Bed milling machine with moving column & CNC

Fanuc Milling Robot X: 10 500 / Y: 3045 / Z: 3500 mm CNC

Condition: good (used), Year of construction: 1978, sheet thickness brass (max.): 3 mm, Motorized folding machine Fab. Lotze Typ. HZ - 2500 x 3mm year 1978 Technical data Make: Lotze Type: HZ-25 Year of construction: 1978 Effective length: 2500 mm Sheet thickness: max. 3 mm Bjdpjrc E S Eofx Ad Aowg Equipment - Bending angle adjustment via potentiometer - Tool package with focus rail, bending rails, reinforcement rails - Manually adjustable back gauge All specifications without guarantee

Condition: refurbished (used), Year of construction: 2010, load capacity: 200 kg, arm reach: 2,400 mm, As PLC Merkezi, we can conduct custom engineering projects with our industrial robots in our stock like this example. We can help you with: - Welding - Cutting - Machine Feeding - Palletising - Depalletising - Marble Processing - Apgant Machine Feeding and Metal Bending - And many other projects Brand: KUKA Model: KR200-3 Comp Condition: Refurbished with 1 year of warranty Version: V5.6.12 Year: 2010 Control Cabin: KRC2 ed 05 Rated Payload: 200kg Bwsdpfeq Dpxdex Ad Ajg Access Distance: 2400mm Included: Manipulator + Control Cabin + All Wiring Sets + Teach Pendant +1 Hertz Spindle Motor (New) + Delta Spindle (Set with the Mechanical System) + Tool Changer Table Not Included: 7th Axis, Engineering Design and Consultancy Shipping: NOT included in the price Payment: 100% payment before collection

Condition: like new (used), Year of construction: 2014, 1 as-new CNC travelling column bed type milling machine Manufacturer: Soraluce Model: FL 8000 Year of manufacture: 2014 Control: Siemens 840 D Solution Line Technical data: Bjdpfxjwzx Nto Ad Ajwg Travel X-Y-Z: 8000 x 1300 x 1800 mm C-axis travel: 360 degrees Table clamping surface: 6000 x 2000 mm Tool holder: SK 50 Capto C8 Speed range up to: 4000 rpm Main drive: 43 kW Rapid traverse: 35 m/min CNC rotary table: 1600 mm, 250 rpm Weight approx.: 40 t Equipment / Accessories: Tool magazine Controlled universal milling head Chip conveyor Full enclosure Complete coolant system Electronic handwheel Through-spindle coolant (IKZ) Indexing clamp Vertical carousel rotary table D=1600 mm: 250 rpm Clamping field 6000 x 2000 mm Planing slide, etc.

Condition: used, Year of construction: 2001, sheet width 3200 mm plate thickness 3.0 mm ST thickness at "Niro-steel" 2.0 mm Opening width / upper beam 300 mm speed OW 40.0 mm/sec Bending beam adjustment 80.0 mm speed BW 90.0 Grad/sec work height max. 900 mm control MULTIBEND 5000 back stop - adjustable 10 - 1550 mm accuracy +/- 0.1 mm air pressure 5.0 bar Number of working hours ca. 1.000 h total power requirement 2x 4.0 kW voltage 400 V weight 4400 kg range L-W-H 4295 x 2225 x 1775 mm New price approx. 85.000 euros Machine with only approx. 1.000 operating hours (!!) good condition (!!) Special price on request - in checked condition - machine video - ?v=VP6emx4HTYM ! Maximum flexibility when bending cassettes, boxes and profiles ! High flexibility in bending part design ! High productivity and throughput ! Easy to use Equipment: - motorized universal swivel bending machine "RAS 73.30" * high-precision mechanics with modern control technology * for individual and series production * robust high-speed machine with high axis speeds * torsion-free welded construction - RAS CNC control model "MULTIBEND 5000" * material and tool library * swiveling - front right * 1x emergency stop button - CNC electro-motorized upper beam adjustment * fast closing and opening speed * programmable opening and closing height * bending radii without special tools (multiple bends) * rigid upper beam for straight bending parts * 1x set of RAS split upper tools .. height 80 mm * RAS "click-in" tool system - CNC electro-motorized bending beam adjustment Bwodpfxjxabz Tj Ad Aog * fast swivel movement: short production time * crowning system compensates for deformation by the bending forces * 1x set of RAS split bending tools - CNC electro-motoric back stop * fast positioning, repeatable work * table plates hold the weight of the sheet * stainless steel table plates with ball rollers - 2x freely movable double foot switch - 1x RAS tool trolley for bending tools (movable) - operating instructions (PDF) + original circuit diagram

Condition: good (used), Year of construction: 2019, Industrial robot Manufacturer: Kuka Model: KR60 HA Year of manufacture: 2018/2019 Low operating hours Reach: 2033 mm Weight: 665 kg Payload: 60 kg Kuka controller KRC4 Bedpon Utbgjfx Ad Aowg Weight: 150 kg Software V8.3.40 Kuka touch panel Kuka connection cables 101225ä

Condition: used, Year of construction: 2006, functionality: fully functional, machine/vehicle number: 0728, X = 5,000 mm Y = 1,025 mm Z = 1,100 mm / Horizontal Z = 1,000 mm / Vertical - Continuously adjustable NC swivel head, +/- 105 degrees, as a CNC axis for horizontal and vertical machining, indexing accuracy +/- 5 seconds - Heidenhain iTNC530 controller, hard disk with approx. 21 gigabytes of free space - HSK100 motor spindle, speed range 20-8,000 rpm, drive power 44 kW, torque 350 Nm - NC rotary table SKH 4/630 Horizontal faceplate Faceplate diameter: 630 mm Standard height: 300 mm Indexing accuracy: +/- 12" Max. load: 900 kg Max. tangential torque at 63 bar: 2400 Nm Includes AC motor with integrated rotational measuring system and hydraulic clamping, as well as an additional CNC axis - NC rotary table SKH-NC 9/1450 Horizontal faceplate Faceplate diameter: 1450 mm Indexing accuracy: +/- 12" Without direct measuring system Max. load: 5,000 kg Max. tangential torque with clamping: 16,000 Nm Includes AC motor with integrated rotational measuring system and hydraulic clamping, as well as an additional CNC axis Special enclosure for rotary table diameter 1450 mm included Bodpexgnfxjfx Ad Aswg Swing circle diameter: 1500 mm No turning operation possible! - 60 tool stations - Fully enclosed working area with roof - Bellows with steel lamellae - Direct measuring system for NC rotary table, indexing accuracy +/- 5 degrees - Direct linear measuring system for X, Y, Z axes - Chip conveyor - Rinsing gun - Centralized oil lubrication - Working area lighting, 6-fold - Mounting elements - 3D wireless measuring probe - Tool probing system for measuring and checking cutting tools in the machine, TT140 - Unilok ESM 130 zero-point clamping system 36 units integrated in the machine table 16 units embedded in the rotary table faceplate (diameter 1450 mm) 4 units embedded in the rotary table faceplate (diameter 630 mm)

Condition: ready for operation (used), total height: 3,850 mm, total width: 4,190 mm, total length: 11,300 mm, controller manufacturer: Heidenhain, empty load weight: 22,000 kg, CNC indexeerfreeskop (2,5°) spaantransporteur inbegrepen Bwodpfx Aoxpgfved Aog Optioneel: machine kan worden uitgerust met nieuwe Heidenhain 320-besturing Longitudinal travel X-axe: 6500 mm Crosstravel Y -axe: 1600 mm Travel Z-axe (Height): 900 mm Dimensions clamping space - table: 8000 x 800 mm Power on spindle: 22/26 kW Admission in millingheadspindle (ISO): ISO 50 Max speedrange: 20 > 3000 rpm

Condition: ready for operation (used), Year of construction: 2001, control type: NC control, working width: 2,500 mm, sheet thickness (max.): 6 mm, back gauge: 1,000 mm, overall weight: 6,700 kg, total length: 2,800 mm, total width: 3,950 mm, total height: 1,900 mm, power: 7.5 kW (10.20 HP), stroke length: 450 mm, Motorized swing bending machine Manufacturer: HERA Model: SM4 2500x6mm Year of manufacture: 2001 Technical data Manufacturer: HERA Model: SM 4 Year: 2001 Capacity: 2520 x 6 mm Upper beam stroke: 450 mm Lower beam adjustment: max. 100 mm Bending beam adjustment: max. 100 mm Connected load: Upper beam 5.5 kW / Bending beam 7.5 kW Operating voltage: 400 V / 50 Hz Control voltage: 230 V Dimensions approx.: L 3.95 x W 2.80 x H 1.9 m Weight: 6.7 t Equipment • 2 x sharp rail • Bending rails: 10mm, 20mm, 40mm • Segmented gooseneck set: H 120mm • Motorized bending beam adjustment • Hydraulic tool clamping • Programmable backgauge 10–1000mm All information provided without guarantee. A live demonstration is possible at any time in our showroom. Bodpfxewxc Rpj Ad Aswg

Condition: used, functionality: fully functional, KUKA & ABB Axes – Various Lengths & Load Capacities Available! We offer a wide selection of linear and auxiliary axes from the brands KUKA and ABB – ideal for expanding existing robotic systems or implementing new automation projects. Available Models • KUKA axes for KRC2 and KRC4 • ABB axes for IRC5 Variants • Various lengths • Different load capacity classes • Optional with or without motor/gearbox Bjdpsxxki Defx Ad Ajwg Condition & Quality • Industrial standard, tested & fully functional • Immediately available (depending on model) Ideal for: • Automation • Material handling • Welding • Pick & place • Special solutions — Enquire now! Simply send us your required length, load capacity, or controller specification – we will prepare a tailored offer for you.

Condition: used, Year of construction: 1999, sheet width 3200 mm plate thickness 4.0 mm ST distance between columns 3300 mm upper clamping bar adjustment 400 mm Adjustment folding beam 80.0 mm pivoting angle 180 Grad clamping capacity max. 200 KN rear stop 10.0 - 1600 mm oil volume 160 Liter total power requirement 9.8 kW weight 8500 kg range L-W-H ~ 4900 x 2000 x 2300 mm From a maintenance workshop Good / well-maintained condition (!!) - in checked conditions - machinevideo - ?v=RY-amZooeX4 Equipment: - Robust CNC folding machine - CNC control unit - CYBELEC "DNC 80 PP" * Swiveling control panel, front right * 2D graphic display for display and multiple simulation * 2D graphic programming * Easy handling - CNC electro-motorized backgauge * Travel range 10.0 - 1,600 mm Bodpfxoxaa A No Ad Aswg * Pneumatic / lowerable stop fingers * Adjustment speed max. 250 mm/sec. * Rear sheet support table with brushes - Electro-motorized lower beam adjustment (S axis) - Electro-hydraulic pivoting movement of the lower beam - Pneumatic upper tool clamping - Pneumatic lower tool clamping - 1x freely movable double foot switch - Original operating instructions + wiring diagram/hydraulic diagram Special accessories included: - 1x split set of goat's foot upper tools, H = 150 mm (not complete) - 1x split set of goat's foot upper tools, H = 200 mm (not complete) - 1x split bending/lower tool - Rear sheet support with brushes
