Optimization cross-cut saws Emmegi 2001

Emmegi

Condition: ready for operation (used), For aluminum, cutting length 6000mm Saw blade diameter maximum 450mm Swivel range: 90°- 45° pneumatic With hydropneumatic saw feed Horizontal workpiece clamping Vertical workpiece clamping Djdpfxowvqt Hj Ad Nskl Fixed unit on the left, the right unit is movable Digital positioning control Roller track moving with the right saw unit

Condition: like new (used), Year of construction: 2021, functionality: fully functional, Maximum frame dimensions with automatic unloading – seamless mode (Y-X mm): 3,430 x 2,630 Minimum frame dimensions with automatic unloading – seamless mode (Y-X mm) - Z Frame: 450 x 370 (*) Minimum frame dimensions with automatic unloading – seamless mode (Y-X mm) - L Frame: 420 x 300 (*) Minimum frame dimensions with automatic unloading – seamless mode (Y-X mm) - Sash: 450 x 330 Minimum frame dimensions with longitudinal frame loading and threshold assembly – seamless mode (Y-X mm) - L Frame: 420 x 410 (*) Minimum frame dimensions with longitudinal frame loading and threshold assembly – seamless mode (Y-X mm) - Sash: 450 x 440 (*) Minimum profile height (mm): 35 Maximum profile height (mm): 110 Djdoy N Dnwopfx Ad Nokl Maximum profile width (mm) – Frame: 115 (*) Maximum profile width (mm) – Sash: 130 (*)

Year of construction: 2020, condition: like new (used), functionality: fully functional, Number of controlled axes: 18 Number of milling units: 9 Contour cutting unit: milling for seamless welding Number of drilling units for wall mounting: 2 Three-point drilling unit Single-tool hinge drilling unit Multi-tool hinge drilling unit Screwing unit: 2 Maximum number of screwing units: 4 Dkjdpoy N Dmaofx Ad Nsl Bar positioning speed (m/min): 50 Bar dimensional checking Operating pressure (bar): 6 ÷ 8 Air consumption (Nl/min): 1,300 Installed power (kW): 22.8 Programmable digital adjustment of clamp pressure

Year of construction: 2004, condition: good (used), Underfloor saw Manual operation For saw blade up to Ø 300 mm Mitre cutting left - right up to 45° Manual spray unit for emulsion Robust steel housing and support table made of grey cast iron Dkodpfxoy Nm Hio Ad Njl 400V Mobile on base frame

Condition: used, Year of construction: 1994, total length: 4,700 mm, total width: 1,200 mm, total height: 1,600 mm, Colour: Grey Weight: 672 kg - Year: 1994 - Documentation available: No - CE marking present: Yes - CE certificate present: No - Serial number: 228822 - Main motor power [kW]: 4.5 - Max. cutting length [mm]: 4040 - Max. cutting height [mm]: 150 - Max. saw blade diameter [mm]: 400 - Arbor saw blade diameter [mm]: 32 Dksdpsxbf E Sofx Ad Njl - Voltage [V]: 380 - Power [kW]: 11.2 - Transport dimensions: 4700mm x 1200mm x 1600mm (l x w x h) - Transport weight [kg]: 672kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: excellent (used), Year of construction: 2017, operating hours: 5,120 h, functionality: fully functional, travel distance X-axis: 7,800 mm, travel distance Y-axis: 1,100 mm, travel distance Z-axis: 655 mm, rapid traverse X-axis: 75 m/min, rapid traverse Y-axis: 60 m/min, rapid traverse Z-axis: 40 m/min, torque: 12 Nm, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Axis Travel Ranges X-AXIS (longitudinal): 7,800 mm Y-AXIS (lateral): 1,100 mm Z-AXIS (vertical): 655 mm B-AXIS (vertical-horizontal rotation of the machining head): 0° ÷ 90° C-AXIS (vertical rotation of the machining head): 0° ÷ 360° Traverse Speeds X-AXIS: 75 m/min Y-AXIS: 60 m/min Z-AXIS: 40 m/min B-AXIS: 3,240 °/min C-AXIS: 3,600 °/min Axis Acceleration X-AXIS: 3 m/sec² Y-AXIS: 3 m/sec² Z-AXIS: 2 m/sec² Motor Spindle Max. power in S1: 15 kW Max. speed: 24,000 rpm Max. torque: 12 Nm Tool holder: HSK – 63F Spindle encoder for rigid tapping Water cooling with cooling unit Automatic Tool Changer Standard for 16 tools Maximum permissible tool size in standard magazine: Dkedpfjy Iqr Tox Ad Njl Ø = 80 mm L = 300 mm Maximum permissible saw blade size in standard magazine: Ø = 180 mm L = 150 mm Saw blade magazine for max. saw blade Ø = 500 mm L = 73 mm Processable Profile Sides With tool without angle head (profile top, profile sides, end faces): 5 With saw blade, Ø = 500 mm (profile top, profile sides, end faces): 1 + 2 + 2 Thread Cutting Performance (with tap on aluminium and through hole) Rigid tapping: M12 Larger threads possible with thread milling cutter Profile Feeding 2 reference stops with fixed positions Functions Dynamic pendulum mode Processing of overlengths up to max. double the machine length (X axis) Cutting and separating of the bar (not with 2-bar parallel operation) Automatic operation: milling and cutting (not with 2-bar parallel operation) Workpiece Clamping Standard equipment pneumatic clamping elements: Versions dynamic and static 7,800/6 Max. number of pneumatic clamping elements: 12 6 clamps per zone, movable along the entire machine range Max. profile width, Y, with standard tool clamping: 550 mm Motorized clamping device Absolute measurement of clamp position Safety Devices and Protective Equipment Light curtain system for workspace access protection 3-sided metal safety fence Full machine enclosure by accident and sound protection cabin Internal lighting Protective cover made of laminated safety glass Machine Structure Monoblock machine frame made of electro-welded and normalized steel Chip conveyor with steel belt on the right side of the machine Machining Unit Portal construction Motor spindle controlled on 5 axes, simultaneous interpolation possible Minimal quantity lubrication system (oil) Central lubrication system for guides Operation and Control Control cabinet with cooling unit Pneumatic control cabinet CNC with real-time control MG-Pilot Industrial PC with touch screen Atom 1600 processor 15” graphic LCD-TFT color display Keyboard, mouse 1 Gbyte RAM 4 Gbyte Compact Flash card 4 USB ports RJ45 network card Software Microsoft® Windows® Embedded Bidi-CAM DRILL Power Supply (Voltage/Phases/Hertz) 400V/3PH/50Hz Software for Machining Center Control CAMPLUS for SATELLITE XT, graphical programming software for machining with 3D visualization SHAPE, software for creating any freeform machining contours

Year of construction: 2009, condition: used, functionality: fully functional, machine/vehicle number: C107230, We are offering a well-maintained Emmegi PHANTOMATIC T3 A CNC machining center, ideal for processing aluminum and light alloy profiles. Machine Details: Manufacturer: Emmegi S.p.A. (Italy) Model: PHANTOMATIC T3 A Year: 2009 Serial Number: C107230 Power: 7.5 kW Dkedpoy Idm Rsfx Ad Nel Voltage: 400 V / 3-phase Current: 16 A Frequency: 50 Hz Weight: 1950 kg Description: The PHANTOMATIC T3 A is a versatile CNC machining center designed for milling, drilling, tapping, and cutting operations on aluminum profiles. Known for its reliability and precision, this machine is suitable for window, door, and façade production, as well as general aluminum fabrication.2Emmegi

Condition: excellent (used), Full automatic Dsdpfx Asy H Dmnod Njkl Saw blade diameter 450 mm Cut range diameter 150 mm Cut off lenght 1000 mm Misc. accessories MARCELS MASCHINEN AG

Year of construction: 2008, condition: used, functionality: fully functional, Three-axis interpolated CNC machining center with angular head accessory (enabling 4-axis machining), model Phantomatic T3 A. Specifically designed for comprehensive processing of aluminum, PVC, and light alloy profiles. Renowned for its historical reliability, precision, and sturdiness, this machine is ideally suited for window and door fabrication workshops as well as light metal carpentry applications. Structure and Configuration • Monoblock, fully enclosed frame with extensive perimeter protections • Completely enclosed working area with safety panels • Extended worktable with multiple pneumatic clamps for secure profile holding • Heavy-duty linear guides and kinematics, engineered for continuous operation Dkjdpfx Adjygumdj Nol • Prepared for machining of longer profiles Machining Unit • High-performance vertical spindle suitable for: o Milling o Drilling o Tapping o Slotting and contoured machining • Tool holding stations in view, including: o Milling head attachments o Drilling tools o Saw blade group (as shown in photos) • Manual tool change with current tool set included Controls and Commands • Emmegi operator console featuring: o Integrated monitor o Physical control keypad o Safety selectors o Emergency stop button • Ergonomic operator station with work surface • User-friendly, proven control system—suitable even for less experienced operators Included Equipment (as pictured) • Tool and toolholder set • Accessory case with: o Service wrenches o Clamping devices o Support equipment • Full set of guards and safety covers • Integrated electrical system on board the machine Applications • Aluminum and PVC windows and doors • Lightweight façades • Industrial profiles • Light metal fabrication • Precision machining of extruded profiles Machine Condition • Used machine • Overall condition: good • Source: production workshop • Dismantled / ready for loading (see photos) • Normal wear consistent with age

Year of construction: 2004, condition: used, Useful lenghtt: 4200 mm Dodoy Hifcjpfx Ad Nekl blade diameter 500 mm
