Engel

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, clamping force: 1,800 kN, screw diameter: 55 mm, displacement volume: 510 cm³, mold height (min.): 300 mm, ejector force: 80,000 N, ejector stroke: 180 mm, total length: 6,200 mm, total width: 1,800 mm, total height: 2,200 mm, overall weight: 12,900 kg, Clamping force: 180t Year of manufacture: 2014 Injection unit 1050 Screw diameter: 55 mm Specific injection pressure: 1615 bar Injection volume: 510 ccm Pump motor power: 30 kW Cylinder heating band power: 16.3 kW Tool closing unit 1800 Clamping force: 180 t Tool plate dimensions: 880 x 830 mm Ejector force: 80 kN Ejector stroke: 180 mm Tool height: from 300 mm Opening stroke: 750 mm Maximum platen distance: 1050 mm Weight: 12900 kg Lhodpfx Aiez Eacwoqsl Dimensions (m) L x W x H: 6.2 x 1.8 x 2.2 m Technical data: - Clamping force 1,800 kN (180 t) - Injection unit 1050, screw diameter 55 mm - Max. injection volume 510 cm³ - Injection pressure 1,615 bar, holding pressure up to 2,050 bar - Injection rate 255 cm³/s - Metering stroke 215 mm, max. screw speed 230 rpm - Opening stroke 750 mm, min. mold height 300 mm - Max. platen distance 1,050 mm - Mounting plates 880 x 830 mm - Max. mold weight 2,250 kg - Ejector: stroke 180 mm, force 80 kN - 6 mold cooling circuits at 10 l/min - Dry cycle time 2.0 s at 250 mm - Oil tank 540 l - Machine weight 12.9 t, dimensions 6.2 x 1.8 x 2.2 m

Condition: good (used), Year of construction: 2011, functionality: fully functional, clamping force: 1,000 kN, screw diameter: 35 mm, injection pressure: 1,600 bar, total length: 4,000 mm, total width: 1,300 mm, total height: 1,900 mm, overall weight: 4,400 kg, warehouse no.: 503730 manufacturer: ENGEL type: e-max 310-100 controller: LC 200 A01 year of construction: 2011 Lodpsz Eabtefx Aiqehl clamping force: 1000 kN distance between tie-bars h x v: 460 x 410 mm size of mould plates h x v: 650 x 600 mm min. mould height: 150 mm max. mould height: 450 mm max. open daylight: 800 mm opening stroke: 350 mm screw diameter: 35 mm swept volume: 135 ccm injection pressure: 1600 bar equipment included incl. Spruepicker screen text german core pulling hydraulically 1x Anti vibration mounts mould heating 8x handling type: Angussentnahmegerät manufacture: ENGEL controller: ER-USP 5 year of construction: 2011 measures of machine l x w x h: 4m x 1.3m x 1.9m total weight: 4400KG

Condition: good (used), Year of construction: 2011, operating hours: 78,000 h, functionality: fully functional, clamping force: 2,200 kN, screw diameter: 55 mm, injection pressure: 1,615 bar, total length: 5,700 mm, total width: 1,700 mm, total height: 2,200 mm, overall weight: 12,200 kg, warehouse no.: 503731 manufacturer: ENGEL type: Victory 1050-220 spex controller: CC 200 A02 year of construction: 2011 operation hours: 78000 h clamping force: 2200 kN size of mould plates h x v: 880 x 830 mm min. mould height: 300 mm max. open daylight: 1050 mm opening stroke: 750 mm Lodpfxoz D U Ilj Aiqohl screw diameter: 55 mm injection volume: 510 ccm Spritzdruck: 1615 bar equipment included: screen text german core pulling hydraulically 2x machine incl. Handling Anti vibration mounts mould heating 8x technical data robot-system handling type: Linear manufacture: ENGEL controller: Viper 6 year of construction: 2011 measures of machine l x w x h: 5.7m x 1.7m x 2.2m total weight: 12200KG

Condition: excellent (used), Year of construction: 2015, ENGEL victory 650/120 tech (25.109 h) (S&P 3793) Ledpfx Ajz D Uthoiqjhl Manufacture year: 2015 Operating hours: 25,109 Stunden Screw: 35 mm Injection pressure: 2400 bar Stroke volume: 192 cm³ Clamping Force: 120 t Tie bar distance: 740 x 680 mm Mould installation height min.: 300 mm Plate distance max.: 800 mm Dimensions: 5100 x 1500 x 2350 mm Eeight: 7000 kg Connected load: 22 kW Automatic door, Corepuller 1x, Airvalve, Hotrunner, price when new 122.000,- € etc... Price: on request contact: Mr. Ralf Schulz

Condition: excellent (used), Year of construction: 2004, Engel Victory 1350/220 Tech, clamping force 220 tonnes, year of manufacture 2004. Clamping plate dimensions (W x H): 860x830 mm. Screw diameter: 55 mm, volume: 618 cm³, center distance: 200 mm. Minimum mold height: 250 mm, maximum: 730 mm. Lhedpjxu Rlksfx Aiqjl

Condition: excellent (used), Year of construction: 2001, Engel ES 500/110 HL Clamping force: 110 tonnes Year of manufacture: 2001 Screw diameter: 45 mm Lhjdjxu Rldopfx Aiqel Injection volume: 318 cm³ Enlarged clamping platen Platen dimensions: 730x600 mm

Condition: ready for operation (used), Year of construction: 2004, clamping force: 1,600 kN, screw diameter: 45 mm, Hydraulic injection moulding machine manufactured in 2004. This Engel Victory 750/180 Power features a clamping force of 1,600 kN and a maximum injection volume of 259 cm³. It includes a screw diameter of 45 mm and a maximum injection pressure of 1,600 Bar. If you are looking to get high-quality injection moulding capabilities, consider the Engel Victory 750/180 Power machine we have for sale. Contact us for further details regarding this machine. • Space between columns: 520 x 520 mm • Maximum mold height: 585 mm • Minimum mold height: 275 mm • Maximum injection volume: 259 cm³ • Maximum injection pressure: 1,600 bar • Centering ring: 160 mm Ljdpfx Aiez Dvd Ieqshl • Hot runners in the machine: 8 • Core puller: 1 • Pneumatic valves: 2 • Programmable inputs: 2 Additional equipment • Robot: Wittmann W818 (MY: 2015)

Condition: ready for operation (used), Year of construction: 2013, operating hours: 65,265 h, clamping force: 1,600 kN, screw diameter: 35 mm, overall weight: 8,700 kg, controller manufacturer: ENGEL, controller model: CC200, Hydraulic injection moulding machine manufactured in 2013. This Engel Victory 500/160 tech features a clamping force of 1600 kN and an injection unit of 500. It includes a patented tiebarless clamping system and a highly abrasion-resistant cylinder. If you are looking to get high-quality injection moulding capabilities, consider the Engel Victory 500/160 tech machine we have for sale. Contact us for further details. • Injection unit: 500 • L/D ratio: 20 • Hydraulics: ECODRIVE SHV1 (high-dynamic servo pump) • Electrical connection: 3 x 400 V + N + PE, 50 Hz • Nominal connected load: approx. 102 kW • Clamping system: Patented tiebarless, fully hydraulic ENGEL clamping system • Centering: 160 mm • Ejector: Central ejector • Hydraulic core pulls: 2 on moving platen • Pneumatic mold valve control: 2-fold FESTO, up to 16 bar • Mold heating: 8 control zones • Cylinder/screw execution: M3 abrasion/corrosion-resistant cylinder (up to 350 °C), hardened screw S8 (Ø 35 mm, L/D 20), non-return valve R9b • Open nozzle: Flange thread M28 x 1.5, radius 15 mm, bore 4 mm Lhsdpfx Asz Dgvzsiqsl • Mold temperature control: Flow regulator 0–10 l/min with 12 circuits (2 x 6 circuits) • Hydraulic tank capacity: Main approx. 330 l; suction approx. 130 l • Interfaces: Coloring device interface; RS-485 for temperature control units; Euromap 67 / AN-146 robot interface; interface for Priamus PDDI 8903D1 and 8903E2 • Languages: Czech and German

Condition: ready for operation (used), Year of construction: 2015, operating hours: 29,446 h, clamping force: 2,600 kN, screw diameter: 60 mm, overall weight: 22,300 kg, controller manufacturer: ENGEL, controller model: CC300, product length (max.): 8,780 mm, Electrical injection moulding machine manufactured in 2015. This Engel e-victory 1640/260 features a clamping force of 2600 kN and an injection unit of 1640. It includes a tiebarless clamping system and a servo-electric injection system for high efficiency. If you are looking to get high-quality injection moulding capabilities, consider the Engel e-victory 1640/260 machine we have for sale. Contact us for further details. • Clamping system: Tiebarless ENGEL clamping system • Injection unit: 1640 • Injection system: Servo-electric, high execution • L/D ratio: 24 • Control unit: ENGEL CC300 (21.5" Full HD touchscreen) • Hydraulics: ECODRIVE SHV1 (1 demand-regulated servo pump) • Electrical connection: 3 x 400 V + N + PE, 50 Hz • Nominal connected load: approx. 164 kW • Centering: 160 mm • Hydraulic core pulls: 2 on moving platen, 2 on stationary platen • Vacuum/compressed air circuits: 8 on stationary platen with Venturi nozzles and pressure switches Lhjdpoz Dgrpefx Aiqel • Pneumatic mold valve control: 2-fold FESTO, up to 16 bar • Mold heating: 16 control zones, max heating power 25 kW • Nozzle radius: 15 mm • Nozzle bore: 4 mm • Nozzle contact stroke: approx. 405 mm • Hydraulic tank capacity: Main tank approx. 490 l, suction tank approx. 220 l • Robot interface: Euromap 67 / AN-146 • Languages: Czech and German Additional equipment • MuCell package: • Complete MuCell Basic Package • PM cold-work steel screw Ø 60 mm • Hydraulic needle shut-off nozzle • Melt pressure sensor • Trexel auxiliary equipment: SII VC 30, MIK 1060 SII • Frame for two 50 L gas cylinders • Mold temperature control: 3 ENGEL flomo distributors (24 monitored circuits total) • GEKU automation with conveyor belts

Condition: ready for operation (used), Year of construction: 2016, operating hours: 33,793 h, clamping force: 4,000 kN, screw diameter: 80 mm, overall weight: 31,000 kg, product length (max.): 10,259 mm, Hydraulic injection moulding machine manufactured in 2016. This Engel Victory 3550/400 tech features a clamping force of 4000 kN and an injection unit with a screw diameter of 80 mm. It includes a fully hydraulic tiebarless clamping system and advanced automation with conveyor belts. If you are looking to get high-quality injection moulding capabilities, consider the Engel Victory 3550/400 tech machine we have for sale. Contact us for further details. • Injection unit: 3550 • L/D ratio: 25 • Control unit: ENGEL CC300 (21.5" Full HD touchscreen) • Drive system: ECODRIVE SHV3-HSI, 2 pump systems, accumulator • Electrical connection: 3 x 400 V + N + PE, 50 Hz • Nominal connected load: approx. 282 kW • Clamping system: Tiebarless, fully hydraulic ENGEL clamping system • Centering: 160 mm • Ejector stroke: 250 mm • Hydraulic core pulls: 2 on moving platen, 2 on stationary platen • Vacuum/compressed air circuits: 4 on moving platen with Venturi nozzle and pressure switch • Pneumatic valve: 2/2-way valve R 1/4" on stationary platen • Pneumatic mold valve control: 4-fold FESTO, up to 16 bar • Mold heating: 32 control zones, max heating power 43 kW • Screw drive: Electromotoric, speed-controlled, max 150 rpm, rated power 47 kW, torque 3700 Nm • Nozzle radius: 15 mm • Nozzle bore: 6 mm • Nozzle contact force: approx. 150 kN • Metering stroke: 390 mm Lhodpfx Aioz Dgpbsqel • MuCell equipment: MuCell Advanced Package; cylinder L/D 24/25; MuCell G25 screw Ø 80 mm; gas injector bore; melt pressure sensor; RS-485 interface to SCF gas plant; emergency stop connection • Mold temperature control: 3 ENGEL flomo distributors with 8 zones each (24 monitored circuits total) • Hydraulic tank capacity: Main tank approx. 690 l; suction tank approx. 290 l • Robot interface: Euromap 67 / AN-146 • Languages: Czech and German Additional equipment • GEKU automation with conveyor belts (included)
