Angel ES 500/125 HL

ENGEL

Condition: excellent (used), Year of construction: 2007, clamping force: 2,000 kN, screw diameter: 55 mm, displacement volume: 618 cm³, injection pressure: 2,183 bar, injection weight: 562 g, mold height (min.): 400 mm, ejector stroke: 180 mm, Engel VC 1350/200 Tech Clamping force: 200 tons Year of manufacture: 2007 Weight: 14,200 kg Dimensions (L x W x H): 6.3 x 1.9 x 2.3 m Injection unit: .../1350 Screw diameter: 55 mm Pgjdpey Ui Nqefx Ap Ejn Injection volume: 618 cm³ Shot weight (for PS): 562 g Specific injection pressure: 2,183 bar Mould clamping system: 200/... Mould platen dimensions: 860 x 570 mm Mould installation height: 400 mm Opening stroke: 750 mm Maximum platen distance: 1,150 mm Ejector stroke: 180 mm Ejector force: 80 kN Equipment: - 2 × hydraulic core on moving platen - Pneumatic valve - 8 hot runner zones - 8-section rotameter

Condition: good (used), Manufacturer: Engel / Bosch Operating pressure: 280 bar Capacity: 65 l/min Podpfxeiy Ddfe Ap Ejgn Overall dimensions: 1800 x 800 x 700 mm Voltage: 380 V Electric power: 15 kW

Condition: repair required (used), Injection moulding machine, Engel ES 330/85, Used machine As shown in the pictures, its working condition is uncertain. Pjdjukn S Hspfx Ap Eegn Overall dimensions :3100 x 1950 x 2600 mm Weight: 5500 kg Manufacturer: Engel Type: ES 330/85 Year of manufacture: 1997 Electrical data: 380V, 60 A, Contoller cards: Keba PS 244; Keba DO 321; Keba DO 321; Keba DO 321; Keba DI 325; Keba DI 325; Keba DI 325; Keba TT 081; Keba AR 181; Keba PD 242; Keba CU 211

Condition: good (used), Year of construction: 2009, Clamping force: 90 t Screw diameter 1 : 30 mm Screw diameter 2 : 25 mm Type: Multicomponent Pjdszg Ib Tspfx Ap Ejgn Drive: Hydraulic

Condition: ready for operation (used), Year of construction: 2000, clamping force: 3,000 kN, total height: 2,460 mm, overall weight: 22,500 kg, product length (max.): 7,290 mm, Hydraulic injection moulding machine manufactured in 2000. This Engel ES1800/300HL features a clamping force of 3000 kN and a maximum opening stroke of 850 mm. It offers multiple screw diameter options of 60 mm, 70 mm, and 80 mm, along with a mould installation height of 350 mm. If you are looking to get high-quality injection moulding capabilities, consider the Engel ES1800/300HL machine we have for sale. Contact us for further details. • Screw diameter options: 60 / 70 / 80 mm • Injection unit: ES 1800 • Stroke volume (max): 763 / 1039 / 1357 cm³ • Injection pressure (specific): 1960 / 1441 / 1105 bar • Injection pressure (specific, increased): 2360 / 1735 / 1330 bar • Opening stroke: 850 mm • Mould installation height (min): 350 mm • Max. daylight (distance between platens): 1200 mm • Mould fixing platen size (H x V): 1050 x 650 mm (standard) / 1050 x 900 mm (enlarged option) • Ejector stroke: 200 mm • Ejector force: 83 kN • Dry cycle / stroke (Euromap 6): 2.2 s / 300 mm • Oil capacity: 810 l Psdpfszg Enwox Ap Ejgn • Pump power: 37 kW (standard) / 45 kW (N-Ausführung) • Heating power: 25.3 / 29.4 / 33.5 kW (standard) or 33.4 kW (N-Ausführung) • Number of heating zones: 5 (including nozzle) • Hopper capacity: 120 l • Control system: Microcomputer EC 100 regulated (standard) / CC 100 regulated (optional) • Standard equipment/features: 10-stage injection speed, 10-stage holding pressure profile, 5-stage screw speed, 5-stage back pressure profile, bimetallic cylinder, ceramic heating bands, energy-saving variable displacement pump hydraulics

Condition: good (used), Year of construction: 2007, Ref. no.: 18597 Manufacturer: ENGEL Type: insert 200 H/70 CC 200 Year of construction: 2007 Clamping unit Clamping force: 70 ton Opening stroke: 305 mm Injection unit Pgodpfx Apsy Au I Us Esn Screw diameter: 25 mm Injection volume: 69 cm³ Shot weight: 62 g Injection pressure: 2381 bar Measurements and weight Dimensions: 4,0 x 1,8 x 2,5 m Machine weight: 5600 kg Further information: The ENGEL INSERT 200H/70 is a professional vertical injection moulding machine specially designed for insert molding and precision technical plastic applications. Built with ENGEL’s compact and robust machine concept, this model has been widely used for many years in the automotive, electronics, cable technology and technical plastics industries. One of the major advantages of this machine is its rotary table system. This design allows the operator to load inserts on one side while production continues on the other side. As a result, cycle times are reduced and production becomes safer and more efficient. This system is especially advantageous for manufacturing metal insert parts, connectors, cable components and precision technical products. Compared to conventional horizontal injection moulding machines, the ENGEL INSERT series offers a much more ergonomic and controlled process for insert placement. Thanks to the vertical clamping system, inserts remain stable inside the mould, enabling highly precise production results. The ENGEL control system used on this machine is known for stable process management and reliable operation. Its user-friendly interface allows easy handling in daily production. The machine has approximately 51,944 operating hours and was reportedly in running condition until removed from production. The overall condition of the machine is clean and well maintained. The electrical cabinet is tidy and the mechanical components appear to be in good condition. The ENGEL INSERT series is particularly suitable for: * insert molding applications * metal/plastic combination parts * electronic component production * connector and cable technology * technical plastic parts * precision industrial products With its robust mechanical construction, compact design and professional production capabilities, the ENGEL INSERT 200H/70 represents a reliable and long-lasting production solution for technical plastic manufacturers.

Condition: good (used), Year of construction: 2013, Ref. no.: 18494 Manufacturer: ENGEL Type: Victory 50-200 Spex Year of construction: 2013 Pgedpfx Apsxzq Ske Eon Clamping unit Clamping force: 50 ton Opening stroke: 400 mm Mould height min.: 200 mm Opening width: 600 mm Platen size (h x v): 500 X 450 mm Injection unit Screw diameter: 25 mm Injection volume: 69 cm³ Shot weight: 62 g Injection pressure: 2400 bar Measurements and weight Dimensions: 3,4 x 1,3 x 1,8 m Machine weight: 2900 kg Additional information & extras Core pull: 1 pcs Further information: ENGEL ENGEL Victory 50 SPEX (2013) – Tie-Barless Injection Moulding Machine For sale is a high-quality ENGEL Victory 50 SPEX injection moulding machine from 2013. Featuring tie-barless technology and a special SPEX configuration, this machine is ideal for precise and flexible production. Key Advantages: Tie-barless design → maximum mould accessibility SPEX special configuration → optimized for specific applications High precision & repeatability Energy-efficient operation Compact design → space-saving Automation-ready (robot interface possible) Applications: Automotive industry Electronics Medical parts Technical plastic components 👉 Machine in good working condition. Inspection possible upon request.

Condition: good (used), Year of construction: 2004, Ref. no.: 18255 Manufacturer: ENGEL Psdpfxowm Iz Ne Ap Eogn Type: Victory 750 / 180 tech Year of construction: 2004 Clamping unit Clamping force: 180 ton Opening stroke: 750 mm Distance between tie bars: 960 x830 mm Mould height min.: 500 mm Opening width: 1250 mm Injection unit Screw diameter: 45 mm Injection volume: 318 cm³ Shot weight: 302 g Injection pressure: 1769/2360 bar Measurements and weight Machine weight: 13500 kg Robot Producer: Wittman Type: W743 Year: 2009 Further information: ENGEL Victory 750/180 Tech – Power, Flexibility and Reliability with Tie-Bar-Less Technology The ENGEL Victory series was specially developed for technical plastic processing and is known as a professional injection moulding machine series offering high energy efficiency and maximum mould flexibility. Unlike conventional tie-bar machines, this series provides a much more flexible working area thanks to its tie-bar-less clamping system. ⸻ 🔍 Advantages of the ENGEL Victory Series ✔ Tie-Bar-Less Design The biggest advantage of the world-renowned ENGEL Victory series is its tie-bar-less construction. This system offers several important advantages: • Larger moulds can be installed easily • Easier access for complex mould geometries • Reduced mould changeover times • Easier robot integration • More efficient use of production space This technology is especially advantageous for automotive, technical plastic parts, packaging and industrial applications. ⸻ ✔ Wittmann Robot Integration The machine has been operated together with a Wittmann robot. Robot specifications: • Wittmann W743-0424 • Year of manufacture: 2009 • Payload capacity: 25 kg • X-axis: 1200 mm • Y-axis: 1600 mm • Z-axis: 4000 mm This configuration provides major advantages for automated production processes. ⸻ 🔍 Machine Operating System The ENGEL Victory Tech series operates with a servo-hydraulic system. ✔ Hydraulic System: • Clamping unit • Injection movements • Ejector system • Mould movements are driven by a high-performance hydraulic system. ✔ Thanks to the servo-controlled hydraulic system: • Only the required amount of energy is consumed • Power consumption is significantly reduced • Quieter operation is achieved • Production stability is improved Unlike older conventional hydraulic machines, the machine does not run continuously at full power. The servo pump system operates only when needed, providing the following advantages: • Lower energy costs • Reduced heat generation • Longer component lifetime • More stable processing conditions

Condition: good (used), Year of construction: 2001, Ref. no.: 18092 Manufacturer: ENGEL Type: ES 1350H 200W / 300HL-2F Year of construction: 2001 Clamping unit Clamping force: 300 ton Opening stroke: 855 mm Platen size (h x v): 1050 x 650 mm Injection unit Screw diameter: 60 +35 mm Injection volume: 735 +135 cm³ Shot weight: 662 + 122 g Injection pressure: 1834 +1620 bar Measurements and weight Dimensions: 7,75 x 2,35 x 2,6 m Machine weight: 24780 kg Further information: ENGEL ES 1350H200W/300HL-2F — 2K Injection Moulding Machine This machine from the prestigious Austrian manufacturer ENGEL, built in 2001, features a clamping force of 300 tonnes and a true 2K L-configuration in horizontal layout. Motor and Hydraulic System The machine is equipped with a powerful electric motor coupled to a high-pressure hydraulic pump group. The electric motor continuously drives the hydraulic pump, providing pressurised oil flow throughout the entire system. This pressurised oil feeds the clamping cylinder, the injection pistons of both units, and the ejector system. The thick red hydraulic hoses visible behind Unit B carry this high-pressure oil flow — both units are supplied via independent hydraulic circuits, allowing Unit A and Unit B to operate simultaneously without influencing each other. Operating Principle The two independent injection units are positioned at 90° to each other — in an L-shape. The mould is locked with 300 tonnes of clamping force. Unit A injects the primary material into the mould at 1834 bar. Immediately afterwards, Unit B injects the second material or colour from a 90° angle into the same mould at 1620 bar. The two materials bond at a molecular level inside the mould, cooling is completed and the ejectors push out the finished 2K part as a single piece. No gluing, screwing or assembly is required — two materials emerge as one single part in a single cycle. Applications Pgsdpfx Apewm Iy Ee Ejn Automotive interior and exterior trim parts, large technical plastic components, parts combining a rigid body with a soft grip surface, two-colour large-surface parts.

Condition: like new (used), Year of construction: 2015, clamping force: 1,200 kN, Engel E-Victory 170H/50V/120 combi (2015) 2k machine CC300 controll Clamping force: 1200 kN Mould min-max: 300mm Total tool max height: 800 mm plate size : 740 x 680mm Opening stroke: 505 mm Ejector stroke: 130 mm Ejector force: 39.8 kN Pump drive power: 15 kW Injection unit 1 Screw diameter: 25 mm Max. swept volume: 59 cm³ Screw speed max: 400 r/min Pgjdpfxexyi Rvo Ap Ejn Screw speed max (current): 400 r/min Injection rate: 109 cm³/s Injection rate (increased): 109 cm³/s Specific injection pressure: 2400 bar Specific injection pressure (increased): 2400 bar Injection unit 2 Screw diameter: 20 mm Max. swept volume: 25 cm³ Screw speed max: 450 r/min Injection rate: 104 cm³/s Specific injection pressure: 2400 bar Machine with conveyor. Working hours : 41.427 h Possible to buy robot Engel VIPER 20 Linear (Z=3320mm)
