Display - Demag

DEMAG

Condition: ready for operation (used), functionality: fully functional, overall weight: 5,000 kg, total length: 7,860 mm, total width: 2,900 mm, load capacity: 5,000 kg, main lifting speed: 5,000 mm/min, TECHNICAL DETAILS Hoist designation: P 35 Lifting speed: 5 m/min FEM group: 1Cm Load capacity: 5 t Rope/chain: 16 mm Y/W dimension 1: 111 mm MACHINE DETAILS Dimensions & weight Dimensions (L x W x H): 7,860 x 2,900 x 1,000 mm Net weight: 5,000 kg Codjyf Av Dopfx Afrsgn EQUIPMENT Wireless remote control Test book available Note: Crane runways are not included in the scope of delivery or sale.

Condition: used, Year of construction: 2007, - Sumitomo Demag IntElect 210/580-1000, year of manufacture 2009: 6260 x 1555 x 2219 mm (L x W x H), net weight 11,000 kg - Sumitomo Demag IntElect 210/580-1000, year of manufacture 2009 (excluding pictured handling equipment / temperature control units / material feed [hopper, conveyor]). Designation: SGM Operating hours Cycle counter Cylinder heating Electric drives Sumitomo Demag IntElect 150/520-610 29,125 26,530 3,562,329 Sumitomo Demag IntElect 210/580-1000 27,297 25,717 3,450,308 Injection moulding machine Sumitomo Demag IntElect 150/520-610, year of manufacture 2007 (excluding pictured handling equipment / temperature control units / material feed [hopper, conveyor]). Cgsdpfxsw E N S To Afren Designation: SGM Operating hours Cycle counter Cylinder heating Electric drives Sumitomo Demag IntElect 150/520-610 29,125 26,530 3,562,329 - Sumitomo Demag IntElect 150/520-610, year of manufacture 2007: 5348 x 1468 x 2400 mm (L x W x H), net weight 7,400 kg. Demag 150: Screw diameter Ø 45 mm

Condition: ready for operation (used), Year of construction: 1995, operating hours: 122,158 h, clamping force: 3,300 kN, screw diameter: 60 mm, This DEMAG ET 330 - 1450 hydraulic injection moulding machine was manufactured in 1995. It features a clamping force of 3300 kN and a screw diameter of 60 mm, providing robust performance for various applications. The machine includes a Wittmann W322-121 linear robot for enhanced automation. Consider the opportunity to buy this DEMAG ET 330 - 1450 hydraulic injection moulding machine. Contact us for further details. • Clamping unit: • Locking force: 3630 kN • Tie bar spacing (H x V): 710 x 630 mm • Platen dimensions (H x V): 1040 x 950 mm • Mold installation height: min 330 mm / max 830 mm • Opening stroke: 675 mm • Platen distance (daylight): 1505 mm • Permissible mold weight: fixed side (DS) 1200 kg; moving side (AS) 2400 kg; total 3600 kg • Ejector: stroke 200 mm; force 80 kN; retraction force 35 kN • Core pull control: yes (2 units, on ejector side/AS) • Shut-off nozzle: yes (hydraulic/pneumatic 1/1) • Injection unit 1: • Unit code: 1450-60 • Screw diameter: 60 mm • Injection pressure: 1905 bar • Stroke volume: 763 ccm • Shot weight (PS): 695 g • Screw L/D ratio: 20 • Nozzle radius: 15 mm • Max dosing stroke: 270 mm • Plasticizing flow: 41 g/s • Configuration/controls: • Armored (wear-resistant) injection unit: yes • Pneumatic ejector: yes • Process control: SPC (Yes/Yes) • Printer interface: integrated • Hot runner control: 0-zone (none) • Maintenance: • Hose replacement performed in 2017 Additional equipment • Wittmann W322-121 CNC linear robot/removal device (included with the machine) Cgjdpfxjyg Nkwe Afron • Travel paths: Y-axis 1600 mm, X-axis 500 mm, Z-axis 2500 mm

Condition: ready for operation (used), Year of construction: 2003, operating hours: 96,986 h, clamping force: 600 kN, screw diameter: 30 mm, This DEMAG ET60-200 concept hydraulic injection moulding machine was manufactured in 2003. It features a clamping force of 600 kN and a maximum mold weight of 580 kg. The machine includes a robust injection unit with a screw diameter of 30 mm and an injection pressure of 1900 bar. Consider the opportunity to buy this DEMAG ET60-200 concept hydraulic injection moulding machine. Contact us for further details. • Clamping unit: • Tie bar spacing (H x V): 420 x 420 mm • Platen dimensions (H x V): 530 x 540 mm • Min. mold installation height: 210 mm • Opening stroke: 400 mm • Max. mold weight: 580 kg (moving side 380 kg / fixed side 200 kg) • Ejector: • Stroke: 125 mm • Force: 41 kN Codpsyg Nfujfx Afregn • Retraction force: 15 kN • Pneumatic ejector: Yes • Core pull control: Yes (2 units, on the ejector side/AS) • Injection unit 1: • Unit size: 200 • Screw diameter: 30 mm • Injection pressure: 1900 bar • Stroke volume: 106 ccm • Shot weight (PS): 94 g • Screw L/D: 20 • Nozzle radius: 15 mm • Armored/wear-resistant injection unit: Yes • Process control: SPC (Yes) • Note: Maximum crane load warning: 2 metric tons Additional equipment • Robot/removal device: W621-1381 • Travel paths: Y 1200 mm, X 550 mm, Z 1500 mm • Hot runner controller: 7-zone integrated control • Mold sensors: Kistler (p=1/t=0)

Condition: excellent (used), Year of construction: 2015, Equipment: documentation/manual, Clamping force: 100 t Opening max: 500 mm Mould heigh: 250 mm Cedpfsyg Eu Ssx Afrogn Platen size: 590x600mm Distance between tie bars V: 420 mm Distance between tie bars H: 420 mm Type: Horizontal Drive: Hydraulic Screw diameter: 30 mm Injection weight: 103 g Injection volume: 115 cm3 Injection pressure: 2755 extra equipment: 1. 2 hydraulic core pull circuits on moving platen (proportional valves) 2. Additional connections for 2 core pulls on fixed platen 3. Pneumatic core pull (2 circuits) on moving platen 4. 4-zone cooling water flow controller with temperature display 5. Compressed air blow valves on fixed and moving platens (programmable) 6. Integrated hot runner control, 8 zones 7. Interfaces for external nozzle heating bands 8. Interface for integrated temperature control units (up to 6 circuits) 9. Interface for mould temperature monitoring (2 circuits) 10. EUROMAP 67 for automation equipment

Condition: used, Year of construction: 2001, Clamping force: 350 t Platten dimensions: 1040 x 950 mm Distance between tie bars: 710 x 630 mm Screw diameter: 50 mm Shot weight: 400 g Shot volume: 442 cm3 -2 core pullers -2 air valves, controllable hot runners: 1-16 chanel Cjdpfeva Ht Ssx Afrjgn -1 kaskade Type: Horizontal Drive: Hydraulic

Condition: good (used), Year of construction: 2008, functionality: fully functional, machine/vehicle number: 8754-0010, Plastic Injection Moulding Machine | DEMAG Ergotech - Multi 125/475-120h/80v (1250-120-80) Clamping force [kN]: 1,250 Number of components: 3 Clamping platen width [mm]: 690 Clamping platen height [mm]: 660 Codpfx Aoyguk Aofrjgn Clear tie bar spacing horizontal [mm]: 475 Clear tie bar spacing vertical [mm]: 450 Locating ring diameter [mm]: 125 Minimum mold height [mm]: 230 Maximum mold height [mm]: 560 Maximum mold opening stroke [mm]: 450 Maximum ejector stroke [mm]: 140 Thread (mounting holes) [M]: 16 Multi turntable type: Rotary table Turntable diameter [mm]: 700 Turntable threads [M]: 16 Maximum mould weight [kg]: 1,160 Maximum mould weight moving side [kg]: 760 Screw diameter [mm]: EE1: 25, EE2: 22, EE3: 14 Maximum shot weight [g] PS: EE1: 63, EE2: 48, EE3: 20 Aggregate configuration: EE1: horizontal, EE2: vertical, EE3: L-position Equipment: 2-core pull, with robot An inspection is possible at any time by appointment. Free loaded onto truck (Butzbach). #Tags: DEMAGergo | Ergotec | Multi125-475

Condition: good (used), Year of construction: 2005, functionality: fully functional, machine/vehicle number: 7174-0115, Plastic Injection Moulding Machine | DEMAG Ergotech - Multi 110/470-200h/120v (1100-200h/120v) Clamping Force [kN]: 1,100 Number of components: 2 Clamping plate width [mm]: 670 Clamping plate height [mm]: 670 Clear tie bar spacing, horizontal [mm]: 470 Clear tie bar spacing, vertical [mm]: 470 Centering ring diameter [mm]: 125 Minimum mould height [mm]: 240 Maximum mould height [mm]: 600 Maximum opening stroke [mm]: 600 Maximum ejector stroke [mm]: 180 Thread [M]: 16 Multi turntable type: Rotary table Turntable diameter [mm]: 600 Turntable thread [M]: 16 Maximum tool weight [kg]: 1,000 Codeyguhhspfx Afregn Maximum tool weight, movable side [kg]: 500 Screw diameter [mm]: EE1: 30, EE2: 22 Maximum shot weight [g] PS: EE1: 94, EE2: 42 Aggregate configuration: EE1: horizontal, EE2: vertical Equipment: 2-core pull, with robot Inspection possible at any time by appointment. Free on truck, loaded (Butzbach). - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: DEMAGergo | Ergotec | Multi110/470

Year of construction: 2024, condition: new, Demag NC3 panel new never used width- 30cm height- 5cm length- 50 cm Cedpfxsqvuins Afrogn Demag Ergotech system 3 panel

Year of construction: 2024, condition: new, Demag Panel NC3 Made in Germany width-30CM height-5CM length-50CM TYPE: 6EJ5 398-0DE14 Cgsdpfx Aeqvuigsfron Demag spare part panel
