Elumatec SBZ 122/30

Elumatec

Condition: used, Year of construction: 2010, machine/vehicle number: 1780021340, Order No. 26305 Three-spindle copy milling machine Technical data: - Operation via two-hand lever Redpozxc Swefx Ab Tecf - Material clamping via pneumatic clamping cylinder - Workpiece width / clamping range B 115 x D 100 mm - Milling area above, to stop / copy template B 340 x D 100 mm - Stroke above D 110 mm - Milling area below, to stop / copy template B 240 x 90 mm - Stroke below, front / rear 95 / 45 mm - Spindle speed 12000 rpm - Metering spray device - Air consumption per working cycle - Without spraying 12 liters - With spraying 24 liters - Left + right original material support - Drive 400 V / 0.75 kW - Space requirement approx. B 900 x H 1400 x D 1250 mm - Weight approx. 300 kg

Condition: ready for operation (used), Year of construction: 2009, Pressing height 140 mm Pressing force 70 kN (7 t) Pneumatic drive Power supply 230 V, 1~, 50/60 Hz Compressed air supply 7 bar Air consumption per working cycle 35 l Length 1,100 mm, depth 950 mm, height 1,230 mm, weight 545 kg For pressing profiles with large dimensions with the highest quality requirements The machine is easy to adjust and operate and has short changeover times thanks to a simple blade-changing system Extremely high pressing force due to large-volume bellows cylinder (maintenance free) With retractable, hydro-pneumatically controlled counter bearing The specially-designed counter bearing head allows pressing of frames with an inner dimension starting at 150 mm (clear dimension) The pressing depth can be set separately for each tool carriage An adjustable pressing blade is also available to compensate for the profile chamber offset (-5 to 15 mm as standard, 15 to 35 mm as an option) Support arms and pressing blades included as standard Rcsdpfxezxc Rms Ab Tjf 2-hand operation

Condition: used, Year of construction: 2010, operating hours: 2,000 h, functionality: fully functional, travel distance X-axis: 8,500 mm, travel distance Y-axis: 480 mm, travel distance Z-axis: 320 mm, nominal power (apparent): 8 kVA, workpiece length (max.): 8,500 mm, total height: 3,100 mm, total length: 11,500 mm, total width: 3,000 mm, rotational speed (max.): 15,000 rpm, overall weight: 6,000 kg, spindle speed (min.): 15,000 rpm, spindle motor power: 5,500 W, input voltage: 400 V, type of input current: three-phase, Equipment: documentation/manual, Elumatec SBZ 130 CNC 3-axis steel processing center, TOP condition Processes steel, stainless steel, aluminum, PVC, etc. Rodpfoziy Idsx Ab Tscf The machine can mill, drill, tap, cut, and notch. All machining operations are performed while the profile is stationary. 8-position tool changer on a turret. Max. milling cutter diameter: 80 mm Max. disc cutter diameter: 200 mm Tools and accessories, including special wrenches, as shown in the picture. Tool holder: BT 30 Max. machining length: 850 cm, with stringer-side machining: 838 cm, y-axis: 48 cm, z-axis: 320 cm Year of manufacture: 2010, spindle speed: 15,000 rpm, spindle power: 5.5 kW Weight: approx. 6 tons. Includes laser and partition, protective mat, machining accuracy: x-axis, y-axis, z-axis +/- 0.1 mm Air consumption: approx. 75 liters, with spray nozzles. Inspection is possible by appointment. The machine is located in 91629 Weihenzell.

Condition: good (used), Year of construction: 2011, machine/vehicle number: 1612124593, Offer 26309 Technical Data: - Saw blade dimensions: 280 x 3.8 x 40 mm - Saw blade speed: 3200 rpm - Cutting range at 90°: approx. 100 x 70 mm - 200 x 40 mm - Miter angle adjustable: Left: 0 - 90° - Right: 0 - 45° - Compressed air connection: 6 - 8 bar - Air consumption per working cycle: 10 L/min - Drive: 400 V / 0.74 kW - Space requirement: approx. W 650 x H 1100 x D 750 mm - Weight: approx. 120 kg - Includes: - Pneumatic vertical clamping device - Pneumatic coolant spray device - Infeed roller conveyor: 2500 mm Redpfx Aozw Datsb Tocf - Outfeed roller conveyor with stop and - Digital position indicator: 3000 mm

Condition: good (used), Year of construction: 2010, machine/vehicle number: 2449333214, Offer 26304 Technical data: Rsdpfx Aezw Azieb Tscf - Saw blade diameter: 550 mm - Max. cutting length: 6000 mm - Smallest cutting length at 90° + 45°: 335 mm - Cutting range: see diagram attached - Swivel range inwards, pneumatically: 90 - 45° - Swivel range inwards, manually: 22.5° - Swivel range outwards: 140° - Tilt range inwards, pneumatically: 90 - 45° - Saw blade speed: 2800 rpm - Drive: 400 V / 2 x 4000 Watts - Space required: approx. W 8000 x H 1600 x D 1400 mm - Weight: approx. 2500 kg - Including: - PC control E 355/1 for cutting length adjustment - Motorized swiveling and tilting of both units - Indexing device - Traveling roller conveyor + separate roller conveyor

Condition: excellent (used), Year of construction: 2017, It has only worked for 445 hours. Rodpozgu Efjfx Ab Tjcf Very good technical condition. Ready for operation. The machine is designed for cutting aluminum and PVC. E 580 control system. Blade diameter: 500 mm. Cutting according to the outer dimension, without correction. Blades guards are automatically lowered and raised. Pneumatic adjustment of the cutting angle from 45 to 90 degrees. Printer included.

Year of construction: 2005, condition: good (used), Double-head PVC profile welding machine. Rjdpfx Abozdqpbe Tjcf

Year of construction: 2013, condition: excellent (used), machine/vehicle number: 6080008264, In very good condition (almost perfect). Rcsdpfszdp Rwox Ab Tjf

Year of construction: 2013, condition: excellent (used), machine/vehicle number: 1425131305, Lightly used, in very good condition. Redjzdpz Nspfx Ab Tecf

Year of construction: 1998, condition: used, 3-sided machining in one setting Speed: 12,000 revolutions per minute 2 pneumatic tracers at the bottom, 1 tracer at the top Rcodpfxjzwl R Te Ab Tef Pneumatic material clamping Minimum quantity spray device Milling area vertical (top): 330 x 130 mm Milling area horizontally (from the front or rear): 220 x 95 mm Stroke: 110mm With side stops Weight: about 350 kg
