FLAT GRINDING MACHINE

ELB-Schliff Flachschleifmaschine

Condition: used, Surface grinding machine BLOHM type HFS 6 make no.: 10493 year of construction 1973 Electro magnetic clamping plate 600 x 300 mm Kjdpfxjd Hbafs Ac Hsnf grinding length 600 mm grinding width 400 mm table longitudinal movement max. 650 mm transversal movement 350 mm distance spindle center - table surface max. 600 mm distance spindle center - magnetic plate max. 517 mm Clamping surface table 1020 x 300 mm grinding wheel diameter 300 mm grinding wheel width 50 mm grinding wheel bore 76 mm table longitudinal feed 2-30 m/min infinitely variable table cross feed 2-65 mm stepless electric cross feed 3 m/min vertical feed 0,001 - 0,020 mm per infeed pulse vertical feed 0,250 m/min grinding wheel speed 1400 / 2800 rpm. Motor power hydraulic pump 2,2 kW Motor power grinding spindle 5 / 6 kW Mains connection 380 Volt, 50 Hz. Total power 11 kW - automatic depth adjustment - hydraulic longitudinal table movement - grinding wheel dresser on the headstock - electromagnetic plate height 83 mm - coolant system adjacent, with magnetic filter in filter housing - grinding spindle circulating lubrication - adjacent control cabinet (800 x 500 mm) - swiveling control panel - operating instructions and spare parts manual space requirement L x W x H 3000 x 2200 x 2100 mm weight surface grinding machine 3000 kg weight switch cabinet 200 kg good condition

Condition: used, grinding length 600 mm grinding width 200 mm workpiece height 250 mm grinding wheel diameter 200 mm grinding wheel width 20 mm weight of the machine ca. 1000 kg dimensions of the machine ca. 2000 x 1200 x 1650 m Knjdpfx Aeu N I Nkec Hef

Condition: used, Year of construction: 2000, grinding length 600 mm Kedow Hg Uzspfx Ac Hjnf grinding width 300 mm magnetic clamping plate 600x250 mm wheel diameter 220-300 mm weight 2200 kg

Condition: ready for operation (used), Year of construction: 1982, Sanding length 500 mm Sanding width 350 mm Sanding height 375 mm Sanding spindle drive 3.7 kW Table speed 2-28 m/min Automatic cross feed 1-60 mm/stroke Automatic vertical feed 0.002 - 0.06 mm/min Grinding wheel dimensions 300 x 76.2 x 50 mm Knodju Ag Aiopfx Ac Hsf Machine weight approx. 2,800 kg
