Victory 330/90 Tech

ENGEL

Condition: excellent (used), Year of construction: 2012, Engel Victory 1350/300 Tech Ecodrive with Sepro Industrial Robot SDR 22S / Hybrid Machine / Operating Hours: approx. 18,000 hours in automatic operation Year of Construction: 2012 Injection Unit: Screw Diameter: 60 mm Shot Weight: approx. 670 g Injection Pressure: 1835 bar Dosing Volume: 735 ccm Clamping Unit: Clamping Force: 300 t Tie Bar Spacing: 0x0 mm Platen Size: 1200x1000 mm Ejector: hydraulic Clamping Unit: hydraulic Control System: CC 200 - Touchscreen Additional Equipment: Production line with Sepro Industrial Robot SDR 22S Machine in very good technical condition Operating Hours: approx. 18,000 hours in automatic operation Tie-barless, hybrid machine: energy-saving and very quiet Hydraulic core pull x 2 Gbodpozc N D Njfx Aagen Control system with hot runner system x 12 Injection unit is wear-resistant and corrosion-resistant Main motor of the machine - driven by a servomotor with inverter - energy saving Proportional valve on the injection unit – precise injection Option to purchase spacer plates (movable and fixed), water-cooled plates, screw hole diameter M20 Material supply system Motan (dosing and conveying unit) available at an extra charge Robot Sepro Industrial Robot SDR 22S Year of Construction: 2016 4-axis robot: 3 axes are driven by servomotors (electric); Axis C - pneumatic Travel distances in axes: X-1500, Y-2200, Z-800 Vacuum x 2 Gripper x 2 Touch control panel Safety package for robot Robot with adapter, conveyor belt, and protective housing from Engel Purchase of the robot and conveyor belt available at an extra charge Dimensions: Weight: 19900 kg Length/Width/Height: 7.06x2.13x2.30 m All offered machines are started by our service technicians before sale. It is possible to obtain a video of the technical tests of the selected machine or to participate in live technical tests at our company in Łódź. Price: On request

Condition: excellent (used), Year of construction: 2017, Engel Victory 1560/300 Tech Ecodrive with Engel Viper 20 robot / hybrid machine / operating hours: approx. 6,000 h in automatic operation Year of manufacture: 2017 Injection unit: Screw diameter: 60 mm Injection weight: approx. 690 g Injection pressure: 2200 bar Dosing volume: 763 ccm Clamping unit: Clamping force: 300 t Tie bar spacing: 0x0 mm Size of clamping plates: 1100x1000 mm Ejector: hydraulic Clamping unit: hydraulic Control system: CC 300 - touchscreen Additional equipment: Production line with Engel Viper 20 robot Machine in very good technical condition Operating hours: approx. 6,000 h in automatic operation Tie-bar-less, hybrid machine: energy-saving and very quiet Air valve x 3 Hydraulic core pull x 2 on the side of the moving clamping plate Control system with hot runner system x 9 Injection unit is wear-resistant and resistant to corrosion Main motor of the machine - servomotor driven by an inverter - energy saving Proportional valve on the injection unit – precise injection It is possible to purchase spacer plates (movable and fixed), water-cooled plates, screw hole diameter M20 Material supply system Motan (dosing and conveying unit) available at an extra charge Robot Engel Viper 20 Year of manufacture: 2017 4-axis robot: 3 axes are driven by servomotors (electric): X, Y (telescopic), Z; axis C – pneumatic Touchscreen control panel Gedpfxezc N Dvo Aagjbn Safety package for robot Robot with adapter, conveyor belt and protective housing of the brand Engel Purchase of the robot and conveyor belt available at an extra charge Dimensions: Weight: 20600 kg Length/Width/Height: 7.06x2.37x2.30 m All offered machines are started by our service technicians before the sale. It is possible to obtain a video of the technical tests of the selected machine or to participate in technical live tests at our company in Łódź. Price: On request

Condition: excellent (used), Year of construction: 2016, Engel e-Motion 740/280 T WP with TecnoMatic robot / Electric machine / Operating hours: approx. 9000 hours in automatic operation Year of manufacture: 2016 Injection unit: Screw diameter: 50 mm Shot weight: approx. 360 g Injection pressure: 1900 bar Dosing volume: 393 ccm Clamping unit: Gbjdszc N Dispfx Aagsn Clamping force: 280 t Tie bar spacing: 780x780 mm Size of mounting plates: 1100x1100 mm Ejector: electric Clamping unit: toggle Control system: CC 300 - Touchscreen Additional equipment: Production line with TecnoMatic robot Machine in very good technical condition Electric machine: energy-saving and very quiet Operating hours: approx. 9000 in automatic operation Euromap 67 Robot interface Air valve x 5 Hydraulic core pull x 4 Control system with hot runner nozzles x 64 Injection unit is wear-resistant and corrosion-resistant Main motor of the machine - servo motor driven by inverter - energy saving Central lubrication Parallel movements Automatic tool height adjustment TecnoMatic Medium robot Year of manufacture: 2020 6-axis robot: 6 axes are driven by servo motors (electric): X, Y-telescopic, Z, A, B, C Touch control panel Safety package for robots Robot with adapter, conveyor belt and protective housing Purchase of the robot and conveyor belt for an additional fee Dimensions: Weight: 17200 kg Length/Width/Height: 7.37x2.10x2.30 m All offered machines are started by our service technicians before sale. It is possible to obtain a video of the technical tests of the selected machine or to participate in technical live tests at our company in Łódź. Price: On request

Condition: excellent (used), Year of construction: 2001, Engel ES 1350/275 HL with Engel ERC 53/1-E Robot / Machine in very good technical condition Year of manufacture: 2001 Injection unit: Screw diameter: 60 mm Shot weight: 547 g Injection pressure: 1834 bar Metering volume: 618 cm³ Clamping unit: Clamping force: 275 t Gbjdpfx Aszc N A Ssagon Tie bar distance: 0x0 mm Platen size: 1050x900 mm Ejector: hydraulic Clamping unit: hydraulic Control system: CC 100 Additional equipment: Machine in very good technical condition Operating hours: 35,819 h in automatic mode Tie-barless machine Hydraulic core pull x 3 Hot runner control x 16 Injection unit hardened - bimetallic Machine has been regularly serviced by authorized Engel service Dimensions: Weight: 20,000 kg Length/Width/Height: 7.10x2.15x2.30 m All offered machines are started and tested by our service technicians before sale. You can request a video of the technical tests of the selected machine or participate in live technical tests at our facility in Łódź. Price: On request

Condition: excellent (used), Year of construction: 2011, Engel Victory 1350/260 Tech Ecodrive with Engel Viper 20 Robot / Hybrid Machine Godszc N Aropfx Aagjbn Year of Manufacture: 2011 Injection Unit: Screw diameter: 55 mm Shot weight: approx. 590 g Injection pressure: 2183 bar Dosage volume: 618 ccm Clamping Unit: Clamping force: 260 t Tie-bar spacing: 0x0 mm Platen size: 1100x1000 mm Ejector: hydraulic Clamping unit: hydraulic Control system: CC 200 - Touchscreen Additional Equipment: Production line with Engel Viper 20 Robot Machine in very good technical condition Tie-barless hybrid machine: energy-saving and very quiet 8x air valve on the fixed platen side 2x hydraulic core pull on the fixed platen side 2x hydraulic core pull on the moving platen side 18 hot runner control zones Injection unit is wear-resistant and corrosion-proof Main drive motor – servo motor with inverter – energy-saving Proportional valve on injection unit – precise injection Engel Viper 20 Robot Year of Manufacture: 2011 6-axis robot: 4 axes (X, Y, Z, B - rotation) driven electrically by servo motors; axes A and C – pneumatic Robot safety package Robot with adapter, conveyor belt, and Engel brand safety enclosure Purchase of robot and conveyor belt available at extra cost Dimensions: Weight: 19,400 kg Length/Width/Height: 7.06x2.03x2.30 m All offered machines are started and tested by our service technicians before sale. A video of the technical tests of the selected machine can be provided, or you can attend live technical tests at our facility in Łódź. Price: On request

Condition: excellent (used), Year of construction: 2021, Engel Victory 2460/260 Tech Ecodrive with Engel Viper 20 Robot / Hybrid Injection Molding Machine / Operating hours: approx. 10,000 h in automatic mode Year of manufacture: 2021 Injection unit: Screw diameter: 70 mm Shot weight: approx. 1,100 g Injection pressure: 2,000 bar Dosing volume: 1,212 cc Clamping unit: Clamping force: 260 t Tie bar distance: 0x0 mm Platen size: 1,100 x 1,000 mm Ejector: hydraulic Clamping unit: hydraulic Control system: CC 300 – Touchscreen Additional equipment: Production line with Engel Viper 20 robot Machine in perfect technical condition Tie-barless hybrid machine: energy-efficient and very quiet Operating hours: approx. 10,000 in automatic mode Gbodpfx Aaozc N Alegsn Air valves x 5 Hydraulic core pull x 2 on the moving platen side Hydraulic core pull x 2 on the fixed platen side Injection unit is wear-resistant and corrosion-resistant Main drive of the machine: servo motor with inverter – energy saving Proportional valve on the injection unit – precise injection Kistler sensor – mold pressure control Engel Viper 20 Robot Year of manufacture: 2021 6-axis robot: all 6 axes driven by electric servo motors: X, Y, Z, B, C Touch control panel Robot safety package Robot with adapter, conveyor belt, and safety enclosure Purchase of robot and conveyor belt available at extra cost Dimensions: Weight: 21,000 kg Length/Width/Height: 7.35 x 2.06 x 2.37 m All offered machines are started up by our service technicians before sale. It is possible to receive a video of the technical tests of the selected machine or to participate in live technical tests at our facility in Łódź. Price: On request

Condition: excellent (used), Year of construction: 2009, Engel e-max 440/180 / All-electric injection moulding machine Year of manufacture: 2009 Injection unit: Screw diameter: 40 mm Shot weight: approx. 199 g Injection pressure: 1950 bar Shot volume: 220 cm³ Clamping unit: Clamping force: 180 t Tie bar distance: 520 x 520 mm Platen size: 760 x 775 mm Ejector: electric Clamping system: toggle lever Control system: CC 200 - touchscreen Additional equipment: Machine in very good technical condition, operated in a clean production environment All-electric machine: high-speed, energy-saving, and very quiet Euromap 67 interface Robot interface 3 x air valves Gbsdpfx Aozc Nz Ijagen Hardened injection unit - bimetallic Parallel movements Central lubrication Automatic mould height adjustment Kistler sensor - mould pressure control Original mould crane Dimensions: Weight: 7,200 kg Length/Width/Height: 5.87 x 1.42 x 2.00 m All machines offered are started and tested by our service technicians prior to sale. It is possible to receive a video of the technical tests carried out on the selected machine, or to participate in live technical demonstrations at our company in Łódź. Price: On request

Condition: excellent (used), Year of construction: 2013, Engel Victory 330H/80V/160 combi Ecodrive / Production line with the Sepro SR S5-25 S3 Trans robot / Operating hours: approx. 18,000 h in automatic mode Year of construction: 2013 Injection unit: Screw diameter: 30 mm Injection weight: approx. 100 g Injection pressure: 2385 bar Dosing volume: 113 ccm Clamping unit: Clamping force: 160 t Distance between tie bars: 0x0 mm Size of the clamping plates: 750x750 mm Ejector: hydraulic Clamping unit: hydraulic Control: CC 200 - touch screen Additional equipment: 2K injection molding machine with rotary table and robot Tie-bar-less machine, hybrid: energy-saving, high-speed and very quiet Very good technical condition Operating hours: approx. 18,000 h in automatic mode Total number of operating hours: 24,312 h Gbodpjzc Nywefx Aagen Euromap 67 Robot interface Air valve x 5 Hydraulic core pull x 5 Control unit with hot runners x 16 Reinforced injection units - bimetal Main motors - 2 x servo motor controlled with inverter Proportional valves on injection units - precise spraying Screw diameter in the vertical injection unit: ⌀22 mm - approx. 28 g/hp It is possible to purchase a turntable Robot Sepro SR S5-25 S3 Trans Year of construction: 2013 3-axis robot: 3 axes are driven by servomotors (electric): X, Y, Z (telescopic) Travel distances in axes approx.: X-2000, Y-1000, Z-1500 Automatic axis lubrication Touch control panel The safety package for robots Robot with adapter and protective housing Purchase of the robot for an additional charge Dimensions Weight: 8700 kg Length/width/height: 5.35x1.76x3.42 m All offered machines are started by our service technicians before sale. It is possible to obtain a video of technical tests of the selected machine or participate in live technical tests at our company in Łódź. Price: On request

Condition: excellent (used), Year of construction: 2017, Engel Victory 330H/200V/140 combi Ecodrive / Production line with the Sepro Multi Inject 20 robot / Operating hours: approx. 18,000 h in automatic mode Year of construction: 2017 Injection unit: Screw diameter: 30 mm Injection weight: approx. 100 g Injection pressure: 2400 bar Dosing volume: 113 ccm Clamping unit: Clamping force: 140 t Distance between tie bars: 0x0 mm Size of the clamping platens: 750x750 mm Ejector: hydraulic Clamping unit: hydraulic Control: CC 300 - touch screen Gjdozc Nyqopfx Aagjbn Additional equipment: 2K injection molding machine with rotary table and robot Tie-bar-less machine, hybrid: energy-saving, high-speed and very quiet Very good technical condition Operating hours: approx. 18,000 in automatic mode Total number of operating hours: 25,369 h Euromap 67 Robot interface Air valve x 8 Hydraulic core pull x 5 Control unit with hot runners x 16 Reinforced injection units - bimetal Main motors - 2 x servo motor controlled with inverter Proportional valves on injection units - precise spraying Parallel movements Built-in pressure quality control system from Sensor Kistler - mold pressure measurement Screw diameter in the vertical injection unit: ⌀25 mm - approx. 58 g/hp It is possible to purchase the original Foboha turntable for an additional charge Turntable diameter: 740 mm Sepro Multi Inject 20 robot Year of construction: 2017 3-axis robot: 3 axes are driven by servo motors (electric): X, Y, Z (telescopic) Travel distances in axes approx.: X-4000, Y-1200, Z-1500 Automatic axis lubrication Touch control panel The safety package for robots Robot with adapter and protective housing Purchase of the robot for an additional charge Dimensions Weight: 10300 kg Length/width/height: 5.56x1.76x3.46 m All offered machines are started by our service technicians before sale. It is possible to obtain a video of the technical tests of the selected machine or participate in live technical tests at our company in Łódź. Price: On request

Condition: excellent (used), Year of construction: 2004, Engel Victory 330/110 Tech / production line with robot Engel ER-HLI 41 and conveyor belt / machine in very good technical condition Year of manufacture: 2004 Injection unit: Screw diameter: 40 mm injection weight: 190 g Injection pressure: 1670 bar Metering volume: 201 ccm Clamping unit: clamping force: 110 t tie bar distance: 0x0 mm Gbedpfx Aajzc Nykjgsn size of clamping platens: 790x680 mm ejector: hydraulic clamping unit: hydraulic Control system: CC 100 Additional equipment: Production line with integrated robot Engel ER-HLI 41 and conveyor belt. Tie-bar-less machine Hydraulic core puller x 1 Injection unit hardened - bimetal Machine serviced by authorized service Engel Machine with original protective housing to the robot and conveyor belt Dimensions: Weight: 7400 kg Length/width/height: 5.10x1.50x2.10 m Drive: Pumps/motor: 18.5 kW Heating power: 9,2 kW Total power: 27,7 kW All offered machines are started by our service technicians before sale. It is possible to get a video of technical tests of the selected machine or participate in live technical tests in our company in Łódź. Price: Upon request
