Condition: used, Year of construction: 1999, functionality: fully functional, Manufacturer: MORI SEIKI Model: MH 770 C Gjdpjz Aktkjfx Adtsug Year: 1999

Condition: excellent (used), Year of construction: 2007, BA 600-2 CNC, Horizontal Milling and Drilling Center SW Schwäbische Werkzeugmaschinen GmbH Travel: X axis: 600 mm Y axis (changeover position): 600 (975) mm Z axis: 500 mm Control: Siemens 840D control, side-mounted Feed/Rapid traverse speeds: X, Y, Z: 1 – 45,000 mm/min Max. feed force X, Y, Z: 15,000 N Average acceleration: X, Y, Z: 2.5 m/s² Measuring system: Direct measuring system X, Y, Z Spindles: Spindle speed (infinitely variable): 20–10,000 rpm Torque: 2 x 363 Nm (S6/40% duty cycle) Power: 2 x 38 kW (S6/40% duty cycle) HSK-A 100, horizontal tandem arrangement Spindle distance: 600 mm Spindle bearing diameter: 100 mm Motor spindles, liquid-cooled, AC technology Working area: Swing carrier with spur gearing, max. workpiece weight 2,000 kg Swivel time 0/180 degrees approx. 6.0 sec 2 NC rotary tables, hydraulically clamped, max. workpiece weight 700 kg, table speed 25 rpm Partition between machining and loading area Tool magazine: 2 x 50 tools HSK-A 100 chain-type magazine Tool change time (chip-to-chip): 4.48 sec Max. tool diameter: 100 mm 250 mm with adjacent slot free Max. tool length: 420 mm Max. tool weight: 20 kg Equipment: Central lubrication Oil minimum quantity lubrication (spindle lubrication) Chip conveyor (hinged belt conveyor) Coolant purification with compact band filter Hydraulic unit Maintenance unit Water recooler Full enclosure, crane loading possible Dimensions: approx. 5.15 x 8.50 x 4.20 m Weight: approx. 20,000 kg Year of manufacture: 2007 Guodez Ahmzepfx Adtjg Other features: Very good condition Setup parallel to main time Available from December 2023/January 2024

Condition: used, Year of construction: 2014, functionality: fully functional, total height: 3,250 mm, total length: 5,200 mm, total width: 3,700 mm, overall weight: 20,000 kg, SW Swabian Machine Tools BA W06-22 CNC control: Siemens SINUMERIK 840 D sl Working area X-axis: 600 mm Y-axis (swiveling): 630 mm (920 mm) Z-axis: 510 mm Spindle distance, fixed (variable)*: 600 mm (590 mm - 651 mm) Workpiece clamping Swiveling table/counter bearing with helical toothing: swiveling time 0/180°: approx. 3.4 s A and U axes, prepared for mounting of clamping bridges, up to max.: Ø 675 mm x 1,430 mm Drive system: Torque motor Transport load: 2 x 600 kg (720 kg)* Speed range A, U axes: 1 - 50 min-1 Working spindle HSK-A63 Speed range: 1 - 17,500 min-1 Acceleration time 0 - nmax: < 0.65 s Spindle bearing Ø: 80 mm Gujdpszz Sdnsfx Adtog Power / Torque (40% ED): 2 x 35 kW / 80 Nm (40% ED) Feed drive Drive system: Linear motor Rapid traverse X / Y / Z: 120 m/min Axis acceleration X / Y / Z: 12 / 10 / 24 m/s2 Max. feed force X / Y / Z: 10,000 / 10,000 / 2 x 5,000 N Accuracy Path measurement: Direct, absolute Position tolerance X / Y / Z: Tp = 0.006 mm Tool magazine Tool changing system: Pick-up Capacity: 2 x 42 (2 x 72 / 2 x 108)* Max. tool Ø: 80 / 200 mm (-o-) Max. tool length: 425 mm Max. tool weight: 10 kg Tool change time, chip-to-chip: approx. 2.25 s Weight / Dimensions Machine weight: approx. 20,000 kg Transport dimensions W x H x D: 3.70 m x 3.25 m x 5.20 m Installation dimensions W x H x D: 4.80 m x 3.50 m x 7.50 m Connection power Operating voltage: 3 x 400 Volt, 50 Hz, TN-S/TN-C network Total connection power: approx. 133 kVA Average air consumption: 0.6 Nm³/min (5.5 bar) Several machines are available. The machines were integrated into an automation system. They were loaded by a robotic system. They were connected to a central coolant system. Therefore, these machines do not have their own coolant system. Chips were also removed via a central disposal system.

Condition: used, Year of construction: 2019, functionality: fully functional, total height: 3,000 mm, total length: 4,850 mm, total width: 2,780 mm, overall weight: 12,500 kg, Technical Data BA one 6 CNC Control: SINUMERIK 840D sl Working Area X-axis: 600 mm Y-axis: 650 mm (adjustable to 925 mm) Z-axis: 500 mm Workpiece Clamping: A/U Swivel carrier/counter bearing with helical gearing: Swivel time 0/180°: approx. 3.5 s A and U axes, prepared for mounting of clamping bridges, up to max.: Ø 725 mm x 830 mm Drive system: Torque motor Transport load: 2 x 450 kg Speed range A/U axis: 10 - 50 min-1 C/W axis, single*: can be upgraded to modular A/U Transport load C/W: 150 kg each Main Spindle: HSK-A63 Speed range / acceleration time 0 - nmax: 1 - 17,500 min-1 / < 0.7 s Spindle bearing Ø: 80 mm Power / torque (40% ED): 35 kW / 80 Nm Feed Drive Drive system: Linear motor Rapid traverse X / Y / Z: 100 / 120 / 100 m/min Axis acceleration X / Y / Z: 10 / 12 / 22 m/s² Max. feed force X / Y / Z: 8,000 / 16,000 / 8,000 N Accuracy Path measurement: Direct, absolute Position tolerance X / Y / Z: Tp = 0.006 mm Tool Magazine Tool changing system: Pick-up Capacity: 30 (60)* (105)* (155) (*optional, upon request) Max. tool Ø: 85 mm / 160 mm (-o-) -o- multiple magazine slot occupancy Max. tool length: 450 mm Max. tool weight HSK-A63: 10 kg Tool change: Chip-to-chip time approx. 2.5 s Weight / Dimensions Machine weight: approx. 12,500 kg Transport dimensions W x H x D: 2.78 m x 3.00 m x 4.85 m Installation dimensions W x H x D: 3.75 m x 3.75 m x 7.4 m Connection power Operating voltage: 3 x 400 Volt, 50 Hz, TN-S/TN-C network Total connection power: 100 kVA Average air consumption: 0.4 Nm³/min (5.5 bar) 2 + 1 machines are available. The machines were integrated into an automation system. Gujdszz N Tgspfx Adtjg They were loaded by a robotic system. They were connected to a central coolant system. Therefore, these machines do not have their own coolant system. Chips were also disposed of via a central system.

Condition: used, Year of construction: 2008, Deckel Maho DMC 55H duoBlock Horizontal Machining Center – Copy" Horizontal Machining Center Deckel Maho Type / Model: DMC 55 H DuoBlock Year of Construction: 2008 Condition: Used Program Runtime: approx. 61,600 h Spindle Runtime: approx. 44,700 h Technical Data Travel ranges X / Y / Z axes: 560 mm / 600 mm / 600 mm Rapid traverse rate (X/Y/Z): 40 m/min Work table & Pallet Changer (APC) Number of pallets: 2-position pallet changer Pallet size: 400 mm x 400 mm Max. workpiece weight: 500 kg Max. workpiece height: 850 mm B-axis (rotary table): 360° (designed as an NC rotary table, usually with 0.001° indexing) Main spindle: 12,000 1/min; HSK 63; approx. 38 kW Tool Changer (ATC) Tool magazine: 40 magazine positions Tool holder: HSK-A63 Max. tool diameter: 80 mm (up to 160 mm with free neighboring positions) Max. tool length: 330 mm Electrical Data Power connection: 400V 3/N, PE 50Hz Gedpfxszzc Eve Adtjug Power consumption: 58 kVA Inrush current: 84 A Max. fuse rating: 100 A DC control voltage: 24 VDC Auxiliary voltage: 230 VAC Dimensions, Weight & Control Machine weight: approx. 11,000 kg to 13,000 kg (depending on magazine size and chip conveyor) Footprint (L x W x H): approx. 5.0 x 3.0 x 2.8 m (pure space requirement without peripherals) Control system: Siemens Sinumerik 840D Equipment NC rotary table Tool measurement system BLUM Mist and fume extractor IIFE-2000 Hydraulic clamping system Proportional amplifier Handwheel BHG Signal light Coolant system 980l Coolant nozzle Rotoclear Chip conveyor Master probe OMP60 Operating mode 4 Quotation item: Transport costs in a separate offer.

Condition: used, Year of construction: 2012, machine/vehicle number: 51357, overall weight: 14,000 kg, No minimum price – guaranteed sale to the highest bidder! The machines are still assembled but disconnected from the power supply. An 11-ton forklift is available on-site for loading. For sale is a horizontal machining center manufactured by Samag, model: SM. TECHNICAL DETAILS Type of machining: Internal machining MACHINE DETAILS Guodpezy Ui Rofx Adtog Total weight: 14,000 kg

Condition: excellent (used), Year of construction: 2007, operating hours: 41,759 h, functionality: fully functional, machine/vehicle number: NH502GC0313, Equipment: chip conveyor, documentation/manual, CNC controller: MSX-701iA Axes X-axis travel mm: 630 Y-axis travel mm: 600 Z-axis travel mm: 670 B-axis travel degrees: 360º (indexing 1º) Number of pallets: 2 Table dimensions mm: 500x500 Spindle Spindle speed rpm: 14,000 Tooling system Tool holder: BT40 Number of tool positions: 120 (60+60) Guodpezyfyysfx Adteg Equipment Chip conveyor Warning light Knoll system, 750 liters Internal coolant supply

Condition: ready for operation (used), Year of construction: 2011, travel distance X-axis: 560 mm, travel distance Y-axis: 630 mm, travel distance Z-axis: 640 mm, total height: 2,791 mm, total width: 2,160 mm, overall weight: 9,500 kg, spindle speed (max.): 18,000 rpm, spindle motor power: 30,000 W, number of slots in tool magazine: 40, tool weight: 8,000 g, product length (max.): 4,463 mm, number of axes: 4, This 4-axis Mazak NEXUS 4000 II was manufactured in 2011. It features an X-axis travel of 560 mm, Y-axis travel of 630 mm, and Z-axis travel of 640 mm. The machine has a maximum workpiece diameter of Ø630 mm and a weight capacity of 400 kg. If you are looking to get high-quality machining capabilities, consider the Mazak NEXUS 4000 II horizontal machining centre we have for sale. Contact us for further details. • Travels • Rapid traverse (X/Y/Z): 60,000 mm/min • Max. cutting feed: 60,000 mm/min • Workpiece capacity • Max. workpiece diameter: Ø630 mm • Max. workpiece height: 900 mm • Max. workpiece weight: 400 kg • Pallet / Table • Pallet size: 400 × 400 mm • Standard pallet changer: 2 pallets • Pallet change time: 6 sec • Standard B-axis indexing: 1° × 360 positions • B-axis indexing time: 1.3 sec / 90° • Optional NC positioning table: 0.001° Gusdpfx Aezx U H Tsdtjg • Optional NC rotary table: 0.0001° • Pallet positioning repeatability: ≤4 µm • Spindle (two configurations) • 12,000 rpm high-torque spindle • 30 kW / 30 min; 22 kW continuous • Max. torque: 300 Nm • 18,000 rpm high-speed spindle • 35 kW / 30 min; 26 kW continuous • Max. torque: 168 Nm • Spindle speed range: 35–12,000 rpm or 35–18,000 rpm (depending on version) • ATC / Tool magazine • Standard magazine: 40 tools • Optional: 60 / 80 / 120 / 160 tools • Tool holder: ISO BT40 • Max. tool diameter: Ø95 mm • Max. tool diameter without adjacent tools: Ø150 mm • Max. tool length: 420 mm • Chip-to-chip time: 2.7 s with tools

Condition: excellent (used), Year of construction: 2004, Year 2004 With 8 station Fastem pallet loading system with tombs Tooling & manuals 12,000rpm 40 ATC Gedpfx Aozxr Twodtsug DIN40 / Renishaw probing Pallet size 400mm x 400mm

Condition: used, Year of construction: 2009, operating hours: 25,000 h, functionality: fully functional, Control system: MSX-701 IV (based on Fanuc) Spindle hours: approx. 18,400 Gsdpfx Ajzxrawedteug Work area & travel ranges Travel range X/Y/Z: 560/560/630 mm Pallet size: 400 × 400 mm Max. workpiece dimensions (D × H): Ø 630 mm × 900 mm Max. pallet load: 400 kg B-axis (table indexing): 1° (standard) or 0.001° full NC (DDM option) Main spindle & drives Spindle speed (standard): 14,000 rpm Tool holder: SK-40 and BT-40 Spindle power (30 min / continuous): 18.5 kW / 11 kW Max. spindle torque: 120 Nm Rapid traverse rate (X / Y / Z): 50 m/min Max. feed rate: 50 m/min Number of tool positions in the magazine: 120 Max. tool weight / length: 8 kg / 400 mm

Condition: used, Year of construction: 2003, functionality: fully functional, For sale: OKUMA MB-500H CNC Horizontal Machining Center Year of manufacture: 2003 Reliable and robust Japanese horizontal machining center equipped with an automatic 2-pallet changer, through-spindle coolant, and chip conveyor. The machine is in working condition and can be inspected under power at our facility in Croatia. TECHNICAL DATA Manufacturer: OKUMA Model: MB-500H Year: 2003 Machine type: CNC Horizontal Machining Center CNC control: OKUMA OSP WORKING AREA X-axis travel: 800 mm Y-axis travel: 800 mm Z-axis travel: 800 mm Distance from pallet surface to spindle center: 70 – 870 mm Distance from pallet center to spindle nose: 150 – 950 mm PALLET / TABLE Number of pallets: 2 Pallet size: 500 × 500 mm Maximum pallet load: 500 kg Pallet changer: Automatic rotary pallet changer (APC) Table indexing: 1° Pallet surface: 24 × M16 tapped holes Guedpfx Aezxq Itedtog The automatic 2-pallet system allows the next workpiece to be set up while the machine is running, significantly reducing non-productive setup time. SPINDLE Spindle speed: 50 – 15,000 rpm Spindle taper: SK40 / MAS 403 SK40 Spindle motor power: 26 kW / 18.5 kW continuous Spindle bearing diameter: Ø70 mm Through-spindle coolant (TSC) AUTOMATIC TOOL CHANGER Magazine capacity: 40 tools Tool holder: MAS SK40 Tool selection: Memory random Maximum tool diameter: Ø75 mm Maximum tool diameter without adjacent tools: Ø145 mm Maximum tool length: 350 mm Maximum tool weight: 8 kg FEED RATES Rapid traverse: up to 90 m/min Cutting feed rate: 1 – 60,000 mm/min EQUIPMENT Automatic 2-pallet changer (APC) 2 × 500 × 500 mm pallets Through-spindle coolant (TSC) Chip conveyor Automatic tool changer 40-tool magazine BT40 spindle Full machine enclosure Coolant system CONDITION The machine has been used in our own production and has been regularly maintained. Machine is fully operational and can be inspected under power. Location: Croatia Inspection and test run are possible by appointment. Additional photos, videos, and information are available on request. Loading/transport can be discussed separately. Price: on request / negotiable

Condition: used, Year of construction: 2012, Deckel Maho NHX 4000 Horizontal Machining Center Horizontal Machining Center, Deckel Maho Type / Model: DMG NHX 4000 Condition: Used Year of Manufacture: 2012 Program Runtime: approx. 48,200 hours Spindle Hours: approx. 39,200 hours Technical Data Travel distances X / Y / Z axis: 560 mm / 560 mm / 660 mm Rapid traverse rate (X/Y/Z): 60 m/min Work table & Pallets: 2-way pallet changer, standard (APC) Pallet size: 400 x 400 mm Max. workpiece weight: 400 kg Max. workpiece dimensions (Ø x H): Ø 630 x 900 mm Pallet changing time: approx. 8.0 seconds B-axis (rotary table): 360° (division 0.001°, direct drive) Main spindle Max. speed: 12,000 rpm Drive power: approx. 11 kW Max. torque: approx. 110 Nm Tool interface: SK 40, tool changer STC Tool changer (ATC) Magazine slots: 60 magazine slots Max. tool diameter: 70 mm (with free adjacent slots up to 170 mm) Max. tool length: 450 mm Max. tool weight: 12 kg Electrical data Power connection: 400 V 3/N, PE 50 Hz Power consumption: 33 kVa In max.: 48 A Max. fuse rating: 80 A DC control voltage: 24 VDC AC supply voltage: 230 VAC Equipment 1: Smartline Line 36kW Equipment 2: NX15 Dimensions & Weight Machine weight: approx. 8,000 kg Footprint / Dimensions (W/D/H): approx. 2,680 x 2,540 mm Control: Siemens 840D SL Equipment Indexing table Tool measuring system, 60 tools SK40 Direct measuring system Tool breakage control MSC Coolant system IKZ 35 bar Chip conveyor Signal light Inquiry item: Transportation costs in individual offer Guodpfszxc H Usx Adtog

Condition: used, Year of construction: 2008, Deckel Maho DMC 55H duoBlock Horizontal Machining Center Horizontal Machining Center – Deckel Maho Type / Model: DMC 55 H DuoBlock Year of Construction: 2008 Condition: Used Program Run Time: approx. 66,600 hours Spindle Run Time: approx. 46,500 hours Technical Data Travel Ranges X / Y / Z Axes: 560 mm / 600 mm / 600 mm Rapid Traverse (X/Y/Z): 40 m/min Work Table & Pallet Changer (APC) Number of Pallets: 2-position pallet changer Pallet Size: 400 mm x 400 mm Max. Workpiece Weight: 500 kg Max. Workpiece Height: 850 mm B-Axis (Rotary Table): 360° (designed as an NC rotary table, usually with 0.001° resolution) Main Spindle: 12,000 1/min; HSK 63; approx. 38 kW Tool Changer (ATC) Tool Magazine: 40 magazine positions Tool Interface: HSK-A63 Max. Tool Diameter: 80 mm (up to 160 mm with free neighboring positions) Max. Tool Length: 330 mm Electrical Data Power Connection: 400V 3/N, PE 50Hz Power Consumption: 58 kVA Inrush Current: 84 A Max. Pre-Fuse: 100 A DC Control Voltage: 24 VDC AC Supply Voltage: 230 VAC Dimensions, Weight & Control Machine Weight: approx. 11,000 kg to 13,000 kg (depending on magazine size and chip conveyor) Guodpfjzxc Ewjx Adtog Footprint (L x W x H): approx. 5.0 x 3.0 x 2.8 m (pure space requirement without peripherals) Control: Siemens Sinumerik 840D Equipment NC rotary table Tool measurement system BLUM Oil mist separator IFE-2000 Hydraulic clamping system Proportional amplifier Signal light Coolant system 980 l Coolant gun Rotoclear Chip conveyor Master probe OMP60 Operating mode 4 Quotation item: Transport costs in a separate offer

Condition: ready for operation (used), Year of construction: 2015, CNC Control: F31iA X mm: 560 Y mm: 560 Z mm: 630 B mm: 360.000 Table load capacity kg: 400 Cutting feed rate mm/min X, Y, Z: 50,000 Maximum rapid traverse rate m/min X, Y, Z: 50 Spindle speed rpm: 14,000 Spindle power kW: 18.5 Taper type: ISO-40 Torque Nm: 120 Tool changer type: Chain Guodpfx Adezu Tryotog Number of positions in tool changer: 60 Maximum tool diameter: mm 70 Maximum tool diameter with adjacent positions empty: 140 Maximum tool length mm: 400 Maximum tool weight kg: 8 Coolant tank capacity l: 500 Through-spindle coolant: Yes

Condition: ready for operation (used), Year of construction: 2011, operating hours: 31,113 h, functionality: fully functional, machine/vehicle number: NHX40KB0083, travel distance X-axis: 560 mm, travel distance Y-axis: 560 mm, travel distance Z-axis: 660 mm, controller model: MITSUBISHI MSX-853 IV, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Travel range, X-axis: 560 mm Travel range, Y-axis: 560 mm Travel range, Z-axis: 660 mm Gujdpfx Adezrl H Rstog Feed rate: 0–60 m/min Distance from spindle nose to table surface: 80–640 mm Number of pallets: 2 Pallet dimensions: 400 × 400 mm Table length: 400 mm Table width: 400 mm Max. workpiece length: 630 mm Max. workpiece width: 630 mm Max. workpiece height: 900 mm Max. workpiece diameter: 630 mm Max. workpiece size: Ø 630 × 900 mm Max. workpiece weight: 400 kg Pallet changing time: 9 s Max. spindle speed: 12,000 rpm Spindle drive power: 15/11 kW Spindle torque: 110 Nm Spindle bearing inner diameter: 80 mm Spindle type: SJ-2B4351TK Tool positions: 40 Max. tool diameter: 70 mm Max. tool diameter with free neighboring positions: 170 mm Max. tool length: 450 mm Max. tool weight: 8 kg Tool holder: MAS-BT40 MACHINE DETAILS Control system: MITSUBISHI MSX-853 IV Rated power: 38 kVA Total power consumption: 38 kVA Dimensions & Weight Dimensions (L x W x H): 2,720 x 4,224 x 2,513 mm Total weight: 7,600 kg Coolant tank capacity: 170 l High-pressure coolant: 15 bar Operating hours Hours under power: 64,734 h Operating time: 31,113 h EQUIPMENT Chip conveyor Work area light 4th axis Cooling High-pressure cooling 2-pallet changer

Condition: used, Year of construction: 2012, 1 used 4-axis horizontal machining center Manufacturer: DMG Type: NHX 4000 Year of construction: 2012 Control: Siemens 840D SL Operate Technical details: X-axis travel: 560 mm Y-axis travel: 560 mm Z-axis travel: 660 mm Gujdpfjzq R Tmjx Adtsg Spindle speed: 20 - 12000 rpm Spindle motor: 25/35 kW Torque at the spindle: 86 / 130 Tool holder: SK 40 Number of tool magazine positions: 40 Maximum tool diameter: 70 mm Tool diameter with free adjacent positions: 170 mm Tool length - max.: 450 mm Maximum tool weight: 12 kg Pallet size: 400 x 400 mm Number of pallets: 2 Workpiece diameter - max.: 630 mm Workpiece height - max.: 900 mm Table load: 400 kg Rapid traverse rates x/y/z: 60 m/min Feed rates x/y/z: 60 m/min Internal coolant supply: 70 bar Machine weight approx.: 8.5 t Overall dimensions: 3200 x 4800 x 2900 mm Equipment: Production package with internal coolant supply (IKZ) at 40 bar

Condition: excellent (used), MATSUURA H. PLUS 300 is a Horizontal machining center with high precision, excellent accuracy and reliability. Travels X/Y/Z 500 mm; workpieces Ø 530 mm, h 700 mm; pallets 300×300 mm (10), max workpiece 250 kg, change 7 s. Spindle BT40 50–15,000 rpm, 95.4 Nm, 15/22 kW; feeds 1–50,000 mm/min, rapid 50 m/min; 3×380 V 50 Hz; weight ≈7000 kg; dims 3660×2463×2445 mm. Tool magazine 90 pos., tool change 2 s, chip-to-chip 2.9 s. Coolant 1500 l, chip conveyor, toolholder set, spindle oil cooler. Suited to tight tolerances in automotive, aerospace, medical, watchmaking and mould/die. Gjdpfx Ajzqblysdteug

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, travel distance X-axis: 560 mm, travel distance Y-axis: 610 mm, travel distance Z-axis: 625 mm, Machine type: Horizontal machining center Manufacturer: OKUMA Type: MA-400HA Year of manufacture: 2008 Control system: OSP P200M Country of origin: Japan Delivery time: short-term, by arrangement 4-axis machining center, high productivity, including various accessories Machine equipment: - ConSep chip conveyor system with high-pressure pump - Various software packages - Touchsetter with length measurement and breakage detection Gsdpfxozm U Ndo Adtoug - Work area shower Technical details: - Travels - Axes X-axis (column right-left) mm 560 Z-axis (table forward-backward) mm 625 Y-axis (spindle up-down) mm 610 B-axis 1° 0 - 360° - Number of pallets: 2 (pallet changer for 2 pallets) - Pallet size (mm): 400 x 400 - Max. pallet load capacity (kg): 400 - Max. pallet workpiece dimensions (mm): 500/600 x 710 - Spindle speed (rpm): 15,000 - Main spindle (10min/cont): 22/18.5 kW - Tool holder: BT40 - Tool magazine: 60 positions Optional: - Transport organization and execution - Machine delivery and installation - Machine commissioning

Condition: used, Year of construction: 1998, x-travel 1800 mm Gujdpfx Adszmy Tzjtsg y-travel 1600 mm z-travel 1400 mm Control Siemens 840 C

Condition: used, Year of construction: 2012, functionality: fully functional, machine/vehicle number: 54, travel distance Y-axis: 1,100 mm, travel distance Z-axis: 1,100 mm, feed length X-axis: 1,400 mm, nominal power (apparent): 170 kVA, controller manufacturer: siemens, controller model: Siemens Sinumerik 840Dsl, workpiece length (max.): 1,100 mm, workpiece width (max.): 1,400 mm, workpiece height (max.): 1,100 mm, workpiece weight (max.): 2,500 kg, spindle speed (max.): 12,000 rpm, number of spindles: 1, number of slots in tool magazine: 150, type of input current: three-phase, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Hello, I am selling a DIXI DH 100 II: a 4-axis, dual-pallet CNC milling machine from 2012. Price: 690,000 PLN net. Machining range: X = up to 1400, Y = 1100, Z = 1100 (workpiece weight up to 2500 kg) Spindle: 12,000 RPM, 36 kW Tool holder: HSK A 100 Table: 1000x1000, 2 pcs Tool magazine: 150 positions Coolant through spindle: 70 bar Configuration: Base machine Universal horizontal machining center DIXI DHP 100 4-axis version Control system Siemens SINUMERIK 840DSL Main drive Electric spindle 12,000 RPM Gsdpfx Adszlxmdetoug Magazine 200-position tool magazine HSK 100 Machine table 2 pallets, 1000 x 1000 mm Cooling / chip removal Chip conveyor with 6 bar pump Coolant tank: 1,400 l Internal coolant supply: 70 bar Cooling unit: CSW2200 PMS Measurement / control Renishaw 3D RMP60 probe BLUM laser probe for tool measurement Additional options 2x Manual rinsing of the machining area – gun Manual control panel (handwheel) 4-color signal lamp Losma oil mist extractor 3 working modes Rotating window in the machine door Automation Automatic pallet changer Documentation Operating manual and electrical diagrams Monitor language English Training Not included

Condition: used, Year of construction: 2007, operating hours: 13,400 h, functionality: fully functional, travel distance X-axis: 450 mm, travel distance Y-axis: 775 mm, travel distance Z-axis: 450 mm, rapid traverse X-axis: 60 m/min, rapid traverse Y-axis: 60 m/min, rapid traverse Z-axis: 60 m/min, feed length X-axis: 450 mm, feed length Y-axis: 500 mm, feed length Z-axis: 450 mm, feed rate X-axis: 10 m/min, feed rate Y-axis: 10 m/min, feed rate Z-axis: 10 m/min, nominal power (apparent): 72 kVA, torque: 65 Nm, controller manufacturer: Indramat, controller model: MTC 200, total height: 3,000 mm, total length: 6,000 mm, total width: 5,500 mm, table width: 700 mm, table length: 1,100 mm, spindle speed (max.): 16,000 rpm, operating hours of spindle: 13,400 h, coolant supply: 70 bar, distance between spindles: 450 mm, spindle motor power: 28,000 W, number of spindles: 2, number of slots in tool magazine: 100, mount diameter: 63 mm, tool length: 320 mm, tool diameter: 160 mm, tool weight: 8 g, input voltage: 380 V, type of input current: three-phase, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, This machine is offered for sale as part of a package that includes two other machines of the same type and with similar operating hours. The advertised price is for the purchase of all three machines, plus a large spare parts package (including two reconditioned spindles), as well as an additional, fourth machine, which the buyer will receive free of charge. Guodpfx Adozk U Hwetjg The machines can be inspected under power at any time by appointment.

Condition: used, TECHNICAL DETAILS - Number of axes : 4 MILLING SPINDLE - Tool holder type : BBT40 - Spindle power : 22 [kW] - Spindle speeds : 13000 [rpm] - Gearbox LINEAR AXES - Travels on X/Y/Z axes : 735/610/610 [mm] B ROTARY AXIS - Travel : 360 [°] - Indexing precision : 0.001 [°] TOOL CHANGER - Auto. Tool Changer type : Bras chargeur - Tool magazine capacity : 100 PALLET CHANGER - Pallet changing device type : Rotopalette - Pallet size : 400X400 [mm] - Pallets number : 2 - Maximum weight upon pallet : 500 [kg] - Maximum workpiece diameter : 700 [mm] - Maximum workpiece height : 960 [mm] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 45 [kW] WEIGHT & DIMENSIONS - Machine floor space : 4650X3300 [mm] - Machine height : 2900 [mm] - Machine weight : 17000 [kg] Gsdpfx Adezhxxrjtjug MACHINE HOURS - Number of hours under power : 16042 [h] - Number of working hours : 5768 [h] EQUIPMENT - CNC : Fanuc 16 iMB - Interface : Ethernet / RS232 / USB / PCMCIA - Electronic handwheel - Rigid tapping - 3 colors status lamp - Coolant tank * with high-pressure pump : 70 [bars] * Coolant through spindle * With cabin washing - Chips conveyor - Spindle cooling unit - Tool probe : Renishaw - Workpiece probe : Renishaw - Electric transformer

Condition: good (used), TSUGAMI MA 3 H - 10-position pallet changer / Fanuc control - Fanuc 11-M control - Travel ranges X/Y/Z 340x280x410mm - 10-position pallet changer - B-axis 360-degree indexing, 0.001mm - Spindle speed range 35 - 5000 rpm - Feed rate range 1 - 6000 mm/min Gsdpfx Aezhgrtedtoug - Rapid traverse rate 12 m/min - Tool holder BT 40 - Tool magazine 62 positions - Dual-arm gripper - Drive power / spindle motor 7.5 KW - Electronic handwheel - RS 232 interface - Chip conveyor - Central lubrication system - Coolant system - Spindle oil cooler - Documentation Dimensions: L x W x H 4 x 2.4 x 2.4 meters / Weight 7000 kg Subject to errors and omissions.

Condition: used, Year of construction: 1996, functionality: limited functionality, travel distance X-axis: 630 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 650 mm, controller model: Fanuc MSX-516, rotational speed (max.): 12,000 rpm, The P8 power supply, valued at €1,500, was only replaced in August 2024! The spindle was repaired in 2017 and has mostly only been used for single-layer operation since then! TECHNICAL DETAILS Travel range X-axis: 630 mm Travel range Y-axis: 600 mm Travel range Z-axis: 650 mm Feed length X-axis: 630 mm Feed length Y-axis: 600 mm Feed length Z-axis: 650 mm Gjdpfezcuyiex Adtjug Table width: 500 mm Table length: 500 mm Number of pallets: 2 Maximum speed: 12,000 rpm Number of tool magazine slots: 60 (BT40) MACHINE DETAILS Control: Fanuc MSX-516 Phases: 3 Frequency: 50 Hz Voltage: AC 200 V Full load current: 181 A Note: The rapid traverse rate of the X-axis is reduced by 20% to extend the service life of the telescopic guides. The sealing ring during pallet changes is likely defective. The seller temporarily resolved this by inserting a ball valve in between when the pallets needed to be changed. EQUIPMENT Documentation/Manual Chip conveyor

Condition: ready for operation (used), Year of construction: 2001, functionality: fully functional, operating hours: 55,569 h, travel distance X-axis: 560 mm, travel distance Y-axis: 560 mm, travel distance Z-axis: 560 mm, number of slots in tool magazine: 126, controller model: Fanuc 16 MC Professional 3, spindle speed (max.): 20,000 rpm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel in X-axis: 560 mm Travel in Y-axis: 560 mm Travel in Z-axis: 560 mm Spindle speed: 20,000 rpm Torque: max. 167 Nm Tool interface: HSK-A63 DIN 69893 Tool magazine: 126 positions Tool change time: 1 s Max. tool diameter: 80 mm Max. tool length: 300 mm Distance from spindle nose to table: 150 - 710 mm Distance from table top to spindle center: 80 - 640 mm Pallet size: 400 x 400 mm Pallet load: 400 kg Pallet change time: 7 s Gusdszb Ewpjpfx Adtog Rotary table indexing: 1° Table rotation speed: 5000 rpm Spindle drive: 22 kW Feed rate: max. 40,000 mm/min Rapid traverse rate: 40,000 mm/min MACHINE DETAILS Control system: Fanuc 16 MC Professional 3 Total power consumption: 64 kW Dimensions & Weight Footprint: approx. 9.0 x 3.0 x 2.8 m Machine weight: approx. 15 t Operating hours Spindle hours: 55,569 h Program runtime: 66,600 h Power-on time: 163,411 h
