Slitting line

Gasparini Slitter

Condition: used, Slitting line SECO 60″ x 0.375″ x 50,000Lb (A3791) is perfect solution for longitudinal coil metal cutting into strips with maximum metal thickness 0.375” and maximum coil width 60” Cold Rolled and Hot Rolled Steel 18-60” Strip Width 2 Speed Gear Box 200-500 FPM Thickness: .032″-.375” Complete Line with the Following Components: L-Type Entry Coil Car 40,000# Max Coil Weight Uncoiler: Coil ID: 23-30.50” Godpfxotiy Nto Aa Iett Coil OD: 72” Maximum Coil Weight: 40,000# Maximum Sliding Base Hydraulic Expansion Peeler and Hold Down Roll 5 Roll Coil Breaker Entry Adjustable Edge Guides Entry Crop Shear Slitting Head: 10” Arbors 40 HP Motor Drive 2 Scrap Winders Recoiler: Coil OD: 72” Max Coil ID: 24” 150HP DC Motor 3 Arm Exit Turnstile 40,000# per Arm Motorized Turn Complete Line with Knives, Rubbers, and Spacers Controls, Hydraulics, and Electrics

Year of construction: 1967, condition: good (used), strip width: 300 - 1.250 mm strip thickness: 0,5 - 3 mm blade shaft Ø: 180 mm Gtjded Ha Irjpfx Aa Ist

Condition: used, SLITTING LINE GEORG 1500x1.5x25 Main technical data Coil thickness: 0.24 – 1.5 mm Uncoiler coil weight: 25 Tn Coil width: 230 - 1500 mm Gtedpfxjxl R A Rj Aa Iot Coil outer diameter: Max. 1850 mm Working speed: 200 m/min Slitting tolerance: +/- 0.125 mm Line direction: Right to left Recoiler coil weight: Max. 16 Tn 2 Slitting heads PLC: Siemens S7 1200 Cutting capacity: number of cuts with 350 MPa 24 cuts for thickness 0.25 mm 28 cuts for thickness 0.50 mm 21 cuts for thickness 0.75 mm 18 cuts for thickness 1.00 mm 15 cuts for thickness 1.25 mm 12 cuts for thickness 1.50 mm Scope of supply 1. Coil Carriage 2. Uncoiler 3. Guiding system with 2 measured edges 4. 203.2 diam. Pinch roll before shear 5. Double interlock table 6. Slitting shear:Shaft diameter: 160 mm 7. 1 off line quick change slitting head available 8. Scrap press and conveyor 9. Intermediate coil table 10. Loop Pit and covering tables 11. Strips Braking Unit 12. Motorised recoiler with hold down separator arm 13. Unloading Coil Car 14. 4 arms turnstile 15. Electrical cabinets & Control panels 16. Existing tooling 17. Existing documentation Coil thickness: 0.24 – 1.5 mm Uncoiler coil weight: 25 Tn Coil width: 230 - 1500 mm Coil outer diameter: Max. 1800 mm Working speed: 200 m/min Slitting tolerance: +/- 0.125 mm Line direction: Right to left Recoiler coil weight: Max. 16 Tn Slitting heads: 2 PLC: Siemens S7 1200 For thickness 0.25 mm: 24 cuts with 350 MPa For thickness 0.50 mm: 28 cuts with 350 MPa For thickness 0.75 mm: 21 cuts with 350 MPa For thickness 1.00 mm: 18 cuts with 350 MPa For thickness 1.25 mm: 15 cuts with 350 MPa For thickness 1.50 mm: 12 cuts with 350 MPa

Condition: used, Year of construction: 1998, functionality: fully functional, For sale: Coil metal decoiling, slitting, and recoiling line Condition: used, connected – available for live demonstration. Designed for coil metal decoiling, precise slitting into narrower strips, and recoiling into smaller coils. Technical specifications: Year of manufacture: 1998 Made in: Poland Gtedjxlcp Nspfx Aa Iet Max. metal width: 1250 mm Knife pairs: 5 Longitudinal slitting, steel: min 0.4 mm / max 1.2 mm Film application function Scrap cutting guillotine Line includes: Decoiler 5 T Recoiler 5 T Multi-knife disc shears Braking and separating segment Turnstile with separator Control panel Purpose: The line is intended for preparation of coil metal for further processing: decoiling, precise longitudinal slitting, recoiling into smaller coils. If you have further questions – we will be happy to assist you.
