for operation (used), Year of construction: 2005, operating hours: 20,729 h, functionality: fully functional, travel distance X-axis: 980 mm, travel distance Y-axis: 630 mm, travel distance Z-axis: 630 mm, controller model: Heidenhain iTNC 530, rotational speed (max.): 18,000 rpm, TECHNICAL DETAILS Travel range X-axis: 980 mm Travel range Y-axis: 630 mm Travel range Z-axis: 630 mm Spindle speed range: 0–18,000 rpm Tool holder: HSK 63 MACHINE DETAILS Control system: Heidenhain iTNC 530 Clamping area: 1,250 × 700 mm Pgjdezmry Tepfx Aflop Operating hours Machine operating hours: 46,922 h Program runtime: 20,279 h Spindle operating hours: 20,746 h EQUIPMENT Fixed angular table 3D measuring probe Heidenhain Tool measurement in the working area with BLUM laser Vertical tool changer with 32 magazine slots Full protective enclosure with sliding doors and interior lighting Electronic handwheel Operating modes 3 and 4 Chip conveyor Coolant system 3 height-adjustable machine feet Spindle cooler Control cabinet cooler from Rittal Operating manuals

Condition: ready for operation (used), Year of construction: 2007, operating hours: 11,421 h, functionality: fully functional, machine/vehicle number: 29100009074, travel distance X-axis: 640 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 500 mm, workpiece diameter (max.): 140 mm, spindle speed (max.): 16,000 rpm, number of slots in tool magazine: 30, TECHNICAL DETAILS Travel range X-axis: 640 mm Travel range Y-axis: 600 mm Travel range Z-axis: 500 mm Clamping area length: 850 mm Clamping area width: 600 mm T-slots: DIN 650-14 Loading height, top edge of table: 850 mm Table load max.: 600 kg Spindle manufacturer: Franz Kessler GmbH Speed: 1,600 - 4,700 / 4,700 - 16,000 rpm Number of magazine slots: 30 Slot coding: Fixed slot coding Load weight max.: 90 kg Chip-to-chip time without free travel logic t3/t2: 6.8 s Chip-to-chip time without free travel logic t1 (30): 7.9 s Chip-to-chip time with free travel logic t3/t2: 8.3 s Chip-to-chip time with free travel logic t1 (30): 9.3 s TOOLS AND TOOL MAGAZINE Diameter, standard tool max.: 100 mm Diameter, special tool with free neighboring slots max.: 140 mm Tool length max.: 300 mm Tool weight max.: 6 kg FEED Feed force X, Y, and Z axes: 7,000 N Feed rate X, Y, and Z axes max.: 40 m/min Rapid traverse speed Y and Z axes: 40 m/min Rapid traverse speed X axis: 70 m/min Ball screw diameter/pitch: 40/15 mm POSITIONING SYSTEMS Positioning accuracy, direct measuring system X-axis: 0.008 mm Positioning accuracy, indirect measuring system Y and Z axes: 0.020 mm Positioning accuracy, direct measuring system (option): 0.010 mm Resolution: 0.001 mm Input fineness X, Y, and Z axes: 0.001 mm MACHINE DETAILS Operating hours: 11,421 h Power-on time: 32,054 h Connected power: 33 kVA Podpozpxqdjfx Aflegp Nominal current max.: 58 A Fuse rating: 63 A Mains voltage: 400 V Mains frequency: 50/60 Hz Control voltage: 230 V Control voltage: 24 V COOLANT AND CHIP MANAGEMENT Chip box container capacity: 150 l Pump capacity, external coolant supply: 50 l/min Pressure, external coolant supply: 2.0 bar Pump capacity, chip flushing: 90 l/min Pressure, chip flushing: 1.9 bar Pump capacity, flushing gun: 50 l/min Pressure, flushing gun: 2.0 bar

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, travel distance X-axis: 600 mm, travel distance Y-axis: 560 mm, travel distance Z-axis: 560 mm, workpiece weight (max.): 600 kg, swivel angle C-axis (max.): 360 °, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel range, X-axis: 600 mm Travel range, Y-axis: 560 mm Travel range, Z-axis: 560 mm Swivel range, B-axis: 360° MACHINE DETAILS Control system: Siemens Number of pallets: 2 Pallet size: 400 × 500 mm Permissible pallet load: 600 kg Pgodpozpxd Rsfx Afljp Machine weight: 10,500 kg

Condition: ready for operation (used), Year of construction: 2002, operating hours: 18,419 h, functionality: fully functional, travel distance X-axis: 630 mm, travel distance Y-axis: 560 mm, travel distance Z-axis: 560 mm, workpiece weight (max.): 350 kg, number of slots in tool magazine: 24, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel range, X-axis: 630 mm Travel range, Y-axis: 560 mm Travel range, Z-axis: 560 mm Tool magazine slots: 24 Tool holder: SK 40 Rotary range, C-axis: 360° Table clamping surface: 600 x 1,000 mm Table diameter: 600 mm Maximum table load: 350 kg Table weight: 800 kg Number of T-slots: 8 / 1 T-slot width: 14 H12 / 14 H7 T-slot spacing: 63 mm MACHINE DETAILS Number of axes: 5 (3+2) EQUIPMENT Controlled NC swivel milling head (B-axis) Psdpfx Afjzpxdwoljgp NC rotary table integrated in the fixed table (C-axis)

Condition: ready for operation (used), Year of construction: 2002, functionality: fully functional, travel distance X-axis: 880 mm, travel distance Y-axis: 630 mm, travel distance Z-axis: 630 mm, controller model: Heidenhain iTNC 530, spindle speed (max.): 12,000 rpm, No minimum price – guaranteed sale to the highest bidder! The spindle was replaced on November 14, 2018. TECHNICAL DETAILS Travel in the X-axis: 880 mm Travel in the Y-axis: 630 mm Travel in the Z-axis: 630 mm Spindle speed: 12,000 rpm Controlled B-axis: -15° to +90° Tool holder: SK 40 Number of tool magazine slots: 32 MACHINE DETAILS Control system: Heidenhain iTNC 530 Spindle operating hours: 50,033 h Psdpfjzpw Iusx Aflegp EQUIPMENT Coolant system

Condition: ready for operation (used), functionality: fully functional, travel distance X-axis: 800 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 550 mm, quill stroke: 80 mm, overall weight: 3,900 kg, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel in X-axis: 800 mm Travel in Y-axis: 700 mm Travel in Z-axis: 550 mm Pgjdpozpwxysfx Aflop Vertical quill travel: 80 mm MACHINE DETAILS Machine weight: 3,900 kg EQUIPMENT Rotary table

Condition: ready for operation (used), Year of construction: 2001, functionality: fully functional, travel distance X-axis: 2,200 mm, travel distance Y-axis: 560 mm, travel distance Z-axis: 720 mm, controller model: Siemens 840D, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Travel range X-axis: 2,200 mm Travel range Y-axis: 560 mm Travel range Z-axis: 720 mm Spindle speed: 20–12,000 rpm Tool holder: SK 40 Spindle power: 35 / 25 kW Tool positions: 32 Max. tool length: 300 mm Max. tool weight: 6 kg Table clamping area: 2,600 × 600 mm Max. table load: 2,200 kg Rapid traverse X-axis: 80 m/min Rapid traverse Y-axis: 50 m/min Rapid traverse Z-axis: 50 m/min Psdozmyd Topfx Aflsgp MACHINE DETAILS Control system: Siemens 840D Power supply: Three-phase Dimensions & Weight Space requirement: approx. 7,000 × 4,200 × 2,700 mm Machine weight: approx. 12,000 kg EQUIPMENT Documentation / Manual Infinitely adjustable speed Chip conveyor Internal cooling: 40 bar Measuring probe: Renishaw OP60

Condition: ready for operation (used), Year of construction: 2000, functionality: fully functional, travel distance X-axis: 800 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 600 mm, controller model: Heidenhain Mill Plus, spindle speed (max.): 18,000 rpm, Vertical machining center with a virtually new spindle (1,023 operating hours)! TECHNICAL DETAILS Travel in X-axis: 800 mm Travel in Y-axis: 700 mm Psdpozqfvisfx Aflsgp Travel in Z-axis: 600 mm Spindle Spindle speed: 18,000 rpm Operating hours of the new spindle: 1,023 h Tool holder: HSK 63 MACHINE DETAILS Internal coolant supply: 40 bar Control system Control system manufacturer: Heidenhain Control system model: Mill Plus EQUIPMENT NC rotary table with C-axis NC swivel head FD function Pallet changer Infrared measuring probe for workpiece measurement Additional magazine with 120 spaces

Condition: good (used), DMG DMC 63 V, serial number 2885-0725, 11,972 operating hours. Podpfozqdlpjx Afljgp Available at the end of 2026.

Condition: ready for operation (used), Year of construction: 2002, operating hours: 20,802 h, spindle speed (max.): 10,000 rpm, total height: 4,500 mm, total width: 10,500 mm, overall weight: 41,500 kg, table width: 1,000 mm, table length: 1,250 mm, travel distance X-axis: 1,600 mm, travel distance Y-axis: 1,250 mm, travel distance Z-axis: 1,000 mm, controller manufacturer: HEIDENHAIN, product length (max.): 10,500 mm, table load: 3,000 kg, number of axes: 5, This 5-axis DECKEL MAHO DMC 160 U Hi-Dyn was manufactured in 2002. It features an impressive X-axis travel of 1600 mm, Y-axis travel of 1250 mm, and Z-axis travel of 1000 mm. The machine includes a tool changer capacity of 60 slots and a maximum load of 3000 kg on the pallet table. If you are looking to get high-quality machining capabilities, consider the DECKEL MAHO DMC 160 U Hi-Dyn universal machining centre we have for sale. Contact us for further details. - Tool Changer Capacity: 60 slots in rack magazine- Gripper Type: Double gripper- Operating Hours: 78,814 hours (as of 11/2024)- Program Run Hours: 20,802 hours (as of 11/2024)- Spindle Hours: 21,295 hours- Enclosure: Full protection cabin- Internal Coolant Supply (IKZ): 40 bar through spindle center (theoretical pump capacity)- Air Blast: Through spindle center, retrofitted (Original DMG)- Chip Conveyor: Scraper belt conveyor- Coolant Tank Capacity: 900 liters- Pallet Changer: Duo-Block pallet changer with 2 pallets- Pallet Table Surface: 1250 x 1000 mm- Clamping Grid: 100 x 100 mm, M20 thread- Milling Head: Universal milling head with controlled B-axis for 5-axis positioning and simultaneous machining- Universal Touch Probe: Heidenhain TS642- Calibration Kit: 3D Quick-Set in case- Operating Mode: Mode 4 capable- Cleaning Equipment: Wash-down gun with pump Pgjdszqcz Njpfx Aflop Technical Specification Taper Size SK 50 Through-spindle Coolant Yes
