CNC lathe

EMCO Maxxturn 65

Condition: like new (used), Year of construction: 2022, operating hours: 850 h, functionality: fully functional, turning length: 610 mm, turning diameter over cross slide: 500 mm, turning diameter: 725 mm, spindle speed (max.): 5,000 rpm, spindle bore: 65 mm, travel distance X-axis: 260 mm, travel distance Y-axis: 80 mm, travel distance Z-axis: 610 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 15 m/min, rapid traverse Z-axis: 30 m/min, feed length X-axis: 260 mm, feed length Y-axis: 80 mm, feed length Z-axis: 610 mm, torque: 250 Nm, bar passage: 65 mm, Equipment: documentation/manual, rotational speed infinitely variable, For sale: As-new EMCO MAXXTURN 65-G2 SMY, year of manufacture 2022, equipped with Siemens Sinumerik ONE CNC control featuring ShopTurn! CNC turning center for complete machining of turned/milled parts. Key features include: - Integrated spindle motors, counter-spindle, water-cooled (preloaded roller guides) with Y-axis, operative on main and sub-spindle - Latest SINUMERIK ONE control with ShopTurn conversational programming Main Spindle: - Max. bar capacity: 65 mm - Max. torque: 250 Nm - Speed range: 0–5000 rpm Rodpfxox E Dnco Afcjp Sub-Spindle: - Drive power: 22 kW - Max. torque: 130 Nm - Speed range: 0–7000 rpm Tool Turret: - 12-station VDI 30 radial turret with directional logic for up to 12 driven toolholders - Max. drive power: 6.7 kW - Max. torque: 25 Nm - Max. speed: 5000 rpm Y-Axis: - Travel: ±40 mm Additional Equipment: - Hollow chuck cylinder incl. draw tube - C-axis for both spindles - Sinumerik ONE / OPERATE control - 22" multi-touch display - ShopTurn, 3D simulation, remnant material detection - USB interface - Electrical cabinet climate control - Coolant system incl. pump (3.5 bar) - Chuck flushing (extra pump 3.5 bar) - Parts ejector and flush through sub-spindle - Hydraulic unit - Interface for chip conveyor - Documentation and CE certificate - Control languages: German / English - Electronic handwheel - EMCO TOOL BREAKAGE AND WEAR MONITORING / SINUMERIK ONE - Alternating spindle speed - Sub-spindle as tailstock: This cycle allows use of the sub-spindle with mounted live center for workpiece support, permitting shaft machining even on machines without a conventional tailstock. Max. support force limited to 50% of maximum axis force. - EMCO PROFI-NET ROBOTIC INTERFACE: Connection interface for robot integration via HARTING connector. Signal exchange via Profinet. Safety signals: 2-channel/potential-free. - Digitalization package for Sinumerik: Condition monitoring - SIEMENS ONE INTERFACE for connection to MDE/BDE systems. Standard info includes: • Machine on - AUX ON • Automatic mode • Production mode - program active • Program running and override between 95–105% • Part count pulse (M30) • Programmable pulse (M300) - 3D machine data / MT65-G2: 3D model of the machine included Pneumatically actuated finished parts catcher for gentle unloading of finished components. Parts are transported to a collection box (standard) or onto a conveyor belt (optional). - Max. finished part length: 175 mm - Max. finished part diameter: 65 mm - Max. finished part weight: 4.5 kg INTERFACE SL1200 HT65-DT/TT + MT65-1000: For connecting the EMCO SL1200 bar feeder. Etc. The machine is immediately available!

Condition: used, Year of construction: 2008, Technical details: turning diameter over bed: 600 mm turning dia. over face-slide: 540 mm turning length: 550 mm longitudinal traverse (z-axis): 800 mm facing movement (x-axis): 260 mm control: Fanuc 18i-TB spindle bore: Ø 73 mm bar material dia.: Ø 65 mm revolution per minute: 0 ... 5000 steples U/min max. torque on the spindle: max. 250 Nm rapid traverse in x-y-z axis: X/Z: 30 m/min. / Y: 12 m/min. rapid traverse c-axis: 1000 U/min. tool turret - number of stations: 12 (Sauter) operating pressure: 6,0 bar electrics - voltage/frequency: 3 x 400 / 50-60 V/Hz operating pressure: 6 bar total power requirement: 40 kVA Weight approx.: 5,7 t dimension machine xH: 2,2 x 3,4 x 2,4 m dimension swarf conveyor LxWxH: ca. 2,9 x 0,6 x 0,55 (0,38 to) m dimensions LxWxH: Spänewanne: ca. 1,6 x 1,3 x 0,25 (0,2 to) m transport measurements machine: ca. 3,3 x 1,9 x 2,2 m The machine has a C-axis, E-axis, Y-axis, and W-axis. Powered tools can be used in all positions. Distance between spindle and counter spindle = 1050 mm. Counter spindle: A2-6, travel distance 800 mm, spindle diameter 105 mm, torque 250 Nm. Control cabinet equipped with Rittal cooler With hinged chip conveyor Chip tray Redovvtpxopfx Afcep Compressed air gun The machine has NO lathe chucks on sale as is! *

Year of construction: 2014, operating hours: 100 h, condition: ready for operation (used), General Data Measurements width 1000 mm Measurements depth 4500 mm Measurements height 1800 mm Machine weight 2200 kg Control Unit Brand FANUC Model 31t- Model B Controller Brand FANUC Model 31i B Main Drive Spindle speed range 5000 Number of axis 3 Workpiece Rjdpfxjx D H Sfj Afcsp Workpiece weight 4.5 kg Additional Equipment Automatic bar loading magazine with adjustable part length and bar diameter Remnant extraction system Guide channel made of polyurethane plastic Displacement system for longitudinal movement This 3-axis EMCO MaxxTurn 65 SMY was manufactured in 2014, featuring a robust FANUC 31i B control system and a dual spindle setup with C and Y axes for complex machining. It includes a 12-position tool turret and a bar feeder with a capacity of 65 mm diameter and 3200 mm length. Ideal for precision turning and milling, this machine offers a comprehensive solution for advanced metalworking. Contact us for more information about this machine. Application Types Turning

Condition: good (used), Year of construction: 2011, operating hours: 4,700 h, functionality: fully functional, machine/vehicle number: S6CZ1151, spindle bore: 65 mm, spindle speed (max.): 5,000 rpm, spindle motor power: 29,000 W, bar passage: 65 mm, Equipment: bar feeder, documentation/manual, Year: 2011 Operating hours: 4,700 h (increasing) Turning diameter: 65 mm CNC type: Fanuc 18i-TB Number of turrets: 1 Axes: X, Y, Z, and C Number of turret stations: 12 Number of driven stations: 12 Main spindle and sub-spindle speed: 5,000 rpm Main and sub-spindle motor power: 29 kW Dimensions (L × W × H): 3,302.0 × 2,057.4 × 2,032.0 mm Weight: 5,700 kg Chip conveyor IEMCA MASTER 880r Verso bar feeder (3 m bar + loading magazine) Numerous fixed and driven tool holders included in the sale: _Axial driven tool holder: 3 _Radial driven tool holder: 4 _Swivel driven tool holder 0–90°: 2 _Fixed turning tool holder: 5 _Fixed drilling tool holder: 7 Rjdpfx Aexwp I Aofcep _Cut-off blade holder: 1 2 sets of chucks for jaw passage (main spindle and sub-spindle). The machine is currently in use but can be made available within 4 weeks. The machine is to be collected on site (Saint Pierre en Faucigny). Loading and transport costs are at the buyer’s expense.

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, machine/vehicle number: S6AW11S1, turning diameter over cross slide: 540 mm, turning length: 550 mm, turning diameter: 600 mm, spindle speed (max.): 5,000 rpm, travel distance X-axis: 260 mm, travel distance Z-axis: 800 mm, Machine with C-axis, E-axis, Y-axis, W-axis, and driven tools at all positions TECHNICAL DETAILS Swing diameter over bed: 600 mm Swing diameter over cross slide: 540 mm Turning length: 550 mm Longitudinal travel (Z-axis): 800 mm Cross travel (X-axis): 260 mm Control: Fanuc 18i-TB Spindle bore: 73 mm Bar capacity: 65 mm Spindle speed: 0 - 5,000 rpm Spindle torque: max. 250 Nm Distance from spindle to sub-spindle: 1,050 mm Sub-spindle: A2-6, travel: 800 mm, spindle: 105 mm, torque: 250 Nm Rapid traverse in X/Y/Z axis: X/Z: 30 m/min / Y: 12 m/min Rapid traverse speed C-axis: 1,000 rpm MACHINE DETAILS Operating pressure: 6 bar Total power requirement: 40 kVA Machine weight: approx. 5.7 t Machine dimensions LxWxH: 2.2 x 3.4 x 2.4 m Transport dimensions of machine: approx. 3.3 x 1.9 x 2.2 m Electric configuration - voltage/frequency: 3 x 400 V / 50-60 Hz Chip conveyor dimensions LxWxH: approx. 2.9 x 0.6 x 0.55 m (0.38 t) Chip tray dimensions LxWxH: approx. 1.6 x 1.3 x 0.25 m (0.2 t) EQUIPMENT - Control cabinet equipped with Rittal cooler Rodow T Sq Tepfx Afcop - Hinged belt chip conveyor - Chip tray - Compressed air gun - No chuck included in the sale

Condition: not inspected (used), Year of construction: 2005, functionality: unexamined, machine/vehicle number: S6AT2502, travel distance X-axis: 250 mm, travel distance Y-axis: 40 mm, travel distance Z-axis: 600 mm, rotational speed (max.): 5,000 rpm, number of slots in tool magazine: 12, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel X-axis: 250 mm Travel Y-axis: mm Travel Z-axis: 600 mm Max. spindle speed: 5,000 rpm Feed force Y-axis: 7,000 N Rapid traverse: 12 m/min DRIVE & PERFORMANCE Rjdpowvi Eusfx Afcjp Max. drive power: 6.7 kW Main spindle speed range: 0–5,000 rpm SUB SPINDLE Chuck diameter: max. 200 mm Speed range: 0–7,000 rpm Travel range: max. 580 mm ELECTRICS Operating voltage: 400 V Frequency: 50–60 Hz Rated current: 85 A MACHINE DETAILS Total height: 2,100 mm Total length: 5,000 mm Total width: 2,000 mm Total weight: 8,000 kg Tool holder: 30 mm Control manufacturer: SIEMENS Control model: SINUMERIK 840D Number of tool magazine positions: 12 EQUIPMENT Continuously variable spindle speed Chip conveyor With Y-axis and sub spindle Tool turret with 12 stations, all driven Tool holder: VDI 30 Includes 3-jaw chuck (RÖHM, Ø 250 mm)
