Condition: used, Model:- AY 1000 x 1000, Serial No: Nc-A3-045 1 metre swing over bed, 1 meter between centres 390mm Swing Over Saddle 180mm Spindle Bore 4 Jaw Chuck 800mm Diameter Bsdpfx Asyn R Hcsh Ield Quick Change Tool Post Fagor 8055 controls Made In Taiwan

Condition: used, Year of construction: 2008, For sale: Honor Seiki CNC Vertical Lathe Model: VL-86A Extremely rigid and reliable machine, ideal for heavy-duty turning of medium-sized workpieces. Main Technical Data: Brand: Honor Seiki (Importer: Tecnor Macchine) Model: VL-86A CNC Control: Fanuc Series (color monitor) Year: 2008 Chuck Diameter: 605 mm Maximum Turning Diameter: 800 mm Maximum Turning Height: 800 mm Travel: X: 450 mm Blsdpsynl Rvefx Ah Ijd Z: 850 mm Spindle Speed: 25 – 1,250 rpm Motor Power: 18.5 / 22 kW Turret: 12 positions Machine Weight: 12,000 kg Included Accessories: Chip conveyor (with rear discharge) Original maintenance manuals and electrical schematics. CE Certified. Condition: Machine in excellent general condition. Scheduled maintenance performed regularly.

Condition: used, Year of construction: 2000, max swing diameter 700mm, X/Y 255/520mm, tailstock, 12-position tool turret, CNC SIEMENS SINUMERIK 840D, 400V 50Hz 45kW, weight 12t Blodoym Sm Uspfx Ah Ied

Condition: good (used), Year of construction: 2000, Ref. -No.: 10623 Manufacturer: WEILER Type: E90 x 4500 Year of construction: 2000 Type of control: CNC Control: SIEMENS D1 - Zyklen Storage location: Halberstadt Country of origin: Germany Bed width: 600 mm Turning Length: 4500 mm Swing Diameter Over Bed Slide: 900 mm Spindle Bore: 128 mm Max. Torque: 6000 Nm Feed Capacity - Z: 20000 kN Feed Capacity - X: 20000 kN Rapid Speed: 10/5 RPM Tailstock Quill Diameter: 140 mm Bsdpfx Asym Nf Ujh Iold Tailstock Quill Stroke: 300 mm Lathe tool dimensions: 32 x 25 mm Front bearing diameter: 178 mm Circumferential diameter over facing slide: 530 mm Spindle head according to DIN 55027 (size): Gr. 11 Tailstock inner cone: MK 6 / 140 Type Machine length: 6900 mm Machine width: 2600 mm Machine Height: 2150 mm Weight Of The Machine Ca.: 10,5 t Further information: The machine can be viewed while powered up.

Condition: used, Year of construction: 2015, CMZ TC 35 Y-800 Swing over bed / slide: 920 / 745 mm Max. turning diameter: 550 mm Distance spindle – tailstock: 866 mm Axis travels X / Y / Z / B: 310 / +80 / −60 / 800 / 803 mm Rapid traverse X / Z / B: 30 m/min Rapid traverse Y: 15 m/min Main spindle: Max. speed: 3,000 rpm Power: 45 / 39 kW at 1,500 / 1,273 Nm Bearing diameter (outer / inner): 240 / 160 mm Bodpfx Aoymc Trsh Ield Spindle bore: 106 mm Bar capacity: 95 mm Chuck diameter: 315 mm Tailstock: Quill diameter / stroke: 110 / 150 mm Travel: 800 mm Tool turret: 12 stations, all driven Max. speed: 4,000 rpm Power: 16 kW Max. torque: 75 Nm CNC control: FANUC 32i TB Supply voltage: 400 V / 50 Hz Connected load: 65 kVA Machine dimensions (L x W x H): approx. 3 x 2 x 2.2 m Weight: approx. 8.3 t Operating hours: approx. 21,934 h Cutting time: approx. 3,899 h Scope of delivery: Bar feeder: BREUNING IRCO ILS-MUK 10016-II, year 2015 Coolant unit

Condition: used, CMZ TC 35Y Serial number 362, year 2011 Fanuc 31i control Approx. 1200mm between centres, 400 mm dia chuck. Swarf FX5002 extraction unit Blodeymctrepfx Ah Isd Tooling including static and driven and jaws.

Condition: used, Year of construction: 2000, Technical details: turning diameter over bed: 340 mm turning dia. over face-slide: 158 mm turning length: 300 mm facing movement (x-axis): 300 mm Bledpfxsylt Nzs Ah Isd longitudinal traverse (z-axis): 300 mm control: Siemens 810T revolution per minute: 60 - 4.000 U/min max. torque on the spindle: 106 - 145 Nm external spindle dia. in forward position: 80 mm feed motor: 8500 N rapid motion - x-axis: 6 m/min tool turret - number of stations: 8 tailstock adjustment: 120 mm Main spindle capacity: 11/15 kW electrics - voltage/frequency: 380/50 V/Hz total power requirement: 20 KVA

Condition: excellent (used), Year of construction: 2013, CNC Turning and Milling Center Okuma Multus B400II-W 2000 Control: OSP-P 300S Year of manufacture: 2013 X-axis: 690 mm Y-axis with travel: 230 mm Z-axis: 2,045 mm B-axis: up to 225°, positioning in 0.001° increments Turning length: 2,000 mm Turning diameter: 710 mm Spindle bore: 110 mm Tool holder: HSK 63 Tool magazine: 80 stations Equipment: - Collision avoidance system - Tool monitoring system - Tool measurement device - Tool presetting - Subspindle with tailstock function - Renishaw probe - Automatic door - NC steady rest carrier with SMW SLU-Z 3.2 steady rest - ONE touch IGF Bledsyk Tv Espfx Ah Isd - Hinged belt conveyor - Main spindle replaced in 2022

Condition: excellent (used), Year of construction: 2022, CNC Lathe Doosan Puma 700 M II Control: Siemens Sinumeric 828 Year of manufacture: 2022 Turning length: 1,600 mm Turning diameter: 900 mm X-axis travel: 470 mm Z-axis travel: 1,650 mm Spindle speed: 3 – 1,500 rpm Tool turret: 12 stations (all driven) Tool holder: BMT 85P Equipment: Self-centering steady rest Chip conveyor Touch setter 3-jaw chuck Programmable tailstock Extraction system Coolant pump 20 bar with cyclone filter Oil mist extractor Blsdpfoyk Tdiox Ah Iod

Condition: used, Year of construction: 1995, functionality: fully functional, Equipment: documentation/manual, rotational speed infinitely variable, Mori Seiki Lathe 3 Axes X, Z, C Model SL-45 MC Year 1995 Fanuc CNC Without jaw chuck Bledpfx Aeykkzfoh Ijd With tooling With chip conveyor With documentation Complete

Condition: good (used), Year of construction: 2017, NC steady rest for shaft machining Y-axis: -60/+80 mm Driven tools/C-axis for milling and drilling operations Tailstock BMT turret VDI 40 / 12 station Spindle bore: 106 mm Draw tube bore: 95 mm SIEMENS 840 D Diameter: 700 mm (27.56 in) Blodeyizdhspfx Ah Isd Rotational speed: 2,500 rpm, 3,500 rpm (15,707.963 rad/min, 21,991.149 rad/min) Workpiece length: 1,300 mm (51 in) Max. turning diameter: 500 mm (20 in) Bar capacity: 95 mm (4 in) X-travel: 318 mm (13 in) Z-travel: 1,360 mm (54 in) Rapid traverse X-axis: 24 m/min Rapid traverse Z-axis: 30 m/min Rated power: 33 kW, 42 kW (44.9 hp, 57.1 hp) Max. torque: 800 Nm, 1,040 Nm (590 ft.lb, 767 ft.lb) Coolant capacity: 350 l (92 gal) Overall length: 6,511 mm (256 in) Overall width: 2,249 mm (89 in) Overall height: 2,150 mm (85 in) Weight: 11,000 kg (24,251 lb)

Condition: good (used), Year of construction: 1997, Manufacturer: MAWItec Maschinenbau | Model: Turnstar III | Serial Number: 1012 | Year of Manufacture: 1997 | Control: MAWItec CNC (integrated operator panel with screen and membrane keypad) | Operating Voltage: 400 V | Frequency: 50 Hz | Design: Enclosed production lathe | Headstock with automatic clamping system | Fully enclosed working area | Integrated coolant system | Dimensions: approx. 2000 mm x 3550 mm x 1900 mm (HxLxW) | The stated dimensions are approximate values. All other information provided without guarantee. | Red/Grey | Steel Bodpfxjyib A Uj Ah Iold

Condition: excellent (used), Year of construction: 2005, operating hours: 1,947 h, functionality: fully functional, turning length: 1,000 mm, WE OFFER AN VERY NICE CONDITION MAZAK QTN-250 / 1000L (built in 2005) FULLY FUNCTIONAL FROM THE PRODUCTION • MAZAK QTN-250 / 1000L (built in 2005) • MAZATROL 640 control • 1 turret • 12 tool positions • includes tool eye and chip conveyor • Speed range 4.000 rpm • fully functional • regular documented maintenance • available from 05/2026 IN MAY 2026 WE CAN LOAD MACHINE FOR CUSTOMER Bljdpfxoyhzv Se Ah Ijd

Condition: good (used), Year of construction: 2023, functionality: fully functional, Machine Parameters: Swing diameter over bed: 750 mm Maximum turning length: 4000 mm Swing diameter over cross slide: 560 mm Description: The machine is in good technical condition and can be inspected by prior arrangement. The machine was installed in 07/2023 and has seen very little use. Total operating hours are 3900, of which the spindle has run for 540 hours. Swing diameter over bed: 750 mm MACHINE SPECIFICATIONS: STYLE 750 Bjdpfx Aoyg R Tgsh Ield Model: STYLE 750 Swing diameter over bed: 750 mm Swing diameter over cross slide: 530 mm Distance between centers: 4000 mm Bed width: 450 mm Maximum load between centers: 1800 kg Maximum load with fixed steady rest (type U): 2500 kg Main Spindle: Spindle motor power (S6): 26 kW Maximum spindle speed (number of speed ranges): 2000 rpm (3) Spindle bore: Ø105 mm Spindle nose: A2-11 X and Z Axis: Ball screw diameter X axis: 32 mm Ball screw diameter Z axis: 50 mm Rapid traverse: 8 m/min Feed range: 0.01-2000 mm/min Tailstock: Quill diameter: 125 mm Quill travel: 225 mm Quill taper: MT 6 General: Machine weight: 8150 kg Machine color: Frame RAL 7021, Panels RAL 9006 Machine dimensions: 6.3 x 2.3 x 2.2 m The machine will be supplied with: - Machine lighting: LED - Coolant system - Automatic lubrication - Steel ball screw covers - Full enclosure - Front sliding doors - Electronic handwheel - Constant cutting speed, chip conveyor Including additional equipment: - Automatic tool changer, 8 positions, VDI-50 - Heavy-duty tailstock, desktop PC software version - 26 kW main motor, handwheel, oil separator - Steady rest D50-300mm, steady rest D60-400mm - Coolant pump switch - 3-jaw chuck D315 – Schunk Rota S Plus2.0 - Speed potentiometer - LED lamp, LAN, heavy-duty coolant system with spray gun Swing diameter over cross slide: 530 mm Distance between centers: 4000 mm Bed width: 450 mm Maximum load between centers: 1800 kg Maximum load with fixed steady rest (type U): 2500 kg Main Spindle: Spindle motor power (S6): 26 kW Maximum spindle speed (number of speed ranges): 2000 rpm (3) Spindle bore: Ø105 mm Spindle nose: A2-11 X and Z Axis: Ball screw diameter X axis: 32 mm Ball screw diameter Z axis: 50 mm Rapid traverse: 8 m/min Feed range: 0.01-2000 mm/min Tailstock: Quill diameter: 125 mm Quill travel: 225 mm Quill taper: MT 6 General: Machine weight: 8150 kg Machine color: Frame RAL 7021, Panels RAL 9006 Machine dimensions: 6.3 x 2.3 x 2.2 m The machine will be supplied with: - Machine lighting: LED - Coolant system - Automatic lubrication - Steel ball screw covers - Full enclosure - Front sliding doors - Electronic handwheel - Constant cutting speed, chip conveyor Including additional equipment: - Automatic tool changer, 8 positions, VDI-50 - Heavy-duty tailstock, desktop PC software version - 26 kW main motor, handwheel, oil separator - Steady rest D50-300mm, steady rest D60-400mm - Coolant pump switch - 3-jaw chuck D315 – Schunk Rota S Plus2.0 - Speed potentiometer - LED lamp, LAN, heavy-duty coolant system with spray gun

Condition: good (used), Year of construction: 2016, functionality: fully functional, Fanuc control system, gantry loader, one turret with Y-axis, two spindles, loader is designed for forged or sawn parts. Bedpfx Aeyg H U Tjh Iold

Condition: good (used), CNC Lathe with y-axis Geminis Goratu - GHT-4 G4-800 Max. turning Ø:800mm Length: 7000mm Width: 2500mm Height: 2500mm Bodpfx Asygv Eujh Iold Weight: 10000kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: used, Year of construction: 2013, Technical details: turning diameter over bed: 284 mm turning length: 406 mm Bjdpfxoydddtj Ah Iold x-axis: 218 mm longitudinal traverse (z-axis): 406 mm control: Siemens 828D revolution per minute: 5000 U/min spindle bore: 62 mm max. torque on the spindle: 125 Nm rapid motion - x-axis: 30 m/min rapid traverse Z-axis: 30 m/min tool turret - number of stations: 12 Stationen / Stations Weight approx.: 2,8 t dimension machine xH: 3,10 x 1,40 x 2,29 m dimension L-W-H: Späneförderer: 3400 x 1150 x 2180 mm

Condition: new, Year of construction: 2026, Heavy-Duty CNC Lathe Series – Precision and Productivity The heavy-duty CNC lathe series guarantees high efficiency in powerful cutting operations combined with excellent machining accuracy. Our CNC Lathe 800 × 3000 is not just a machine—it is a reliable partner for both experienced professionals and those starting their journey in manufacturing. Its power and stability, supported by wide guideways, make it an indispensable solution for even the most demanding metalworking projects. CNC Lathe 800 × 3000 The CNC Lathe 800 × 3000 is a professional numerical control machine designed for high-precision metal machining in demanding industrial applications. Thanks to its rigid construction and advanced control systems, it delivers reliability and high productivity in both serial and single-piece production. Bljdpfx Ajycrz Reh Isd CNC Control – Siemens Sinumerik 808D Siemens Sinumerik 808D is a cost-effective CNC control system dedicated to entry-level CNC lathes and milling machines, ideal for small and medium-sized workshops. Its key features include: Intuitive operation – Graphical interface and Teach-In function simplify programming and significantly reduce operator training time. High reliability – Rugged design resistant to dust and moisture ensures stable operation in harsh workshop environments. Compatibility – Designed for machines with standard requirements, offering seamless integration with SIEMENS servo drives. Cost optimization – Low energy consumption and minimal maintenance requirements make it ideal for first-time CNC users. Technical Specifications – CNC Lathe 800 × 3000 Distance between centers: 3000 mm Maximum turning diameter: 800 mm Maximum turning diameter over cross slide: 520 mm Bed width: 600 mm Spindle bore: 104 mm (130 mm optional) Spindle speed range: 22–108 / 60–300 / 240–1200 rpm Maximum X/Z axis travel: 420 / 1350, 2850 mm Rapid traverse X/Z: 4 / 8 m/min Positioning accuracy: 0.03 / 0.04 mm Repeatability X/Z: 0.012 / 0.02; 0.025 mm Tailstock quill diameter: 100 mm Maximum tailstock quill travel: 250 mm Tailstock taper: MT5 Number of tools: 4 (6 or 8 optional) Tool size: 32 × 32 mm Maximum load capacity: 1700 kg Main motor power: 15 kW Machine weight: 8700 kg Machine dimensions (L × W × H): 5200 × 2540 × 1860 mm Standard Equipment Fully enclosed working area 4-station tool post 320 mm 3-jaw chuck Chuck and manual tailstock Fanuc or Siemens CNC control Coolant system Machine lighting

Condition: excellent (used), Year of construction: 1993, functionality: fully functional, turning diameter over cross slide: 710 mm, turning length: 2,000 mm, turning diameter: 1,000 mm, spindle bore: 128 mm, rapid traverse X-axis: 5 m/min, rapid traverse Z-axis: 2 m/min, rotational speed (min.): 6 rpm, rotational speed (max.): 1,600 rpm, total height: 2,250 mm, total length: 5,800 mm, total width: 2,005 mm, quill travel distance: 280 mm, quill diameter: 125 mm, swing diameter over cross slide: 710 mm, torque: 4,260 Nm, overall weight: 10,100 kg, Equipment: documentation/manual, - Swing diameter over bed: 1000 mm - Swing diameter over cross slide: 710 mm - Feed rate in X, Z axes: 0.01–50 mm/rev - Feed speed in X/Z axes: 5/2.5 m/min - Rapid traverse in X/Z axes: 10/5 m/min - Feed force in X/Z axes: 20,000/12,500 N - Constant cutting speed: 1–9999 m/min - Distance between centers: 3300 mm - Faceplate diameter: 900 mm - 3-jaw chuck diameter: 500 mm - Bed width: 560 mm - Cross slide travel: 540 mm - Top slide travel: 250 mm - Metric thread pitch: 0.1–400 mm - Spindle nose: KK 11 DIN 55027 - Number of motor gear stages: 2 - Spindle speed range (first gear): 6.3–360 rpm - Spindle speed range (second gear): 28–1600 rpm - Spindle bearing diameter (front): 170 mm - Spindle bore diameter: 128 mm - Spindle internal taper: 136 metric Bledpfx Aheya Dz Dj Ied - Tailstock quill diameter: 125 mm - Tailstock quill stroke: 280 mm - Tailstock quill internal taper: Morse 6 (MK6) - Cross slide dimensions (L x W): 1005 x 320 mm - Top slide width: 200 mm - Tool cross-section per DIN 770: 40 x 25 mm - Main drive power (60%/100% duty): 46/37 kW - Main drive torque (60%/100% duty): 5300/4260 Nm - Total power requirement: 60 kVA - Power supply: 400 V - Control cabinet dimensions (L x W x H): 1800 x 500 x 1600 mm - Machine dimensions (L x W x H): 5800 x 2005 x 2250 mm - Machine weight: approx. 10,100 kg CNC controller: SIEMENS SINUMERIK - Toolholder: MULTIFIX type D - AC servo drives - Reliable stepless AC main drive - Work area lighting

Condition: good (used), Year of construction: 2014, operating hours: 8,500 h, functionality: fully functional, turning diameter over cross slide: 800 mm, turning length: 900 mm, turning diameter: 500 mm, spindle bore: 77 mm, spindle speed (max.): 3,200 rpm, Spinner TC 800-77 MCY Year of manufacture: 2014 Maximum turning diameter: 500 mm Maximum turning length: 900 mm Control: Fanuc 31i Maximum swing diameter: 800 mm Main spindle: Maximum speed: 3,200 rpm Drive power (main spindle): 24 / 33 kW Maximum torque: 630 Nm Chuck diameter: 250 mm Spindle nose: A8 Bar capacity: 77 mm Travel distances: X-axis: 360 mm Y-axis: 120 mm (-55/+65) Z-axis: 900 mm C-axis: 360° Tool turret: Tool stations: 12 positions Driven stations: 12 positions Tool holder: VDI 50 Speed range (driven tool stations): max. 4,000 rpm Drive power (driven tool stations): 5 / 9.6 kW Bjdpfx Ajyax Hbjh Ijld Torque: 18 / 35 Nm Feeds: Rapid traverse X: 15 m/min / Z: 24 m/min Total power requirement: - kW Machine weight approx.: 7.5 t Space requirement approx.: 4.3 x 3.0 x 2.2 m Control ON hours: 44,700 Operating hours: 8,518 Machining hours: 6,631

Condition: like new (used), Year of construction: 1999, functionality: fully functional, MORI SEIKI SL-600B/2000 CNC LATHE Category: CNC Turning Centers Reference No.: 400212 Capacity: Ø900 X 2000 MM Year of Construction: 1999 Technical Specification: CNC Control : Fanuc 18iT WORKING CAPACITY Max Turning Diameter : 900 mm Max Turning Length : 2000 mm Swing over bed : 994 mm Distance Between Centers : 2300 mm Swing over cross slide : 733 mm Travels (X) : 485 mm (440 + 45) mm Travels (Z) : 2150 mm TURRET Turret : 12 Station Square tool shank size : 32 mm Bledpex Nv Shefx Ah Ied Boring bar shank diameter : 65 mm TAILSTOCK Tailstock : MT5 Tailstock Quill Travel : 150 mm Tailstock Quill Dia : 150 mm SPINDLE Max Rotation Speed : 1500 RPM Main Spindle Nose : JIS A2-15 Main Spindle Bore : 185 mm Spindle Type : 3 Step Gearbox Spindle bearing inner diameter : 260 mm MACHINE DIMENSIONS Weight : 16T Additional Details: All Specifications are found online, and subject to verification by buyer.

Condition: good (used), VICTOR VTURN-46 CNC HEAVY DUTY SLANT BED LATHE WITH FANUC SERIES O-T CONTROL UKUK 4 Jaw Ø505mm Chuck. Maximum Turning Ø730mm. Standard Turning Ø520mm. Distance Between Centres 1,750mm. Axis Travel 'X'=365mm, 'Z'=1,650mm. Rapid Traverse 'X'=15m/min, 'Z'=12m/min. Spindle Speed 1,500rpm (30kW Motor). 10 Station Turret. S/No. MB-1193. DESCRIPTION With Coolant System, Chip Conveyor, Filtermist F21/8 Mist Extraction Unit, Tool Setting Arm, 3 Jaw Ø445mm Hydraulic Chuck, Tailstock, 2 Steadies, Foot Switches, Signal Tower, Large Quantity Of Jaws, Tool Blocks & Boring Bar Sleeves. Overall Dimensions L6,200 x W2,500 x H2,500mm. Weight 12,800kg. Blodpfx Ahjx Naqne Ied

Condition: good (used), Year of construction: 2007, Turning Length 3.500 mm Turning diameter 720 mm Bodpfx Asx Hvvuoh Ijld Some technical details are shown on photos.

Condition: used, Year of construction: 1998, turning length: 800 mm, turning diameter: 600 mm, spindle bore: 127 mm, spindle speed (max.): 2,500 rpm, travel distance X-axis: 345 mm, travel distance Z-axis: 995 mm, Mori Seiki SL-400B CNC Lathe (1998) Machine Type: CNC Turning Center (2-Axis) Year of Manufacture: 1998 Control System: Mori Seiki MSC-501 Machining Capacity Maximum Turning Diameter: approx. 600 mm Maximum Turning Length: approx. 800 mm Distance Between Centers: approx. 940 mm X-Axis Travel: approx. 343 mm Z-Axis Travel: approx. 993 mm Spindle Nose: A2-11 Spindle Bore: approx. 127 mm (5") Spindle Speed: up to 2,400 rpm Spindle Motor Power: approx. 30 kW Tool Turret: 12 Stations Bljdpox Hpw Sefx Ah Isd Machine Weight: approx. 9,500 Machine Dimensions (L × W × H): approx. 4,300 × 2,000 × 2,100 mm

Condition: used, Year of construction: 1998, turning length: 800 mm, turning diameter: 600 mm, spindle bore: 127 mm, spindle speed (max.): 2,500 rpm, travel distance X-axis: 345 mm, travel distance Z-axis: 995 mm, Mori Seiki SL-400B CNC Lathe (1998) Machine Type: CNC Turning Center (2-Axis) Year of Manufacture: 1998 Control System: Mori Seiki MSC-501 Machining Capacity Maximum Turning Diameter: approx. 600 mm Bjdpfxjx Hpvus Ah Ield Maximum Turning Length: approx. 800 mm Distance Between Centers: approx. 940 mm X-Axis Travel: approx. 343 mm Z-Axis Travel: approx. 993 mm Spindle Nose: A2-11 Spindle Bore: approx. 127 mm (5") Spindle Speed: up to 2,400 rpm Spindle Motor Power: approx. 30 kW Tool Turret: 12 Stations Machine Weight: approx. 9,500 Machine Dimensions (L × W × H): approx. 4,300 × 2,000 × 2,100 mm
