Jig

GF AgieCharmilles Spirit 4

Condition: refurbished (used), Year of construction: 2008, functionality: fully functional, travel distance X-axis: 700 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 400 mm, workpiece weight (max.): 2,000 kg, quill stroke: 400 mm, distance table to quill: 215 mm, workpiece length (max.): 920 mm, workpiece width (max.): 550 mm, workpiece height (max.): 550 mm, overall weight: 4,000 kg, Sinker EDM machine GF AgieCharmilles Spirit 4 Year of manufacture: 2008 Travel ranges (X/Y/Z): 700 x 500 x 400 mm Max. workpiece dimensions: 920 x 550 x 370 mm Max. workpiece weight: 2000 kg Distance table - quill: 215 - 615 mm Bath level up to 415 mm Includes pneumatic chuck of the 3R system or Erowa ITS 50 (customer’s choice) Includes 15-position electrode changer in magazine Max. electrode weight: 80 kg Includes C-axis with U = 0-40 rpm Pedjz D Apdspfx Ai Tsrc Total weight (without dielectric fluid): 4000 kg Dimensions: 3000 x 3000 x 2865 mm After receiving your order, the machine will be cleaned, serviced, and tested by us. We would be pleased to offer you the following additional services and products: - Commissioning - Transportation - Training - Clamping devices - Dielectric fluid - Cooling unit

Condition: refurbished (used), Year of construction: 2008, functionality: fully functional, travel distance X-axis: 550 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 350 mm, workpiece weight (max.): 1,000 kg, workpiece length (max.): 760 mm, workpiece width (max.): 450 mm, workpiece height (max.): 255 mm, overall weight: 4,000 kg, Wire EDM machine GF AgieCharmilles Spirit 3 Year of manufacture: 2008 Travel ranges (X/Y/Z): 550 x 400 x 350 mm Max. workpiece dimensions: 760 x 450 x 255 mm Max. workpiece weight: 1000 kg Distance table - quill: 170-520 mm Bath level up to 295 mm Includes pneumatic chuck of the 3R system or Erowa ITS 50, selectable Includes 10-position electrode changer in the magazine Max. electrode weight: 50 kg Includes C-axis with U=0-40 RPM Total weight (without dielectric fluid): 3300 kg Prsdszcawmepfx Ai Tec Dimensions: 2800 x 2800 x 2690 mm After receiving your order, we will clean, service, and test the machine. You will then receive a 6-month warranty on the machine. We would be happy to provide you with free training on the machine at our facility. We would also be pleased to offer you the following additional services and products: - Commissioning - Transport - On-site training - Clamping devices - Dielectric fluid - Cooling unit
