Gearwheel grinding machine

Reishauer RZ 301 S

Year of construction: 1992, condition: ready for operation (used), Gear diameter range: 10mm-330mm, gear width: 180mm, max. module: 7, min. module: 0.5mm, clamping length: 420mm, number of teeth range: 10-600, helix angle: +/-45°, speed: 1900rpm, grinding wheel diameter range: 280mm-350mm, grinding wheel width range: 84mm-104mm. Machine dimensions X/Y/Z: approx. 4500mm/6000mm/2300mm, weight: approx. 5100kg, control: Fanuc Series 160i-T. Documentation available. An on-site inspection is possible. Pgodpozg Iq Ijfx Afpjr

Year of construction: 2016, condition: new, 1 unit of a completely overhauled, unused industrial bevel-helical gearbox from ASUG. TGL 21815. All gearbox parts have been replaced, with the exception of the housing!!! Clutch: 800 mm (only one half available) Podpogwlrdofx Afpogr Maximum torque: 27,829 Nm Gear ratio: i = 1:80 Maximum power: 51 kW Oil capacity: 170 kg Speed: n1 = 1400 Speed: n2 = 17.5 Weight: 1450 kg Shaft diameter d1: 65 mm Shaft diameter d2: 160 mm Shaft height h1: 500 mm Overall height h2: 925 mm Length of base: 1170 mm !! The gearbox does not have an oil cooler !!

Condition: excellent (used), Year of construction: 1991, max. wheel diameter 10 - 330 mm gear width 180 mm max. module 7 min. module 0,5 clamping length 420 mm number of teeth 10 - 600 Pgedpfx Afszd Hgispjr ical angle +/- 45 ° turning speeds 1100 - 1900 U/min grinding wheel diameter 280 - 350 mm grinding wheel width 84 - 104 weight of the machine ca. 5,1 t dimensions of the machine ca. 4,5 x 6,0 x 2,3 m

Condition: excellent (used), Year of construction: 2021, operating hours: 3,000 h, travel distance X-axis: 6,100 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 950 mm, CNC Travelling Column Milling Machine – Fully Retrofitted by REM (2021) Powerful and versatile heavy-duty milling machine, completely modernized by REM specialists in 2021 with state-of-the-art Heidenhain TNC 320 control. Ready for immediate production use. KEY SPECIFICATIONS: • X-axis (transversal travel): 6,000 mm Pedpfx Aon D N H Tefpsgr • Y-axis (vertical head travel): 2,000 mm • Z-axis (axial slide travel): 950 mm • Dual-spindle head | Head rotation: 360° • Spindle speed: 1,000 – 4,000 rpm • Spindle taper: ISO 50 (automatic locking/unlocking) • Head dimensions: 290 × 290 mm • Spindle motor power: 15 kW (DC) • Machine weight: approx. 32 tonnes • CNC Control: Heidenhain TNC 320 WHY BUY FROM REM? ✔ Machine fully inspected and tested in working conditions ✔ Modern CNC retrofit – new electrics, new drives ✔ Documentation and technical support available ✔ Export worldwide | Competitive shipping Ideal for heavy component machining in aerospace, energy, and heavy industry. Contact us today for full technical specifications, photos, and video demonstration.

Condition: used, Year of construction: 2009, faceplate diameter 3000 mm swing diameter 3500 mm turning height 3200 mm Control Fanuc type Series 320i Model A slide adjustment 1750 mm ram head dimension 300x300 mm x-axis 2700 mm Table load 30000 kg main drive motor 100 kW Tool changer 16 weight of the machine ca. 89 t Pgodpfx Afoyqu Rwjpor dimensions of the machine ca. 8,5x6x8 m No. 1104 The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: excellent (used), The HURTH MODUL ZSTK 251 bevel gear planing machine was designed as a special machine and is used by manufacturers of drive systems in the drive technology, automotive, agricultural machinery, machine tools, mining technology, aviation and textile machinery sectors for the gear shaping of straight-toothed bevel gears with a short run-out. We still have 1 of these machines in stock, which, in conjunction with the Klingelnberg BF 203 bevel gear milling machine, can also produce crowned bevel gear sets in high quality. Technical data Workpiece diameter: 315 mm Module max.: 10 mm Tooth width: 45 mm Dimensions: 2.7 x 2.3 x 2.1 m Weight: 7,000 kg *Information and data are non-binding and subject to prior sale Viewing under operating conditions possible after consultation. Pgjdpfx Aoup T Rljfpsr

Condition: good (used), functionality: fully functional, Vertical lathe BERTHIEZ Brand: BERTHIEZ Podpfsy Egb Ssx Afpegr Table diameter: 2550 mm Max. turning diameter: 2800 mm Machinable height: 2300 mm Max. load: 25 t Speeds: 1 - 160 rpm Floor dimensions: 4000 x 4000 mm

Condition: good (used), Year of construction: 2002, turning length: 6,000 mm, spindle bore: 122 mm, travel distance X-axis: 90 mm, travel distance Y-axis: 300 mm, travel distance Z-axis: 6,110 mm, rotational speed (max.): 2,200 rpm, total height: 3,300 mm, total length: 16,000 mm, total width: 5,300 mm, overall weight: 32,000 kg, Multi-tasking lathe HEYLIGENSTAEDT - Heynumat 35/6000 MACH-ID 9643 Make: HEYLIGENSTAEDT Type: Heynumat 35/6000 Control: SIEMENS 840D Max. turning Ø: 890mm X-Axis: -10 to +490mm Y-Axis: -130 to +300mm Z-Axis: -180 to +6110mm Spindle bore: 122mm Speedrange: 2200Rpm Spindle power: 80kW ATC / revolver: 100 Pjdpfezclqlex Afpsgr B-Axis Toolsystem:Capto C8 Sandvik B-Axis Speedranges:2200Rpm B-Axis power: 28kW Length: 16000mm Width: 5300mm Height: 3300mm Weight: 32000kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: good (used), Year of construction: 2007, operating hours: 4,262 h, functionality: fully functional, machine/vehicle number: R7AV13, turning diameter: 65 mm, Can be powered up, the condition of the bar feeder is unknown, removed from production due to arrival of a new machine. On both turret heads, the use of a driven tool holder is possible in all positions. Pgsdpfjyxxhqjx Afpsr

Condition: excellent (used), General machine data: Manufacturer: GILDEMEISTER Model: CTX 500 E Machine type: CNC lathe / CNC slant-bed lathe Year of manufacture: 1998 Country of manufacture: Germany Control system: HEIDENHAIN CNC Pilot Work area: Max. turning diameter: approx. 440 mm Max. turning length: approx. 1,000 mm Swinging diameter over machine bed: approx. 680 mm Swinging diameter over cross slide: approx. 455 mm Main spindle Max. spindle speed: 3,600 rpm Spindle bore: approx. 107 mm Spindle drive power: approx. 23 kW Axes and travels Travel X-axis: approx. 220 mm Travel Z-axis: approx. 1,000 mm Rapid traverse X-axis: approx. 24 m/min Rapid traverse Z-axis: approx. 30 m/min Tool turret Number of tool stations: 12 Tool holder: VDI40 Driven tools Pgjdpfjzklu Esx Afper Tailstock CNC lathe with tailstock Suitable for machining longer workpieces Hydraulic tailstock quill Quill diameter: approx. 120 mm Quill holder: MK 5 Machine dimensions and weight Machine length: approx. 5,020 mm Machine width: approx. 2,200 mm Machine height: approx. 1,900 mm Machine weight: approx. 7,500 kg
