Mannseichner Metallbau GmbH

Condition: new, 6,5 mm ST 40 3,5 mm VA 90° Grad Gjdpexcux Defx Afpsbu blade length 250 x 250 mm table: 810 x 750 mm work height max. 950 mm engine output 4,0 weight 630 kg range L-W-H 810 x 750 x 1150 mm Characteristics : - Notching with a burr-free cut, without deformation of the cut edges - Blades made of surface-hardened tool steel - Operation by means of a foot pedal, so both hands are free for the workpiece - Large dimensioned work table with built-in scales - T-slots for precise guidance of the swiveling stops - Protective cover in front of the cutting blade for high security scope of delivery - 1 set of cutting knives - 2 swiveling material stops - Plexiglas protective cover - Foot pedal with emergency stop

Condition: excellent (used), functionality: fully functional, The machine is fully functional and has been used only very occasionally. Additional new knives and complete documentation are included. Gbodsxaw U Aspfx Afpou

Condition: new, plate thickness max. 5.0 mm tube diameter 27.9 - 61.0 mm motor 400 Volt total power requirement 2.2 kW weight of the machine ca. 93.0 kg. The AL1-2U electric pipe notcher is started at the push of a button, and the pipe notcher is driven continuously. This means you can continually work on new parts without having to switch the machine on again each time. With the electrically driven AL1-2U pipe notcher you can notch pipe outer diameters of Ø 26.9 (3/4?), Ø 33.7 (1?), Ø 42.4 (1 ¼"), Ø 48.3 (1 ½"), Ø 60.3 (2?). This pipe notcher is also suitable for notching a zinc outlet in round and rectangular metal pipes. You can notch pipe outer diameters of ø 20.0 -60.3. Do you often notch pipes? Then the electrically driven pipe notcher AL1-2U with the 2.2 kW electric motor is just the thing for you. The motor forms a unit with the special eccentric shaft that drives the notching tool. The motor is also equipped with an on/off switch with 0-voltage protection and a protective cap. Equipment: - electro-motor pipe notching machine - including notching station for zinc run-out notches - for pipes 27.9 - 34.8 - 42.8 - 49.0 and 61.0 mm Gbodpfxexaadms Afpou - operating instructions

Condition: excellent (used), Year of construction: 1998, FIM corner notching machine Model Goal 200/6 Gbodpow Tk Haefx Afpju Year : 1998 Capacity : 200 x 6 mm. Fixed angle : 90 grader Footpedal

Condition: used, Year of construction: 2002, Station 1 Disengagement: Max. sheet thickness: 6 mm steel, 4 mm stainless steel Fixed 90 degree angle with stops Gbjdpfowx Iwnox Afpeu Blade length 225 mm Station 2 Cutting: Max. cutting width: 25 mm in one cut at 100 mm cutting depth Max. sheet thickness: 4 mm steel Weight: 800 kg

Condition: good (used), Used notching machine from Euromac Type: 250 4 s Capacity: 250 x 250 x 4 mm Godpfowprmhsx Afpebu

Condition: excellent (used), Motorised notching machine with fixed cutting head 90° Table size 1050 x 900 mm Blade length 225 x 225 mm Cutting thickness for standard steel: t = 3 mm for sheet length 220 mm t = 4 mm for sheet length 140 mm t = 5 mm for sheet length 70 mm t = 6 mm for sheet length 10 mm Number of strokes 80/min. Drive power 1.5 kW Dimensions L x W x H 1300 x 1200 x 1200 mm Weight 770 kg Accessories / Special features: • Large worktable with 2 T-slots • Mechanical foot release Gedpfewntc Ijx Afpobu Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 D - 44143 Dortmund - Wambel

Condition: used, Angle cutter, Angle machine, Angle shears Manufacturer: FIM Type: Goal 200/6, Goal 206 Year of construction: 2000 Cutting width: 200mm Max. thickness: 6mm Fixed angle: 90gr Gbodpfxownitps Afpeu Engine power: 4kW Machine-afmetingen: 1200x1250x1300mm Machine weight: 1200kg - Documentation available: No Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: used, Year of construction: 1998, Notching machine, notcher Manufacturer: FIM Cutting-width: 200mm Max. thickness: 6mm Variable Angle-Adjustment Motor-power: 4kW Machine-dimensions: 1200x1250x1300mm Machine-weight: 1200kg - Year: 1998 - Documentation available: No Financial information VAT: The price shown is exclusive of VAT Gjdpfx Ajwnh Thjfpsbu VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: ready for operation (used), Hydraulic fixed angle notching machine COMA CA MOD. CHP 260. Two workstations: notching machine + punching machine. Blade length: 260 mm. Work surface: 850 x 700 mm. Gsdpjwhpg Aefx Afpobu Workable thickness: 6 mm No. 4 blank holder pistons. Punching: Power T 14 Weight: 1300 kg Use and maintenance manual.

Condition: ready for operation (used), functionality: fully functional, Year of construction: 1991, cutting force: 250 t, sheet thickness (max.): 6 mm, cutting length (max.): 220 mm, No reserve price - guaranteed sale to the highest bidder! TECHNICAL DETAILS Sheet thickness: 6 mm Pressure: 250 t Gbodpewf It Aefx Afpju Blade length: 220 mm Stroke length: 24 - 26 mm Ram stroke: max. 32 mm MACHINE DETAILS Machine weight: 1,600 kg

Condition: used, Year of construction: 2003, sheet thickness: 6messurements (LxWxH): 900 x 900 x 1150weight approx.: 850 Gedsv Ncn Rspfx Afpjbu

Condition: good (used), Year of construction: 2000, machine/vehicle number: M 100-34 E3-D, Offer 24371 Technical data: Gbjdou Rartspfx Afpeu - Machine for the production of closed cold-formed corners - Material thicknesses 0.8 to 2.5 mm - max. achievable shelf height see table - min. Workpiece length / min. workpiece width 120 mm - Production time per formed corner, independent of material 10 sec. - Drive 400 V / 4 kW - Control panel with E - foot switch - Space requirement station 1 approx. W 1100 x H 1650 x D 1100 mm - Weight of station 1 approx. 800 kg - Space requirement for station 2 approx. W 800 x H 1400 x D 900 mm - Weight of station 2 approx. 500 kg

Condition: used, plate thickness 4 mm Cutting thickness max. At (60 kg / mm²) 3 mm blade length 90 mm weight ca. 30 kg dimensions of the machine ca. 0,45 x 0,30 x 0,2 m Notching unit for installation under a hydraulic or eccentric press. The cutting thicknesses are estimated to be low. Machine dealer with own stock of 1600 m². Godpfx Afeu I Et Repsbu

Condition: used, Technical details: total power requirement: 2,2 kW table-size: 500 x 780 mm working area: 250 x 250 mm Gjdsu Icq Tjpfx Afpsbu height over floor: 940 mm voltage: 380 V / Hz Weight approx.: 0,642 t dimension machine xH: 1,0 x 1,3 x 1,2 m HYDRAULIC NOTCHING MACHINE On the table there are left and right 90° linear scales length 250mm stop bars length 400mm; angle adjustable left/right 90°) operated by switch button and/or hand/foot control incl. tool 2x upper and lower knives built in (knife length 250mm) *

Condition: new, - Capacity 250 x 8 mm - Hydraulic - Foot control Gedpfenwlptjx Afpsbu - Central lubrication system - Emergency stop - Documentation - 400V

Condition: used, Year of construction: 1988, Year ca. 1988 plate thickness bei Stahl max. 3,3 mm table: 1100 x 700 Gbjdpfx Afeiqu Ukspsu +++++ Please note: The machine is dismantled and ready for loading. It is not possible to show it under power or make a video. Our offer includes already the best pictures. So we don’t have and won’t send additional pictures. +++++

Condition: as good as new (ex-display), Year of construction: 2024, Boschert Notching Machine LB13 Punching Type LB13 Punching/Trunk Cutting capacity 6 mm St40/ 4 mm V2A Inner stop for cutting strips. Station 2 punching with Trumpf tool system Punching diameter max 76 mm throat 150 mm Gbsdpfshp N Ryox Afpju Punching force approx 15 tons with active stripper system Prefeeding machine year 2022

Condition: used, Year of construction: 1986, plate thickness 6,0 mm pressure 18 t cutting angle - upper blade 90 ° Gsdpfxjg Ip Efe Afpobu blade length 225 x 225 mm voltage 380 V total power requirement 5,5 kW weight of the machine ca. 650 kg dimensions of the machine ca. 1,10 x 0,80 x 1,05 m - Angular stops adjustable

Condition: as good as new (ex-display), Year of construction: 2024, Demonstration machine. Like new. The machine is fully equipped with: - large, comfortable table - Inside fence with adjustment scale and quick adjustment for cutting strips. - 4 locking precision stops with sliding and interchangeable stop bars 500 mm long. - 2 left and 2 right T-slots parallel to the blades - Plexiglass protection for clear notching - Lift release with freely movable foot pedal - Three stroke types: set-up stroke, single stroke and continuous stroke - 1 front cross stop system consisting of T-slot and scale - 1 left and 1 right scale, parallel to the knives Gjdefhw N Iepfx Afpjbu - 1 left and 1 right guide rail for notching magnification over 225 mm - 2 hold-down devices Two stations: Station 1 Disengage: cutting capacity: - 225 x 225 x 6mm in ST 45 - 225 x 225 x 4mm in stainless steel Station 2 punching with trump tool and/or cutting in thirty degrees max 4mm St45 max 3mm stainless steel Throat: max. 100mm

Condition: new, messurements (LxWxH): 0,80 x 0,85 x 1,20weight approx.: 0,610total power requirements: 4sheet thickness: 6 Gbedpfx Afed Ab Icepju

Year of construction: 2023, condition: as good as new (ex-display), Notching machine Boschert LB12/6 Machine colour blue Ral 5017 Cutting angle 90 Cutting capacity 6 mm St42 4 mm stainless steel Connected load 4kW Weight 800 kg Machine equipped with 2 stops with movable stop bar 300 mm Gbedpfx Aeb Raddsfpeu inner stop for cutting strips up to 225 mm 2 movable hold downs plexi protection CE and new machine guarantee
