DYE TVC 1300 CNC Vertical Lathe – Ø1900DYE
TVC-1300-NC
Machine data
- Machine type:
- DYE TVC 1300 CNC Vertical Lathe – Ø1900
- Manufacturer:
- DYE
- Model:
- TVC-1300-NC
- Condition:
- refurbished (used)
- Functionality:
- fully functional
Price & Location
- Location:
- POLIGONO INDUSTRIAL DE ITZIAR, PARCELA C2, 20829 Deba, ES
Technical details
- Travel distance X-axis:
- 2,650 mm
- Travel distance Z-axis:
- 700 mm
- Spindle motor power:
- 52,000 W
- Spindle speed (max.):
- 400 rpm
- Turning diameter over cross slide:
- 1,900 mm
- Turning diameter:
- 1,900 mm
- Turning height:
- 1,700 mm
- Rotational speed (max.):
- 400 rpm
- Input voltage:
- 400 V
- Workpiece diameter (max.):
- 1,900 mm
- Clamping diameter:
- 1,300 mm
- Faceplate diameter:
- 1,300 mm
- Input frequency:
- 50 Hz
- Equipment:
- rotational speed infinitely variable
Details about the offer
- Listing ID:
- A105-97601
- Update:
- 27.05.2025
Description
Special offer: Fully reconditioned CNC vertical lathe, ideal for large workpieces and demanding machining tasks. Ready to operate, includes full documentation.
🛠 Key technical specifications:
• Chuck diameter: 1300 mm
• Max. turning diameter: 1900 mm
• Max. turning height: 1700 mm
• Vertical ram travel: 1200 mm
• X-axis travel: 2650 mm
• Z-axis travel: 700 mm
• Main spindle motor power: 52 kW
• Spindle speeds:
o Range 1: 0–100 rpm
o Range 2: 0–400 rpm
• Driven tool motor: 24 kW
Hfjdpfx Asmdqibsfpsn
• Driven tool speeds: 0–2000 rpm
• CNC: FAGOR 8065 with dual-channel execution
⚙️ Included equipment:
• C-axis with angular Heidenhain encoder ±5
• 6-position turret, including dual-output CAPTO C-6
• Automatic dual pallet changer
• New telescopic steel guards on X-axis
• New electric cabinet and wiring (CE compliant)
• Includes PLC programming, project design, and full documentation
✅ Ideal for:
• Heavy industry part manufacturers
• Complex large-part machining
• Shops requiring turning over 1.5 meters in diameter
📌 Professionally reconditioned and ready for immediate delivery.
An excellent choice for shops demanding precision, torque, and large-scale capability.
