Hoist motor KBH 140 B2/12

Demag

Condition: excellent (used), Bridge crane, overhead crane, disc brake, crane brake, disc, drum and storm brakes, traveling crane brake, brake ring, conical brake disc -Manufacturer: Demag, brake ring for conical brake disc, unused -Type: 628 626 44 RIW -Dimensions: see photos -Dimensions: Ø 310 x 37 mm -Weight: 1.0 kg Laodozixx Uopfx Amvsg

Condition: good (used), Year of construction: 2021, machine/vehicle number: 2-021-810-002, Offer 25221 Technical data: - Load capacity: 2000 kg - Outreach: approx. 3000 mm - Slewing radius: approx. 180° - 2 lifting speeds: approx. 3.0 + 0.75 m/min - Hook travel: approx. 3000 mm - Chain hoist control via hand remote pendant - Manual slewing of boom + manual trolley travel - Boom IPE 300 - Overall height with slewing arm holder: approx. 1220 mm - Power connection: 400 V - Weight: approx. 500 kg - Test book Lajdewvtpdopfx Amvsg

Condition: used, Year of construction: 2006, CLAMPING UNIT Lajdpsz D U Skefx Amvjg Clamping force: 800 kN Locking force: 800 kN Distance between tie bars: 420 x 420 mm Max. opening stroke: 450 mm Min. mould height: 250 mm (200 / 175 mm with ZE 214) Max. distance between platens: 700 mm (750 / 800 mm with WA 211) Platen size (H x V): 590 x 600 mm Max. mould weight: 700 kg Max. mould weight on moving platen: 450 kg HYDRAULIC EJECTOR Ejector stroke: 150 mm Ejector force: 41.2 kN Ejector retraction force: 14.8 kN INJECTION UNIT (120) Screw diameter: 22 mm L/D ratio: 20 Injection pressure: 2591 bar Stroke volume: 41.8 cm³ Shot weight (PS): 37 g Max. dosing stroke: 110 mm Max. nozzle stroke: 200 mm Nozzle penetration depth: 40 mm Nozzle contact force: 60 kN Barrel heating power: 5.1 kW Hopper capacity: 35 l GENERAL Oil tank capacity: 140 l Pump motor: 5.5 / 7.5 kW Total installed power: 10.6 / 12.6 kW Dry cycle time (EUROMAP 6a): 2.01 s – 196 mm / 1.82 s – 196 mm Net weight (without oil): 2550 kg (2650 kg with full cladding) Dimensions (L x W x H): 3.4 x 1.2 x 2.0 m (3.6 x 1.2 x 2.0 m with full cladding) Noise level (idle / full load): 56 / 71 dB(A)

Condition: used, Year of construction: 1998, CLAMPING UNIT Clamping force: 2000 kN Locking force: 2200 kN Max. opening stroke: 575 mm Min. mould height: 310 mm Max. mould height: 660 mm (760 mm with WA) Max. distance between platens: 1235 mm (1335 mm with WA) Platen size (H x V): 830 x 830 mm Distance between tie bars (H x V): 560 x 560 mm Max. mould weight: 2500 kg Max. mould weight on moving platen: 1700 kg HYDRAULIC EJECTOR Ejector stroke: 180 mm Ejector force: 80 kN Ejector retraction force: 35 kN INJECTION UNIT (840) Screw diameter: 50 mm L/D ratio: 20 Injection pressure: 1946 bar Stroke volume: 442 cm³ Shot weight (PS): 400 g Max. dosing stroke: 225 mm Max. nozzle stroke: 400 mm Lodpfez D U Rmsx Amvsag Nozzle penetration depth: 40 mm (30 mm with SPI) Nozzle contact force: 80 kN Barrel heating power: 14.8 kW Electric screw drive (WA): 20.5 kW Hopper capacity: 70 l

Condition: used, Year of construction: 2007, operating hours: 67,000 h, clamping force: 250 kN, displacement volume: 530 cm³, injection pressure: 2,426 bar, overall weight: 14,200 kg, screw conveyor diameter: 50 mm, Freight base: FCA Pegnitz Delivery time: by arrangement Payment terms: 100% before takeover of the machine, net Ljdpfx Amswlkcaevjag

Condition: used, Year of construction: 2003, CLAMPING UNIT Clamping force: 500 kN Locking force: 500 kN Distance between tie bars: 370 x 370 mm Max. opening stroke: 400 mm Min. mould height: 210 mm (160 / 135 mm with ZE 214) Max. distance between platens: 610 mm (660 / 710 mm with WA 211) Platen size (H x V): 540 x 530 mm Max. mould weight: 580 kg Max. mould weight on moving platen: 380 kg HYDRAULIC EJECTOR Ejector stroke: 125 mm Ejector force: 41.2 kN Ejector retraction force: 14.8 kN INJECTION UNIT (200) Screw diameter: 30 mm L/D ratio: 20 Injection pressure: 1900 bar Stroke volume: 106.0 cm³ Shot weight (PS): 94 g Max. dosing stroke: 150 mm Barrel heating power: 8.3 kW Hopper capacity: 20 l INJECTION UNIT – HORIZONTAL Max. nozzle stroke: 361 mm Nozzle penetration depth: 40 mm Nozzle contact force: 60 kN INJECTION UNIT – VERTICAL (parting line injection) A min / A max: 100 / 300 mm B min / B max: 100 / 468.5 mm Max. nozzle stroke: 368.5 mm Nozzle contact force: 15 kN GENERAL Oil tank capacity: 180 l Pump motor: 18.5 kW Total installed power: 26.8 kW Dry cycle time (EUROMAP 6a): 1.80 s – 224 mm / 1.80 s – 259 mm Net weight (without oil): 3400 kg Lajdpfx Amez D U Ixjveg Dimensions horizontal (L x W x H): 3.9 x 1.2 x 2.0 m Dimensions vertical (L x W x H): 3.9 x 1.2 x 3.4 m Noise level (idle / full load): 56 / 71 dB(A)

Condition: used, Year of construction: 2000, CLAMPING UNIT Clamping force: 2000 kN Locking force: 2200 kN Max. opening stroke: 575 mm Min. mould height: 310 mm Max. mould height: 660 mm (760 mm with WA) Max. distance between platens: 1235 mm (1335 mm with WA) Platen size (H x V): 830 x 830 mm Distance between tie bars (H x V): 560 x 560 mm Max. mould weight: 2500 kg Max. mould weight on moving platen: 1700 kg INJECTION UNIT (610) Screw diameter: 50 mm L/D ratio: 20 Injection pressure: 1598 bar Stroke volume: 399 cm³ Shot weight (PS): 360 g Max. dosing stroke: 203 mm Max. nozzle stroke: 400 mm Nozzle penetration depth: 40 mm (30 mm with SPI) Nozzle contact force: 80 kN Barrel heating power: 14.8 kW INJECTION UNIT (120) Screw diameter: 30 mm L/D ratio: 20 Injection pressure: 2420 bar Ljdpfx Amez D U Hbjvsag Stroke volume: 124 cm³ Shot weight (PS): 110 g Max. dosing stroke: 175 mm Max. nozzle stroke: 350 mm Nozzle penetration depth: 40 mm (30 mm with SPI) Nozzle contact force: 80 kN Barrel heating power: 7.9 kW Electric screw drive (WA): 12.6 kW Hopper capacity: 70 l

Year of construction: 2006, condition: excellent (used), machine/vehicle number: MBUT133-767, Steel single girder suspension crane Bridge crane Crane runway Indoor crane Gantry crane width approx. 8,3m - length approx. 11m, payload 500KG Track width can be changed, end beams (125cm) are bolted with 8 bolts. incl. approx. 2x 11m running rails IPE 300 (were cut in the middle) Lajdpfx Aoty Sx Romvsg incl. conductor rail for the power supply by means of the crane track's current grinder The width of the trolleys can also be adjusted to a different girder dimension. Incl. complete control system, floor operation by means of control bottle The crane can be moved electrically in all 3 axes Lifting height/hook path approx. 4m Connection to 400V 16A, year of construction approx. 2006 Very good condition, equipment was only used for maintenance - hardly used Shipping by forwarding agent, collection preferred Location 75053 Gondelsheim Please ask for shipping prices by postal code, we will send you an immediate and non-binding offer!

Condition: used, Year of construction: 2003, CLAMPING UNIT Clamping force: 2000 kN Locking force: 2200 kN Max. opening stroke: 575 mm Min. mould height: 310 mm Max. mould height: 660 mm (760 mm with WA) Max. distance between platens: 1235 mm (1335 mm with WA) Platen size (H x V): 830 x 830 mm Distance between tie bars (H x V): 560 x 560 mm Max. mould weight: 2500 kg Max. mould weight on moving platen: 1700 kg INJECTION UNIT (120) Screw diameter: 30 mm L/D ratio: 20 Injection pressure: 2420 bar Stroke volume: 124 cm³ Shot weight (PS): 110 g Max. dosing stroke: 175 mm Max. nozzle stroke: 350 mm Nozzle penetration depth: 40 mm (30 mm with SPI) Nozzle contact force: 80 kN Barrel heating power: 7.9 kW Laedez D U D Topfx Amvsg Electric screw drive (WA): 12.6 kW Hopper capacity: 70 l INJECTION UNIT (840) Screw diameter: 50 mm L/D ratio: 20 Injection pressure: 1946 bar Stroke volume: 442 cm³ Shot weight (PS): 400 g Max. dosing stroke: 225 mm Barrel heating power: 14.8 kW Electric screw drive (WA): 20.5 kW Hopper capacity: 70 l

Condition: used, Year of construction: 2001, CLAMPING UNIT Clamping force: 2000 kN Locking force: 2200 kN Max. opening stroke: 575 mm Min. mould height: 310 mm Max. mould height: 660 mm (760 mm with WA) Lsdpfxoz D Uyuj Amveag Max. distance between platens: 1235 mm (1335 mm with WA) Platen size (H x V): 830 x 830 mm Distance between tie bars (H x V): 560 x 560 mm Max. mould weight: 2500 kg Max. mould weight on moving platen: 1700 kg HYDRAULIC EJECTOR Ejector stroke: 180 mm Ejector force: 80 kN Ejector retraction force: 35 kN INJECTION UNIT (840) Screw diameter: 60 mm L/D ratio: 20 Injection pressure: 1351 bar Stroke volume: 636 cm³ Shot weight (PS): 570 g Max. dosing stroke: 225 mm Barrel heating power: 23.1 kW Electric screw drive (WA): 20.5 kW Hopper capacity: 70 l

Condition: used, Year of construction: 2001, CLAMPING UNIT Clamping force: 2000 kN Locking force: 2200 kN Max. opening stroke: 575 mm Min. mould height: 310 mm Max. mould height: 660 mm (760 mm with WA) Max. distance between platens: 1235 mm (1335 mm with WA) Platen size (H x V): 830 x 830 mm Distance between tie bars (H x V): 560 x 560 mm Max. mould weight: 2500 kg Max. mould weight on moving platen: 1700 kg HYDRAULIC EJECTOR Ejector stroke: 180 mm Ejector force: 80 kN Ejector retraction force: 35 kN NJECTION UNIT (120) Screw diameter: 30 mm L/D ratio: 20 Injection pressure: 2420 bar Stroke volume: 124 cm³ Shot weight (PS): 110 g Max. dosing stroke: 175 mm Max. nozzle stroke: 350 mm Nozzle penetration depth: 40 mm (30 mm with SPI) Nozzle contact force: 80 kN Barrel heating power: 7.9 kW Electric screw drive (WA): 12.6 kW Hopper capacity: 70 l GENERAL Oil tank capacity: 500 l Pump motor: 22 / 30 kW Total installed power: 30 kW (38 kW with electric screw drive) Dry cycles (EUROMAP 6a): 1830 / 1900 per hour Dry cycles without nozzle retraction: 2200 / 2300 per hour Net weight (without oil): 6200 kg Dimensions (L x W x H): 5.1 x 1.6 x 2.1 m (length without injection unit overhang) Noise level (idle / full load): 66 / 77 dB(A) Demag Ergotech 150-840 NC4 INJECTION UNIT (840) Screw diameter: 60 mm L/D ratio: 20 Injection pressure: 1351 bar Stroke volume: 636 cm³ Shot weight (PS): 570 g Max. dosing stroke: 225 mm Max. nozzle stroke: 400 mm Nozzle penetration depth: 40 mm (30 mm with SPI) Nozzle contact force: 80 kN Barrel heating power: 23.1 kW Electric screw drive (WA): 20.5 kW Hopper capacity: 70 l GENERAL Ledpsz D Uv Nsfx Amvjag Oil tank capacity: 500 l Pump motor: 22 / 30 kW Total installed power: 45 kW (53 kW with electric screw drive) Dry cycles (EUROMAP 6a): 1700 / 1870 per hour Dry cycles without nozzle retraction: 2000 / 2200 per hour Net weight (without oil): 7700 kg Dimensions (L x W x H): 5.4 x 1.6 x 2.1 m (length without injection unit overhang) Noise level (idle / full load): 66 / 77 dB(A)

Condition: used, Year of construction: 2001, Clamping force: 420 t Screw diameter: 60 mm Type: Multicomponent Laodpfx Amjz D T Ikoveg Drive: Hydraulic

Condition: excellent (used), Year of construction: 2014, Clamping force: 650 t Screw diameter: 60 mm Injection volume: 891 cm3 Shot weight: 810 g Distance between tie bars V: 1020 mm Distance between tie bars H: 1020 mm Platten dimensions H x V: 1450 x 1470 mm Max. oppening stroke: 930 mm Min Mould installation height: 450 mm Type: Horizontal Drive: Hydraulic \+ Cooling water flow controller (2x 6 circuits) \+ Robot Sepro SR SDR5X35 HL S5 TRANS (2014) Hot Runners 1. 24-zone integrated hot runner controller (ZE 273) 2. 32-zone integrated hot runner controller on fixed platen (ZE 274), extended to 36 zones (SO 10) 3. Pneumatic needle valve nozzle control, 1× 5/2-way valve (ZE 276) 4. Hot runner connector upgrade for 24 zones (SO 01) 5. Total: 60 zones across two controllers Equipment Highlights Injection 1. Electric screw drive, frequency-controlled (WA 313) 2. High-speed injection with central accumulator, servo-valve controlled (WA 361 + SO 12) 3. 4-fold pneumatic cascade injection + Gammaflux cascade interface (SO 05 + SO 08) Quality & Process Monitoring 1. Priamus cavity pressure measurement + BlueLine integration (SO 02 + SO 04) 2. Holding pressure switchover with peak value capture and recording (ZE 350) 3. 100% process data recording (PDE) with statistics and graphics (ZE 420) Mold & Core Pulls 1. 4 core pull circuits via proportional valves, flow-independent (ZE 234 + ZE 237) 2. Electric pressure relief for core pulls (SO 27) 3. Separate pneumatic hot runner needle (SO 04x) Quick Mold Clamping 1. Full quick-clamp system — interface, power supply, installation & testing (SO 23a–d) Connectivity & Automation 1. OPC/UA interface for host systems (SO 5631) 2. WC5 World Connect — remote access and service (ZE 571) 3. Integrated BDE/PDE production data management (ZE 471 + ZE 420) Lsdpoyzylvsfx Amvsag 4. Demag robot interface via CAN bus (ZE 752) Energy & Infrastructure 1. Integrated energy monitoring with per-part cost calculation (ZE 4921) 2. Elastic machine mounting / vibration isolation (WA 180) \+ 2x Magnetic platten
