Condition: excellent (used), Year of construction: 2018, functionality: fully functional, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,100 mm, travel distance Z-axis: 900 mm, feed rate X-axis: 20 m/min, feed rate Y-axis: 20 m/min, feed rate Z-axis: 20 m/min, table length: 2,100 mm, table width: 1,100 mm, rotational speed (min.): 10 rpm, rotational speed (max.): 10,000 rpm, Equipment: rotational speed infinitely variable, CNC Gantry Milling Machine Gualdoni GDV-400 – Year 2018 – Fully Functional – Turin (TO) Gualdoni GDV-400 CNC gantry milling machine, year 2018, in good condition and fully operational. Fixed gantry structure with longitudinal moving table, ideal for machining large workpieces. Available for inspection and testing by appointment in Turin. Main technical data: Hsdpfjy A Tuyjx Ad Hsff - X-axis travel (longitudinal): 2,000 mm - Y-axis travel (cross): 1,100 mm - Z-axis travel (vertical): 900 mm - Table dimensions: 1,100 × 2,100 mm - Installed power: approx. 45 kW - Spindle speed: 100 – 10,000 rpm (stepless adjustment) - Tool holder interface: ISO 40 (DIN 69871) - Rapid traverse X/Y/Z: 20,000 / 20,000 / 20,000 mm/min - Feed rates: 10 – 5,000 mm/min - ATC tool magazine: 24 positions – 4 sec tool change - Max tool diameter: 106 mm | Max length: 300 mm - CNC control: FAGOR (ISO + conversational) - 3 controlled axes: X – Y – Z - Machine footprint: 7,500 × 3,000 × h 3,800 mm - CE compliant | Year: 2018

Condition: ready for operation (used), Year of construction: 2010, operating hours: 55,000 h, travel distance X-axis: 10,000 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 1,000 mm, spindle speed (max.): 6,000 rpm, spindle motor power: 36,000 W, controller manufacturer: SIEMENS, controller model: Sinumerik 840 D, number of axes: 3, This 3-axis Unisign uniport 6000 gantry milling machine was manufactured in 2010. It features an impressive X-axis travel of 10,000 mm, Y-axis travel of 1,500 mm, and Z-axis travel of 1,000 mm. The machine is equipped with a powerful 36 kW main drive and a 30-pocket automatic tool changer. If you are looking to get high-quality milling capabilities, consider the Unisign uniport 6000 gantry milling machine we have for sale. Contact us for further details. • Space requirement: approx. 12 x 11 m • Passage: height 1,000 mm / width 1,500 mm • Max torque: 720 Nm • Gearbox: 2-stage, ratio 1:4 • Machining capacities (C45): drilling 120 mm dia / tapping M55 / milling 100 cm³/min Hfedpfxey A Ifms Ad Hsf • Construction: Gantry design with movable portal bridge and stationary clamping table • Table configuration: Clamping bars in transverse direction with 750 mm spacing (standard plate fields omitted) • Tool changer: Automatic tool change; 30-pocket chain magazine on the portal column (capable of tool change into the angular head) • Operation mode: Pendulum machining capability • Cooling: Machine cooling unit; water-air heat exchanger integrated into the control cabinet • Coolant system: Operated dry; pre-fitted/ready for coolant use • Maintenance status: Tool magazine and X1/X2 ball screws completely overhauled in 2023; last manufacturer maintenance in 2023 • Installation: Machine recessed and anchored in a foundation pit Additional equipment • Angle boring and milling head, 1 unit, 4,000 rpm, SK50, with Hirth coupling for high accuracy and stability; plus 1 spare unit • Probing: RWP20.50-M probe; plus 1 spare Hexagon RWP 20.50-M probe • Hydraulic clamping device with clamping bridges for axis machining, including hydraulic unit • 1x T-slot clamping field (2500 x 1200 mm) as an alternative to the hydraulic fixture • Chip conveyor: Hinged belt type • Safety fence with Sick light grids • Makrolon curtains on both sides of the bridge (motorized height adjustment) • Separation wall with viewing window • Setup and leveling elements • Diverse spare parts • Documentation included Technical Specification Taper Size SK 50

Condition: good (used), Year of construction: 1999, functionality: unexamined, travel distance X-axis: 6,000 mm, travel distance Y-axis: 3,200 mm, travel distance Z-axis: 2,050 mm, total length: 13,000 mm, table length: 5,000 mm, table width: 3,000 mm, total width: 8,000 mm, spindle speed (min.): 12,000 rpm, total height: 6,000 mm, table load: 50,000 kg, overall weight: 120,000 kg, number of slots in tool magazine: 32, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, HEYLIGENSTAEDT HEYMUNILL 3200-P heavy-duty portal-type machining center with fixed cross beam, designed for processing large and heavy workpieces. Large working area with travel distances of X 6,000 mm / Y 5,000 mm / Z 1,500 mm, table size approximately 5,000 x 3,000 mm, and table load capacity of approx. 50,000 kg. Portal clearance approx. 3,220 mm width / 2,050 mm height. 5-axis machining / milling heads A and B axes (swivel axes in the milling head) C axis (360° rotation) Simultaneous 5-axis machining possible (with fork milling head) Milling heads: Straight milling head FK 120/340 90° angular milling head WFK 100/750M Fork milling head FK 100/2D Milling head magazine: 5 positions automatic milling head changer Additional equipment: ICS approx. 7 bar 32-position tool changer (SK50, Fibro ATC 32/50) Tool holder SK50 (DIN 69871) Tool length measuring system (laser) Chip conveyor Coolant system Hsdpfx Adey Anrto Hjff Adaptive feed control Heidenhain linear measurement systems X/Y/Z

Condition: good (used), Year of construction: 1999, travel distance X-axis: 3,000 mm, travel distance Y-axis: 2,500 mm, travel distance Z-axis: 1,150 mm, Control: Siemens 840 D Powerline Tool holder: HSK-A63 Max. rpm: 16,000 X-travel: 3,000 mm Y-travel: 2,500 mm Hfedjy Am Dhspfx Ad Hsf Z-travel: 1,150 mm A-axis: +/- 100 mm C-axis: +/- 181.5 mm Table size: 3,000 mm x 2,500 mm Option: External blowing air Kinematics: Fork head

Condition: ready for operation (used), Year of construction: 2003, travel distance X-axis: 2,000 mm, travel distance Y-axis: 2,500 mm, travel distance Z-axis: 800 mm, total width: 4,300 mm, spindle speed (max.): 24,000 rpm, total height: 4,789 mm, table load: 10,000 kg, overall weight: 30,000 kg, spindle motor power: 45,000 W, controller manufacturer: HEIDENHAIN, controller model: k25, product length (max.): 4,280 mm, number of axes: 3, This 5-axis Breton Matrix WM 800 K25 was manufactured in 2003. It features a substantial table dimension of 2000 x 3000 mm and impressive axes strokes of 2000 mm in X, 2500 mm in Y, and 800 mm in Z. The machine has a maximum rotation speed of 24000 rpm and a rapid forward speed of 40 m/min. If you are looking to get high-quality milling capabilities, consider the Breton Matrix WM 800 K25 gantry milling machine we have for sale. Contact us for further details. Hedey Amd Iepfx Ad Hoff • Table dimensions (X/Y): 2000 x 3000 mm • Rapid traverse (X/Y/Z): 40 / 40 / 20 m/min • Power: 45 / 20 kW

Condition: ready for operation (used), Year of construction: 1997, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,250 mm, travel distance Z-axis: 1,200 mm, total width: 3,600 mm, spindle speed (max.): 3,000 rpm, total height: 7,200 mm, table load: 10,000 kg, overall weight: 21,000 kg, spindle motor power: 22,000 W, controller manufacturer: HEIDENHAIN, controller model: TNC, product length (max.): 5,200 mm, number of axes: 3, This 3-axis Rambaudi RX 1250 gantry milling machine was manufactured in 1997. It features a substantial table dimension of 2500 x 1250 mm and impressive axes strokes of 2000 x 1250 x 1200 mm. With a rotation speed of 3000 rpm and a power of 22 kW, this machine is designed for high-performance milling applications. If you are looking to get high-quality milling capabilities, consider the Rambaudi RX 1250 machine we have for sale. Contact us for further details. Hjdpsy Aaw Uofx Ad Hoff • Table dimensions (X/Y): 2500 × 1250 mm

Condition: ready for operation (used), Year of construction: 2024, functionality: fully functional, Gantry Portal Milling Machine / Manufacturer: WALDRICH SIEGEN Type: PF-S-150 - 1953: Original year of manufacture (originally a workbench) - 1974: Reconstruction by the manufacturer WALDRICH SIEGEN to a portal milling machine (completely new milling support) - 2001: Modernised to CNC, with new electrical control cabinet - 2015: Modernization / Reconstruction to NC table drive - 2024: Reconstruction to crossbeam drive (gantry) Machining options: - Milling/Boring: horizontal/vertical The machine can be inspected by appointment under power. Condition: Ready for operation. Hfedoyz Ru Ujpfx Ad Hjf TECHNICAL DATA / DESCRIPTION: Travel distances of feed axes (CNC): - Table: 14.000 mm - Crossbeam support: 4.500 mm - Crossbeam: 4.000 mm - Stand passage: width 4.545 mm - Clear width: 4.200 mm - Height from table to spindle: 4.000 mm - Quill: 450 mm - Table size / clamping: 14.000 x 4.350 mm - Table load: max. 200 tons (10 tons point load) - Drive power of main spindle motor: 125 kW - Total machine weight: approx. 350 tons - Space requirement for entire machine: Length 40 / Width 10 / Height above floor 9 m EQUIPMENT / ACCESSORIES: - CNC control: SINUMERIK 840D - Documentation - Additional comprehensive equipment ... No guarantee is given for the completeness and accuracy of the technical information and equipment. - Subject to prior sale - Detailed technical data sheet and information on equipment available on request.

Condition: ready for operation (used), Year of construction: 1995, functionality: fully functional, travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,750 mm, travel distance Z-axis: 1,000 mm, controller model: Siemens NCU 840 W Serie 2, number of axes: 5, TECHNICAL DETAILS Travel X-axis: 2,500 mm Travel Y-axis: 1,750 mm Travel Z-axis: 1,000 mm A-axis: 20 arcseconds C-axis: 30 arcseconds Rapid traverse X-axis: 17 m/min Hjdpfxoyz Abtj Ad Heff Rapid traverse Y-axis: 17 m/min Rapid traverse Z-axis: 10 m/min Rapid traverse A-axis: 9 rpm Rapid traverse C-axis: 80 rpm Infinitely variable feed X and Y axes: up to 15,000 mm/min Feed Z-axis: up to 4,000 mm/min Table plate: St 52-3 Table dimensions (L x W): 3,631 x 1,200 mm Milling head: FK 115 - SK40 Speed: 14–1,000 rpm Bearing: A9 LC8 CNC A-axis: spindle swivel axis A-axis Swivel angle: ±120 degrees Torque: 450 Nm Speed: 8 rpm Resolution: 20 arcseconds Clamping: hydraulic C-axis Rotation angle: 365 degrees Torque: 580 Nm Speed: max. 8 rpm Resolution: 30 arcseconds Clamping: hydraulic MACHINE DETAILS Control: Siemens NCU 840 W Series 2 CNC controlled axes: 5 Voltage: 400 V 50 Hz Power: approx. 35 kW Weight: 18,500 kg EQUIPMENT Swarf conveyor Sliding door Side window Tool changer stationary at center of machine/ rear crossbeam Disc magazine with 16 stations SK40 Heidenhain length measuring system Note: The seller can arrange an external service provider for the removal of the machine.

Condition: good (used), Year of construction: 2002, functionality: fully functional, Initial commissioning: 2002 Control: Heidenhain iTNC530 Machine hours: to follow X-axis: approx. 6,000 mm Hsdpfx Adsyzz R Ho Heff Y-axis: approx. 3,500 mm Z-axis: approx. 1,100 mm A-axis: C-axis: 2-axis milling head Spindle speed: max. 14,000 rpm Additional equipment - Double-sided enclosure Machine condition Fully functional, in very good condition. Machine remains powered and is available immediately.

Condition: ready for operation (used), Year of construction: 2004, travel distance X-axis: 3,800 mm, travel distance Y-axis: 2,800 mm, travel distance Z-axis: 1,200 mm, spindle speed (max.): 8,000 rpm, spindle motor power: 25,000 W, number of axes: 5, This 5-axis OMAG Blade G gantry milling machine was manufactured in 2004. It features a substantial X-axis travel of 3,800 mm, Y-axis travel of 2,800 mm, and Z-axis travel of 1,200 mm. The machine is equipped with a powerful 25 kW spindle motor and a maximum saw blade diameter of 1,000 mm. If you are looking to get high-quality milling capabilities, consider the OMAG Blade G machine we have for sale. Contact us for further details. Hfsdoyzzlwspfx Ad Hjf • Spindle motor: Omag 50 • C-axis: ±200° • B-axis: ±120° • Max saw blade diameter: 1,000 mm Additional equipment • CAD/CAM: DDX Technical Specification Taper Size ISO 40

Condition: used, Year of construction: 1990, functionality: fully functional, machine/vehicle number: 2124, travel distance X-axis: 1,200 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,375 mm, feed rate X-axis: 20 m/min, feed rate Y-axis: 20 m/min, feed rate Z-axis: 20 m/min, spindle speed (max.): 4,000 rpm, 5-axis machine Pallet size: 800 × 800 mm Automatic workpiece change: 5 pallets CNC control: FANUC 15M Spindle: 22 kW – 4000 rpm, FANUC Hsdjyzxyxopfx Ad Hsff Axis motor (20 m/min) + drive: FANUC Tool magazine: 118 tools, type 50, DIN 69871

Condition: ready for operation (used), Year of construction: 2021, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,900 mm, travel distance Z-axis: 760 mm, table length: 3,216 mm, table width: 1,500 mm, total width: 4,660 mm, spindle speed (max.): 8,000 rpm, total height: 4,100 mm, overall weight: 29,000 kg, tool weight: 20,000 g, spindle motor power: 22,000 W, controller manufacturer: FANUC, controller model: 31iM-F CNC with 10.4" LCD, product length (max.): 8,700 mm, number of slots in tool magazine: 32, swivel angle C-axis (max.): 5 °, number of axes: 4, This 3+1-axis AWEA LP3016YF gantry milling machine was manufactured in 2021. It features a substantial working area of 3216 x 1500 mm and a maximum workpiece weight of 10,000 kg. The machine is equipped with a FANUC 31iM-F CNC control and includes a 32-position tool changer. If you are looking to get high-quality milling capabilities, consider the AWEA LP3016YF machine we have for sale. Contact us for further details. • Worktable: 3216 x 1,500 mm • Max. workpiece weight: 10,000 kg • Distance plane to spindle nose: 200–960 mm • Distance between columns: 2,300 mm • Spindle taper: MAS BBT50 • Rapid traverse (X/Y/Z): 20 m/min (15 m/min) • Feed (X/Y/Z): 1–10,000 mm/min • Tool changer: Arm type, 32 positions • Max. tool diameter: Ø127 mm • Max. tool diameter with free adjacent pockets: Ø215 mm • Max. tool length: 400 mm Additional equipment • Full machine encapsulation with roof (CE compliant) • Cooling and thermal management: • 20 bar high-pressure coolant system with filters • Low-pressure pumps (Grundfos/Walrus) • Spindle oil cooling system / oil cooler • Cooling system, spindle exhaust, heat exchanger in electrical cabinet • Chip handling: • Double screw-type chip conveyor along the table • Chain-type chip conveyor in Y-direction, located at one end • Probing: • Renishaw 3D workpiece probe system • Renishaw TS 27R tool-setting probe • Lighting: Double LED machine lighting plus LED spot • Tooling package: 20 pcs BBT50 tool holders incl. 32 pcs tightening bolts (through-coolant) • Power: 3x400V 50Hz CE transformer • Base/accessories: Steel machine shoe • F option (angle head and automation): • 90° angle head with automatic 5° indexed C-axis • Automatic change of vertical head; head stored in a box at the machine portal • Swing-away angle head storage • ATC change in both horizontal and vertical positions Hfodpfx Adjyzr Sbs Hsf • Max. angle head rpm: 3,000 rpm • Transverse travel upgrade: Y = 1,900 mm (with F option) Technical Specification Taper Size BT 50

Condition: good (used), Year of construction: 2018, Ref. -No.: 10643 Manufacturer: FERMAT Type: Gantry Year of construction: 2018 Type of control: CNC Hfodpfx Aoyzpxfed Hjf Control: Siemens Sinumeric Storage location: Halberstadt Country of origin: Czech Republic X-Travel: 20000 mm Y-Travel: 7800 mm Z-Travel: 2000 mm W-Travel: 1000 mm Turning Speeds: 20000 RPM Speed work spindle: 0 - RPM Max. Torque: 3294 Nm Rapid Traverse X/Y/Z: 40000 m / min Table-Size (Lxw): 20000 x 5000 x 300 mm Power Capacity: 74 kW Headstock - (spindle diameter): 160 mm Further information: - Tool cooling - Low pressure - Tool cooling - High pressure 50 bar (6,000 liters) - Tool cooling - Oil separator - Sludge pump - Machine enclosure (CE) - Electrical - Linear measurement - Electrical - Remote diagnostics - ATC/Robot Robot 140 - Chip conveyor 2 - Operator cabin / protective screen - Electrical - HH iTNC 640 control system - Electrical - Handwheel - Electrical - Air conditioning for the distributor - Head - Type 2x UHA 0.001 The machine can be viewed while powered on by prior arrangement.

Condition: excellent (used), Year of construction: 2013, functionality: fully functional, Datron M8 Datron V9 Control Year of manufacture: 08 / 2013 Spindle operating time: approx. 1947 hours 3KW high-frequency spindle with HSK25 tool holder, 1000 rpm to 40000 rpm HIB HF spindle cooling unit 2 x 5-position tool changers Renishaw 3D probe Tool length measuring probe Microjet minimum quantity lubrication system Vacuum table measuring 1000mm x 700mm 2-way vacuum distributor Software: V9 • Protected zones • Tool monitoring by path and time • Smoothing Hfodpjyzbmhefx Ad Hsf • G-code input filter The machine is in very good condition.

Condition: ready for operation (used), Year of construction: 2001, Technical Features of this Bridge Type Milling Machine Manufacturer ZAYER Model KPU-5000 AR Hfjdpfoyxv Unex Ad Hjf Year 11/2001 CNC HEIDENHAIN TNC-430 Table surface 6.500 x 1.800 mm Longitudinal travel (X Axis) 6.500 mm Cross travel (Y Axis) 3.050+873 mm Vertical travel (Z Axis) 1.250 mm Distance between columns 2.450 mm Maximum height between spindle nose and table with spherical head 1.565 mm. Maximum height between spindle nose and table with 45º head in vertical position 1.574 mm. Rapid feed (X, Y, Z) 25.000 mm/min Max. working feed 15.000 mm/min Heads 45º Automatic head INCLUDED 45º Head (A Axis / B Axis) 360.000 posiciones Automatic Head 45º Taper ISO-50 – DIN 69871 Automatic Head 45º Speed 6.000 r.p.m. Spherical Rotation Head INCLUDED Direct Output Head Taper ISO-50 Main Motor Power 37 kW. Speed Ranges 2 Manual Head Change INCLUDED Retractable Automatic Support in the Right Side For 45º Head INCLUDED Retractable Automatic Support in the Right Side For Direct Output Head INCLUDED Ethernet Connection INCLUDED Double Chip Conveyor One at each side of the machine INCLUDED 1000 l Oil Tank with Filter Paper + Magnetic Separator INCLUDED Internal coolant 20 Bar INCLUDED External coolant10 bar INCLUDED Automatic tool changer INCLUDED ATC positions 60 CNC 3D ROT Function INCLUDED Others Positioning Accuracy 0.010 mm. Repetitive Accuracy 0.005 mm. Handwheel HEIDENHAIN HR-410 Carrying Load Table 20.000 Kg. Machine Weight 52.000 Kg.

Condition: used, Year of construction: 2008, functionality: fully functional, travel distance X-axis: 3,150 mm, travel distance Y-axis: 1,850 mm, travel distance Z-axis: 1,000 mm, feed rate X-axis: 30 m/min, feed rate Y-axis: 30 m/min, feed rate Z-axis: 24 m/min, spindle speed (max.): 24,000 rpm, torque: 87 Nm, Fidia C20 CNC WORKING AREA X-axis longitudinal travel: mm 3,150 Y-axis transverse travel: mm 1,850 Z-axis vertical travel: mm 1,000 MAX AXIS SPEEDS X, Y axis feed rate: m/min 30 Z axis feed rate: m/min 24 WORK TABLE Clamping surface: mm 3,000 x 1,600 Maximum permissible load: kg/m² 5,000 T-slots: • Longitudinal 8 H12 + 1 H8 • Width mm 22 • Pitch mm 160 ELECTROSPINDLE Maximum power (S6 60%): kW 55 Spindle speed range: rpm 240 ÷ 24,000 Constant power range: rpm 6,000 ÷ 24,000 Maximum torque: Nm 87.5 Tool holder: HSK-A63 C-axis travel: ± 200° C-axis speed: °/min 2,000 C-axis offset from spindle axis: mm 75 A-axis travel: +95° / -110° A-axis speed: °/min 2,000 Max distance spindle nose – table surface: mm 1,175 Machine equipped with: Hodpfx Aoyw Tdded Heff • 24-position tool magazine • Remote electronic handwheel • HMS system for head calibration • Various equipment included with the machine • User and maintenance manual and CE declaration of conformity

Condition: ready for operation (used), Year of construction: 2003, travel distance X-axis: 4,000 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 760 mm, spindle speed (max.): 10,000 rpm, overall weight: 26,000 kg, tool weight: 15,000 g, spindle motor power: 30,000 W, controller manufacturer: FANUC, controller model: Series 18i-MB, number of axes: 4, This 4-axis EDEL Koordimatic XL 4020 gantry milling machine was manufactured in 2003. It features a substantial working area of 4000 x 2000 mm and a maximum spindle speed of 10,000 rpm. The machine is equipped with a powerful 30 kW electrospindle and has a travel distance of 760 mm in the Z-axis. If you are looking to get high-quality milling capabilities, consider the EDEL Koordimatic XL 4020 machine we have for sale. Contact us for further details. Hjdpfeyw Nppsx Ad Heff • Condition: Refurbished (used) • Functionality: Limited functionality • Power: 30 kW (40.79 HP); electrospindle after full regeneration (new bearings and clamping system) • Working area: 4000 x 2000 mm • Rapid traverse X/Y/Z: 20 / 20 / 15 m/min • Rotational speed (max): 300 rpm • Tool magazine: 36 positions (damaged – no changer arm) • Distance table to spindle center: 150 mm • Mount diameter: 50 mm Technical Specification Taper Size SK 50

Condition: ready for operation (used), Year of construction: 2000, travel distance X-axis: 7,230 mm, travel distance Y-axis: 1,100 mm, travel distance Z-axis: 850 mm, spindle speed (max.): 18,000 rpm, number of axes: 5, This 5-axis Handtmann PBZ NT 600 AS gantry milling machine was manufactured in 2000. It features a maximum profile length of 6500 mm and impressive X-axis travel of approximately 7230 mm. The machine is capable of working with steel and aluminium, offering advanced programming aids for milling and drilling cycles. If you are looking to get high-quality milling capabilities, consider the Handtmann PBZ NT 600 AS machine we have for sale. Contact us for further details. • Control: BWO CNC 900 multi-axis CNC • Control features: tool radius compensation in 3 axes; RAM for programs/parameters; programming aids for milling/drilling cycles; contour (short) programming; NC program I/O interface; interface for portable control panel (teach panel); control panel with swivel console; color TFT display; 3.5" floppy drive; CD-ROM drive • Material capability: steel and aluminium • Rotary axes: C ≈ ±200°; A ≈ ±120° • Positioning accuracy (linear axes): ±0.05 mm/m • Speeds: Y working/rapid max 45 m/min; Z working/rapid max 45 m/min; X rapid max 90 m/min • Maximum profile length: 6500 mm Hsdpfx Aeyw Ipued Hoff

Condition: good (used), Year of construction: 2017, functionality: fully functional, machine/vehicle number: 4480, total length: 14,500 mm, total width: 7,800 mm, total height: 3,500 mm, overall weight: 20,000 kg, Reichenbacher Machining Center VISION III-TT-L – 5-Axis, 3-Axis, MBG8, 5x SNA Equipment: 5-Axis Unit with Cardanically Mounted Spindle: Max. speed: 24,000 rpm Nominal speed: 10,000 rpm Power in S1*: 15 kW Max. power in S6: 20 kW Torque in S1*: 14.5 Nm Torque in S6: 19 Nm Nominal voltage: 380 V Nominal current: 37 A Nominal frequency: 380 Hz Speed freely programmable from 0 – 24,000 rpm, in 1 rpm increments Clockwise/counterclockwise rotation selectable via program Hfedpfxjywzq Se Ad Hof Driven by frequency inverter Maintenance-free Water-cooled Hybrid bearings Automatic spindle stop in case of emergency stop Orientated stop for thread cutting Tool holder: HSK-F63 hollow shaft taper according to DIN 69893-6 Max. tool length usable from spindle nose: 240 mm Max. tool weight: 6 kg 3-Axis Unit with Vertically Mounted Spindle: Max. speed: 24,000 rpm Nominal speed: 10,000 rpm Power in S1*: 15 kW Max. power in S6: 20 kW Torque in S1*: 14.5 Nm Torque in S6: 19 Nm Nominal voltage: 380 V Nominal current: 37 A Nominal frequency: 380 Hz Speed freely programmable from 0 – 24,000 rpm, in 1 rpm increments Clockwise/counterclockwise rotation selectable via program Driven by frequency inverter Maintenance-free Water-cooled Hybrid bearings Automatic spindle stop in case of emergency stop Orientated stop for thread cutting Tool holder: HSK-F63 hollow shaft taper according to DIN 69893-6 Max. tool length usable from spindle nose: 240 mm Max. tool weight: 6 kg 8-Spindle Drilling Unit (1 unit): L-Shape, Grotefeld Drill spindles: individually selectable Rotation direction: clockwise/counterclockwise Pitch: 32 mm Power: 2.5 kW Speed: 5,000 rpm fixed Z-axis stroke: +75 mm Holder: D = 10 mm H7 Plunge stroke: 80 mm Grooving Unit (5 units): GROTEFELD Angle Saw Unit F100-S The working/milling stroke is pneumatic. Drive: three-phase motor with multi-ribbed belt LEFT version Drive rotation direction: clockwise/counterclockwise Speed reduction: 1:2.86 – belt drive Power: 2.20 kW – 220-240/380-415 V – 50 Hz Speed: n1 = 2,800 rpm, n2 = 8,011 rpm at 50 Hz Spindle power: 2.2 kW Feed: 150 mm Tool holder: Ø30 x 1.5 mm – 5.0 mm Tool holder rotation: opposite to drive rotation direction Feed force: 2565 N Underfloor Drilling Unit in Machine Bed (1 unit): GROTEFELD Angle Milling Head G06-1.1-P The working/drilling stroke is pneumatic. Drive motor: 1.1 kW 220-240/380-415 V 50-100 Hz Drive rotation direction: clockwise Speed reduction: 1:1.55 gear drive Drive speed: 2,800 – 5,600 rpm Tool spindle speed: 4,340 – 8,680 rpm Tool holder: 1x HI-Q/ERM25 DIN6499-C (8°) For ER25 collet DIN 6499-B Ø0.5–16 mm max. Tool holder rotation direction: clockwise Flange clamping piece: FK45 Feed slide: with pneumatic cylinder and double steel guideways Feed: 80 mm

Condition: ready for operation (used), Year of construction: 2010, operating hours: 68,648 h, travel distance X-axis: 2,300 mm, travel distance Y-axis: 1,300 mm, travel distance Z-axis: 1,000 mm, table length: 1,800 mm, table width: 1,800 mm, spindle speed (max.): 10,000 rpm, overall weight: 36,000 kg, tool weight: 12,000 g, controller manufacturer: HEIDENHAIN, controller model: iTNC530, number of slots in tool magazine: 10, number of axes: 5, This Trimill VU 2313 Vertical Machining center was manufactured in the year 2010 in the Czech Republic and has 68648 hours, of which 40637 are spindle hours. It is equipped with a Heidenhain iTNC530 control unit and has 5 axis. The machine has a spindle speed of 10000 rpm, is in good condition, and is well maintained. Machine Benefits Qualitative Machine Benefits • Good condition! Hfedpfx Adsywlv Ej Hjf Technical Machine Benefits • Spindle motor power/torque 25 kw / 195 nm • B-axis (head) -2°/+92° • C-axis table n x 360° • Working feedrates x, y, z 30. 000 mm/min • Rapid feedrates x, y, z 3 m/sec² • Through spindle coolantMachine options: Connection station for high-frequency finishing spindle IMT ● HEIDENHAIN probe for workpiece positioning and measurement, infrared transmission ● BLUM probe - for tool measurement, laser - non-contact ● Tool cooling with liquid through the center of the spindle + external nozzles ● Lift Off - prevents the Z axis from sinking and damage to the part in the event of a power failure Technical Specification Taper Size HSK 100

Condition: ready for operation (used), Year of construction: 2002, operating hours: 4,486 h, functionality: fully functional, travel distance X-axis: 3,000 mm, travel distance Y-axis: 2,360 mm, travel distance Z-axis: 1,500 mm, rotational speed (max.): 18,000 rpm, controller model: Fidia C20 mit Bedienteil HPX, The machine is in fully operational, very good condition. It has been dismantled, is in storage, and available immediately! TECHNICAL DETAILS Travel range X-axis: 3,000 mm Travel range Y-axis: 2,360 mm Travel range Z-axis: 1,500 mm Rotary axis A: 105° Rotary axis C: 300° Clamping area: 5,000 mm x 2,000 mm Table load: 15,000 kg/m² T-slot spacing: 18H12 / 250 mm Feed rate X, Y, Z axes: 20 m/min Axis acceleration X, Y, Z axes: 1.5 m/s² Max. spindle speed: 18,000 rpm Torque: 90 Nm Tool holder: HSK 63A MACHINE DETAILS Spindle power: 28 kW Connected load: 40 kW Main fuse: 80 A Hfodsywgyrjpfx Ad Hef Spindle hours: 4,486 h Machine hours: 146,161 h Dimensions & Weight Space required for machine with peripherals (L x W x H): 7,300 x 5,600 x 5,600 mm Machine weight: 16,500 kg EQUIPMENT 3-sided enclosure, without extraction ducts

Condition: excellent (used), Year of construction: 2016, functionality: fully functional, travel distance X-axis: 4,000 mm, travel distance Y-axis: 2,200 mm, travel distance Z-axis: 1,100 mm, table length: 4,500 mm, table width: 2,500 mm, spindle speed (max.): 22,000 rpm, CNC Heidenhain iTNC 640 WORKING AREA: Longitudinal X-axis travel: mm 4.000 Transversal Y-axis travel: mm 2.200 Vertical Z-axis travel: mm 1.100 Maximum speed with interpolating axes: m/min 50 WORKTABLE: Dimensions: mm 4.500 x 2.500 Height: mm 300 Load capacity: T/m² 15 Hfodpfx Ajyv In Ijd Hef T-slots for workpiece clamping mm 28 DIN 650 (H12), complete with leveling elements. T-slot direction parallel to Y-axis movement. CONTINUOUS POSITIONING UNIVERSAL HEAD WITH ELECTROSPINDLE: Automatic universal head indexed to 360,000 positions (every 0.001°). Rotation is driven by direct drive motors and controlled by the CNC as a positioning axis. Automatic tool clamping. Allows 10° undercut machining. Internal cooling system for bearings and axis motors. C-axis rotation range: ± 270° A-axis rotation range: ± 185° Maximum axis rotation speed: rpm 30 Maximum torque available on A/C axes: Nm 450 Axis clamping torque: Nm 1.400 Spindle power (S1/S6): kW 22/33 Spindle torque (S1/S6): Nm 84/128 Maximum spindle speed: rpm 22.000 Constant power range: rpm 3.000 to 18.000 Constant torque range: rpm 10 to 3.000 Tool interface: HSK-A63 DIN 69893 ELECTROSPINDLE HSK-A100 WITH SEMI-AUTOMATIC CHANGE SYSTEM Spindle power (S1/S6): kW 37/43 Spindle torque (S1/S6): Nm 140/165 Maximum spindle speed: rpm 15.000 Constant power range: rpm 2.500 to 12.000 Constant torque range: rpm 10 to 2.500 Tool interface: HSK-A100 DIN 69893 CHAIN TOOL MAGAZINE – 55 POSITIONS, HSK-A100 / HSK-A63 Floor-mounted fixed chain magazine located at the rear of the machine, fully enclosed for operator protection, equipped with a vertical tool change arm and automatic tool pre-selection. Fixed-pocket management system. Hydraulic axis locking Total tools: No. 55 HSK-A63 tools (DIN 69893): Number of tools: No. 30 Max tool diameter: mm 90 Max tool diameter (with adjacent pockets free): mm 160 Max tool length: mm 300 Max tool weight: kg 10 HSK-A100 tools (DIN 69893): Number of tools: No. 25 Max tool diameter: mm 100 Max tool diameter (with adjacent pockets free): mm 160 Max tool length: mm 450 Max tool weight: kg 20 REQUIRED CONNECTIONS Maximum installed power: kVA 177 Maximum current required: A 235 MACHINE EQUIPPED WITH: • Heidenhain HR550 remote electronic handwheel • High-pressure water and air through the spindle • Semi-automatic electrospindle change system with HSK-A63 and HSK-A100 interfaces • Various tooling included with the machine • Renishaw probe • BLUM laser presetting system • AUTOCAL automatic head calibration system • Visormax subscription for remote monitoring • Electrical cabinet air conditioning unit • Cooling system for all axes and the electrospindle • User and maintenance manual and CE declaration of conformity

Condition: not inspected (used), Year of construction: 2000, functionality: unexamined, machine/vehicle number: 2259, travel distance X-axis: 6,000 mm, travel distance Y-axis: 3,500 mm, travel distance Z-axis: 1,900 mm, rotational speed (max.): 24,000 rpm, controller model: Siemens 840D, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Hfjdpfx Adeyv A Dkj Hef Travel X-axis: 6,000 mm Travel Y-axis: 3,500 mm Travel Z-axis: 1,900 mm B-axis: +/- 110° C-axis: 360° Spindle speed: 24,000 rpm Spindle taper: HSK 63 Spindle motor: 25 kW Table size: 6,000 mm x 2,500 mm (hole pattern 22H7 / M16) Feedrate X + Y: 30,000 mm/min Feedrate Z: 28,000 mm/min Rapid traverse: 30,000 mm/min MACHINE DETAILS Control: Siemens 840D Tool changer: 40 tools EQUIPMENT Spindle: Fischer (type MFWS 1709/30, 2 units) Milling head: Forest Line (type: fork head, B-axis swivels +/- 110°, C-axis rotates 360°) Richter chip conveyor (scraper conveyor) Blum tool measurement Parking station for milling head (2 units)

Condition: ready for operation (used), Year of construction: 2004, operating hours: 23,291 h, functionality: fully functional, travel distance X-axis: 3,200 mm, travel distance Y-axis: 1,400 mm, travel distance Z-axis: 750 mm, table length: 3,200 mm, table width: 1,400 mm, TECHNICAL DETAILS X-axis travel: 3,200 mm Y-axis travel: 1,400 mm Hfsdpjyvub Uefx Ad Hof Z-axis travel: 750 mm Table size: 3,200 x 1,400 mm MACHINE DETAILS Control type: CNC Control system: Heidenhain Operating hours Spindle run time: 23,291 h Program run time: 27,807 h Control on time: 83,301 h Machine on time: 73,907 h

Condition: excellent (used), Year of construction: 2018, functionality: fully functional, travel distance X-axis: 6,000 mm, travel distance Y-axis: 2,700 mm, travel distance Z-axis: 1,500 mm, feed rate Y-axis: 50 m/min, table length: 6,000 mm, total width: 3,000 mm, spindle speed (max.): 22,000 rpm, rapid traverse X-axis: 50 m/min, rapid traverse Y-axis: 50 m/min, rapid traverse Z-axis: 50 m/min, spindle nose: hsk 100, CNC Heidenhain iTNC 640 WORKING AREA X-axis longitudinal travel: mm 6.000 Y-axis transversal travel: mm 2.700 Z-axis vertical travel: mm 1.500 Maximum feed rate with interpolated axes: m/min 50 WORK TABLE Dimensions: mm 6.000 x 3.000 Height: mm 300 Load capacity: t/m² 15 T-slots for workpiece clamping: mm 28 DIN 650 (H12), complete with leveling elements. T-slot direction parallel to Y-axis movement. CONTINUOUS POSITIONING UNIVERSAL HEAD WITH MOTOR SPINDLE Automatic universal indexed head with 360,000 positions (every 0.001°). Rotation is driven by direct drive motors and controlled by the CNC as a positioning axis. Automatic tool clamping. Allows 10° undercutting. Internal cooling system for bearings and axis motors. C-axis rotation range: +/- 270° A-axis rotation range: +/- 185° Maximum axis rotation speed: rpm 30 Maximum torque on A/C axes during operation: Nm 450 Axis clamping torque: Nm 1.400 Spindle power (S1/S6): kW 22/33 Spindle torque (S1/S6): Nm 84/128 Maximum spindle speed: rpm 22.000 Constant power speed range: rpm from 3.000 to 18.000 Constant torque speed range: rpm from 10 to 3.000 Tool interface: HSK – A63 DIN 69893 HSK – A100 MOTOR SPINDLE WITH SEMI-AUTOMATIC CHANGE SYSTEM Hjdpfx Asyvtt Ned Hoff Spindle power (S1/S6): kW 37/43 Spindle torque (S1/S6): Nm 140/165 Maximum spindle speed: rpm 12.000 Constant power speed range: rpm from 2.500 to 12.000 Constant torque speed range: rpm from 10 to 2.500 Tool interface: HSK – A100 DIN 69893 CHAIN TOOL MAGAZINE – 55 POSITIONS, HSK-A100 / HSK-A63 Floor-mounted chain magazine located at the rear of the machine, enclosed for operator protection, with vertical tool change arm and automatic tool preselection. Fixed-position management. Hydraulic axis clamping Total tools: No. 55 HSK-A63 tools (DIN 69893): Number of tools: No. 30 Max tool diameter: mm 90 Max tool diameter with adjacent free positions: mm 160 Max tool length: mm 300 Max tool weight: kg 10 HSK-A100 tools (DIN 69893): Number of tools: No. 25 Max tool diameter: mm 100 Max tool diameter with adjacent free positions: mm 160 Max tool length: mm 450 Max tool weight: kg 20 REQUIRED CONNECTIONS Maximum installed power: kVA 177 Maximum current required: A 235 MACHINE EQUIPPED WITH: • Heidenhain HR550 remote electronic handwheel • High-pressure coolant (water and air) through the spindle • Semi-automatic spindle change system with HSK-A63 and HSK-A100 interfaces • Various tooling included with the machine • Renishaw probe • BLUM laser tool presetting system • AUTOCAL automatic head calibration system • Visormax subscription for remote monitoring • Electrical cabinet air conditioning unit • Cooling system for all axes and motor spindle • User and maintenance manual and CE declaration of conformity
