Injection molding machine

Engel ES7050

Year of construction: 2012, condition: ready for operation (used), Clamping force: 62.5kN, opening stroke: 110mm, ejector force: 6.4kN, ejector stroke: 60mm, platen distance: 119mm-229mm, mold carrier (fixed): 247mm/172mm, mold carrier (movable): 128mm/155mm, screw diameter: 12mm, injection volume: 6.8cm³, injection pressure: 1360bar. Machine dimensions X/Y/Z: approx. 700mm/1200mm/1650mm, weight: approx. 350kg. Documentation available. On-site inspection is possible. Tsdpfewyxa Nox Agcjf

Year of construction: 2014, condition: ready for operation (used), Clamping force: 1600kN, weight: 9t, operational hours counter: 3638h, with Handling Robot ENGEL viper 20. Tjdpfeh Nypfjx Agcsf

Condition: like new (used), Year of construction: 2005, Injection moulding machine ENGEL CL 2550/550 Year of manufacture - 2005 Name of the robot-"ENGEL ERC53/1-F" Closing force [tons]- 550 Tjdpfoq Nybgex Agcsf Maximum distance between plates [mm]-1650 Min. mold height [mm]-310 Max. mold height [mm]-800 Column spacing (mm)-915x860 Size of mounting plates (mm)-1345x1280 Ejector stroke (max) [mm]-250 Auger diameter [mm]-80 Injection weight [g]-1800 Oil quantity [liter]-1000 Injection sequence into the mold -2 Machine with robot ready to work Number of hydraulic cores S/R- 1/1

Condition: used, Year of construction: 1998, clamping force: 50 kN, displacement volume: 200 cm³, injection pressure: 2,587 bar, overall weight: 2,500 kg, load hours: 45,000 h, screw conveyor diameter: 18 mm, terms of delivery: FCA Pegnitz delivery time: on request Tjdpfx Aswi Uzhjgcjf terms of payment: 100% prior to delivery

Condition: good (used), Year of construction: 2004, ENGEL DUO 4550/700 – Technical Specification General Information: Machine designation: DUO 4550/700 Controll : CC100 Clamping Unit: Clamping force: 7000 kN Opening force (with pressure pads): 510 kN Opening stroke: 1350 mm Minimum mould height: 450 mm Maximum mould height: 1350 mm Daylight (platens open): 2700 mm Platen dimensions (H × V): 1460 × 1360 mm Tie bar distance (H × V): 1030 × 930 mm Max. mould weight: 9000 kg Tsdpfx Ajv U Dn Negcsf Ejector stroke: 300 mm Ejector force: 90 kN Ejector strokes (Euromap 6): 8 Dry cycle time (Euromap 6): 7.0 seconds Injection Unit: Screw diameter: 90 mm L/D ratio (barrier): 24 Plasticizing rate: 2488 cm³/s Shot volume: 2860 cm³ Shot weight (theoretical): 2600 g Injection flow rate: 533 cm³/s Injection pressure: 1910 bar Specific injection pressure: 2100 bar Nozzle length: 185 mm Nozzle contact force: 65 kN Heater capacity (zone 7): 62 kW Pump drive power: 75 kW Oil capacity: 1000 liters Weight: Net weight of clamping unit: 22 tons Net weight of injection unit: 10 tons Cores: 2+2 Linear Robot Engel ERC

Condition: good (used), Year of construction: 2004, ENGEL DUO 4550/700 Origin: ENGEL St. Valentin, Austria 🔧 CLAMPING UNIT 1. Clamping force: 7000 kN Tsdewnqk Njpfx Agcjf 2. Opening force (with pressure pads): 510 kN 3. Opening stroke: 1350 mm 4. Minimum daylight: 450 mm 5. Maximum daylight: 1900 mm 6. Minimum mold height: 450 mm 7. Maximum mold height: 950 mm 8. Distance between tie bars (H × V): 1465 × 1360 mm 9. Mold plate size (H × V): 1025 × 990 mm 10. Ejector stroke: 250 mm 11. Ejector force: 63 kN 12. Dry cycle time (Euromap 6): 3.6 s (Z) / 2.4 s (Stroke) 🔩 INJECTION UNIT 1 1. Screw diameter: 90 mm 2. Max. shot volume: 3180 cm³ 3. Max. shot weight (PS): 2880 g 4. Injection pressure: 1470 bar 5. Injection speed: 100 mm/s 6. Plasticizing capacity (3-zone screw): 270 g/s 7. Plasticizing capacity (barrier screw): 308 g/s 8. Injection flow rate: 465 cm³/s 9. Heating zones: 7 10. Installed heating power: 75 kW 11. Hydraulic pump drive: 100 kW Engel Linear Robot ERC53/1-E 22 Hotrunner 4 core pullers PC, ABS material

Condition: excellent (used), Year of construction: 2004, Engel ES 3550/600 HL Technical Data Year of manufacture: 2004 Clamping Unit: Clamping force: 6000 kN Platen size (W x H): 1480 x 1300 mm Minimum mould height: 500 mm Maximum mould height: 1700 mm Opening stroke: 1200 mm Ejector stroke: 250 mm Ejector force: 110 kN Injection Unit: Screw diameter: 80 mm Shot volume: 1960 ccm Specific injection pressure: 1730 bar Screw length: 22 l/d Tedexu Hnbspfx Agcjf Dosing stroke: 390 mm Number of heating zones: 6 Nozzle stroke: 700 mm

Condition: used, Year of construction: 2011, Great opportunity to buy a 2-plate injection moulding machine ENGEL type DUO 4550/650 from 2011. This machine is in very good condition with 51435 operating hours and equipped with robot arm marked ROBOT VIPER 40 - RC200 CONTROL and a volumetric mixing and dosing device for 3 components (manufacturer MICO MV - 1993). PS: robot cage is not included. Full technical specifications in the attached document. Viewing of the machine is possible upon appointment. Please note: The information on this page has been obtained to the best of our ability and belief. This information is provided in good faith, but its accuracy is not guaranteed. Accordingly, this information is not binding and does not constitute a contractual condition. We recommend that you check all essential details during an inspection of the machine. To save unnecessary travel costs for our customers, in most cases we recommend organizing a live video inspection. Control: CC200 Tjdpfjxfayxex Agcjf Clamping force: 6500 kN Opening force: 190 kN Opening stroke: 1650 mm Ejector force: 150kN Ejector stroke: 210 mm Mold height min.: 350 mm Mold height max.: 1000 mm Tie bar diameter: 175 mm Screw diameter: 90 mm Screw stroke: 390 mm Injection pressure: 1910 bar

Condition: good (used), Year of construction: 2002, Engel ES200/45VTHL-PRO-ELAST (2002) Clamping force: 45 t Type: Vertical Drive: Hydraulic Machine for Rubber. Tjdpsvy Anxjfx Agcef

Condition: used, Year of construction: 2003, Injection molding machine Engel HL 7050/600, year of manufacture 2003. The Engel is equipped with a 120 mm screw. Tedpfoxwll Rex Agcjf The machine features a single-cavity shut-off nozzle for the mold, as well as a shut-off device in the injection unit. In 2020, the Engel received new pumps. Operating hours: 70,366 h. The machine is still in production.
