FIDIA KR214

Condition: refurbished (used), Year of construction: 1987, functionality: fully functional, turning diameter: 4,300 mm, faceplate diameter: 4,000 mm, Vertical Turning Lathe SC43 CNC, retrofitted and upgraded with CNC Fanuc 0𝑖-TF Plus Made in Romania by TITAN Year of manufacture: 1987 The machine was completely retrofitted in 2026 Main technical data: FACE PLATE DIA. MM 4000 MAX. SWING MM 4300 MAX HEIGHT UNDER THE CROSSRAIL MM 2000 MAX. LOADING ADMITTED KG 18,000 FACEPLATE SPEED RANGE 1-92 RPM Tsdpfxjy A Iife Aklsa FEEDS RANGE MM/ROT 0.05-5 CARRIAGE RAPID FEEDS MM/MIN 2500 MAIN D.C. MOTOR POWER KW 55 SIEMENS WITH SIEMENS DRIVER MACHINE WEIGHT APPROX. 63 TONS The machine has the following brand new components: - New electrical equipment with parts made by Schneider, Shrack, Siemens, with a new cabinet - New control panel - New micro switches - New hydraulic pump and components - New pump for guideway lubrication, and the entire installation was redone - New CNC Fanuc 0𝑖-TF Plus 55KW Main motor, Siemens, refurbished in 2018 with Siemens driver The main gearbox was checked and refurbished with new bearings. The machine was repainted. We grant a 6-month guarantee for parts. We can send more photos and a video showing the machine’s precision measurements. Do not hesitate to contact us.

Condition: excellent (used), Motor-driven NC rotary table Stepless rotary table (pitch 0.001°) Attached pallet station: pallet changing table (2 pallets) Manufacturer: Rückle Type: PKTF 1200 Table size: 1200 mm x 1200 mm Total height: 660 mm Centring hole: 100 H6 mm Clamping grooves: 7 pieces Slot dimension: 22 H7 mm Slot distance: 160 mm The displacement is measured via a ROD 250 rotary encoder. Condition: Very good (used) Optionally with machine bed (travel = 2000 mm ) Todsfk R Tdjpfx Aklja About us: MBM Maschinenservice & Gebrauchtmaschinen GmbH, is a free specialist for SHW machine tools. Our main focus lies in the field of tool milling machines. Our services include the supply of spare parts, on-site customer service, machine overhauls and control modernization. Services: - Used machines - spare parts - after-sales service - machine service - machine overhauls - control modernization

Condition: used, Year of construction: 1967, grinding length 1650 mm grinding width 700 mm workpiece height 600 mm Tsdpfett S Uaex Aklsa table surface area 1500 x 500 mm table speeds 0 - 20 m/min cross feed autom. 0 - 20 mm/Hub grinding spindle speed 2000 U/min grinding wheel diameter 300 mm total power requirement 19 kW weight of the machine ca. 5 t dimensions of machine L x W x H 5,92 x 3,12 x 2,65 m Accessories: 2 magnetic plates, each 750 x 600 mm; grinding wheel with flange, various grinding wheels and flanges separate, wet grinding attachment

Condition: used, swing diameter 2000 mm turning height 1800 mm Control Siemens Sinumerik 840 Dsl turning speeds range 2,8-315 U/min cross rail adjustment - vertical 1200 mm Tsdey Dvlqopfx Aklea cross rail adjustment - horizontal +/- 1150 mm 1500 mm bit feeder section 240 x 240 mm Minimum immersion diameter 340 mm cutting capacity 50 kN max. torque on the faceplate 50000 Nm speed range step 1 2,8 - 80 U/min speed range step 2 12 - 315 U/min Max. clamping weight 12000 Kg power capacity faceplate 105 kW weight of the machine ca. 33 t dimensions of the machine ca. 10 x 5 x 6,5 m Further technical data: - Feed range of three-phase servo motors: 1–3000 mm/min; 0.01–50 mm/rev - Crossbeam travel speed: 425 mm/min Features/Accessories - Increased turning height (+600 mm) - Z-axis extended to 1500 mm - Magazine capacity: 20 positions - Magazine type: disc magazine - Max. tool length: 525 mm - Chip conveyor - Workpiece measurement - Renishaw probe - Coolant tank capacity: approx. 2000 litres - Coolant pump flow rate: 60 litres/min at 2 bar Overhaul: - Extensively overhauled in 2012 by Siemens Industry Munich - Items overhauled included: control system, cabling, motors, measuring systems, etc. - Further information can be found in the PDF

Condition: good (used), Year of construction: 2008, functionality: fully functional, travel distance X-axis: 6,000 mm, travel distance Y-axis: 3,400 mm, travel distance Z-axis: 1,500 mm, table length: 6,000 mm, table width: 3,000 mm, spindle speed (min.): 3,000 rpm, A CNC portal milling machine FKD-Feichter with double column is available. Travel range X/Y/Z/W: 6000mm/4800mm/1500mm/1300mm, table dimensions X/Y/Z: 6000mm/3000mm, max. workpiece weight: 115,000kg, max. table load: 6,400kg/m², total machine bed length: 14,500mm, portal dimensions X/Y: 3,000mm/4,400mm, C-axis: 360°, A-axis: +/-120°, ram section: 700mm/700mm, feed rate: 10m/min. Total system dimensions X/Y/Z: approx. 15,100mm/6,100mm/7,000mm, total system weight: approx. 115,000kg, control system: Heidenhain. Includes chip guard, coolant system, and hydraulic unit. The machine was built at the site in 2022. The ram and spindle have been freshly overhauled. Documentation is available. On-site inspection is possible. Immediately available. Tedexp Rgkjpfx Aklsa Three heads: Fork milling head with A-axis, 90-degree angular head, spindle extension – straight head, tool holder SK 50.

Condition: new, Year of construction: 2025, functionality: fully functional, turning height: 1,600 mm, turning diameter: 2,000 mm, CNC Vertical Turning Center Model: VTC-16/20R with Fanuc 31i-B Table Diameter: Ø1,600 mm Max. Swing Diameter: Ø2,000 mm Max. Turning Height: 1,600 mm Table Speed: Max. 250 rpm Table Load Capacity: 8,000 kg Table Indexing Speed: 720°/min Table Indexing Accuracy: 0.001° X-Axis (Ram horizontal): -100 mm to 1,170 mm Z-Axis (Ram vertical): 900 mm Drive Spindle Speed: Max. 2,000 rpm Ram Size: 240 mm x 240 mm Milling Spindle Taper: ISO 50 Tool Shank Size: 40 mm x 40 mm Crossrail (vertical travel): 250 mm x 3 stages (hydraulic) Table Drive Motor: AC 37/45 kW (continuous/30 min. duty) Milling Spindle Drive Power ISO 50: 15/18.5 kW (continuous/30 min. duty) Control System: Fanuc 31i-B Display Unit: 15-inch TFT-LCD Memory Capacity: 1 MB Automatic Tool Changer: 24 positions (for 7 turning tools + 1 cover + 16 milling tools) Standard Tool Holders: New 240 TCR-01 (2 pcs) Splash Guard: Table version (R-Type standard design) External Coolant System: 3 bar (80 l/min) Chip Conveyor: Hinged belt type Table Bearing Cooling Device 4-Jaw Independent Manual Chuck Foundation Anchor Bolts / Base Plates Maintenance Tools and Toolbox Hydraulic Power Unit Work Area Lighting Signal Lamp: 3 colors (green, red, yellow) Operating Manuals (English): 1 CD with Fanuc manuals and 3 books with mechanical/electrical manuals Power Supply: 220 V, 60 Hz, 3-phase Machine Color: Manufacturer standard OPTIONAL ACCESSORIES (#1) Turning Tool Holder: Type 240TCR, 4x included Rigid Tapping: 1x included OPTIONAL ACCESSORIES (#2) Automatic power-off for N.C. - on request Turning tool holder type 240TCR - on request Tjdpfxsxp Nb Ts Akloa Through-spindle coolant supply: 30 bar (pump pressure) - on request Transformer 415 V, 50 Hz, 3-phase - on request Linear scales X-, Z-axis (Fagor, Spain) - on request Workpiece measuring device - on request Tool measurement TS27R, Renishaw - on request Other information: INSTALLATION, COMMISSIONING, TEST OPERATION, AND TRAINING - not included in the price INSURANCE AND FREIGHT - not included in the price Image shows machine with pallet changer. The offered machine DOES NOT INCLUDE A PALLET CHANGER! Errors in technical data excepted. The scope of accessories is as described in the text of this article only. There is no entitlement to any other accessories, such as those shown for illustration purposes. The general terms and conditions of JS-Werkzeugmaschinen GmbH apply.

Condition: excellent (used), Year of construction: 2018, total length: 9,800 mm, total width: 4,000 mm, feed length X-axis: 3,500 mm, feed length Y-axis: 1,100 mm, feed length Z-axis: 1,100 mm, feed rate X-axis: 30,000 m/min, feed rate Z-axis: 5,000 m/min, table length: 3,000 mm, table load: 6,000 kg, table width: 1,200 mm, power: 22 kW (29.91 HP), Surface grinder Ziersch - Z1030 MACH-ID 9597 Make: Ziersch Type: Z1030 Control: Mitsubishi Touch Year: 2018 X - Travel: 3500mm Y - Travel: 1100mm Z - Travel: 1100mm Table Length: 3000mm Table Width: 1200mm Table load: 6000 Tjdpfx Aoy En Dneklja Feed rate X-Axis: 30000mm/min. Feed rate Z-Axis: 5000mm/min. Grinding stone dimensions:500 x 100 x 203mm Power: 22kW Speeds: 3000Rpm Cooling system: yes Feed rate Y-Axis: 3000mm/min. Length: 9800mm Width: 4000mm Height: 4500mm Weight: 27500kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: used, Year of construction: 1990, turning diameter 2400 mm faceplate diameter 2200 mm turning height 2100 mm control SIEMENS Sinumerik 850T workpiece weight 17 t Tol measurements 32 Werkzeuge Crossbeam travel: 700mm Crossbeam support Travel from centre of rotation to the right: 700mm Crossbeam support Travel from centre of rotation to the left: 700mm Machine table drive Main drive power: 80kW Number of gearboxes: 2 Step change: 3.84 Speed range of the 1st gear stage: 2-32-139 rpm Speed range of the 2nd gear stage: 9-125-500 rpm Max. Machine table load: 6 tonnes Feed drive Cross beam support Horizontal feed speed: 0.1 - 8 m/min Cross beam support Vertical feed speed: 0.1 - 8 m/min Cross beam support Rapid traverse speed horizontal/vertical: 8 m/min Cross beam adjustment speed: 425 mm/min Tool system Tool system: 180.1 Cutting force on the turning tool: 30 kN Tjdpfxoygx D He Aklea

Condition: good (used), We offer contract deep-hole drilling work. From a diameter of 0.5 to 400 mm and up to a drilling depth of 12,000 mm, everything is possible! Please contact us and we will be happy to prepare a quotation for you. Please let us know the quantity, the material, the drilling diameter and the drilling depth. Todpfxsrt T U Ej Aklsa

Condition: used, machine/vehicle number: 109369/109370, Technical Data Manufacturer: ZEISS Serial No. 109369/109370 The plate is divided in the middle. Measuring Plate Length = 6000 mm Width = 3000 mm Height = 350 mm The machine can be modernized with new software according to customer requirements. Price: upon request! Installation and commissioning possible! Tsdpfx Ajdbi Nljkloa We would be happy to prepare a detailed offer for you! Note: Our offer is exclusively aimed at specialist customers! (Changes and errors in the technical data, information, and prices, as well as prior sale, are subject to change!)
