CNC turning and milling center

DOOSAN MX 2600 ST

Condition: excellent (used), Year of construction: 2013, Doosan Puma MX2600ST Fanuc 31i-A with Manual Guide i Swing over bed: Ø 1000 mm Max turning diameter: Ø 760 mm Max part length: 1540 mm Bar capacity: Ø 76 mm Movement: X1: 630mm Z1: 1585 mm Y: 230 mm (± 115 mm) X2: 220mm Z2: 1515 mm A: 1550 mm Left/right spindle: Spindle speed: 4000 rpm Spindle nose: A2-8 Spindle power: 22/26 kW C-axis: 360° (0.001) Milling spindle: 12,000 rpm Spindle power: 15/18.5/22 kW Spindle taper: Capto C6 B-axis: 0.001° Lower turret: 12 stations, 4000 rpm, BMT65P Tool magazine: 40 positions Automatic tool measurement Swarf conveyor Ledpfxov Hyf Us Ammsac Coolant for driven tools Coolant through milling spindle 1.5 KW , 2.0 MPA , 21.6 l/min Coolant pump for lower turret 2.2 KW , 1.0 MPA , 30 l/min Cutting force monitoring

Condition: ready for operation (used), Year of construction: 2009, turning diameter over cross slide: 925 mm, turning length: 2,800 mm, turning diameter: 1,200 mm, spindle bore: 132 mm, spindle speed (max.): 2,000 rpm, CNC Siemens 840D 48-tool changer, Capto C8 tools chip conveyor Forkardt 400MM chuck, 2 hydraulic steady rests SMW Autoblok Ljdowzyn Ropfx Ammoac capacity 2800x1250MM, spindle bore 132MM weight 23,500 kg

Condition: used, Year of construction: 2001, Technical details: x-travel: 2500 mm y-travel: 1000 mm z-travel: 750 mm table surface area: 3220 x 1000 mm Workpiece weight approx.: 3000 kg spindle taper ISO: 50 milling spindle turning speeds: 20 - 5000 U/min feed speeds: 1- 30000 mm/min rapid traverse: 30 m/min total power requirement: 40 kW dimensions of the machine ca.: 6,9 x 4,1 x 3,7 m weight of the machine ca.: 21 t with CNC HEIDENHAIN TNC 426 30-pockets autom. toolchanger RENISHAW measuring probe coolant attachment with TSC and chip conveyor diverse toolholders Lajdpfx Asvptmwsmmsc *

Condition: refurbished (used), Year of construction: 2005, functionality: fully functional, travel distance X-axis: 6,800 mm, travel distance Y-axis: 3,000 mm, travel distance Z-axis: 1,200 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, 5-axis gantry machining center CYPORT CP 6830 Travels X/Y/Z: 6,800 / 3,000 / 1,200 mm Gantry passage Y/Z: 3,276 / 1,405 mm Rapid Traverse X/Y/Z 30/30/30m/min 2-axis-NC-swivel head M-Series of German manufacturer Cytec: Swivel range A-axis : +/-110° Swivel range C-axis +/- 360° Powerful milling spindle of German manufacturer Cytec: Tool taper: HSK-A100 Speed: 8,000 rpm Power: 50/64 kW (100%/40% DC) Torque: 240/300 Nm (100%/40% DC) Control: HEIDENHAIN TNC 530 (Heidenhain TNC 640 / 7 possible) 5-axis path control DXF-converter CAD-Viewer KinematicsOPT Energy efficiency certificate Remote Service Tool magazine: Number of pockets: 39 pcs. HSK-A63 max. tool diameter: 125/175 mm max. tool length: 300 mm max. tool weight: 15 kg Coolant system Manufacturer: KNOLL Tank volume: 1,600 L external coolant supply: 20 bar internal coolant supply: 50 bar Paper band filter, Spray gun Chip conveyor Coolant-airblast-changeover Work piece measuring system: Touch probe BLUM TC 60 - radio controlled Working area coverage Safety light sensors Documentation CE-certification Laedeigrikepfx Ammoc Made in Germany

Condition: used, Year of construction: 2007, x-travel 900 mm y-travel 300 mm z-travel 1000 mm control Siemens Sinumerik 840D max. workpiece diameter 1600 mm Laodpfx Amow Rrb Hjmec max. module 20 mm tip circle diameter 350 mm Milling arbour diameter 375 mm Total closing value 80 kVa weight of the machine ca. 33,5 t dimensions of the machine ca. 10,530 x 6,375 x 4,680 m Feed rate: - X-axis 1 to 3000 mm/min - Y-axis 1 to 3000 mm/min - Z-axis 1 to 4000 mm/min Spindle speeds in rpm: - Tool 26 to 265 - Workpiece table 0 to 8 Equipment/accessories: - M 2 motor milling head - Milling mandrels - Oil cooler - Technical documentation

Condition: used, Year of construction: 2017, pipe diameter (max.): 80 mm, mandrel length: 4,500 mm, Mandrel bending machine S8004 ----- For the production of dimensionally accurate pipe geometries with bending radii of up to 1.5XD → maximum bending performance pipe 76 x 4 mm (400 N/mm²) → maximum bending performance pipe 60 x 60 x 3 mm (400 N/mm²) → maximum bending performance pipe 76 x 2.9 mm (stainless steel) → total connected load 7 kW → pipe length 4.5 mtr Robust and durable steel construction in a force-locking connection - no construction susceptible to torsion due to, for example, the split construction of the bending head and mandrel carrier. Maintenance-free electromechanical drive of the bending axis. The touch display of the control enables simple and intuitive programming and use of the system. After the pipe has been pushed on, it is fixed in the carriage by the chuck. This enables the pipe to be positioned precisely and thus the creation of dimensionally accurate geometries. The standard also includes checking the pipe geometry before the bending process: If the bending process is started in the wrong position, the machine does not give permission for this. This prevents incorrect operation. Optional additional features provide more convenience and increase the output and thus the efficiency of the system. Ljdpfx Ajttah Rsmmeac Data is exchanged from the optional pipe calculation program TBS-3D (PC version) via USB stick or via FTP access from the computer to the machine control system. USB or LAN connectors (RJ45) are available as standard. Existing pipe geometries can be converted quickly and easily, for example, using the STEP format. Standard equipment: → Electromechanical drive of the bending axis 4 kW → Speed 2.9 rpm (=17°/sec.) → Bending direction left → Bending angle resolution 0.1° → Max. bending radius 200 mm → Bending shaft diameter 50 mm → Electronic length measurement ±0.1mm → Electronic twist measurement ±0.1° → Manual stop system (overtravel stops in length) → Manual locking system (15° in twist) → Three-jaw chuck for locking the pipe in the carriage → External control panel PLC control: → Touchscreen 10.1" → ETH 10/100, X2X Link, USB → Foot switch operation → Data transfer via network (W)LAN or USB → Material database Unique graphic programming: Simple geometries can be calculated directly on the machine. The control calculates the feed values directly after entering the length and angle and the bending angles. Hydraulics: → Hydraulic power 3 kW → Hydraulic pipe clamping with adjustable clamping pressure → Programmable early mandrel retraction Options (can be ordered as additional equipment): → Variable bending speed using frequency converters or servo motors → Automatic tool retraction (manual or controlled) → Pneumatic chuck → Automatic mandrel lubrication → Pneumatic stop system (length + twist) → Mobile version (rollers) → Radius extension Pictures show new machine

Condition: good (used), total width: 3,500 mm, total length: 19,000 mm, total height: 2,100 mm, workpiece weight (max.): 6,000 kg, grinding diameter: 850 mm, grinding length: 6,000 mm, center height: 425 mm, Cylindrical grinder Schmaltz - RM 82/6000 MACH-ID 9492 Make: Schmaltz Type: RM 82/6000 Centre height: 425mm Grinding Ø: 850mm Grinding length: 6000mm Grinding stone dimensions:1100 x 80 x 560mm Grinding stone speeds: 700Rpm Table inclasement: -5 to +5° Tailstock: 160 x 100Mk Lajdpey Dr Eajfx Ammoc Length: 19000mm Width: 3500mm Height: 2100mm Weight: 31000kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: used, Craven 2000mm x 8000mm Heavy Duty Lathe 2000mm swing over bed 1500mm swing over saddle 8,000mm between centres Ljdpfx Amox Hp Iwomsac Main drive 60kW, 40 ton load capacity Spindle speeds 2 – 152 rpm Steadies 2000mm Bed extension

Year of construction: 2005, condition: ready for operation (used), Travel X/Y/Z: 2500mm/900mm/800mm, speed: 18000rpm, spindle power: 35kW, max. table load: 3000kg, tool places: 30, machine dimensions X/Y/Z: approx. 6500mm/3000mm/3000mm, weight: approx. 20000kg, control: Siemens Sinumerik 840D, operating hours: 55730h, spindle hours: 18696h. Z-axis brake defective, roller shutter in machine room defective, screen cable defective. Including cooling lubrication system Knoll VRF 250/1250, documentation available. On-site inspection is possible. Lodpfsvamqdex Ammeac

Condition: excellent (used), Year of construction: 2013, operating hours: 64,269 h, functionality: fully functional, travel distance X-axis: 2,200 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 1,000 mm, table length: 2,300 mm, table width: 1,600 mm, spindle speed (max.): 20,000 rpm, overall weight: 30,000 kg, For sale is a well-maintained Parpas Diamond Linear. – C-axis (milling head): (degrees) +/- 370 – A-axis (milling head): (degrees) +/- 105 Distance between columns: (mm) 2,700 Distance between table surface and spindle nose with milling head mounted, max.: (mm) 1,220 – X and Y axis rapid traverse: (m/min) 60 – Z axis rapid traverse: (m/min) 40 Spindle: 5-axis orthogonal milling head – Internal coolant supply (ICS): (bar) 20 – Maximum spindle speed: (rpm) 20,000 – Drive power S1 / S6: (kW) 29 / 37 – Torque S1 / S6: (Nm) 92 / 115 Tool magazine – Tool holder: HSK 63 A – Tool positions: 42 – Tool diameter: (mm) 80 – Tool length: (mm) 350 – Tool weight: (kg) 6 Machine table – Table size L x W: (mm) 2,300 x 1,600 – T-slot spacing: (mm) 200 – T-slot dimensions: (mm) 22 – Max. workpiece weight: (kg/m²) 6,000 FEATURES & EQUIPMENT + Heidenhain iTNC 530 control + Portal (gantry) design: U-shaped "monoblock" construction with one crossbeam and stationary workpiece + Milling head (A- and C-axis), A-axis with torque motor and hydraulic clamping, A-axis positioned perpendicular to the C-axis Ledsxxvp Nepfx Ammjac + No foundation required + Glass scales in X, Y, and Z linear axes + C-axis with Heidenhain angle measurement system, resolution 0.001 degrees + Heidenhain HR 520 electronic handwheel + 2 chip conveyors (one at the front and rear of the table) + Internal coolant supply (ICS) 20 bar + Paper filter unit + Sliding roof with opening for loading and unloading
