KPS-Schleiftechnik GmbH

Condition: used, TECHNICAL DETAILS - Distance between centers : 600 [mm] - center height : 125 [mm] - Table orientation : 11 [°] GRINDING WHEEL HOLDER HEADSTOCK - Left grinding wheels dimensions : 400 x 50 x 127 [mm] Laodszf Rcdopfx Ammec - Power : 3 [kW] - Spindle speeds : 1500 / 1700 / 2200 [rpm] - Orientation of grinding wheel holder headstock : 270 [°] PART-HOLDER HEADSTOCK - Orientation of part holder headstock : 360 [°] - Spindle speeds : 20 - 400 [rpm] - Spindle internal cone : Morse 5 - Power : 0.9 [kW] TAILSTOCK - Internal cone : MT4 - Quill stroke : 30 [mm] POWER SUPPLY - Supply voltage : 380 [V] WEIGHT & DIMENSIONS - Machine floor space : 2580 x 1680 [mm] - Machine height : 1670 [mm] - Machine weight : 2200 [kg] EQUIPMENT - Coolant tank * with paper filtering unit - 1 internal grinding spindle - Lubricating tank with pump

Condition: ready for operation (used), Year of construction: 1998, functionality: fully functional, machine/vehicle number: LEAN PRO, FANUC 16 T Ljdpezfx D Nofx Ammjac FULLY FUNCTIONAL RANGE OF ACCESSORIES FILTRATION SYSTEM MIST EXTRACTOR MACHINE MANUALS

Condition: used, TECHNICAL DETAILS - Distance between centers : 1000 [mm] - center height : 175 [mm] - Table orientation : 9 [°] GRINDING WHEEL HOLDER HEADSTOCK - Left grinding wheels dimensions : 400 x 50 x 127 [mm] - Right grinding wheels dimensions : 225 x 20 x 76,2 [mm] - Power : 3 [kW] - Spindle speeds : 1500 / 1700 / 2200 [rpm] - Orientation of grinding wheel holder headstock : 270 [°] - Boring for internal spindle : 90 [mm] PART-HOLDER HEADSTOCK - Orientation of part holder headstock : 360 [°] - Spindle speeds : 20 - 400 [rpm] - Spindle internal cone : Morse 5 - Power : 0.9 [kW] TAILSTOCK - Internal cone : Morse 3 - Quill stroke : 30 [mm] POWER SUPPLY - Supply voltage : 380 [V] WEIGHT & DIMENSIONS - Machine floor space : 2860 x 1680 [mm] Lasdpfxozfqzae Ammec - Machine height : 1670 [mm] - Machine weight : 2500 [kg] EQUIPMENT - Automatic cycle work (rough part, finishing and reverse) - Kelco 5 display - Coolant tank * with paper filtering unit - 1 internal grinding spindle : 5400 [rpm] - Chuck 4 jaws - 1 three-key steady rest - Set of wheels

Condition: good (used), Year of construction: 1996, functionality: fully functional, grinding length: 1,000 mm, External cylindrical grinding machine KARSTENS K29 Year of manufacture: 1996 The machine underwent a complete mechanical overhaul in 2022. Invoices are available. Grinding length: 1,000 mm Grinding diameter: Accessories: Ljdezfgvajpfx Ammoac - Coolant system - Various grinding wheels - Measuring probe Further details to follow.

Condition: used, External/Internal Cylindrical Grinding GENDRON RU 28.100 Lajdpezd Um Rofx Ammoc Between points: 1000 mm Maxi grinding diameter: Ø 290 mm Tool holder rotation: from 70 to 370 RPM 4-jaws Ø 200 mm chuck Grinding wheel: Ø 300 mm Auto pass plug Swivel table External hydraulic group External lulbricant tank Voltage: 380 V Dimensions (L x W x H): 3000 x 1900 x 2000 mm Weight: approx 3 T

Condition: good (used), Year of construction: 1997, Ref. -No.: 10619 Manufacturer: KELLENBERGER Type: 600 U Nr. 35 Year of construction: 1997 Type of control: Konventionell Control: n/a Storage location: Halberstadt Country of origin: Switzerland Distance between center: 600 mm Center height (standard): 125 mm Height of centers by lifting work blocks head and tailstock: 175 - 250 mm Swing diameter with lifting blocks max.: 350 - 500 mm Table swivel / each side: 10 ° Dwell time of the table reversal: 0- 5 Sec Diameter / width / hole: 250 x 13 x 76 mm Speeds of the grinding wheel spindle: 1500 / 1700 / 2200 / 3600 Swiveling grinding wheel head: 360° ° Cross movement of the grinding wheel head: 285 mm Quickly pulling the wheel head back and forth: 40 mm Intermittent injection for each reversal of the table: 0,001 - 0,03 mm / dia Working speeds continuously adjustable (normal / special): 20-400 / 10-400 Max. Grinding length: 900 mm Further information: The machine can be viewed while powered up. Ledjzc D Dqspfx Ammjac

Condition: good (used), Year of construction: 2001, Ref. -No.: 10617 Manufacturer: KELLENBERGER Type: 600 U Nr. 36 Year of construction: 2001 Type of control: Konventionell Control: n/a Storage location: Halberstadt Country of origin: Switzerland Distance between center: 600 mm Center height (standard): 125 mm Ljdpfjzc D Dksx Ammoac Height of centers by lifting work blocks head and tailstock: 175-250 mm Swing diameter with lifting blocks max.: 350 - 500 mm Table swivel / each side: 10 ° Dwell time of the table reversal: 0 -5 Sec Diameter / width / hole: 250 x 13 x 76 mm Speeds of the grinding wheel spindle: 360° Cross movement of the grinding wheel head: 285 mm Quickly pulling the wheel head back and forth: 40 mm Intermittent injection for each reversal of the table: 0,001 - 0,03 mm / dia Micro-corrector of the feed, 1 division of the dial: 0,001 mm / Ø Working speeds continuously adjustable (normal / special): 20 - 400 / 10-400 Max. Grinding length: 900 mm Further information: The machine can be viewed while powered up.

Condition: ready for operation (used), Year of construction: 1989, functionality: fully functional, machine/vehicle number: 32.469.3143, center height: 125 mm, grinding length: 1,000 mm, The machine underwent a partial overhaul in 2009. TECHNICAL DETAILS Maximum height: 125 mm Lasdpfx Amjzcwfnomec Maximum width: 1,000 mm EQUIPMENT Automatic working cycle Intermediate plates 50 mm for a maximum height of 175 mm Vibration-damping pads Machine light Internal grinding device for a maximum diameter of 70 mm Internal grinding spindle UJ7P Coolant supply through the workpiece spindle, including protective cover Side and angled dressing device Swiveling dressing device for internal grinding Dressing stop for internal grinding Collet chuck Set of collets Dial indicator stop for table swiveling with a 1/100 mm dial indicator Sine bar Table fixed stop Strip-type filter system SONY digital measuring system, 2 axes Documentation

Condition: refurbished (used), Year of construction: 2004, functionality: fully functional, machine/vehicle number: 027.0149, CNC internal and external cylindrical grinding machine S33 CNC – undergoing refurbishment. Ljdpfx Ajzcuwbemmjac Delivery time: approximately 14 weeks. Technical data and accessories as per the attached PDF. Photo = sample photo only.

Condition: good (used), functionality: fully functional, Stanko 3A151 Cylindrical Grinding Machine For sale is a high-quality cylindrical grinding machine, type Stanko 3A151. The machine is suitable for the precise external cylindrical grinding of cylindrical workpieces as well as flat cones and is ideal for use in workshops, toolmaking, series production, and maintenance. Technical data: Max. workpiece diameter: 200 mm Max. workpiece length: 700 mm Max. grinding length: 630 mm Center height: 110 mm Max. workpiece weight: 30 kg Table travel: 650 mm Continuously adjustable table speed: 100–6000 mm/min Grinding wheel diameter: 450–600 mm Max. grinding wheel width: 63 mm Grinding spindle speed: 1112 / 1272 rpm Workpiece spindle speed: continuously adjustable 63–400 rpm Lasdpfxezcg H Is Ammec Travel of grinding head: 200 mm Main drive grinding spindle: 7.5 kW Number of electric motors: 7 Machine dimensions (L × W × H): 3100 × 2100 × 1500 mm Machine weight: approx. 4,200 kg Equipment and features: Hydraulic table drive Automatic and manual transverse feed Rapid traverse of the grinding head Hydraulic tailstock quill Cooling system Lubrication system Magnetic separator Suitable for longitudinal and plunge grinding High precision and robust industrial design Condition The machine is in technically perfect condition. It is ready for immediate use and impresses with its robust construction and high grinding accuracy. Inspection and test run possible by appointment. Available from week 30.

Condition: refurbished (used), Year of construction: 2023, operating hours: 3,000 h, functionality: fully functional, center height: 180 mm, workpiece weight (max.): 200 kg, grinding length: 1,000 mm, center width: 1,000 mm, grinding wheel diameter: 500 mm, total width: 2,600 mm, total length: 4,700 mm, total height: 2,200 mm, grinding diameter: 300 mm, workpiece weight between centers: 200,000 g, type of input current: three-phase, workpiece diameter between centers: 300 mm, workpiece length between centers: 1,000 mm, grinding wheel width: 100 mm, spindle speed (max.): 1,200 rpm, spindle speed (min.): 10 rpm, feed length X-axis: 320 mm, feed length Z-axis: 1,100 mm, feed rate X-axis: 1,000 m/min, feed rate Y-axis: 1,500 m/min, grinding spindle speed: 1,700 rpm, overall weight: 7,500 kg, pivoting range: 30 °, warranty duration: 12 months, year of last overhaul: 2023, input frequency: 50 Hz, rapid traverse X-axis: 1,000 m/min, rapid traverse Z-axis: 1,500 m/min, input voltage: 400 V, Schaudt PF43 U1000, manufactured in 1994, retrofitted (premium refurbished) by GSN in 2023. Siemens Sinumerik 840 D SL control system. Low operating hours, approximately 3000 hours since the retrofit. MK4 workpiece spindle, MK4 tailstock. Grinding travel: 300mm Workpiece length, including clamping devices, at maximum grinding travel: 450mm Grinding wheel dimensions: 500x100mm Bore diameter: 203.2mm Controlled workpiece circumferential speed (WUG) Lodpfezcfnqex Ammsac SUG external cylindrical grinding spindle: 45m/s Freely positionable, automatic B-axis Machine with new, fully enclosed splash guard GSN measuring head Diatronic 22 including C2 and W axes/turret Touch probe sensor with hydrophone (water jet) including collision monitoring Tailstock retrofitted with automatic cylinder error compensation Clamping/unclamping adjustable via hydraulic clamping device Upgrade to a 15" screen on the control panel NEW PRICE GROSS 2023: €407,432.20 plus additional tools, etc.

Condition: used, Year of construction: 2020, operating hours: 6,875 h, machine/vehicle number: IntNr231185, EMAG WEISS W11 CNC SL650 – Universal cylindrical grinding machine – Year of manufacture: 2020 A used EMAG WEISS W11 CNC SL650 is available for sale – a high-performance universal cylindrical grinding machine with CNC control. The machine is ideally suited for demanding grinding tasks on individual parts, prototypes, and small to medium production runs. Machine specifications Manufacturer: EMAG WEISS Type: W11-CNC SL650 Year of manufacture: 2020 Operating hours: approx. 6,850 spindle hours / approx. 20,422 operating hours Condition: Used, well-maintained, ready for immediate use Technical data Control: CNC-controlled (e.g., Heidenhain / Siemens / Fanuc – depending on the configuration) Laodpozcfgmefx Ammjc Max. grinding length: 650 mm (between centers) Center height: approx. 200 mm External grinding diameter: up to approx. 390 mm Max. workpiece weight (overhang): approx. 100 kg (MK4) Max. workpiece weight between centers: approx. 250 kg X-axis travel: approx. 380 mm Z-axis travel: approx. 1,150 mm Grinding wheel diameter: 400 – 500 mm, depending on configuration Rated power: 9 – 11 kW (approx. 12 – 15 hp) Peripheral speed: 20 – 50 m/s Features and performance characteristics CNC touchscreen operation with a Windows-based interface – user-friendly programming via dialogue or DIN/ISO (optional) Two-in-one concept: the machine can be operated both conventionally and with CNC control High-precision linear and ball screw guides for high accuracy Direct measuring system (glass scales) (optional on many machines) Automatic grinding wheel truing with compensation Crash control & gap monitoring for machine and process safety Coolant system, emulsion separator, and chip conveyor available (depending on configuration) Preparation for automation / robot interface is possible The machine can be inspected in operation by appointment. Subject to changes, errors and prior sale!

Condition: ready for operation (used), Year of construction: 1997, functionality: fully functional, machine/vehicle number: 011.257.90.043, center height: 175 mm, center width: 1,000 mm, controller manufacturer: Fanuc, TECHNICAL DETAILS Ljdpfxozb Hxns Ammjac Maximum center height: 175 mm Distance between centers: 1,000 mm Longitudinal slide Maximum longitudinal slide travel: 1,050 mm Cutting speed (vt): 0.0001–10,000 mm/min Resolution: 0.0001 mm Table tilt: max. 8.5° Cross slide Maximum cross slide travel: 275 mm Cutting speed (vt): 0.0001–10,000 mm/min Resolution: 0.0001 mm MACHINE DETAILS Control system manufacturer: Fanuc

Condition: used, Year of construction: 2020, functionality: fully functional, For sale is a KNUTH RSM 1000 C cylindrical grinding machine in very well-maintained and fully functional condition. The machine comes from a working production facility and is in very good optical and technical condition. It is ideally suited for precise grinding operations in metalworking, toolmaking, manufacturing, and industry. Ledpfx Aezb Ag Ismmsac Technical data: * Manufacturer: KNUTH * Model: RSM 1000 C * Machine type: Cylindrical grinding machine / Precision grinding machine * Year of manufacture: 2020 * Condition: very well-maintained / fully functional * Application area: Metalworking, toolmaking, precision manufacturing * Location: Meinerzhagen

Condition: refurbished (used), Year of construction: 2005, functionality: fully functional, machine/vehicle number: 019.3790, Machine undergoing repair/overhaul = estimated delivery time approximately 8-10 weeks. Technical data + accessories, see separate PDF. Ljdozbqzaspfx Ammoac

Condition: good (used), Year of construction: 1989, functionality: fully functional, center height: 180 mm, grinding length: 1,000 mm, grinding wheel diameter: 400 mm, Round grinding machine KARSTENS K11 Control: hydraulic, manual Lodpfozbhkxsx Ammoac Grinding length: 1000 mm Grinding diameter: 360 mm Grinding wheel diameter: 400 mm Peripheral speed: 35 m/s Drive power: 5.5 kW Spindle diameter: 60 mm Tailstock arbor: MK 4 Swiveling stroke: Y-axis: Belt filter system Digital display

Condition: reconditioned (used), Year of construction: 2003, functionality: fully functional, machine/vehicle number: 055 - 030.0221, Complete overhaul Year 2003 - Fanuc 16i-T Center height 175 mm and distance between centers 650 mm 2 external grinding wheels + B-axis fine adjustment Ljdszbaz Ajpfx Ammjac Country of origin: CH Voltage: 3x400V Dimensions: 3680x2165x2100 mm Net machine weight: 5500 kg TECHNICAL SPECIFICATIONS Center height: 175 mm Distance between centers: 650 mm LONGITUDINAL SLIDE (Z) Maximum travel: 800 mm Speed: 0.001 – 10,000 mm/min Resolution: 0.0001 mm TRANSVERSE SLIDE (X) Maximum travel: 254 mm / SPW 650 Speed: 0.001 – 5,000 mm/min Resolution: 0.0001 mm Maximum weight of workpiece clamped between centers: 80 kg TAILSTOCK Taper: Morse 3 Sleeve: Ø 50 mm Sleeve travel: 35 mm UNIVERSAL GRINDING WHEEL HEAD Left wheel dimension: 500 x 80 x 203 mm Right wheel dimension: 400 x 80 x 203 mm Grinding wheel head power: 12.5 kW Rotation speed: 3,200 min-1 Programmable cutting speed up to: 50 m/s B-axis travel: -15 to +195° B-axis indexing accuracy: 0.0001 ° LEFT WORKPIECE HEAD Taper: CM3 Power: 4 kW Rotation speed: 1-1000 min-1 C-axis indexing accuracy: 0.001 ° RIGHT WORKPIECE HEAD Taper: CM3 Power: 4 kW Rotation speed: 1-1000 min-1 C-axis indexing accuracy: 0.001° Hydraulic feed with pressure control Subject to errors and omissions, the technical specifications are provided without commitment. Inventory No. 2250029: STUDER S31 CNC, S/No. 055 - 030.0221 Completely overhauled: Mechanical, geometry, hydraulics, and electrical components (checked and/or replaced) Grinding wheel head Disassembly, cleaning of parts, replacement of worn and defective parts, overhaul of the motor, replacement of bearings, replacement of belts, spindle disassembly, replacement of seals and O-rings + adjustment. New paint. Workpiece head Disassembly, cleaning of parts, replacement of worn and defective parts, overhaul of the motor, replacement of belts. New spindle bearings. New paint. Tailstock Disassembled, inspected, overhauled Hydraulics Disassembly, motor check, replacement of pipes, defective and worn parts. Check the hydraulic block. X-axis Disassembly, replacement of worn parts such as O-rings, seals, segments, etc., overhaul of the hydraulic piston, re-grinding of the tables. Z-axis Disassembly, re-grinding of the tables, replacement of worn and defective parts, overhaul of the hydraulic piston, new paint. Electrical cabinet Complete check, replacement of various relays. Paint Colors: White RAL 9003 and gray RAL 7011 Geometry according to manufacturer's protocol. Inspection and cleaning of various accessories.

Condition: used, 3 flanges for type 600 U – available for sale individually or as a set Ledpfx Aoza Hnyommsac

Condition: used, Technical details: grinding length: 300 mm centre height: 175 mm swing diameter: 315 mm table clamping surface LxW: 1.800 x 200 mm control: Heidenhain Longitudinal adjustment of grinding unit on table max.: 1100 mm work piece spindle speed: 3steps/1500-2200 U/min feed continuous: 0,001-1 mm Max. travel x-axis: 300 weight of the machine ca.: 3,1 t dimension machine xH: 2,9 x 1,6 x 1,4 mm Swivel for right and left machining Automatic table reversal Tailstock: MK3 holder Operation: Manual control unit/foot switch Coolant: System with feed Heidenhain measuring device Ledpfxozaunzs Ammsac *

Condition: used, Year of construction: 1999, grinding diameter 350 mm grinding length 1000 mm centre height 175 mm GENERALÜBERHOLT Foto von ähnlicher bereits gelieferter Maschine - Schleifscheibenausrüstung LINKS 500mm - Schleifscheibenausrüstung RECHTS 400mm - Innenschleifeinrichtung 120mm für riemengetriebene Innenschleifspindeln (standard) - CNC-Steuerung FANUC 18i-TA - vorbereitet für Messsteuerung Marposs kombiniert (Minialsar, Positionar)mit E5N - B-Achse - Kel-Set - hydraulischer Pinolenrückzug - Mikroverstellung am Reitstock - Werkstückspindelstock mit schwenkbarem Unterteil - Schleifscheibenausrüstung LINKS 500mm - Schleifscheibenausrüstung RECHTS 400mm - Innenschleifeinrichtung 120mm für riemengetriebene Innenschleifspindeln (standard) - CNC-Steuerung FANUC 18i-TA - vorbereitet für Messsteuerung Marposs kombiniert (Minialsar, Positionar)mit E5N - B-Achse - Kel-Set - hydraulischer Pinolenrückzug - Mikroverstellung am Reitstock Laodpfx Amjy U N Hpomoc - Werkstückspindelstock mit schwenkbarem Unterteil

Condition: used, Year of construction: 2010, grinding diameter 350 mm grinding length 1000 mm centre height 175 mm Control Fanuc 310is CNC control GE Fanuc 310is Hand panel for CNC control GE Fanuc Wenger loader optional Turned part with automatic indexing 1° Grinding head UR 1-2-3 Grinding wheel equipment left 500 x 80 mm Grinding wheel equipment right 400 x 63 mm Operating unit for one high-speed internal grinding spindle MFV / MFZ High-frequency internal grinding spindle MFN 1090 Coolant supply through the workpiece spindle Dressing unit on the upper table Swivelling holder for PCD diamond plates Basic module for KEL-TOUCH gate sensor and KEL-BALANCE balancing devices KEL-TOUCH lead sensor for universal grinding head variants R / RS / UR / URS KEL-TOUCH on the workpiece headstock for internal and external grinding Lsdpfx Aey U N Hijmmeac Preparations for Movomatic ESZ 400 or Marposs P7 ME measuring controls Preparation for external filters Cooling lubricant switch-off for table devices Full casing emulsion Emulsion sanding mist extraction system Maintenance unit for additional pneumatic functions Preparation for KEL-VITA gantry loader KEL-POS, MOVOMATIC: C25 measuring probe Hydraulic preparation for arobo bezel

Condition: ready for operation (used), Year of construction: 2012, functionality: fully functional, machine/vehicle number: GD12002, workpiece weight (max.): 150 kg, grinding length: 1,000 mm, grinding diameter: 360 mm, overall weight: 4,700 kg, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Grinding diameter max.: 360 mm Grinding length max.: 1,000 mm Workpiece weight max.: 150 kg MACHINE DETAILS Power of the main drive: 5 kW Dimensions & Weight Dimensions (L x W x H): 3,030 x 2,250 x 2,030 mm Weight: 4,700 kg EQUIPMENT PLC controlled Tailstock Work spindle Grinding spindle with flange and grinding wheel Internal grinding device Wet grinding system Electric handwheel Work light Center point Chuck Manual Lajdpsy Ukz Ujfx Ammoc

Condition: used, Year of construction: 2000, Kellenberger 600 U cylindrical grinding machine Condition: Used Year of manufacture: 2000 Technical data: Table: Distance between centers: 600 mm Travel: 900 mm Travel per handwheel revolution, coarse/fine: 20 / 2.5 mm Travel per division on the handwheel: 0.05 mm Speed, hydraulically continuously variable: 0.02 - 6 m/min Reversal travel, minimum: 2.5 mm Dwell time during reversal, continuously variable: 0 - 5 sec Swiveling range: 11 degrees Cross slide: Travel with feed handwheel in fine or coarse mode: 220 mm Travel per handwheel revolution, coarse/fine: 8 / 1 mm/ø Division on the handwheel: 5 µm/ø Division with micrometer adjustment: 1 µm/ø Rapid traverse, hydraulically: 40 mm Feed, hydraulically: 0.95 mm/ø Lajdpfsy T E Rzjx Ammsc Form grinding: Feed rate: 0.25 - 25 µm/sec Surface grinding: Feed increments per table reversal: 130 µm/ø Grinding spindle head: Grinding wheel for external cylindrical grinding: 400 x 50 x 127 mm

Condition: excellent (used), Year of construction: 1998, center height: 630 mm, workpiece weight (max.): 3,000 kg, grinding length: 4,000 mm, grinding parameters 630x4000 mm max. weight of workpiece - 3000 kg (in centers) Lsdpfx Aoy Tkgnjmmoac main motor (spindle) - 19 kW

Condition: repair required (used), Type AS - 900 Machine No. 74054 Centre distance 900 mm Centre height 150 mm Max. grinding wheel 400 x 80 x 127 mm Centre height 150 mm Centre distance 900 mm ..... Condition: The machine cannot be switched on! The following applies to this machine: Condition unknown! Scope of delivery as per attached images .... Lajdsy St Irjpfx Ammec
