Hydr. pressbrake

ERMAK POWER BEND PRO 26.100

Condition: good (used), Year of construction: 2008, Used 6-meter CNC press brake by Amada Type: HFE 400 6 L Capacity: 6100 x 400 tons Stroke: 350 mm Y1, Y2, X1, X2, R1, R2, Z1, and Z2 CNC controlled 9204 operating hours Weight: 36 tons Ksdpfx Aoy T Hltjkwsdt Transport in 2 parts (main frame + separate lower table) Self-adjusting crowning system in the lower table 450 mm mounted on the floor foundation Dismantling and loading included

Condition: excellent (used), Year of construction: 2005, functionality: fully functional, controller manufacturer: Cybelec, controller model: Cybtouch 12, working width: 6,000 mm, bending force (max.): 300 t, control type: CNC control, number of axes: 4, Equipment: CE marking, emergency stop, european tool clamping system, safety light barrier, Used 6metre x 300ton Adira Cnc Press Brake - Hydraulic Pressbrake 300 Ton 6000mm bending Length Back gauge: X and Z Axis Upgraded touch screen control Cyblec CybTouch 12 Control System Year of Manufacture - 2005 Good service history including rebuilt ram cylinders, rebuilt crowning and upgraded control system Kdsdpowu Ua Usfx Akwjt Euro tool clamping

Condition: new, machine/vehicle number: 0770, empty load weight: 2,800 kg, maximum load weight: 20,000 kg, overall weight: 22,800 kg, axle configuration: 2 axles, loading space length: 6,000 mm, loading space width: 2,000 mm, loading space height: 640 mm, tire size: 450x300x305, tire condition: 100 %, Year of construction: 2026, operation weight: 22,800 kg, Transportwagen TPW 20 AL-AS Typ: TPW 20 AL-AS Nutzlast: 20.000 kg Baujahr: 2024: Länge Ladefläche: 6000 mm Breite: 2000 mm Höhe: 620 mm Kdodehbh Rtjpfx Akwjt Transportboden: 40 mm Fichte Lenkung: Allradlenkung-Achsschenkel-Niederflur Bereifung: 450x300 Zugdeichsel: 1.600 mm Lackierung: RAL 2000 #Schwerlasttransport #Innerbetriebliche Transportsysteme #Schwerlastanhänger 6-100 Tonnen #Schwerlastanhänger ab 3 Tonnen bis 100 Tonnen #Schwerlast Transport Plattformwagen #Plattform Schwerlastanhänger #Allradlenkung #Transportwagen #Niederflur

Condition: new, functionality: fully functional, machine/vehicle number: 0640, empty load weight: 2,200 kg, maximum load weight: 20,000 kg, overall weight: 22,200 kg, axle configuration: 2 axles, first registration: 01/2025, next inspection (TÜV): 01/2026, loading space length: 5,000 mm, loading space width: 2,200 mm, tire size: 23x10-12 SE, color: orange, Year of construction: 2025, operation weight: 22,200 kg, TPW 206 AL - AS SE payload 16000 kg on the loading area at 6 km/h. Dimensions: 5000 mm long, 2200 mm wide and 680 mm high. Transport floor made of spruce wood 40 mm tongue and groove Kdsdorcf H Uspfx Akwst Super elastic tires with profile 23x10-12 with steel rims, conical bearings on both sides, sealed with Nilos ring Drawbar with fall protection and height adjustment, towing eye 40 mm. Steering: all-wheel steering knuckle. Safety: weld-on supports, five per long side (see load securing and double-acting wheel chock mounted on the frame) Paint: yellow orange RAL 2000

Condition: new, pressure 400 t chamfer lenght 4100 mm distance between columns 3550 mm column arm 510 mm ram stroke speed 110 mm/sec work speed 8.4 mm/sec return speed 130 mm/sec work stroke 375 mm dayligth 650 mm table height 1000 mm table width 240 mm back stop - adjustable max. 800 mm oil volume 400 ltr. voltage 400 Volt total power requirement 30.0 kW weight 26409 kg range L-W-H 5450 x 2650 x 3470 mm ----- HIGH-SPEED hydraulic press brake with increased installation height increased cylinder stroke enlarged projection ----- Furnishing: - DELEM CNC control model DA 66T - swiveling touchscreen control unit - 7 controlled axes: Y1 - Y2 - X - R - Z1 and Z2, as well as CNC crowning - electr. controlled backgauge X-axis = 800 mm / R-axis = 250 mm - on ball screws - controlled electr. Stop fingers Z1 + Z2 - split upper deer foot tool Roleri 135.85.R08, "System A" - with additional crowning of the upper wedge - Universal die block - LEUZE light barrier behind d. machine - BOSCH / HOERBIGER hydr. Components - SIEMENS - electrical system - FIESSLER AKAS laser protection device in front of the machine (including FPSC) - 2 front support arms with SLIDING system (plain bearings) - Double foot operation Kdedexaadtspfx Akwst - CE mark / declaration of conformity - User manual: machine and control in German - Safety manual: press brakes Special equipment including: - electrical central lubrication

Condition: new, pressure 175 t chamfer lenght 3100 mm distance between columns 2600 mm column arm 410 mm ram stroke speed 180 mm/sec work speed 10.0 mm/sec return speed 135 mm/sec work stroke 275 mm dayligth 550 mm table height 900 mm table width 90.0 mm oil volume 200 ltr. voltage 400 Volt total power requirement 15.0 kW weight 9450 kg range L-W-H 4250 x 2150 x 2800 mm ----- Press brake with special equipment * increased installation height * increased cylinder stroke * as well as increased bending beam speeds ----- Furnishing: - DELEM CNC control model DA-58T graphic/touch screen * 2D graphical programming * 15" TFT color screen with high resolution * Bending sequence calculation * Product programming and real size display * USB interface - Motorized backgauge with R-axis, on ball screws - X = 800 mm R = 250 mm with 2 stop fingers - controlled axes Y1 - Y2 - X - R - C (crowning) - electr. Crowning controlled by CNC - Deer foot upper tool with PS 135.85-R08, system "A" with quick-change clamp - additional crowning device in the tool holder of the upper tool - 4V universal die block M 460 R with die shoe 60 mm mount - BOSCH/HOERBIGER hydr. components Kdedpoxaax Rsfx Akwot - SIEMENS electrical system - LEUZE light barrier behind the machine - FIESSLER AKAS laser with FPSC protection device v.d. machine - Swiveling control panel, mounted on the left - 2x front support arms "Sliding-System", with T-slot and cam - 1x double foot control - CE mark / declaration of conformity - Operating manual: Machine and control in German - Safety manual : press brakes

Condition: ready for operation (used), Year of construction: 2007, operating hours: 20,700 h, pressing force: 337 t, total width: 2,200 mm, total height: 3,715 mm, overall weight: 24,000 kg, travel distance X-axis: 800 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 610 mm, controller manufacturer: DELEM, controller model: DA-66W, product length (max.): 5,100 mm, number of axes: 6, This 6-axis GASPARINI PSG 330/4000 Variante C was manufactured in 2007. It features a bending force of 330 tons and a useful bending length of 4100 mm. The machine includes a stroke of 400 mm and an X-axis travel of 800 mm. If you are looking to get high-quality bending capabilities, consider the GASPARINI PSG 330/4000 Variante C press brake we have for sale. Contact us for further details. Kodpfxsy U Hwrj Akwjdt - Bending Force / Press Capacity: 330 Ton / 3300 kN- Usable Bending Length: 4100 mm- Distance Between Uprights: 3600 mm- Stroke / Y-Axis Travel: 400 mm- Installation Height / Daylight: 600 mm- Throat / Ausladung: 500 mm- Approach Speed: 0 - 200 mm/s- Return Speed: 0 - 125 mm/s- Working Speed: 0 - 8.5 mm/s- X-Axis Speed: 300 mm/s- X-Axis Accuracy: ±0.05 mm- R-Axis Stroke / Travel: 250 mm- R-Axis Speed: 160 mm/s- R-Axis Accuracy: ±0.1 mm- Z-Axis Speed (Option): 1000 mm/s- Z-Axis Accuracy (Option): ±0.25 mm- Z-Axis Repeatability (Option): ±0.15 mm- Motor Power: 30 kW- Power Supply: 400V / 50Hz- Oil Tank Capacity: 420 L- Recommended Hydraulic Oil: Shell Tellus Oil TX 46- Machine Weight: ca. 24 Ton (23 t on nameplate)- Table Width: 90 mm- Working Height: 965 mm- Hydraulic Components: Rexroth- Electrical Components: Telemecanique- Pneumatic Components: SMC- Control Unit CNC: Delem DA-66W- Safety System: Nuova Elettronica DFS Laser Beam - RX (Type 4 Safety Device)- CNC controlled Z1-Z2-Z5 with 6-axis control DA - 66 W- Tool holder with upper and lower jaw clamping system Technical Specification Bending Length 4100 mm

Condition: used, Year of construction: 2006, Injection moulding machine Krauss Maffei KM 800-4300 MX, year 2006 The machine is equipped as follows: - 5 hydraulic cascade controls - Injection unit with a 90 - MT5 control system - Krauss Maffei handling system Kjdpfew Hwr Dex Akwodt - 2 conveyor belts

Condition: new, Year of construction: 2024, Hydraulic Guillotine Shear QC12Y 10x3200 SMO-3210-N Specifications - Maximum thickness mild steel (PN-EN S235): up to 10.0 mm - Maximum working length: 3200 mm - Cutting angle: 1.5° - Strokes/minute: 10 - 12 - Backgauge retract distance: 600 mm - Motor power: 15.0 kW - Length: 4000 mm - Width: 1800 mm - Height: 2100 mm - Total mass: 8400.0 kg Equipment - Backgauge powered by an electric motor (on ball screws) - Hydraulic sheet metal clamping over the entire working length - Blade clearance adjustment - Ball transfer units built in on the table - Workspace illumination - Front Suports - Mobile foot switch Rear ramp The rear ramp has been fitted with ball transfer units so that cut-offs are never left over on the machine. E21S Controller (Mounted on a swivel arm on the left side of the machine) - Backgauge control - 40 programs can be stored - up to 25 different steps in each program - Retract function - One-touch parameter saving - Parameters memory in case of power failure Steel hydraulic lines Hydraulic lines made of steel instead of rubber reduce the chances of future leaks. OCS - Oil Cooling System Oil Cooling System - guarantees the stability of the machine's operating parameters even after long, continuous operation. PCS - Preassure Control System Pressure Control System ensures reliable operation of the blade for many years. Assistance by a specialist We make sure to stay in constant touch with our Clients. Therefore, we add a package of tech support hours of Otinus Professional Assistance to every machine purchased. Technical consulting We have specialists who will determine the right machine and accessories before the purchase - on the basis of technical drawings of the parts you plan to make. See and test the machine Join us for a special demonstration where a qualified Otinus technician will show you the full functionality of the machine. In addition, you will be able to try out how the device will perform against your needs. You can provide technical drawings and sample material. Included in the machine price Jednodniowe szkolenie wraz z instalacją maszyny - 1 day (up to 8 hours) - installation of the machine and learning to use the controller. Telephone consultation with a specialist - 7.30 am - 9.00 pm (Mon-Sat) – a time package of 8 tech support hours to be used within 12 months. Free loan of transport rollers and two lifting jacks for easier positioning of the machine at the Client's site. The rollers and jack will be delivered upon prior (no less than 7 days before delivery of the machine) request. Terms of cooperation - 24 month warranty. - Lead time: approx: 10 - 12 weeks. Not applicable if a machine is labeled as available immediately. - The machine is brand new. Kdjdoiukw Tspfx Akwot - Warranty and post-warranty service provided by the seller. - The Client is responsible for the machine during unloading and transport on their premises.

Condition: new, Year of construction: 2024, Hydraulic Guillotine Shear QC12Y 6x3200 SMO-3206-N Specifications - Maximum thickness mild steel (PN-EN S235): up to 6.0 mm - Maximum working length: 3200 mm - Cutting angle: 1.5° - Strokes/minute: 14 - Backgauge retract distance: 600 mm - Motor power: 7.5 kW - Length: 3900 mm - Width: 1600 mm - Height: 1740 mm - Total mass: 5200.0 kg Equipment - Backgauge powered by an electric motor (on ball screws) - Hydraulic sheet metal clamping over the entire working length - Blade clearance adjustment - Ball transfer units built in on the table - Workspace illumination - Front Suports - Mobile foot switch Rear ramp The rear ramp has been fitted with ball transfer units so that cut-offs are never left over on the machine. E21S Controller (Mounted on a swivel arm on the left side of the machine) - Backgauge control Kdodpfx Asgih Utokwjt - 40 programs can be stored - up to 25 different steps in each program - Retract function - One-touch parameter saving - Parameters memory in case of power failure Steel hydraulic lines Hydraulic lines made of steel instead of rubber reduce the chances of future leaks. OCS - Oil Cooling System Oil Cooling System - guarantees the stability of the machine's operating parameters even after long, continuous operation. PCS - Preassure Control System Pressure Control System ensures reliable operation of the blade for many years. Assistance by a specialist We make sure to stay in constant touch with our Clients. Therefore, we add a package of tech support hours of Otinus Professional Assistance to every machine purchased. Technical consulting We have specialists who will determine the right machine and accessories before the purchase - on the basis of technical drawings of the parts you plan to make. See and test the machine Join us for a special demonstration where a qualified Otinus technician will show you the full functionality of the machine. In addition, you will be able to try out how the device will perform against your needs. You can provide technical drawings and sample material. Included in the machine price Jednodniowe szkolenie wraz z instalacją maszyny - 1 day (up to 8 hours) - installation of the machine and learning to use the controller. Telephone consultation with a specialist - 7.30 am - 9.00 pm (Mon-Sat) – a time package of 8 tech support hours to be used within 12 months. Free loan of transport rollers and two lifting jacks for easier positioning of the machine at the Client's site. The rollers and jack will be delivered upon prior (no less than 7 days before delivery of the machine) request. Terms of cooperation - 24 month warranty. - Lead time: approx: 10 - 12 weeks. Not applicable if a machine is labeled as available immediately. - The machine is brand new. - Warranty and post-warranty service provided by the seller. - The Client is responsible for the machine during unloading and transport on their premises.
