Tool presetter

EZSET EZ400

Year of construction: 2005, condition: ready for operation (used), travel distance X-axis: 285 mm, travel distance Z-axis: 1,150 mm, controller manufacturer: FANUC, controller model: 21i-TB, spindle motor power: 7,500 W, spindle speed (max.): 3,200 rpm, number of axes: 3, This 3-axis STUDER S33 CNC cylindrical grinding machine was manufactured in 2005 and completely overhauled in 2026, with 0 operating hours post-overhaul. It features a center height of 175 mm and a center distance of 1000 mm. The machine is equipped with a powerful 7.5 kW motor spindle and a control system with a 10.4" color touch screen. If you are looking to get high-quality grinding capabilities, consider the STUDER S33 CNC machine we have for sale. Contact us for further details. - completely overhauled in 2026- Operating Hours: 0h after overhaul- Center Height: 175 mm- Center Distance: 1000 mm- Machine Base: Mineral cast Granitan S103- Strokes: 285 mm (X-axis) x 1150 mm (Z-axis)- X-axis Drive: AC Servomotor and ball screw, 0° angle, feed rate 0.001–5.000 mm/min- Z-axis Drive: AC Servomotor and ball screw, feed rate 0.001–10.000 mm/min- Measuring System: Incremental scale for X and Z axes, resolution 0.0001 mm- Grinding Headstock: Universal for external and internal grinding, Hirth serration 1° (-15° to +195°)- Motor Spindle (Pos. 2): 7.5 kW, 1400 to 3200 rpm, programmable cutting speed max. 50 m/s- External Grinding Guard: Wheel size D. 500x63mm F1 (80mm F5) with automatic contact protection- Internal Grinding Spindle (Pos. 3): Studer belt-driven internal grinding spindle (180°) with frequency inverter- Workhead Stock: Universal, roller bearing mounted, taper MK5, cylindrical outer nose D. 70mm, spindle bore D. 28mm, manual spindle lock- Workhead Drive: 1.8 kW AC Servomotor, speed range 1–1500 rpm, jog speed 1–50 rpm- Workpiece Weight: Max. 80 kg between centers- Tailstock: Taper MK4, 35 mm stroke, quill diameter 50 mm, hydraulic quill retraction with monitoring, manual fine adjustment +/- 0.04 mm- Pneumatic Lifters: Pneumatic lift-off for easy shifting of workhead and tailstock- Control System: Fanuc 21i-TB with 10.4" color touch screen, integrated PLC, 32KB user memory, 400 program storage slots- Power Supply: 400V +/- 10%, 50 Hz +/- 1Hz, 24V DC control voltage Optional Equipment: - Dittel Sensitron 6 contact detection with magnetic sensor (1 pc)- Movomatic C25 LP active probe- 3 pcs levelling elements- Air conditioning unit for electrical cabinet- Euchner hand-held control unit- Swiveling dresser for internal grinding- Park position for tailstock- 3 pcs Studer belt-driven internal grinding spindles (24,000 rpm / 40,000 rpm / 60,000 rpm)- Foot pedal for C-axis override with open doors- Foot pedal for clamping device actuation (tailstock)- Electrical interface for rotary dressing (spindle optional)- Movomatic in-process gauge control ES 124 control (measuring head optional)- 8 pcs used grinding wheel flanges for external grinding- Various new MK4 centers- Various dressers Additional Capabilities: - Capable of thread and form grinding (software must be requested directly from Fritz Studer AG) Bljdszwd Hgspfx Ahmen

Condition: used, Year of construction: 2022, functionality: fully functional, machine/vehicle number: 6861-0024, workpiece weight (max.): 250 kg, grinding length: 500 mm, grinding wheel diameter: 300 mm, total width: 4,600 mm, total length: 4,650 mm, total height: 3,580 mm, type of input current: three-phase, spindle speed (max.): 12,000 rpm, feed length X-axis: 500 mm, feed length Y-axis: 650 mm, feed length Z-axis: 650 mm, feed rate X-axis: 50 m/min, feed rate Y-axis: 30 m/min, feed rate Z-axis: 30 m/min, grinding spindle motor power: 50,000 W, grinding spindle speed: 12,000 rpm, overall weight: 9,000 kg, input frequency: 50 Hz, rapid traverse X-axis: 50,000 m/min, rapid traverse Y-axis: 30,000 m/min, rapid traverse Z-axis: 30,000 m/min, input voltage: 400 V, space requirement height: 3,580 mm, MFG: Magerle (United Grinding) Model: MFP51 (MFP-51-50.65.65) Linear Axes Max X Travel = 500 mm Max X Travel Speed = 50000 mm / min Max Y Travel = 650 mm Max Y Travel Speed = 30000 mm / min Max Z Travel = 650 mm Max Z Travel Speed = 30000 mm / min Spindle Max. spindle power = 50 kW Max. speed = 12000 RPM Max. grinding wheel diameter = 300 mm Max. grinding wheel width = 60 mm Swivel Axles Swivel Range A = 210° Swivel Range B = 360° Swivel Range C = 360° Bjdpfx Ahezwugdsmsln Automatic 68-position tool change magazine portal magazine with inspection window and electromechanically interlocked loading station for manual loading of the tools. Ready to ship from Bangkok, Thailand

Condition: used, Year of construction: 2003, machine/vehicle number: V420D2-0038, Zoller Venturion 500, Tool presetting device. Versatile: Flexible turret table configuration to suit your requirements. Universal: A single measuring device for almost all different tool holders. Simple: Comfortable controls and user-friendly software. Time-saving: Turret table equipped with frequently used holders. Stable: Special alloy and robust construction. Economical: Consistent use of branded components and excellent price-performance ratio. Bedpfx Ahoy D D Utsmsln

Condition: used, Year of construction: 2017, functionality: fully functional, type of input current: AC, overall weight: 280 kg, input frequency: 60 Hz, compressed air connection: 8 bar, For sale is a fully functional, tested EZset tool presetter, type EZS420C2X, manufactured in 2017, complete with monitor and printer – tested and ready for immediate use. This system is of German manufacture (EZset GmbH & Co. KG, Pleidelsheim) and is designed for precise use in tool and machine construction. The unit has been regularly maintained, operated exclusively in a climate-controlled measuring room, and is in very good technical and visual condition. Technical data: - Manufacturer: EZset GmbH & Co. KG - Model: EZS420C2X-00074 - Year of manufacture: 2017 - Original purchase date: 23.11.2018 (invoice included) - Power: 600 VA - Voltage: 100–120 V / 200–240 V AC · 50/60 Hz - Pneumatics: 6–8 bar (80–110 PSI) - Weight: 280 kg - Tool holder: Adapter-SK 40 & Adapter-HSK 63 Measuring ranges: - Z = 420 mm - D = 420 mm - max. jaw diameter = 100 mm Blsdpfx Ahoy S Ti Nemjn Operating monitor: MOSTRON PPC13-113286-F (12–24 V DC, 50 W) with touchscreen Operating system: Windows Embedded Standard (licensed) Backup software: Drive Snapshot 1.4 (licensed) Label printer: TSC Auto ID DT2205 (24 V, TÜV and CE certified) Equipment & Functions: - Precise measurement of tools in the X and Z directions - High-resolution camera and screen display - Pneumatic tool holder - Intuitive touch operation with EZset software - Label printer for tool identification - Fully integrated control and pneumatics - All original nameplates and CE certificates are available Condition: - Fully functional and ready for use - No error messages or defects - Clean, well-maintained overall condition - Directly from ongoing operation Scope of delivery: - EZset EZS420C2X unit - MOSTRON operating monitor - TSC label printer - Pneumatic connection - All connecting cables and accessories as shown in the pictures

Condition: used, Year of construction: 1997, Measuring Machine Zeiss Prismo7, Year 1997, Completely Refurbished in 2024 ZEISS Prismo7 CNC – COMPLETELY REFURBISHED!! USED MACHINE Made in Germany Year of manufacture: 1997, modernized in 2024 with new control system, new probe system, and new user-friendly measuring software. Measuring volume: 1,500 x 900 x 700 mm Measurement accuracy according to ISO 10360-2: MPEe=(1.9+L/450)μm, MPEp=1.9μm Including base frame with integrated active vibration damping. Covered auxiliary support guide with additional scale to increase measuring accuracy. The scope of delivery also includes the following accessories: 1. Motorized rotary/swivel head PH10T Plus by Renishaw and interchangeable probe TP200 by Renishaw 2. Probe change magazine TW200. In total, 2 TP200 Standardforce probe modules are included. 3. Measuring software ThomControl CNC Basic Geometry. All geometric elements can be measured, graphically displayed, and documented. Evaluation of all form and positional tolerances. ISO tolerance database is integrated. Measurement programs can be created via teach-in. CNC measuring strategies are graphically displayed. Bledpfx Aoxuravohmsn 4. The MCU-Lite2 one-hand joystick from Renishaw features stepless speed control, emergency stop, and freely assignable function keys. 5. CNC control unit UCC2-2 Plus by Renishaw, housed in a separate control cabinet. 6. Powerful DELL PC with 8 GB RAM, 500 GB HDD, 2GB graphics card, WINDOWS 11 Professional 64-bit, sound card, network connection, 24" TFT monitor, including 3-year on-site service and an "ALL IN ONE" HP color printer. 7. Calibration sphere Ø25. 8. M2 stylus kit, 10 pieces.
