ES 1350/250 HLST

ENGEL

Condition: used, Year of construction: 2018, Serial no. 221921, control system, manufacturer Engel, type CC300, clamping force 1,700 t, 2 injection units, rotary table, installation height min./max. 800 - 1,600 mm, platen distance 3,350 mm, clear width horizontal/vertical 1,850 / 1,415 mm, 16 cascades, 64 hot runner nozzles, core pulls hydr. 4 (DS) / 4 (AS), screw diameter 105 / 50 mm, shot weight 4,050 / 410 g, operating hours 22,401, machine weight 75,400 kg, mold temperature control unit, manufacturer Oni, type Rhytemper FlexControl 32, 4x 8-channel block modules 125 °C, 6-channel block modules 125 °C, visualization unit, parts removal handling system, manufacturer Engel, type Viper 60, 5 axes (X, Y, Z, C, B axis), nozzle spacing 300 mm, year of manufacture 2018, serial no. 221938, part enclosure, discharge conveyor, mobile conveyor, manufacturer Engel, type BGR FB100 KMAT, year of manufacture 2018, serial no. 2144098, length approx. 4,200 mm, width 1,000 mm, external temperature control unit and material dosing system are not included in this item. Damages: hydraulic hoses leaking. +++ Attention: Machine is part of an online auction! +++ Nodpfsy I R Tqox Ackolf

Condition: excellent (used), Year of construction: 2010, operating hours: 20,656 h, functionality: fully functional, machine/vehicle number: 174620, clamping force: 260 kN, The machine comes from toolmaking and was only used for sampling. This is why it has low operating hours and is in very good condition. Please check the documents; the order confirmation is included there. Nledpfsxfgfzsx Ackof

Condition: excellent (used), Year of construction: 2015, ENGEL victory 650/120 tech (25.109 h) (S&P 3793) Manufacture year: 2015 Operating hours: 25,109 Stunden Screw: 35 mm Injection pressure: 2400 bar Stroke volume: 192 cm³ Clamping Force: 120 t Tie bar distance: 740 x 680 mm Mould installation height min.: 300 mm Plate distance max.: 800 mm Nsdpfx Aezv Sy Esckslf Dimensions: 5100 x 1500 x 2350 mm Eeight: 7000 kg Connected load: 22 kW Automatic door, Corepuller 1x, Airvalve, Hotrunner, price when new 122.000,- € etc... Price: on request contact: Mr. Ralf Schulz

Condition: used, Year of construction: 1998, operating hours: 129,241 h, functionality: unexamined, machine/vehicle number: 37064, clamping force: 800 kN, overall weight: 5,900 kg, Year of manufacture: 1998 Serial number: 37064 Weight: 5,900 kg Operating hours: 129,241 hours (as of 02/2025, continued operation until 12/2025) with ERC handling arm with Piovan material separator C10IX, SN: 3AL 9945 / Year of manufacture: 1998 with 2x Piovan temperature control units ETM09 with Engel ERC 23/3-CL, serial number 93996, year of manufacture 1998 Functionality and technical data have not been verified. without any further items/without any further accessories, unless explicitly stated as part of the item. If interested, please contact us via email! Nedpfszv Rdisx Ackelf

Condition: used, Year of construction: 1998, operating hours: 151,023 h, functionality: unexamined, machine/vehicle number: 37065, clamping force: 800 kN, overall weight: 5,900 kg, Year of manufacture: 1998 Serial number: 37065 Weight: 9,000 kg Operating hours: 151,023 hours (as of 02/2025, continued operation until 12/2025) Nlodpfx Aszv N Uajcksf with ERC handling arm with Piovan temperature control unit THW9, serial number: 120000025075, year of manufacture: 2016 with single temperature control unit 1-9-B5/10-TK6, year of manufacture: 2013 with Engel ERC 23/3-CL, serial number: 93997, year of manufacture: 1998 Functionality and technical data have not been verified. without any further items/without any further accessories, unless explicitly stated as part of the item. If interested, please contact us via email!

Condition: used, Year of construction: 1998, operating hours: 140,252 h, functionality: unexamined, machine/vehicle number: 37066, clamping force: 1,250 kN, overall weight: 9,000 kg, Year of manufacture: 1998 Serial number: 37066 Weight: 9,000 kg Operating hours: 140,252 hours (as of 02/2025, continued operation until 12/2025) with Engel ERC 33/1-CL, serial number 93998 with Piovan material separator C10IX, year of manufacture 1998 with Piovan ETW09-P6, year of manufacture 2019 with Single 1-9 B5/10-TK6, year of manufacture 2008 Functionality and technical data have not been verified. without any additional items/without any additional accessories, unless explicitly mentioned as part of the item. Njdpfxjzv N Iys Ackolf If interested, please contact us by email!

Condition: used, Year of construction: 2021, operating hours: 5,048 h, functionality: fully functional, machine/vehicle number: 245467, ENGEL DUO 17060/2000 injection moulding machine with ENGEL Viper 60 robot (robot working area, conveyor belt) – year 2021 For sale: ENGEL DUO 17060/2000 injection moulding machine, year of manufacture 2021, in excellent technical condition. The machine has been regularly serviced and operated in stable production conditions. Technical data and information: - Manufacturer: ENGEL - Model: DUO 17060/2000 - Clamping force: 2000T Nsdsycc N Sjpfx Ackslf - Year of manufacture: 2021 - Operating hours: 5048 h - Type: two-platen injection moulding machine - Condition: very good, fully functional Additional equipment: - ENGEL Viper 60 robot – perfectly matched to the machine, ready for direct integration into a production line, robot working area, conveyor belt. Offer advantages: - Low number of operating hours - Modern, energy-efficient design - High process repeatability and precision - Complete package: injection moulding machine + robot, robot working area, conveyor belt Ready for immediate commissioning

Condition: ready for operation (used), Year of construction: 2013, operating hours: 60,672 h, clamping force: 4,000 kN, screw diameter: 80 mm, total height: 2,360 mm, overall weight: 11,000 kg, product length (max.): 7,420 mm, This Engel DUO 3550/400 pico was manufactured in 2013. It features a clamping force of 4,000 kN, a screw diameter of 80 mm, and a maximum injection volume of 1,960 cm³. The machine dimensions are 7,420 × 2,360 × 2,360 mm, and it weighs 11,000 kg. It is equipped with a robot interface Euromap 67. Contact us for more information about this machine. • Operating hours: 60,672 h • Condition: Excellent • Status: In production • Maximum injection volume: 1,960 cm³ • Minimum mould height: 350 mm • Maximum mould height: 850 mm • Platen opening stroke: 1,050 mm • Platen dimensions (W × L): 1,100 × 1,190 mm • Tie-bar distance: 800 × 800 mm • Motor power: 70 kW • Heater power: 52.95 kW • Number of electrical connection pins: 32 • Injection nozzle radius (tip): R35 • Centering ring diameter: 200 mm • Number of cores: 0 • Number of heating zones: 0 Additional equipment Nlodpox Nr Ryjfx Ackef • Robot equipped: Yes • Robot interface: Euromap 67

Condition: excellent (used), Year of construction: 2017, ENGEL DUO 11050/2300 injection molding machine Year of manufacture: 2004 Operating hours: 70,029 h Type: hydraulic, two-platen, large-format injection molding machine Clamping unit • Clamping force: 23,000 kN / 2300 t • Dimensions of mounting plates: 2900 × 2500 mm • Distance between columns: 2000 × 1600 mm • Minimum mold height: 700 mm • Maximum mold height: 1890 mm • Maximum opening width: 3800 mm Injection unit • Screw diameter: 135 mm • Injection volume: 8870 cm³ • Injection shot weight for PS: 8071 g Nlsdpfxjzvwl Te Ackjf • Maximum injection pressure: 1600 bar • Screw: replaced in 2011 • Screw design: reinforced, adapted for processing special materials Additional equipment • Magnetic plates for mold mounting – functional and ready for use • Number of hydraulic cores: 2 • Number of mold heating zones / hot runner channels: 36 • Number of hydraulic cascades: 10 • Mold tilting option • Robot: not included Magnetic mold clamping system The machine is equipped with functional magnetic plates, enabling quick mold mounting and replacement. The system is fully operational and constitutes a significant piece of additional equipment for the machine, especially with frequent mold changes. Machine weight • Weight of the main unit: approx. 113 t • Weight of the control cabinet and additional elements: approx. 18 t • Total approximate weight: approx. 131 t

Condition: ready for operation (used), Year of construction: 2004, operating hours: 96,194 h, clamping force: 2,000 kN, screw diameter: 40 mm, injection weight: 216 g, This Engel ES650H/200W-200HL-2F was manufactured in 2004. It features a clamping force of 2000 kN and platen dimensions of 920 x 760 mm. The machine includes a two-component system with screw diameters of 40 mm and 25 mm, and a robot system ERC 23/1-E for enhanced automation. Ideal for precision in hydraulic injection moulding. Contact us for more information about this machine. • Configuration: 2K (two-component injection molding machine) • Clamping unit: • Platen dimensions (H x V): 920 x 760 mm • Mold installation height (min): 500 mm • Opening stroke: 750 mm • Max. daylight (platen distance): 1150 mm • Max. mold weight: 3000 kg (1500 kg per side) • Ejector stroke: 150 mm • Ejector force: 80 kN • Core pulls: 3 (ejector side) • Centering ring diameter (ejector side): 200 mm • Injection unit 1 (Primary - 650H): • Screw diameter: 40 mm • Injection pressure: 1946 bar • Shot volume (swept): 251 ccm Nlsdozvu U Sepfx Ackof • Shot weight (PS): 216 g • Screw speed: 290 rpm • L/D ratio: 20 • Nozzle radius: 15 mm • Injection unit 2 (Secondary - 200W): • Screw diameter: 25 mm • Injection pressure: 2089 bar • Shot volume (swept): 69 ccm • Shot weight (PS): 60 g • Screw speed: 480 rpm • L/D ratio: 24 • Interfaces/Control: Printer interface; process control available Additional equipment • Robot system: ERC 23/1-E linear robot • X-axis stroke: 500 mm • Y-axis stroke: 1000 mm • Z-axis stroke: 1600 mm • Hot runner control: 16-zone
