Double surface grinder

FLP HP 720

Condition: ready for operation (used), Year of construction: 1996, 630T press retrofitted in 2010 by the company LITOSTROJ RAVNE Capacity: 630 tons Total power: 15 - 630 tons Ring power: 10 - 230 tons Lifting power: 50 tons max Back pressure power: 5 - 120 tons Ejection power: 22 tons max Max slide stroke: 180 mm Ring race: 30 mm Back pressure stroke: 30 mm Slide surface: 900 x 900 mm Table surface: 900 x 900 mm Hpedshh Hwlopfx Ahzea Number of strokes: 28 - 72 s.p.m. Power requirement: 80 kW Default configuration

Year of construction: 1992, condition: used, grinding height 50 mm grinding width 120 mm grinding wheel diameter 600 mm total power requirement 85 kW weight of the machine ca. 9500 kg Hpjdot Hw Naspfx Ahzja D I S K U S (Germany) CNC Controlled Double Sided Vertical Spindle Surface Grinder with Rotary Workpiece Feed System and IONIC Size Control Model DDS 600 III PLM - CNC Year 1992 erial No. 7924 _____ Grinding wheel Ø x bore x height, each 600 x 150 x 75 mm Approximate Workpiece dimensions: Grinding height, approx. 1.5 – 50 mm Grinding width, appox. 20 - 120 mm Vertical quill adjustment, each, approx. 150 mm Infeed of grinding wheels via CNC 0.0001 mm Feed of workpiece transportation device, infinitely variable 40 – 235 mm/sec Grinding wheel speed, each (30 m/s) 191 - 955 rpm Grinding spindle drive, each infinitely variable 37 kW Total electrical load, approx. 85 kW - 380 V - 50 Hz Weight, approx. 9,500 kg Accessories / Special Features * SIEMENS CNC Control, Model SINUMERIK 810 G, with monitor, for 4 axes i.e. * Movement of 2 spindle quills, dressing device, WP Rotation. Direct programming of Grinding Process data on keyboard. In connection with a IONIC Size Control No. 17 A / 68.000 with two tracers for measuring the thickness of the workpieces after grinding process, and corresponding infeed of the grinding wheels. Continuous display of measuring results on the monitor, with statistics, workpiece counter, etc. Digital Display Ampere for both grinding wheel drives and for grinding spindle speeds, etc. . * Positioning control device for supervising the height of the lower grinding wheel.. * Double column design as a portal for extra stability and higher accuracy * Rotary workpiece transportation device with infinitely variable feeds. The workpieces are Manually stacked in a device and forwarded by a transportation carrier disk thru the grinding wheels, there are two WP- down holders, one equipped with a overheight stop-control. * Angled grinding wheel dressing device, with automatic dressing process, integrated in the control as CNC axis, with safety switch-off. * Separate large switch cabinet. * Automatic central lubrication. Large pneumatic control system * Large Coolant device 6 (F) with filtering unit and magnetic separator. * Various Grinding wheels, WP transport carrier disks, 2 flanges, large Olimist separator, etc. This machine is very suitable for simultaneous double-sided grinding of large series of workpieces, e.g. punched parts, piston rings, hydraulic parts, rotors, distance rings, etc. Condition : Very good. Machine can be soon inspected under power. Delivery : Ex stock, as inspected. Payment : Net, after conclusion of contract.

Condition: excellent (used), Year of construction: 1987, pressure 320 t plate thickness 0 mm no. of strokes 80 Hub/min pressing capacity total 320 t stroke 30 - 80 mm table surface area unten: 630 x 740 mm table surface area oben: 630 x 630 mm total power requirement 60 kW This fineblanking press FEINTOOL HFA 320 was completely overhauled in 2019 and is in new condition with new CE mark MAIN RAM total force (nominal) 320 to stroke min. 30 mm stroke 80 mm V-RING nominal force 160 to stroke 30 mm COUNTER RAM nominal force 80 to stroke 30 mm Hpsdpevwgl Njfx Ahzja TOOL DIMENSIONS lower table - width 630 mm lower table - depth 740 mm upper table - width 630 mm upper table - depth 630 mm daylight max. 320 mm ELECTRICAL SPECIFICATIONS total power consumption 60 kW

Condition: like new (used), Year of construction: 1989, operating hours: 810 h, functionality: fully functional, machine/vehicle number: 892161, total height: 2,860 mm, sheet thickness (max.): 6 mm, total width: 2,425 mm, overall weight: 9,000 kg, ram adjustment: 61 mm, pressing force: 160 t, Here you have the unique opportunity to purchase a Feintool GKP F 160 that has seen barely any use. The machine has only 810 operating hours. As you can see from the photos, the machine is in excellent condition. We acquired the press in 2019, but, just like the previous owner, never put it into operation. The machine was test run without tooling at our facility and is fully functional. An on-site inspection under power is possible by arrangement. Technical specifications of the FEINTOOL GKP F 160 fineblanking press: - Maximum sheet thickness: 6 mm - Maximum sheet width: 210 mm - Total force including auxiliary functions: 160 t - Shearing force: 100 t - Hydraulic counterforce (upper bolster): 1–40 t Hpodjumigqjpfx Ahzja - Hydraulic force of the ring blank holder (lower bolster): 12–50 t - Ejector force (pump pressure): 4–8 t - Hydraulic shearing force: 7.5 t - Pneumatic shearing force: 6.6 t - Slide stroke: 61 mm - Maximum number of strokes: 72/min - Minimum number of strokes: 18/min - Motor power: 11 kW - Pump capacity: 4 kW - Air supply: 6 bar - Dimensions (L x W x H): 2380 x 1870 x 2860 mm - Weight of machine GKP F 160: 9000 kg

Year of construction: 2003, condition: ready for operation (used), There are 3 retrofit Feintool fineblanking presses with controls from Pneutronik available. 1) Feintool GKP-F 160, year of manufacture: 2001, cutting force: 100t, total pressing force: 160t, head pressure: 40t, table pressure: 50t, stroke rate: 70/min, power: 22kW, max. material thickness: 6mm, stroke height: 62mm, machine dimensions X/Y/Z: approx. 1800mm/1800mm/2800mm, weight: approx. 9000kg, control: Pneutronik. 2) Feintool GKP-F 160, year of manufacture: 2003, cutting force: 100t, total pressing force: 160t, head pressure: 40t, table pressure: 50t, stroke rate: 70/min, power: 22kW, material thickness: 6mm, stroke height: 60mm, machine dimensions X/Y/Z: approx. 1800mm/1800mm/2800mm, weight: approx. 9000kg, control: Pneutronik. Presumably there is bearing damage to the flywheel. 3) Feintool GKP-F 250, year of manufacture: 2000, total pressing force: 250t, head pressure: 75t, table pressure: 75t, ejector force: 18t, material thickness: 10mm, lifting height: 61mm, machine dimensions X/Y/Z: approx. 2100mm/3100mm/3200mm, weight: approx. 14500kg, control: Pneutronik. Presumably there is bearing damage to the worm shaft. Documentation available. On-site inspection is possible. Hpedpfx Ahju Dalyjzea

Condition: used, Year of construction: 1995, Technical details: grinding height: -- mm grinding width: 220 mm grinding wheel diameter: 762 mm Hjdjwi Nh Nopfx Ahzepa total power requirement: 90 kW weight of the machine ca.: 13 t grinding spindle 1 drive:: 37 kW grinding spindle 2 drive:: 37 kW Grinding machine for pre-grinding the connecting rod With 2 replacement spindle motors *

Condition: reconditioned (used), controller manufacturer: BECKHOFF, CONTROLS .. PC controller BECKHOFF Offer for services of complete Overhaul of a Customer-Supplied Fineblanking Press FEINTOOL GKP 160 Scope of Overhaul • Complete disassembly into individual components • Inspection of all parts, including crack testing of critical components • Overhaul of the drive system, new motors • Reworking and precise alignment of all guideways • Complete overhaul of the hydraulic cylinders • Overhaul of the clamping tables • Installation of a new hydraulic unit • Renewal of the pneumatic system • Renewal of the electrical system Modernisation / Retrofit • Combined table • Servo feed systems • Central lubrication system • RAZIOL band lubrication • New brake/clutch unit • BECKHOFF PC-based control system with touch panel • PILZ safety control system • Implementation of CE conformity Notes • Special options and customer-specific extensions can be integrated upon request. • The images shown depict a reference machine. • The offer is based on the assumption that the essential mechanical components can be reconditioned and reused. In the event that new parts must be manufactured, additional costs will apply. A list of the components concerned and their cost will be defined in the service contract. Any affected parts will be presented to the customer for inspection and decision. Hedpfxex D Ak Rs Ahzepa We will be pleased to provide further information or answer any questions you may have.

Condition: used, Year of construction: 1983, Spiertz press Hpsdpfx Aoxypzuohzoa

Condition: reconditioned (used), pressing force: 250 t, year of last overhaul: 2024, controller manufacturer: BECKHOFF, lifting height: 61 mm, CONTROLS .. PC controller BECKHOFF PRESS DESIGN .. drive system: knuckle-joint SLIDE .. total force (nominal): 250 to .. stroke: 61 mm .. stroke rate (max.): 60 /min COUNTER RAM .. nominal force: 75 to .. stroke: 15 mm V-RING .. nominal force: 75 to .. stroke: 13 mm TOOL DIMENSIONS .. lower table (left-right): 540 mm .. lower table (front-back): 540 mm .. upper table (left-right): 540 mm .. upper table (front-back): 540 mm .. shut height max.: 320 mm .. ram adjustment: 145 mm .. distance between columns (H-frame): 560 mm .. passline opening (free passage in side columns): 270 mm STRIP-FEEDER .. feeder type: roll feeder .. sheet width max.: 250 mm .. sheet thickness max.: 10 mm .. feeding step max.: 999.99 mm .. sheet length min: 1900 mm .. pilot release system: yes .. band lubrication system: yes Complete refurbished fineblanking press: * disassembly into individual parts Hedpsxrkmiefx Ahzopa * findings of all components (crack test) * overhaul of the drive * overhaul of the guides * overhaul of the impression cylinders * overhaul of the clamping tables * new hydraulic unit * new pneumatics With modernization: * servo feeders * central lubrication * new brake/clutch unit * PC control BECKHOFF with touch display * safety control unit PILZ * CE conformity + overhaul is offered including machine provided by ProdEq. + optional customer requests can be integrated + pictures show a reference machine (work picture) -> If you are interested or have any questions on our services, please do not hesitate to contact us!
