Log turning conveyor

Germany

Condition: excellent (used), A robust machine designed for punching holes in steel, aluminum, and other metals. Thanks to its foot control, it provides convenient and safe operation. Its compact design makes it suitable for both a locksmith's workshop and a production facility. Fpedpfxjzkmi De Aptsi Technical specifications: Manufacturer: Mubea (Muhr und Bender) Model: KL30 Year of manufacture: 1975 Machine number: 38601 Country of manufacture: Germany (West Germany) Power supply: 3× 220/380 V Frequency: 50 Hz Motor power: 1.5 kW Rated current: 5.8 / 3.4 A Protection rating: IP44 Control: foot pedal Punching capacity: Ø 30 mm in sheet metal with a thickness of 8 mm Ø 20 mm in sheet metal with a thickness of 12 mm (Parameters correspond to the manufacturer's nameplate for a material with a strength of approximately 45 kp/mm².) Condition: Used machine. Visual condition matches the photos. Robust, heavy-duty industrial design. Ideal for locksmith workshops, steel structure production, and workshops involved in metalworking.

Condition: refurbished (used), Year of construction: 2017, functionality: fully functional, overall weight: 120,000 kg, total height: 5,600 mm, pressing force: 1,250 t, air pressure: 6 bar, distance between side stands: 1,200 mm, distance between stands: 1,400 mm, stroke length: 500 mm, table length: 1,850 mm, table width: 1,600 mm, Straight-sided eccentric press ERFURT type PKZe 1250 Superb working condition, after full, professional overhaul. After - newer used. Specification: Capacity: 1250 ton force Slide stroke: 500 mm Slide adjustment: 215 mm Maximum shut height between bolster plate and slide (stroke down, adjustment up): 860 mm Bed area (width x depth): 1600x1850 Slide area (width x depth): 1300x1400 mm Opening in the bed (width x depth): 1100x1100 mm Main motor rating: 90 kW at 1478 RPM Ram adjusting motor rate: 7.5 kW at 1450 RPM Number of single strokes: 8 min-1 Cushion capacity: 200 ton force Fpodpfoubyrxex Aptei Cushion stroke: 200 mm Height above floor: 7900 mm Press weight: 130 000 kg.

Condition: new, Features > 5-axis simultaneous CNC machine > Basic structure made of polymer concrete > Wet/dry machining > Workpiece zero-point clamping system > Servo drives with absolute encoder > Integrated control with touchscreen Options > Machine base frame > Various Zero-point clamping devices: T-slotted plate, four-jaw chuck, precision vice and blank holder > Automatic placement system Fpedpfohqhkijx Aptji > 3D measuring probe > Why buy? Simply finance. Talk to us! The iMG 1010 is a compact solution for processing workpieces up to 100x100x100 mm. With its basic structure made of polymer concrete, it enables precise processing of numerous materials such as titanium, steel, CoCr, ceramics, sapphire, zirconium or aluminum. Particularly noteworthy is the arrangement of the Y-axis, which ensures high stability and enormous vibration damping thanks to its installation positions. Almost all positions on the workpiece can be reached without reclamping. The selection of workpiece clamping devices and holders in conjunction with the zero-point clamping system makes the machine a versatile machining center. Its design enables wet/dry machining without time-consuming retooling. The CNC machine can be extended with an optional loading and unloading system, which accesses the machine room from the right, left or from above. This allows workpieces to be changed automatically. The zero-point clamping system serves as an interface and ensures the exact and repeatable positioning of the workpiece. The system can be integrated into network-controlled, automated production processes using software interfaces. The maintenance-friendly design and the long-lasting direct spindle drives save service costs and time and offer a reliable machining system. During the design phase, care was taken to ensure that all elements are easily accessible and yet protected from external influences in order to guarantee a long service life. The sophisticated system offers numerous options for expansion.

Condition: new, machine/vehicle number: 246203 xxxx, functionality: fully functional, Ideal basis for setting up CNC machines and applications Fpodpfx Apshqmamjtji The FB2 flatbed unit is ideal for getting started with CNC technology and is ideal for model making and hobby applications. The FB2 is also often used in industry for measuring and dosing technology, as it offers extensive expansion options. The unit also offers access to the isel modular system. Various sizes from travels of 530 x 500 mm to 1030 x 1250 mm and extensions such as base frame and housing are available and can be individually combined. BEST SUITABLE FOR: • modular isel building block system • universal range of applications • easy handling • ideal for laboratory, model making and workshop use • assembly and mounting • printing and engraving • drilling and milling • dosing and screwing • forming and modeling • gluing and casting • soldering and welding • measuring and testing • sawing and cutting and much more Z-passage = 190 mm (Z-passage = 300 and 500 mm on request!) FEATURES: • durable stepper motors in the 200 W range • reliable LES units with steel ball screws are installed as drives • clamping of workpieces using a T-slotted plate • available with and without protective cover • variable gantry apertures, depending on customer application OPTIONS: • iSA milling spindles and water-cooled HF milling spindles • Cooling spray device • Cold air cooling, Cool-Min • Automatic tool length measurement • Rotation units • Workpiece clamping systems (hand lever, vacuum clamping tables, etc.) • Suction systems • LED machine room lighting • RAL color selection • CAD/CAM-Software • Diffusers 190 mm, 300 mm or 500 mm • Powerful 4-axis control controller • Underframe • Enclosure with sliding/folding door

Condition: new, Portal machine - the space miracle! CNC portal milling machine for large traverse paths with small space requirements! ADVANTAGES: -optimized space utilization, completely free table clamping area -best possible chip protection due to overhead axes -particularly suitable for high and bulky components -PILZ safety technology -Windows 10 APPLICATIONS: -chipping -measuring and testing -dosing applications FOR MACHINING: -Aluminum / light metals -Milled plastics Fpodpfx Apjhqhlvjtoi -Ceramics -Non-ferrous metals (brass, bronze, etc...) -Plastics -Wood Maximum functionality with minimum space requirements is the motto of the OverHead Gantry M. The basic machine can be optimally configured for many sectors and work areas using a variety of variable equipment features and additional options. The possible applications of the OverHead Gantry M include measuring, testing and metering applications in addition to machining. The power of the milling motor of up to 2.2 kW and 20,000 rpm and a traverse speed up to 250 mm/sec make it suitable for processing wood and plastic as well as light and non-ferrous metals. The free processing area and its excellent price/performance ratio off er decisive benefits compared to similar products. The OverHead® Gantry M is available in five different sizes for different process areas from M20 to M50. Do you require the control cabinet on the right-hand side or would you prefer the control panel to be on the left? No problem – we will be happy to accommodate your requirements. And of course we will take care of maintenance and support for your OverHead® Gantry M. Our service technicians can be reached by telephone and can attend to you quickly on-site as needed. In addition, we also off er our in-house isy-CAM 2.8 software and can advise you on your specific application. BENEFITS: -Optimal use of space -Free machining area -Fixed table, mobil portal -Variable clearance of 340- 590 mm -Also suitable for a large chip volumes SET UP: Portal: mobil, Table: Fixed

Condition: new, machine/vehicle number: 280270 0001, ADVANTAGES: compact table machine simple operability 3-axis stepper motor control with path operation Ball screws 2-phase stepper motors CNC control software included ICP series - with stepper motor drive and path control GENERAL CNC machines of the ICP series are further developments of the proven CPM series. The introduction of a sliding door means that the machines can now be operated from a seated position, which results in shorter cycle times for hood opening, among other things. The chassis is completely bolted together instead of welded as in the predecessors. This results in greater precision when setting up the machine, as well as improved serviceability. Furthermore, the resonance and vibration behavior has been optimized, resulting in lower noise levels. X = 400mm Y = 300 mm Z = 140 mm Diffuser = 200 mm -in use for over 40 years!!! -over 20,000 systems sold. HIGHLIGHTS compact table machine simple operability 3-axis stepper motor control with path operation Ball screws 2-phase stepper motors CNC control software included Mosaic Safety Circle POPULAR MATERIAL Foam Plastics ACCESSORIES Length gauge Spindles (iFM1000ER, iFM1000WS) Fpsdpfx Apjlkbpzetei Quick clamping system Spannzangen Suction device

Condition: new, machine/vehicle number: 280261 0001, Features > CNC machine ready for mains connection > Low-noise due to maintenance-free servo motors > ergonomically slim design > powerful isel control with maintenance-free servo motors > reliable linear units with steel ball screws are installed as drives > effortless operation thanks to height-adjustable display > network-compatible control PC with WINDOWS > user-friendly soft-lift hood > clamping of the workpieces by means of T-slot plate options > milling spindle 500W - 1200W > Linear tool changing station > Tool cooling as cooling spray or air version (CoolMin) > Length measuring probe > Vacuum clamping table > Maintenance unit with valve terminal > Substructure table with swivel screen and integrated keyboard > Substructure table is used to install the vacuum pump, cooling unit and other peripheral devices > Automatic hood opening > Safety light curtain > Why buy? Simply finance. Talk to us! The iCV 4030 EC is a compact tabletop machine with a proven, optimized chassis design. A practical substructure table with monitor and integrated keyboard is available as an option. The CNC machine has a modular design; all control components, including the isel CNC control and the control computer, are installed at the rear and are easily accessible for servicing. Fjdpfx Aslnikkoptjpi All linear axes mounted in the machine are from the isel range; they run with linear ball bearings on ground precision steel shafts. Backlash-free ball screw drives with various spindle pitches are used as drives. The machine table made of face-milled T-slot profiles offers a wide range of clamping options for individual workpiece fixtures and clamping devices. The iCV 4030 EC is suitable for numerous areas of application and industries; experience has shown that it is preferably used for machining. A comprehensive range of accessories tailored to your application rounds off the program.

Year of construction: 2005, condition: good (used), machine/vehicle number: 815 1015 1794, Manufacturer: CFS Germany GmbH Type: JuniorPak M420 Year of manufacture: 2005 Voltage: 400 V Phases: 3-phase + N + PE Current: 29 A Power: 20 kW Frequency: 50 Hz Weight: 2200 kg This is a thermoforming machine (deep-draw machine) for the production of vacuum-packed or MAP-packed food. It is designed for medium-sized production lines and is often used for meat, cold cuts, cheese, fish, and ready meals. How the JuniorPak M420 works 1. Bottom film feeding A roll of plastic film is mounted at the rear of the machine. The film is drawn forward using conveyor chains with grippers. Common materials: APET/PE PA/PE PP PET barrier film 2. Heating The bottom film enters the heating zone. Here, the plastic is heated to approximately: 90–140 °C, depending on the material type. The temperature is controlled by electric heating plates. 3. Deep drawing This is the machine's most important process. The mold closes. Then, usually: vacuum is applied under the film compressed air is applied above the film, if required the film is drawn down into the mold The result is finished plastic containers or trays. The forming depth is determined by the mold. 4. Filling zone After forming, the process stops. Operators or automatic equipment place the product in the trays. Examples: meat burgers bacon cheese fish 5. Top film A new film is fed in from above. This lies over the product. 6. Vacuum/MAP The sealing chamber closes. The machine can: create a vacuum flush with gas seal directly In MAP, the following are often used: CO₂ N₂ O₂ The gas mixture depends on the product. 7. Sealing The top film is sealed to the bottom film. Sealing occurs with: temperature pressure time These three parameters are crucial for a tight seal. 8. Cutting The cutting tool cuts each individual package. Excess film is transported out as scrap. 9. Ejection Finished packages are transported out onto a conveyor belt. They can then: be labeled be weighed be checked with a metal detector be packed in boxes A JuniorPak M420 normally consists of: Frame made of stainless steel Film transport with chains Heating station Forming station Filling zone Vacuum/MAP chamber Sealing tool Cutting tool Ejection conveyor Vacuum pump Pneumatic system Hydraulics (on some models) PLC control with HMI Typical technical data For the M420 series, typical values are: Maximum film width: approx. 420 mm Forming depth: up to approx. 100–120 mm, depending on the tool Fodpfx Apszka Rujtjpi Cycle time: 5–15 cycles/min Capacity: from a few hundred to several thousand packages/hour, depending on the product and tool Connection: 400 V 3-phase Power: 20 kW (as shown on the nameplate)

Condition: excellent (used), For sale: professional tool holder from the renowned brand WNT Germany – model B40 ER16M A=100. The holder is equipped with a Centro-P Germany HPC16MS-DI precision collet, ensuring maximum accuracy and clamping stability. The set also includes a VHM drill, making it ready for immediate use on a CNC machine. Condition: very good, the holder is fully functional, no play, with normal signs of use. Premium-class equipment – ideal for professional machining centers where precision and reliability are crucial. Fpodpfxow Rr A Do Aptei

Condition: excellent (used), For sale: a complete set of professional measuring stations from the renowned German brand ULTRA Germany, models: • ART. 27484-032 – POS. 12 • ART. 27484-033 – POS. 10 • ART. 27484-030 – POS. 8. The devices are designed for precise positioning, inspection, and calibration of mechanical and measuring components in production and quality control processes. An ideal solution for measurement laboratories, quality departments, research centers, or tool shops requiring high repeatability and accuracy. • Construction made of high-quality steel and aluminum – robust, stable, and durable • Precision linear guides ensure smooth movement and high measurement accuracy • Height adjustment and holder locking for quick adaptation to the tested component • Capability to mount dial indicators, holders, and other measuring accessories • A reliable solution for series measurements and part positioning in production processes. Condition: used, in very good technical and visual condition – devices are fully functional, sourced from a quality control department. Price refers to Fpodpsxltn Asfx Aptoi
