Mondiale

Condition: ready for operation (used), Year of construction: 2018, functionality: fully functional, center width: 1,200 mm, overall weight: 7,000 kg, travel distance X-axis: 500 mm, travel distance Z-axis: 800 mm, controller model: Bosch Rexroth MTX, TECHNICAL DETAILS Center distance: 1,200 mm Max. outer diameter: 350 mm Max. workpiece weight between centers: 50 kg Cross slide, X-axis Travel, X-axis: 500 mm Hnedpezwm Akjfx Ac Aet Max. speed: 30 m/min Resolution: 0.1 µm Longitudinal slide, Z-axis Travel, Z-axis: 800 mm Max. speed: 30 m/min Resolution: 0.0005–0.1 mm Multi-function head, B-axis Swivel range: -45° to +225° Swivel time for 180°: < 3 s Positional accuracy: 0.0002° Repeatability: 1″ Resolution: 0.001° External machining Max. machining length: 750 mm Peripheral speed: 50 corundum / 80 CBN Drive power: 15 kW Max. grinding wheel dimensions: Ø 400 × 50 × 152.4 mm Internal machining Max. bore diameter: 250 mm Max. bore depth: 235 mm Drive power S1: 1.8–7.5 kW Speed range: 30,000–50,000 rpm Workpiece spindle, C-axis Max. speed: 1,500 rpm Drive power: 1.8 kW Drive torque: 90 Nm Resolution of measuring system: 0.001° Roundness accuracy: 0.8 µm Positional accuracy: 0.0001° Tailstock Quill stroke: 50 mm / 80 mm Quill diameter: 60 mm Bearing: hydrostatic Fine adjustment for cylindricity corrections: ± 40 µm 3-point steady rest Clamping range, diameter: 20 – 150 mm Coarse adjustment: 40 µm Fine adjustment: 2 µm Adjustability: stepless MACHINE DETAILS CNC control: Bosch Rexroth MTX Dimensions & Weight Dimensions (L x W x H): 2,850 x 2,470 x 2,290 mm Weight: 7,000 kg EQUIPMENT 3-point steady rest

Condition: reconditioned (used), KELLENBERGER UR 175 x 1500 is a Cylindrical grinder engineered for precision, high accuracy and reliability. Working capacities: centre height 175 mm, distance between centres 1500 mm; grinding diameter 340 mm, grinding length 1500 mm; wheel Ø400×50 mm, bore 127 mm; table angular displacement 10°. Main specs: wheel speeds 4 steps 1500–3600 t/min, angular displacement 270°; workpiece spindle stepless 20–400 t/min, rotatable 360°; table speed stepless up to 6 m/min; external wheel motor 4.0 CV; 50 Hz 3x380 V; weight ≈2200 kg; overall 3000×1750×1600 mm. Accessories: tailstock with fine adjustment, internal grinding attachment, measuring control, redressing device, magnetic chuck Ø230 mm, wheel with flange, lamp, steady. Enables tight tolerances, suited to applications requiring high precision. Hnodpszv I Ncjfx Ac Ajt

Condition: used, TOS BHU 50×2000 – USED UNIVERSAL CYLINDRICAL GRINDER A used TOS BHU 50 universal cylindrical grinder, center distance 2,000 mm, from a company liquidation. Inspection on-site or via video call is possible at any time. The following technical data are taken from the machine-specific TOS-BHU-50 data sheet and serve as a technical reference. Binding values for this individual machine will be determined after inspection. KEY FEATURES - Automatic program for longitudinal, transverse, and plunge grinding, external and internal - Precision standard IT class 5 - Spindles on hydrodynamic bearings with automatic bearing adjustment - Infinitely variable workpiece spindle speed, swivel headstock on both sides - Swiveling grinding wheel head Hnodpfx Acjzi Stro Ajt TECHNICAL DATA (BHU 50 SERIES) - Grinding diameter: 500 mm - Center distance: 2,000 mm - Center height: 250 mm - Grinding wheel (Ø x width x bore): 500 x 80 x 203 mm - Diameter of worn grinding wheel: 380 mm - Diameter of workpiece in open/closed steady rest: 110 mm - Diameter of chuck: 200 mm - Taper in workpiece spindle and tailstock spindle: MK 5 - Swivel range of workpiece spindle headstock: 90°, grinding wheel headstock: ±45° - Largest longitudinal travel of the table (at 2,000 mm center distance): 2,290 mm - Table speed, infinitely variable: 0.05-5 m/min - Grinding spindle speed: 1,230 / 1,470 rpm - Workpiece spindle speeds: 16 steps, range 12-400 rpm - Grinding wheel headstock motor: 7.5 kW - Total power consumption: 16 kVA - Machine weight (at 2,000 mm center distance): approx. 6,600 kg - Largest workpiece weight: 300 kg between centers, 300 kg cantilevered STANDARD EQUIPMENT (SERIES) - Grinding wheel 500 x 80 x 203 mm for 33 m/s circumferential speed, flange, and guard - Dressing and mounting device for the grinding wheel flange, balancing mandrel - 2 fixed centers MK 5, 2 open steady rests (Ø 10-110 mm) - Sedimentation coolant system, splash guard - Micrometric dressing device for the grinding wheel (tailstock) - Driver and operating key set, machine lamp, technical documentation We would be happy to clarify in advance whether the specific machine has the full range of features based on its actual equipment. CONDITION Used machine from a company liquidation. Sold "as is, where is," warranty excluded. On-site inspection or video call inspection is highly recommended; independent functional and accuracy testing is available upon request. A general overhaul is possible upon request and for an additional charge. OUR SERVICE Online or on-site factory inspection, transport can be organized upon request, installation, commissioning, and operator training by our service technicians, direct German-speaking contact person for spare parts and support, member of FDM, the German Association of Machine and Tool Wholesale. As this is an individual machine, availability is subject to prior sale. Please call or write to us briefly, and we will arrange an inspection appointment as soon as possible.

Condition: excellent (used), Year of construction: 1969, BHU 40/1500 TOS Hostivar Cylindrical Grinder Grinding diameter 400 mm Grinding length 1500 mm Maximum workpiece weight 300 kg Grinding wheel: 600 x 150 mm Longitudinal travel of the table (x-axis): 1 – 1790 mm Grinding head swivels +/- 45° Table swivels +/- 5° Spindle taper: Morse 5 Maximum rotational speed of the grinding wheel spindle: 1240 rpm / 2100 rpm Total power consumption: 22 kVA Machine weight: approx. 7000 kg Cooling system: none Accessories: none Hsdpjzg H E Rofx Ac Aent

Condition: reconditioned (used), Year of construction: 2026, SCHAUDT E450x1500 cylindrical grinding machine, following a complete overhaul and modernization to a CNC grinding machine. The machine has geometrical acceptance parameters in accordance with WOT acceptance conditions. Safe operation of the grinding machine is ensured by a semi-enclosed cabin and all electrical and mechanical safety devices in compliance with CE standards. SCHAUDT E450 x 1500 1. Nominal grinding length – 1,500 mm 2. Maximum length of workpiece clamped in centers – 1,623 mm 3. Maximum grinding length – 1,540 mm 4. Center height – 150 mm 5. Maximum weight of workpieces clamped in centers – 200 kg 6. Maximum permissible weight of workpiece clamped in a chuck – 50 kg 7. Grinding machine length – 5,600 mm 8. Grinding machine depth – 2,600 mm 9. Grinding machine height – 2,000 mm 10. Center height above the floor – 1,020 mm 11. Total weight – 5,200 kg 12. Total power consumption – 15 kVA 13. Total travel in the X-axis – 300 mm 14. Rapid traverse speed of the grinding wheel (JOG) AUTO – 750 / 1000 m/min 15. Grinding wheel spindle speed - non-adjustable – 1,430 rpm 16. Grinding wheel feed rate in the X-axis in INC mode: Min – 0.001 mm Max – 0.1 mm 17. Grinding wheel feed rate in the Z-axis in INC mode: Min – 0.001 mm Max – 0.1 mm 18. Feed rate range in plunge grinding mode – 0.06-20 mm/min 19. Total travel of the spindle base – 300 mm 20. Power of the grinding wheel drive motor – 7.5 kW 21. Grinding wheel peripheral speed – 32 m/s 22. Diameter of the new grinding wheel – 500 mm 23. Bore for mounting the grinding wheel – 203 mm 24. Maximum workpiece diameter when clamped in collets – 0.5-20 mm Hodpfxezfyw Rs Ac Asnt 25. Workpiece spindle speed range – 1-400 rpm 26. Power (torque) of the workpiece spindle drive motor – 1.9 (11) kW(Nm)

Condition: used, Year of construction: 2026, grinding diameter 350 mm grinding length 1500 mm centre height 175 mm grinding wheel diameter 400 mm grinding wheel width 50 mm bore 127 mm MK5 work piece spindle speed 20-400 U/min grinding head swivelling 360 ° grinding spindle head - swivable 180 + - ° grinding spindle speed 1500,1700,2200 U/min 0,001-0,030 mm/Ø 0-0,95 mm/Ø ± 6 ° Hnjdpfjy R Edvsx Ac Aot longitudinal feed of the table 1750 mm table speeds 0,02-6 m/min 130 kg 130 inkl. Spannugkg kg 80 mm total power requirement 6,5 kW weight of the machine ca. 2,9 t dimensions of the machine ca. 5,6 x 2,0 m Komplett überholt mit Umbau auf Technik der modernsten Ausführung. -Neuer Schaltschrank -Modernes Hydraulikaggregat -Moderner Werkstückspindelstock -Moderner Reitstock mit Feinverstellung -Moderner Steuerblock,Zustellung,Getriebekasten -Innenschleifvorrichtung für Spindeln mit 80mm Durchmesser -Schwenkwinkelanzeige Schleifspindelstock -Schleifwinkelanzeige Obertisch -Luftabhebung Obertisch -Reitstock mit Feinverstellung -Sinuslineal -stufenlos regelbare Schleifspindeldrehzahl 70-100% -stufenlos regelbare Innenschleifspindeldrehzahl 70-100% -Auf Wunsch Umbau auf separaten Innenschleifspindelantrieb mit Kühlung und regelbarer Innenschleifspindeldrehzahl 0-100% -Spritzschutztüren z-Achse Optionen: Schwenkwinkelanzeige Werkstückspindelstock Schwenkwinkelanzeige Schleifspindelstock Schwenkwinkelanzeige Obertisch Teilraumverkleidung in X sowie Sonderwünsche

Condition: good (used), Year of construction: 2009, functionality: fully functional, Travel distances Max. grinding diameter: 500 mm Max. grinding length: 2000 mm Hedpfx Acey Idtqs Aont Max. workpiece weight: 500 kg between centers Swiveling of grinding head: +45 / -15° (manual) Grinding wheel: 500/80/203 mm Accessories: - Steady rest - Enclosure A video of the machine under power can be provided upon request.

Condition: used, Year of construction: 2000, grinding diameter 300 mm grinding length 1200 mm workpiece turning speeds 6000 U/min max. workpiece weight 70 kg control FANUC Hedpfx Aey Dibxjc Aont peripheral speed 140 m/sec grinding wheel size CBN 400 x 5 mm Spindle power 24 kW weight of the machine ca. 11 t Quickpoint 5002/10 CNC external cylindrical grinding machine, built in 2000 - Regular maintenance carried out - Documentation available Special accessories: - Junker novotecnic cooling lubricant system - 2x LTA II R/H extraction systems - Hyfra recooler - 4 grinding wheel blanks - Oil pan with grating *Disclaimer: All information is non-binding and may be incomplete or inaccurate. Subject to change without notice. No liability is accepted for the accuracy or completeness of the information provided. The disclosure or transfer of the data provided by us is not permitted without our express written consent. Translated with (free version)

Condition: used, KELLENBERGER KEL-VARIA R175 x 1500 is a CNC cylindrical grinder engineered for high precision, top accuracy and reliable production. Capacities: centre height 175 mm, distance between centres 1500 mm, Z-axis 1650 mm, workpiece weight on centres max. 150 kg; grinding wheel Ø500×80 mm (bore 203 mm) or Ø400×63 mm (bore 127 mm); max wheel travel 320 mm. Key specs: wheel speeds stepless 1000–2150 rpm (peripheral speed 45 m/s); feed 7500 mm/min; work spindle swivels -10/+100° with 8–800 rpm; permitted load 160 Nm; grinding spindle motor 7.5 kW; work spindle motor 2 kW; 3×400 V 50 Hz; rapid 15 m/min; approx. weight 6000 kg; dimensions 4700×2300×2000 mm; air 6 bar. Accessories: coolant system, paper filtration, MARPOSS touch probe, set of grinding wheels, rotary centre, set of centers, set of workpiece drivers, set of throat gauges, lamp, 2 tool cabinets, tailstock with fine adjustment, oil mist extractor, spindle nose for collets. Achieves tight tolerances; typical applications: automotive, watchmaking, machine tool Hjdpfxeyxn Ite Ac Aont

Condition: used, KELLENBERGER KEL‑VARIA R175 x 1500 is a CNC cylindrical grinder engineered for precision, high accuracy and reliable operation. Capacity: centre height 175 mm, distance between centres 1500 mm, Z 1650 mm, max 150 kg; wheels Ø500×80 mm (Ø400×63 mm option). Specs: wheel speeds 1000–2150 rpm, peripheral 45 m/s, max travel 320 mm, feed 7500 mm/min, motors 7.5/2 kW, rapid 15 m/min, 3×400 V, weight ≈6000 kg, dims 4700×2300×2000 mm. Equipment: paper/coolant filtration, MOVOMATIC, Renishaw LP2H probe, wheel flange extractor, remote hand control, MPM balancing. Achieves tight tolerances; suited to automotive, watchmaking, machine tools, aerospace and medical. Hodeyxn A Repfx Ac Aent

Condition: ready for operation (used), Year of construction: 1995, functionality: fully functional, machine/vehicle number: 630005, center height: 305 mm, center width: 1,000 mm, travel distance X-axis: 350 mm, travel distance Z-axis: 1,160 mm, controller model: KELCO 90, TECHNICAL DETAILS Centre height: 225 mm / 305 mm Centre distance: 1,000 mm Travel Z-axis: 1,160 mm Travel X-axis: 350 mm Hodpfxsyhnrvj Ac Asnt Max. workpiece weight: 200 kg Workpiece diameter: 449 mm Left grinding wheel diameter: 500 mm Left grinding wheel width: 80 mm Left grinding wheel bore: 203 mm Right grinding wheel diameter: 400 mm Right grinding wheel width: 40 mm Right grinding wheel bore: 127 mm B-axis swiveling range: +30° / -190° Max. grinding wheel speed: 1,720 rpm Peripheral speed: 45 m/s Workpiece spindle speeds from: 5 rpm Workpiece spindle speeds up to: 500 rpm Spindle taper: Morse taper 5 (MT 5) Tailstock quill taper: 4 Morse (MT 4) Tailstock quill stroke: 50 mm Feed rate X-axis: 8 m/min Feed rate Z-axis: 16 m/min Max. table tilt: -1° / +11° MACHINE DETAILS Control: KELCO 90 Total power requirement: 25 kW Connection: 50 Hz, 3x 380 Volt Dimensions & Weight Machine dimensions (L x W x H): 2,850 x 2,200 x 2,100 mm Control cabinet dimensions (L x W x H): 550 x 450 x 900 mm Machine weight: approx. 6,000 kg EQUIPMENT 80 mm riser block Coolant system Automatic tool measurement KELSET Wheel dressing device Internal grinding device (without spindle) Set of flanges Set of grinding wheels Balancing arbor Lamp Magnetic chuck diameter (2x): 300 mm / 500 mm Electronic hand-held control panel

Condition: good (used), Year of construction: 1990, Ref. -No.: 10301 Manufacturer: TITAN Type: RU 350 x 1-1500 Year of construction: 1990 Type of control: Konventionell Storage location: Halberstadt Country of origin: USA Max. Grinding length: 1.500 mm Max. Workpiece Weight: 300 kg Grinding Diameter: 350 mm Max. Dia. Of Grinding Wheel: 280-500 mm Hsdpfx Acoycpv So Ajnt Grinding Wheel Width: 80-100 mm

Condition: refurbished (used), Year of construction: 2025, functionality: fully functional, machine/vehicle number: 1845/455, Completely refurbished: Mechanics, geometry, hydraulics, and electrical components Wheelhead Disassembly, cleaning of parts, replacement of worn and defective components, motor overhaul, replacement of bearings, replacement of belts, spindle disassembly, replacement of seals and O-rings, plus adjustment. New paintwork. Workhead Disassembly, cleaning of parts, replacement of worn and defective components, motor replacement, replacement of belts. New spindle bearings. New paintwork. Tailstock Disassembly, cleaning of parts, replacement of worn and defective components, motor replacement, replacement of belts. New spindle bearings. New paintwork. Internal grinding attachment Disassembly, cleaning of parts, replacement of worn and defective components, installation of the support and geometry alignment. New paintwork. Hydraulics Disassembly, motor replacement, hose replacement, defective and worn parts replaced. Hydraulic block checked. X-Axis Disassembly, replacement of worn items such as O-rings, seals, rings, etc., overhaul of hydraulic piston, regrinding of tables. Z-Axis Disassembly, regrinding of tables, replacement of worn and defective parts, overhaul of hydraulic piston, scraping of V and flat guides. New paintwork. Hnodpfxjxt Ilfe Ac Ajt Measuring system Digital 2-axis display included. Electrical cabinet Replacement of motor contactors and relay controls. New wiring. New variable speed drive (frequency inverter) for the workhead. TECHNICAL SPECIFICATIONS Distance between centers: 1500 mm Distance between centers (workhead to tailstock overhang): 1650 mm Center height, standard: 125 mm Center height with riser blocks: 225/250 mm Maximum grinding diameter: Ø 250 mm Maximum grinding diameter with riser blocks: 450/500 mm Table Usable surface: 2060 x 140 mm Max. length and width for surface grinding: 1750 x 200 mm Longitudinal travel, manual or hydraulic: 1750 mm Manual table movement, 1 handwheel revolution – coarse: 20.006 mm Manual table movement, 1 handwheel revolution – fine: 2.457 mm Table speed, continuously via hydraulics: up to 6 m/min Table swivelling: 6° Stop and return: 0–5 sec. Workspindle Workpiece speeds, continuously variable (electric): 20–400 rpm Swivelling: 360° Workspindle taper (internal): MT5 Tailstock Internal taper, tailstock spindle: MT3 Spindle retraction, manual or hydraulic: 30 mm Diamond dresser taper (internal): MT0 Universal grinding head Cross slide travel for wheel: 285 mm Rapid traverse for wheel slide, front and rear: 40 mm Grinding spindle speeds: 1500 – 1700 – 2200 – 3600 rpm Vertical grinding spindle movement, center heights: 125–330 mm Max. wheel for cylindrical grinding: 400 x 50 x 127 mm Max. wheel for surface grinding: 250 x 20 x 76 mm Head swivelling with locking at every 90°: 270° Wheel feed 1 division of the micrometer drum: 0.005 mm/Ø Automatic wheel feed, max.: 0.9 mm/Ø Motors Grinding spindle motor: 2,900 rpm / 4.0 hp Workspindle motor: 3,000 rpm / 2.0 hp Coolant pump motor: 2,850 rpm / 0.12 hp Internal grinding attachment Bore: 70 mm Internal grinding spindle speed Ø70 mm: 14,000 rpm Internal grinding spindle speed Ø50 mm: 21,000 rpm Subject to error or omission, the technical information is provided without obligation.

Condition: refurbished (used), Year of construction: 2025, functionality: fully functional, machine/vehicle number: 510-1986, CYLINDRICAL GRINDER JOTES SCHAUDT A440X1500 Specifications Maximum longitudinal travel: 1500 mm Grinding diameter: 298 mm External grinding: Yes Internal grinding: Yes Dimensions (L x W x H): 5400 × 2400 × 1600 mm Weight: 4800 kg Operating hours: — Power-on hours: — Condition: Rebuilt Compliant with local standards: — Status: Under power Technical features - Grinding length [mm]: 1500 Hnsdpfjw T Ti Dsx Ac Ast - Grinding diameter [mm]: 300 - Manual table displacement [mm/rev]: 10 - Table speed range [mm/s]: 0.01–5 - Smallest table stroke [mm]: 3 - Wheelhead swivel [°]: ±90 - Centre sleeve taper [Morse No.]: 4 - Grinding wheel dimensions [mm]: 500 x 63 x 203 - Spindle speed [rpm]: 32–500 - Grinding wheel drive motor power [kW]: 5.5 - Workpiece drive motor power [kW]: 0.75 - Hydraulic pump motor power [kW]: 1.5 - Grinding attachment drive motor power [kW]: 0.75 - Machine dimensions [mm]: L=5400 / W=2400 / H=1580 / Machine weight [kg]: 4800

Condition: used, functionality: unexamined, Danobat Universal Grinder model 1200 RP with automatic diamond dressing device, capable of working in automatic cycle, maximum grinding diameter 270mm, maximum wheel diameter 400mm, maximum wheel width 60mm, head power 12 HP. Hnedpfx Acew Iv Huo Ajt

Condition: like new (used), Year of construction: 2024, functionality: fully functional, grinding length: 1,650 mm, grinding diameter: 400 mm, We offer a new BUB40 x 1500 NC machine equipped with a MITSHUBISHI NC controller. The machine is still under lease with ING Lease. It has been thoroughly refurbished based on the TOS HOSTIVAR BUB 40 model by FAS GŁOWNO. Technical data: • Maximum workpiece diameter: 400mm • Maximum workpiece length: 1500mm • Centre height: 200mm • Distance between centres: 1500mm • Minimum grindable workpiece diameter with a 380 mm grinding wheel: 20mm • Tailstock quill stroke: 40mm • Maximum tailstock clamping force: 4000N • Spindle headstock centre taper: ISO 296-1991/Morse 5 • Tailstock centre taper: ISO 296-1991/Morse 5 • Maximum workpiece weight between centres: 500kg • Maximum workpiece weight in chuck (including chuck): 100kg • Machine width (with enclosure): 6650mm • Machine depth (with enclosure, without control panel): 2400mm • Machine height (with enclosure): 1850mm • Machine weight: 7000kg • Total power requirement: 38kVA Grinding spindle: • Standard grinding wheel dimensions: 500 x 80 x 203.2mm • Grinding spindle drive motor power: 11kW • Grinding spindle rated speeds (for 430 mm / for >430 mm and 500 mm wheels): 2000 / 1744 rpm • Grinding headstock traverse servo motor power: 2kW • Grinding headstock traverse servo motor torque: 9.5Nm • Maximum continuous X-axis traverse speed: 2m/min • Minimum X-axis grinding wheel increment: 0.001mm • Maximum continuous X-axis traverse speed: 6m/min • Minimum X-axis grinding wheel increment: 0.001mm • Maximum grinding wheel increment in INC mode: 0.1 mm • Table traverse servo motor power: 3.5 kW • Table traverse servo motor torque: 16.7 Nm Hnsdpfjwzkywox Ac Ajt Workpiece spindle: • Workpiece spindle speed range: 1 – 150 rpm • Workpiece spindle servo motor power: 3.5kW • Workpiece spindle servo motor torque: 16.7Nm More information available upon request via email or phone.

Condition: used, Year of construction: 2017, grinding length 1000 mm centre height 180 mm length 3600 mm width 1650 mm Hnedpfx Acowp Tums Aet height 1800 mm weight of the machine ca. 3,7 t

Condition: used, Year of construction: 2017, grinding length 1500 mm centre height 180 mm weight of the machine ca. 3,9 t dimensions of the machine ca. L: 4900 x 1650x 1800 m Hnjdpfx Aewm Rqgec Aet

Condition: used, functionality: fully functional, Maximum workpiece length: 500 mm Minimum workpiece length approx.: 5 mm Maximum workpiece length for plunge grinding: 50 mm Hnodpfjwhp D Ujx Ac Aot Max. grinding diameter without steady rests: 100 mm Max. diameter: 240 mm Workpiece Swivel: 90° Grinding spindle slide Min./max. swivel: 30° Min./max. transverse movement including 300 mm quick adjustment: 100 mm Wheel diameter after rotation 1st degree: 320 - 400 mm 2nd degree: 260 - 320 mm Max. workpiece weight between centers: 60 kg Max. workpiece weight in chuck: 20 kg Max. workpiece weight in faceplate: 20 kg 8 workpiece spindle speeds: 45 - 500 rpm Min./max. Tilt: 12° Min./max. longitudinal travel: 2 - 500 mm Infinitely variable table travel: 0.5 - 5 m/min Handwheel adjustment: 2 and 20/rev

Condition: as good as new (ex-display), Year of construction: 2025, functionality: fully functional, Demonstration machine BUB 50/3000 CNC Control system: Siemens One Digital axis drives Includes extensive application software Includes electronic handwheel for X/Z axis Center height: 400 mm Distance between centers: 3000 mm Weight between centers: 500 kg Z-axis travel: 3250 mm Positioning accuracy X-axis: 0.001 mm Tool holder for workpiece spindle: MK 5 Tool holder for tailstock: MK5 Hsdjv N D Hbepfx Ac Aont Drive power: - Grinding spindle: 11 kW - Workpiece spindle: 2.5 kW - Total installed: 22 kW Machine design with full enclosure Preparation for dust extraction system included Separate screen, touch probe control, automatic balancing and gap/crash control included. 1 grinding wheel: 508 x 80 x 203.2 mm Immediately available. Optional filter system available in various designs.

Condition: reconditioned (used), Year of construction: 2024, functionality: fully functional, grinding wheel diameter: 500 mm, total width: 2,300 mm, total length: 6,730 mm, total height: 1,800 mm, grinding diameter: 320 mm, workpiece weight between centers: 250 g, grinding wheel width: 80 mm, spindle speed (max.): 1,800 rpm, feed length X-axis: 350 mm, feed length Z-axis: 1,550 mm, Good morning, We have to offer a six months old CNC SWG32 x 1500 CNC machine with SIEMENS SINUMERIC 828D sL control (after a complete revitalization of TOS HOSTIVAR BUB32 machine) The machine is still in Lease at ING Lease. The machine has already been partially repaid, our company does not want to recover the repaid installments. The assignment of the lease applies only to the remaining installments to be repaid (the cost of the assignment is borne by our company). For more technical and financial details, I invite you to contact me at the e-mail address or by phone Hnjdpfx Acevkc D Is Ajt Specification of the machine: - Year of manufacture:2024 - Maximum grinding diameter: 320 - Maximum grinding length: 1500 - Supply voltage: 3 x 400V - Control voltage: 24V - DC - Metric system - Maximum permissible weight of objects clamped in the canine: 250 kg - Total travel distance in the X axis: 350mm - Rotation of the grinding wheel spindle: 50 - 1500 rpm (7.5kW) - Plunge grinding infeed speed range 0.03 to 20mm/min - Wheel diameter: 500mm - Morse taper 5 - Measuring probe to determine the workpiece - Workpiece support - Electronic wheel (handheld panel)

Condition: used, Year of construction: 1994, Technical details: grinding diameter: 300 mm grinding length: 600 mm centre height: 190 mm z-axis: 865 mm x-axis: 250 mm clamping length: 1000 mm peripheral speed: 45 m/sec grinding slide swivable +/-: 8 ° grinding wheel width x diameter: 80 x 508 mm work piece spindle speed: 1 - 800 U/min weight of the machine ca.: 5 t Machine with SIemens 840 C control - coolant device Hedpovgbzdsfx Ac Ajnt - Marposs measuring device *

Condition: reconditioned (used), Year of construction: 2024, functionality: fully functional, grinding length: 1,500 mm, grinding diameter: 400 mm, Technical data - grinding length [mm] - 1500 - grinding diameter [mm] - 400 - range of table speed [mm/min] - 0 - 10 - smallest table travel [mm] - 0,001 - taper in tailstock sleeve {Morse no.] - 5 - grinding wheel dimensions [mm] - 500x80x203 - power of grinding wheel drive motor [kW] - 11 - power of grinding wheel drive motor [kW] - 3,5 Hnsdpfx Ajvga Ayoc Ajt - overall dimensions [mm]: length - 6650 width - 2300 (without desktop) height - 1800 - weight of machine tool [kG] - 6900 - central lubrication system; - Mitsubishi control system; - movement of the grinding wheel headstock - application of ball screw and servo motor; - table travel - use of ball screw and servo motor; - headstock of the workpiece - use of a new motor along with stepless speed control controlled from the operator panel; - "electronic wheel" for precise raids in both servo X and Z axes, e.g., for set-up work; We also make machines with Siemens 828D or 840Dsl control. It is possible to make machines up to a grinding length of 2000 / 2500 / 3000 mm.

Condition: used, Year of construction: 2002, grinding diameter 450 mm grinding length 1500 mm centre height 225 mm Control FAGOR EQUIPEMENT - T1: grinding wheel diameter 500 mm - T2: grinding wheel diameter 400 mm - T6: HF Fischer spindle MFV or MFZ 1224/1242/1260 - T7: HF Fischer spindle MFV or MFZ 1224/1242/1260 - Marposs tool measurement - active longitudinal positioning - Elaso GAP-control on T1 and T2 contactless integrated in the control surface - Elaso GAP internal grinding with fluid sensor for T6 and T7 - semi-automatic balancing by Elaso integrated in the control surface for T1/T2 - tailstock hydraulic with fine adjustment +/- 150 microns - dresser on workpiece spindle side table mounted - dresser on tailstock side table mounted - dresser on upper table - new service- and userfriendly housing SPECIAL EQUPEMENT: Workhead with direct drive - strongly recommended for non-circular grinding - workpiece weight flying max. 75kg - workpiece weight between centres 150kg Hodpfxsuxfu No Ac Asnt - water-cooled B-axis with direct drive - center height 225 mm - extremely torsionally stiff - highly accurate positioning - resolution ° - water-cooled Hydrostatic ball screw - x-axis - wear-free, as there is no contact during operation - no loss of precision, even during long-term use at full load and maximum speed - no friction at low speeds - no friction force backlash when the direction of rotation changes - translates even the smallest rotational movements - no stick-slip effect even at low speeds - no fluctuations in frictional torque due to ball circulation - higher axial stiffness compared to ball screws - significant improvement in damping, resulting in better workpiece surface finish and tool life - no oscillations due to ball circulation - also suitable for high speeds and accelerations - cost-effective alternative to the linear motor with greater precision and significantly lower heat generation - significantly less power dissipation and, as a result, no problems with swarf on permanent magnets New hydraulic unit - optimized temperature control (chiller) - Energy-saving Only one pump controlled by VFD - Pressure monitoring - monitoring of the hydrostatic oil for water content. (Damage to the bellows is recognised and detected prematurely) -fine adjustment +/- 150 microns Paper belt filter 375l – alternative 480l Grinding mist extraction system – emulsion MECHANICAL OVERHAUL -complete machine according to Kellenberger protocoll -new painting ELECTRICAL OVERHAUL - new modern Fagor CNC with BEMA HMI - new electric cabinet - new digital drive technology - replacement of all electrical cables, switches etc. - new absolute external scales in x- and z-axis - new absolute encoder (B-axis) Grinding software BEMA-Standard: - workpiece zeroing - grinding wheel zeroing - dressing diamond measuring - corrections - external and internal surface grinding - external and internal angle grinding (turning of the b-axis, dressing with straight wheel) - external and internal radius grinding (radius dressed on wheel) - semi-automatic traverse grinding - workpiece zeroing - 2 dressing diamonds - 1 dressing blade - dressing roll - 3 flat dresser - corrections - Z-position measurement - GAP control Optional grinding cycles at no extra charge: Profile plunge grinding: - external and internal profile plunge grinding with profile wheel Pr...

Condition: used, grinding diameter 350 mm grinding length 1500 mm centre height 175 mm grinding wheel diameter 400 mm grinding wheel width 50 mm bore 127 mm MK5 work piece spindle speed 20-400 U/min grinding head swivelling 360 ° grinding spindle head - swivable 180 + - ° grinding spindle speed 1500,1700,2200 U/min 0-40 mm/Ø 0-40 mm/Ø ±6,5 ° longitudinal feed of the table 1530 mm Hnjdpfx Acsuxftrs Ast table speeds 0,02-6 m/min 130 kg 130 inkl. Spannung kg cross travel max. 270 mm 80 mm tailstock quill taper MT 3 quill travel 30 mm total power requirement 6,5 kW weight of the machine ca. 3,05 t dimensions of the machine ca. 4 x 2 m Overhauled according to Kellenberger guidelines including new, modern and future-proof control system. Photo of machine already delivered with special options -Operation via the touch panel is extremely simple. -The symbols on the control panel are practically identical to the original original control system, so there is no need for familiarisation. -Diagnostic function with display of PLC messages and digital I/O -Dressing function can be extended or changed at the customer's request. -Orientated spindle stop of the workpiece spindle possible on request. -New maximum infeed of 40 mm can be extended on request. -Digital display in 2 axes. Resolution x-axis 0.5my Options: -Encoder with digital display in the workpiece headstock -Rotary encoder with digital display in the grinding headstock (no height adjustment with spindle possible) with spindle possible) -New stable internal grinding device diameter 80mm or 100mm with height adjustment. -Increase of the centre height to max. 225mm -Speed control for the grinding spindle Included: -Operating tool -Clamping tube for chuck Further accessories on request. The x-axis of the machine has an electronically controlled infeed system with stepper motor drive. Hydraulic longitudinal and rapid traverse table movement. Versatile application in production for external cylindrical and internal internal grinding or for external, face and internal grinding in one clamping clamping of individual parts. Possible options: -Semi-automatic dressing cycles for external and internal grinding -automatic dressing compensation. -Measuring control
