Centerless grinder cnc

GHIRINGHELLI M250 SP610

Condition: excellent (used), Control SIEMENS 840D Lsdpfx Ajyrhl Rjiqshl

Condition: excellent (used), Year of construction: 2014, functionality: unexamined, workpiece weight (max.): 2,500 kg, total width: 3,200 mm, total length: 15,800 mm, distance between centers: 6,000 mm, workpiece diameter between centers: 850 mm, overall weight: 19,000 kg, We offer this very good Hol-Monta spol.sro UB 85 / 6000 CNC cylindrical grinding machine, year of construction 2014. Model: UB 85 / 6000 CNC Control type: Kavalir K 51-2 Serial number: H 214 09 005 Swing dia. 850 mm Center distance 6 000 mm Internal Grinding attachment Lhjdpoy Hgrgofx Aiqel Steadyrests etc.

Condition: good (used), Year of construction: 2014, Offered here is a centerless cylindrical grinding machine from the manufacturer Tschudin, including automation. The machine is in very good condition and can be inspected upon request. Technical data – see PDF. Lhjdpfx Aisx Urh Aoqel

Condition: used, Year of construction: 1975, workpiece diameter 125 mm grinding depth 50 mm clamping length 2000 mm total power requirement 0,5 kW weight of the machine ca. 1000 kg dimensions of the machine ca. m T E C H N I C A (Switzerland) Centre Hole Grinding Machine Model ZSM 5100 – 2.000 Year approx.. 1975 S/N 66 32 7872 – J 3278 _____ Distance between centres 50 – 2.000 mm Height of centres approx. 125 mm Workpiece Ø in clamping Vice 8 – 125 mm Swing of workpiece over tailstockguide 290 mm Swing of Workpiece max. over grinding head pillar 300 mm ght of workpiece 250 kg Max. centre hole taper Ø 2 – 50 mm Max. centre hole taper angle 60 ° Lhjdpfx Asvanrcoiqol Clamping range of vice approx. 5 – 160 mm Grinding head adjustable in vertical axis 160 mm Stroke of grinding tool on workpiece 0.75 – 5 mm Grinding tool Ø 15 – 60 mm Grinding spindle speeds 13,000 – 45,000 rpm Total electrical load, approx. 1 kW - 380 V - 50 Hz Weight, approx. 1.000 kg Accessories / Special Features Machine is suitable for workpiece length up to 2.000 mm with a basement extension * A cone shaped grinding wheel is employed, but it is only in line contact with the centrehole surface, in addition it is reciprocating simultaneously along this line. The workpiece remains stationary, enabling the generation of perfect centre holes. * To clamp cylindrical Workpieces one uses a height adjustable 2 jaw vice which gives three point contact and always coincides with the center of the grinding spindle. * Height-adjustable workpiece centering vice with carbide inserts. Manual adjustment of appropriate workpiece diameter with clamping screw. * Dressing device, mounted on the side of the grinding spindle, stroke approx. 40 mm, for producing a geometrically exact conical form and with oscillation of diamond tool. * Pre-centering device for Workpiece adjustment between centers. * Pneumatic Oil Lubrification of grinding spindle by oil-mist. * Manually adjustable Tailstock with handwheel but without motorized drive. Condition : Good to very good. Machine can be inspected under power. Delivery : Ex stock, as inspected Payment : Net, after conclusion of contract

Condition: excellent (used), Year of construction: 1981, Description to follow! Lsdoynmn Aspfx Aiqehl

Condition: excellent (used), Year of construction: 2000, Description to follow! Lhedpfx Asyrtwxoiqol

Condition: used, Year of construction: 1995, grinding diameter 350 mm Lsdpfx Aijxyadaeqjhl grinding length 1000 mm centre height 175 mm Completely overhauled in 2013 Heavy duty workpiece headstock tailstock Without chuck and without bezel in the photo Kelco 90 control The machine can be viewed in operation at the customer's premises from 2025 up to and including January 2026.

Condition: used, KELLENBERGER KEL-VARIA RS 175 / 1000 is a CNC cylindrical grinder engineered for high precision, delivering exceptional accuracy and industrial reliability. Key capacities: centre height 175 mm, distance between centres 1000 mm, max. grinding diameter 349 mm; right-hand wheel Ø500×80 mm bore 127 mm; Z axis 1150 mm, X axis 320 mm; workpiece weight on centres up to 150 kg. Main specs: wheel speeds 1500–1800 rpm, peripheral speed 32 m/s, automatic indexing 0.1°; rapid feed 10 m/min; work spindle stepless 5–500 rpm, taper 5 CM (rotatable -30/+120°); tailstock taper 4 CM stroke 50 mm; table speed up to 8 m/min; max table angle 9°; grinding spindle motor 7.5 kW, work spindle motor 3 kW; 50 Hz 3x380 V; air 4 bar; machine weight ≈6000 kg; footprint L3600×W2000 mm. Accessories: coolant system, MARPOSS touch probe and measuring head, Positionar Passiv, grinding wheel with flange, lamp, tailstock with fine adjustment. Achieves tight tolerances; suitable for automotive, watchmaking, machine tools, aerospace and medical a Lhedpfx Aszv I I Soiqol
