Jig boring machine

DIXI M300

Year of construction: 2016, condition: new, 1 piece reconditioned unused industrial bevel helical gearbox from ASUG. TGL 21815 All parts of the gearbox are renewed, except the housing !!! Bwsdpfjgwlrdjx Afpek Claw coupling: 800 mm (only one half available) Maximum torque: 27.829 Nm Gear ratio: i= 1:80 max. power: 51 kW oil filling: 170 kg Speed: n1= 1400 Speed: n2= 17,5 weight: 1450 Kg Shaft diameter d1: 65mm Shaft diameter d2: 160 mm Shaft height h1: 500 mm Total height h2: 925mm Length from base: 1170 mm !! Gearbox has no oil cooler !

Year of construction: 1971, condition: used, Technical details: Bwedpfx Afjvc Apbspjk max. wheel diameter: 300 mm max. module: 5 module min. : 0,5 max. workpiece weight: 60 kg weight of the machine ca.: 4,0 t dimensions of machine: 1800x1850x2500 mm dimensions electric cabinet: Nr. 1: 1930x400x1920 mm dimensions electric cabinet: Nr. 2: 800x230x1950 mm dimensions:: Abluftanlage: 1400x700x560 mm dimension cooling device LxWxH: 1,2 x 1,0 x 0,45 m Electronically controlled tooth flank grinding machine up to module 5 and a Ø of 240 - 300 mm feed speed per workpiece revolution infinitely variable 0.4 - 3.2 mm max./min. Number of teeth: 130 / 12 max./min. Pressure angle: 30° / 14°30` max./min. Spiral pitch with 24 teeth: 6000 / 200 mm max. tooth helix angle, both sides: 45° Speed of the grinding worm: 1900 rpm without dressing device Equipment: approx. 77x change transmission wheels, pipe extensions and various tools Two of these machines are for sale. Both machines are supplied via two common control cabinets and an exhaust air system. *

Condition: new, Year of construction: 2025, saw band length: 4,420 mm, saw band width: 34 mm, Double-column bandsaw, fully automatic Everising H-360 HB Cutting range round: 0 - 360mm Cutting range square: 360 x 360mm Bundle tension: Width: 180 - 280mm Bundle tension height: 50 - 160mm Drive power: 3.7 kW Saw blade dimensions: 4420 x 34 x 1.1mm Weight: 2310 KG Machine dimension 2500 x 2200mm The standard equipment of the machines is as follows: Bjdpjq St U Nefx Afpewk Solid steel construction in double column principle - NC feed system - Frequency-controlled cutting speed (infinitely variable, inverter-controlled) - Digital cutting speed display - Hydraulically controlled double horizontal clamping vices - Hydraulic saw blade tensioning - Saw band guides (incl. band back guide) made of carbide - Hydraulically pre-tensioned band guides - Precise PLC control (SPS) for all hydraulic and electrical components. - Cutting counter with automatic switch-off - Automatic out-of-stock switch-off - Multi-job function - Bundle clamping device - Driven chip brush - Automatic band breakage control incl. emergency stop - Chip flushing gun - Flexible work light - 2 meter roller conveyor - Tool box - Carbide function Special equipment included: - Variable clamping pressure reduction - Cutting process control Extensive complete German documentation.

Condition: used, Year of construction: 1976, cone distance min./max. 0/108 mm Pitch angle min/max 5°/84° Pitch diameter (1:1 ratio) 152 mm pitch diameter (10:1 ratio) 216 mm Diametral pitch (finest/coarsest) 1.3/8.5 Mod. Bsdpfx Afsyh Rmtspjwk Face width gear wheel max. 35 mm speeds: 98-286 weight of the machine ca. 6577 kg dimensions of the machine ca. 1560 x 2140 x 2200 mm Equipment/accessories: -Cutting tools -Spacer angle -Technical documentation

Condition: ready for operation (used), Year of construction: 2008, operating hours: 27,167 h, functionality: fully functional, Technical Data – HERMLE C 40 UP Control System: - Heidenhain iTNC 530 - Travel X/Y/Z: 850/700/500 mm Options: - Heidenhain DNC - DXF Import Bodpexx Rxrofx Afpowk - Kinematic Opt iTNC Main Spindle: - Speed: 18,000 rpm - Tool Holder: HSK-A63 Tool Magazine: - Additional Magazine ZM43 Feed / Axes: - Linear guideways – Dynamic Version - Table variant: NC-SRT Ø 420 mm, worm gear drive - Table axis: A-axis offset from center - Table specification: Pallet clamping system Coolant System: - Internal coolant supply 80 bar - Coolant filter type: Paper band filter for internal coolant system Chip Disposal: - Scraper belt conveyor Cab / Safety: - Base structure - Automatic cabin door - Manual roof cover - Laminated safety glass window Electrics: - Frequency: 50 Hz - Country key: DE Pallet Automation: - Pallet changer: PW160, 400 × 400 mm - Pallet storage MMS / Measuring Systems: - External MQL (Minimum Quantity Lubrication) - Tool breakage monitoring A2 Blum - Heidenhain touch probe - Prepared for additional touch probe Software / Options: - Event Messenger - Tool identification HSK - Machine license: TCS-Soflex - System monitoring Free Accessories: - Electronic thermal compensation - Electronic hand-held control module - Oil mist extraction (prepared & with post filter) - Flange for oil mist extraction - Sealing air for scales - Chip washdown gun - Bed flushing - Internal & external air blast - Signal light - Test documentation - Test protocol: C 40 iTNC 530 PW160

Condition: excellent (used), The HURTH MODUL ZSTK 251 bevel gear planing machine was designed as a special machine and is used by manufacturers of drive systems in the drive technology, automotive, agricultural machinery, machine tools, mining technology, aviation and textile machinery sectors for the gear shaping of straight-toothed bevel gears with a short run-out. We still have 1 of these machines in stock, which, in conjunction with the Klingelnberg BF 203 bevel gear milling machine, can also produce crowned bevel gear sets in high quality. Technical data Workpiece diameter: 315 mm Module max.: 10 mm Tooth width: 45 mm Dimensions: 2.7 x 2.3 x 2.1 m Weight: 7,000 kg Bsdsup T Rlopfx Afpewk *Information and data are non-binding and subject to prior sale Viewing under operating conditions possible after consultation.

Condition: excellent (used), Year of construction: 2006, operating hours: 53,244 h, functionality: fully functional, Technical Data – Gleason Phoenix II 600HC (CNC Hypoid Gear Cutting Machine) Working Area Max. workpiece diameter: Ø 600 mm Max. tooth depth: 24.6 mm Max. gear width: 110 mm Number of teeth: 1–300 Cutterhead size face milling (FM): 18" diameter Cutterhead size hobbing (FH): 210 mm radius Max. cutter spindle speed: 600 min⁻¹ Work Spindle Front taper diameter: Ø 203 mm Taper bore diameter: Ø 181 mm Bwodexwzu Ijpfx Afpsk Bore depth: 884 mm Max. work spindle speed: 600 min⁻¹ Dimensions and Weight Footprint L × W × H: 4.4 × 3.5 × 3.5 m (incl. peripherals) Machine weight: 26,000 kg Connection Data Total connected load: 139 kVA Main fuse: 200 A Operating voltage: 400 V Mains frequency: 50 Hz Control voltage: 24 V DC

Condition: used, cone distance min./max. 0-108 mm Pitch angle min/max 5°/84° Control GE Fanuc Series 0-GC Pitch diameter (1:1 ratio) 152 mm pitch diameter (10:1 ratio) 216 mm Diametral pitch (finest/coarsest) 1.3/8.5 Mod. Face width gear wheel max. 35 mm Knife spindle - Speed range 41-121 U/min working spindle speed range 0-33.33 U/min weight 9025 kg dimensions of the machine ca. 2707 x 2720 x 2200 mmxmmxmm Equipment/accessories: Bwodpfxsyh Rmme Afpek -Knife -Chip conveyor -Technical documentation

Condition: used, Year of construction: 1988, functionality: limited functionality, gear diameter: 320 mm, workpiece weight (max.): 10,000 kg, total height: 2,000 mm, total length: 2,900 mm, total width: 2,000 mm, workpiece diameter (max.): 320 mm, Straight bevel gear machines type 5C267P, made Stanko in 1988 year, completed, need starting works for electric and hydraulic part. Slightly used, mechanical part in good condition. Available for sale two pieces. Price is 35000 Euro for 1 machine. Bwodpfxjykmdis Afpsk

Condition: good (used), Year of construction: 1992, functionality: fully functional, machine/vehicle number: 68910, workpiece weight (max.): 5,100 kg, wheel width: 180 mm, grinding wheel diameter: 330 mm, helix angle: 45 °, rotational speed (min.): 1,100 rpm, rotational speed (max.): 1,900 rpm, type of input current: AC, wheel diameter: 10 mm, gear diameter: 330 mm, overall weight: 5,100 kg, total height: 2,300 mm, total length: 6,000 mm, total width: 4,500 mm, Wheel diameter - max. 10 - 330 mm Wheel width 180 mm Module - max. 7 Module - min. 0.5 Clamping length 420 mm Number of teeth 10 - 600 Helix angle - max. +/- 45° Speed 1100 - 1900 rpm Grinding wheel diameter 280 - 350 mm Grinding wheel width 84 - 104 mm Machine weight approx. 5.1 t Bwedpfx Afjykrmcspek Required space approx. 4.5 x 6.0 x 2.3 m Grinding oil filtration unit Reishauer AF
