Aluminium machining centre

Emmegi

Year of construction: 2019, condition: excellent (used), functionality: fully functional, CNC machining center with 4 controlled axes and automatic spindle rotation (0-180°). This enables the machine to reach all 3 profile sides of the workpiece without manual repositioning. The machine is equipped with a water-cooled spindle capable of 20,000 rpm. It is suitable for machining profile bars or parts made of aluminum, PVC, light metal alloys, and steel up to 2 mm. Features a manual tool magazine with 9 slots and an automatic tool magazine with 4 slots on the left side of the enclosure. Additionally, it has a second automatic tool magazine with 4 slots on the right side of the enclosure. The profile is positioned by a pneumatically operated stop on the left, and secured by 4 robust clamps that are positioned and monitored automatically. With a second pneumatic stop on the right-hand side, processing of long bars—twice the machining length (overlength machining)—is possible. A movable clamping area also simplifies loading and unloading of workpieces and considerably increases the maximum workable cross-section. Rjdpfsyzb Eksx Ammsu The machine comes with the following special equipment: - CamPlus software - Shape software for creating custom machining operations and for importing machining drawings/contours - An additional tool magazine - A second stop - A safety enclosure (fully enclosed) Setup, commissioning, and operator training can also be provided by us!

Condition: good (used), Year of construction: 2004, functionality: fully functional, cutting length (max.): 100,000 mm, feed length X-axis: 5,050 mm, saw blade diameter: 550 mm, type of input current: three-phase, saw blade speed: 2,800 rpm, input voltage: 380 V, air pressure: 6 bar, overall weight: 1,800 kg, The Twin Electra 550 is a dual miter saw with 3 axes and an automatically adjustable saw head on linear guides. Electronic control of all miter angles via a brushless motor, from 45° (inward) to 22°30’ (outward), with a precision of 240 positions per degree. Connection to window construction software (orgadata / Unilink / Wictop... etc.) is possible. The machine features the following equipment: Rsdpfx Aszav U Nsmmou - Industrial PC - Additional clamping device on the roller conveyor - Automatic profile support - Shortcut function - Overlength cutting - Crosscut - Automatic cutting - Connection to external software possible (Orgadata, Unilink, Wiktop... etc.)

Condition: like new (used), Year of construction: 2019, functionality: fully functional, cutting length (max.): 10,000 mm, feed length X-axis: 5,020 mm, saw blade diameter: 500 mm, total length: 7,100 mm, type of input current: three-phase, saw blade speed: 2,800 rpm, input voltage: 380 V, air pressure: 6 bar, overall weight: 1,600 kg, Classic Magic, extremely little use – like new Protective film still in place in many areas -Double miter saw with program/positioning control Rjdpszav A Tjfx Ammou -Electrically adjustable saw head, V = 20 m/min -Saw blade diameter 500 mm -Saw blade bore 32 mm -Max. cutting length 4,200 mm; automatic cutting up to 10,000 mm possible in oversized cutting mode -Min. cutting length at 90° = 225 mm -Horizontal pivoting of the cutting heads -Miter range from 90° to 22.5° (outward) -Saw heads with automatically controlled full-protection guards -Profile support roller conveyor (right) -Pneumatic material/workpiece clamping The machine comes with the following accessories: -Cleverbridge for data transfer via USB or RJ45 -Label printer for marking profiles -Long roller conveyor -Additional tensioner on the roller conveyor -Horizontal + vertical tensioners -Macro function (ideal for mosquito screen manufacturers) -Oversized cutting -Shortcut -Crosscut -Automatic cutting -Automatically extending profile support

Condition: excellent (used), Year of construction: 2013, functionality: fully functional, cutting length (max.): 100,000 mm, feed length X-axis: 4,000 mm, saw blade diameter: 500 mm, total length: 5,500 mm, type of input current: three-phase, saw blade speed: 2,800 rpm, input voltage: 380 V, overall weight: 1,400 kg, -Double-mitre saw with program-/positioning control -Electrically adjustable saw head, speed V = 20 m/min. -Saw blade diameter 500 mm -Saw blade bore 32 mm -Max. cutting length 4,200 mm; automatic cutting up to 10,000 mm possible in overlength mode -Min. cutting length at 90° = 225 mm -Horizontal swiveling of the saw heads -Mitre angle range from 90° – 22.5° (outward) -Saw heads with automatically controlled full guard -Profile support roller conveyor (right) -Pneumatic material/workpiece clamping Machine includes the following accessories: -Cleverbridge for data transfer via USB or RJ45 Redpfozav Atex Ammeu -Profile height measurement -Long roller conveyor -Horizontal + Vertical clamps -Macro function (ideal for mosquito screen manufacturers) -Overlength cut -Shortcut -Crosscut -Automatic cut

Condition: excellent (used), Year of construction: 2009, functionality: fully functional, cutting length (max.): 10,000 mm, feed length X-axis: 5,000 mm, saw blade diameter: 550 mm, total length: 7,500 mm, saw blade speed: 2,800 rpm, input voltage: 380 V, air pressure: 6 bar, saw blade bore: 32 mm, Emmegi Twin 550 double mitre saw for aluminium and PVC. The Twin Electra 550 is a double mitre saw with 3 axes and an automatically adjustable saw head on linear guides. Electronic control of all mitre angles via a brushless motor from 45° (internal) to 22°30’ (external) with a precision of 240 positions per degree. The machine features the following accessories: -Preparation for a label printer, which enables labelling and assignment to the corresponding order -Retractable material support Rsdpezak Iqsfx Ammsu -Support for long profiles (roller conveyor) -Industrial PC with Windows Embedded -Additional tensioner on the roller conveyor -Pro software package -Overlength cut -Cross cut -Shortcut -Automatic cut -Connection to window construction software (orgadata / Unilink / Wictop...etc) possible Well-suited for precise and industrial processing of profiles in window and door manufacturing.

Year of construction: 2020, condition: excellent (used), Emmegi Classic Magic Electronic double‑head cutting‑off machine Twin‑head saw for aluminium and PVC profiles, with NC‑controlled DC motor driving automatic mobile head movement. All angles pneumatically settable down to 22°30’ external. Key Features Blade: Ø 450 / 500 mm cemented carbide blades Cutting length: 5 m useful cut Angle range: 90° to 22°30’ external (pneumatic tilt) Positioning: Magnetic strip direct measuring system Control: Alphanumeric fluorescent display (2 × 40 chars) Memory: 99 profile corrective values (auto angle calculation) 20 cutting lists (50 rows each) via keyboard 10 cutting lists (100 rows each) via USB (PC) Connectivity: USB port, RJ45 network card; label printer ready Clamping: Horizontal/vertical pneumatic vices with low‑pressure device Safety: Pneumatic full protective hoods for cutting zones Lubrication: Water spray‑mist (oil emulsion or minimal quantity oil) Technical Specifications Motors: 2 × 2.2 kW (400 V); total 5.3 kW Blade speed: 2,800 rpm Operating pressure: 6–8 bar; air consumption 15 NL/cycle Dimensions (5 m version): 9,400 × 1,080 × 1,840 mm (L×D×H) Weight: Approx. 1,500 kg Applications Rodpoy U Tczjfx Ammju High‑precision cutting of aluminium / PVC profiles for windows, doors, curtain walls, and light alloy processing.

Condition: like new (used), Year of construction: 2011, functionality: fully functional, operating hours: 1,600 h, input voltage: 380 V, type of input current: AC, number of slots in tool magazine: 8, spindle motor power: 7,500 W, number of spindles: 1, spindle speed (max.): 18,000 rpm, tool diameter: 180 mm, tool length: 160 mm, tool weight: 2,000 g, Equipment: documentation/manual, Machining center with 4 CNC-controlled axes for processing profile bars or components made of aluminum. Well-maintained profile machining center!!! The machine is in exceptionally good condition and is well equipped! Machining center with 4 CNC axes for machining bars or workpieces made from aluminum, PVC, and light metal alloys in general, as well as steel up to 2 mm. Tool magazine with 8 positions, also accommodates an angular head and a disc cutter to machine the workpiece on 5 sides. Capable of machining bars up to 4 m in one go; processing of lengths up to 8 m is possible with automatic transfer. The 4th CNC axis allows for stepless rotation of the electrospindle from 0° to 180°, enabling machining along the entire profile perimeter. Additionally, the movable worktable facilitates loading and unloading of the workpieces and significantly increases the machinable cross-sectional area. The machine features 3D programming software. Barcode scanner. Accessories: - MG Pilot handheld control panel - 3D Cam/Plus software - Secondary material stop for multiple loading or oversized lengths Redpjww Nyuofx Ammsu - Barcode scanner - Tool changer with 8 positions Installation / commissioning / training can be provided by us upon request!

Year of construction: 2010, condition: excellent (used), functionality: fully functional, The Trimmer 2A is a CNC corner cleaning machine for PVC window frames, equipped with 2 interpolated axes and an automatic cycle. When properly configured, it is able to check the dimensions of the workpiece. It is fitted with a 275 mm diameter blade, which allows, through different machining programs, the cleaning of the external corner on various profiles. The Trimmer 2A also features upper and lower units with blades for cleaning the bead seams, as well as upper and lower units with knives for cleaning internal corners. Cleaning of both internal and external corners can be completed using the upper and lower drilling/milling units for cleaning the corners or the gasket seats. The processing units can be programmed independently via a CNC PC, which controls the profile programming and the machine’s operation, in either manual or automatic mode. Rsdpfx Aow Hk T Ujmmju

Year of construction: 2006, operating hours: 7,000 h, condition: excellent (used), functionality: fully functional, X-axis travel (longitudinal axis) mm 7280 Y-axis travel (transverse axis) mm 525 Z-axis travel (vertical axis) mm 380 A-axis rotation (spindle rotation) mm from 0° to 180° continuous Maximum positioning speed X-axis m/min 80 Maximum positioning speed Y-axis m/min 60 Maximum positioning speed Z-axis m/min 30 Maximum A-axis positioning speed From 0° to 90° in 1" Electrospindle power kW 7 Electrospindle speed rpm variable up to 20,000 Tool holder taper HSK-40E Tool magazine capacity qty. 8 Number of clamps qty. 8 Automatic clamp positioning Installed power kW 16 Residual-current circuit breaker on main line A 0.3 Rsdpfjyi Umpsx Ammsu Weight t 4.8 Operating pressure bar 6 ÷ 8

Year of construction: 2007, condition: excellent (used), functionality: fully functional, Bar loading warehouse Maximum bar length that can be loaded: 7500 mm Bar positioning unit Trolley travel speed: 0-60 m/min Milling unit: 4 electric spindles, 4.5 kW each Tool shank: ISO 25 X-axis travel: 240 mm Rsdey Tqabopfx Ammju Y-axis travel: 350 mm Z-axis travel: 350 mm Cutting unit with pneumatic positioning Blade diameter: 550 mm Cutting angles: 45° – 90° – 135° Automatic discharge
