Laser cutting machine

DURMA 10 kW HD-F 3015 III Fiber

Condition: new, Year of construction: 2025, machine/vehicle number: OR-220701306, Description: AORE PG3015: ( 3 Kw) 40 sold in 10 month. We can deliver this type Laser cap. from (1 till max 20 Kw) A Compact Design with Complete Protection (CE) table length 3050 mm table width 1530 mm laser head ( SWISS RAYTOOLS ) autofocus laser capacity Kw 6 overall dimensions 8265 x 2280 x 2150 mm weight of the machine ca. 5.400 kg Furnishing: - Max-photonics Laser source 3 Kw - CYPCUT (full option, no extra control option cost) - High integrated, simple operation, leading technology - Ray-tools autofocus cutting head Bledpfx Aljlkgd Iezep - CYPCUT - CAD / CAM software include: - Nestling, With leapfrog, Edge seeking, Fly cutting, ETC - 23" touchscreen, keyboard, control panel - additional loading unit - central Lubrication system Cutting capacities: ( for 3 Kw ) - normal steel 20 mm - stainless steel 10 mm - aluminium 10 mm - brass 9 mm - copper 7 mm Axes: - Machine axes: 3 axes (X, Y, Z,) - X-axis travel 3000 mm - Y-axis travel 1500 mm - Z-axis travel 315 mm - Axis speed X / Y: 100 m / min - Positioning accuracy: +/- 0.03 m - Reputability accuracy +/- 0.02 mm - Acceleration max. 1,5 G Automatic table change: - Number of table 2 (15 second max for changing) - automatic change, max load on tables 1440 kg. - 2 x CCTV camera on pallet arear on screen assisting gases: - mild steel - oxygen (0.5 - 25 bar) - stainless steel - nitrogen (0.5 - 25 bar) - Aluminium - compressed air or nitrogen (0.5 - 25 bar) including: - Compatible suction system, cap 3 Kw - Spare part basic supply package - cutting from reflective sheet metal materials - 3 part trolly under work table - Machines for cutting thin sheets - axes equipped with Japanese servo motors YASKAWA - Servo motors reach up to 100 m/min. - Accelerations up to 1.5 G - Fiber laser is the green laser technology for the future - (Saving of at least 50% energy costs) - Components / therefore very low-maintenance - Save up to 50% per part through more efficient production - In addition, precise cuts and smooth surface quality - Heavy-duty constructed frame, - equipped with world-famous, durable, high-quality components We use the most high quality parts Like: -- Yaskawa servo drives -- Hiwin linear rails -- Tongfei water chiller dual use for source and laser head -- 2 CCTV camera’s on screen -- Auto central lubrication -- Touch screen 23 inch -- For providing quickly service, we add WIFI function for our technician operates troubleshooting and adjust parameters remotely -- YYC/APEX rack and pinion -- standard delivery is with power transformer and stabilizer total power requirement 50 kW -- TBI high precision ball screw for Z axis -- saw tooth blade table -- air and gas pressure real time monitoring on screen -- CE declaration -- warranty 2 year, max 3600 hours Price is EXW (Stock Europe), Include loaded on truck. Transport, installation, commissioning, training, and yearly service contracts are available upon request for an additional fee. Installation and training is always done by our high qualified Service team in 3 locations in Europe. Netherlands, Germany, Romania. Official Dealer CNC Top Ten b.v. Coevorden Holland
