MW-Machines Martin Wögerbauer

Condition: used, functionality: fully functional, Used Schenck Balancing Machine HU 9 T with used CAB 690 H measuring unit. The machine comes with original foundation drawings, documentation and manuals. The machine can be test run in Kerava. Technical data: - Maximum rotor weight with roller bearings: 50 000 kg - Maximum weight for symmetrical rotor: 56 000 kg - Load capacity per bearing pedestal: 28 000 kg - Load capacity per T-slot pedestal: 28 000 kg - Minimum rotor weight: 2 500 kg (1000 kg) - Maximum diameter over machine base: 4 000 mm - Machine bed length: 15 000 mm - Adjustable roller bearing diameters: 125–270 mm , 450–900 mm - ABB electrical drive FC: 90 kW - 4-speed gearbox: approx.120–1400 rpm - Pneumatic locking for end drive - Electrically operated movable pedestals - Accuracy: Umar 0,5gmm /kg 270 rpm 1000 gmm Itsdpfx Adjw Aaugs Dsp

Condition: new, workpiece weight (max.): 10,000 kg, rotor diameter: 2,500 mm, Horizontal soft-bearing Balancing machines 9K719 with load capacity from 100 to 10000 kg are designed for high-precision balancing of rotors of electric motors, pumps, compressors, blowers and exhausters, gearboxes, turbines of power engineering. Self-aligning rollers ensure proper rotor alignment, simplifying setup and reducing balancing time. Combined Drive System has a unique configuration with two axial drives and a belt drive mounted on a single bed. Overall, this machine is highly versatile and effective in balancing various types of rotors, making it ideal for repair and production shops. HIGHLIGHTS • Soft-Bearing System: This system ensures linear sensitivity across the entire speed range during balancing. The result is exceptionally high balancing accuracy, achieving up to 0.04 g·mm/kg across all rotor mass ranges. • Self-Aligning Roller Cassette automatically adjusts to the rotor along two axes, eliminating the need for precise centering. This design reduces machine setup time and, consequently, the overall time required for balancing. • Wide Contact Area Rollers: The cylindrical rollers provide a broad contact surface, preventing scoring or deformation of the rotor's support surfaces. This is crucial when balancing heavy rotors for extended periods, minimizing the risk of damage due to prolonged contact or improper loading. • Combined Drive System: Rotors of relatively low mass can be driven by “belt drive”, which makes the machine more versatile and allows balancing a very wide range of parts. Heavy rotors are rotated by "axial drive" using a cardan shaft. • Rotor Jacks: Specialized loading devices can be integrated to ensure smooth and precise rotor placement onto the roller supports. This minimizes the risk of damage to the delicate roller assembly, particularly when handling heavy or sensitive rotors. Itodpswdgptefx Ad Dsp • High balancing accuracy due to automatic calibration of the balancing machine directly for each rotor by determining the influence coefficients. Its ease of use, high measurement accuracy, and integrated specialized features enable balancing professionals to achieve outstanding results in the shortest possible time. • The frequency converter drive provides smooth acceleration and deceleration of the electric motor and infinitely variable speed control of the rotor. • No need for special foundations and vibration isolation, no need to fix the machine to the floor. SPECIFICATIONS Weight range of balanced rotors 100 - 10'000 kg Maximum rotor diameter (above the bedding) 2500 mm Distance between centres of rotor supports 400 – 5600 mm Support type Rollers Transmission element for rotor rotation Belt / Cardan Minimum achievable residual specific unbalance 0.4 g*mm/kg Rotor speed range 300 – 1000 rpm Electric motor power 30 kW Parameters of the supply network 380V, 3 Ph, 50Hz Do you need a machine for a different load capacity, diameter or length? We manufacture balancing machines for every needs. Please contact us to get the best offer! 👇

Condition: new, total length: 6,000 mm, rotor diameter: 500 mm, The 97VK1000 balancing machine is a high-tech equipment designed for service and repair companies specializing in the maintenance of industrial drive shafts weighing up to 1000 kg. Iedewc T Utspfx Ad Detp It provides accurate and efficient balancing of cardan shafts, reducing repair time and ensuring high productivity of work processes. The 97VK1000 balancing machine is the perfect combination of high technology, reliability and versatility, making it an essential tool for engineers and technicians involved in the maintenance and repair of industrial cardan shafts. HIGHLIGHTS 1. Hard-Bearing Design: Designed with high precision and reliability in mind, the 97VK1000 balancing machine features a hard-bearing design to balance shafts with large initial imbalances. 2. Universal Design and Equipment: The 97VK1000 is equipped with universal equipment to balance shafts with flanges of various shapes and sizes. Special plates and adapters allow cardan lengths up to 6000 mm and flange diameters up to 500 mm. 3. Fast and Efficient Balancing Process: Thanks to the short unbalance measurement cycle, the 97VK1000 provides fast and accurate adjustment, which reduces repair time and increases the productivity of service and maintenance operations. 4. Safety and Ease of Operation: Screw jacks provide comfort and safety when working on the machine, the asynchronous variable frequency drive allows infinitely variable speed control without stopping the motor, providing optimal modes for balancing. MEASUREMENT AND CONTROL • We make balancing easier - the main advantage of our balancing systems. • The balancing process is displayed in real time and the unbalance behaviour of the rotor is monitored on the screen to achieve the best possible result. • The maximum sensitivity of the machine at any moment of operation, the set-up and calibration of the machine is carried out by the operator himself. • Free from the influence of external vibration factors on the measurement result, it has a high degree of protection against various types of interference. • Easy to learn working skills and maintenance for any employee. SPECIFICATIONS Weight range of balanced shafts 50 - 1000 kg Maximum tube diameter 300 mm Maximum flange diameter 500 mm Maximum drive shaft length 6000 mm Minimum achievable residual specific unbalance 10 g*mm/kg Rotor rotation speed 300 – 1000 rpm Electric motor power 11 kW Parameters of the supply network 380V, 3 Ph, 50Hz Do you repair industrial drive shafts? Then we can additionally offer an Assembly-Welding Workbench for heavy shafts. Please contact us to get the best offer! 👇

Condition: used, workpiece weight 100 kg workpiece length 1000 mm diameter 500 mm centre height 280 mm total power requirement 2,5 kW Itedov Nq Swopfx Ad Dop weight of the machine ca. 1 t dimensions of the machine ca. 1,6x 1x1,6 m

Condition: new, workpiece weight (max.): 10 kg, rotor diameter: 250 mm, High-Precision Vertical Balancing Machine for Disk-Type Rotors up to 10kg Itjdpfxeu U Nqde Ad Dsp The 97V10 is a versatile vertical balancing machine designed to efficiently balance disk-type rotors without their own bearing surfaces. Ideal for serial, small-scale, and single-piece production, it ensures optimal performance and reliability of your products. HIGHLIGHTS • High Accuracy: Delivers precise unbalance measurement with an accuracy of at least 4 g∙mm/kg. • Versatile Design: Accommodates a wide range of disk-type rotors, including: - Discs of various designs - Pulleys and flywheels - Fan impellers - Brake discs and drums - Couplings - Pump impellers - Cutting tools • Efficient Operation: - Vertical axis of rotation for quick part replacement and easy access. - Semi-automatic mode for streamlined operation. - Protective covers and compliance with CE and ISO safety standards. • Flexible Configuration: - Customizable with drilling or milling modules for in-situ unbalance correction. - Available with various spindle fits (cylindrical or tapered) and mandrels. - Options for pneumatic or manual collet chucks and hydraulic jacks for heavy workpieces. SPECIFICATIONS Weight range of balanced rotors 0.1 - 10 kg Maximum rotor diameter 250 mm Maximum rotor height 150 mm Minimum achievable residual specific unbalance 4 g*mm/kg Number of measurable rotor correction planes 1 & 2 Rotor speed range 300 – 1500 rpm Electric motor power 1.0 kW Parameters of the supply network 380V, 3 Ph, 50Hz For more information and to discuss your specific balancing needs, please contact our sales team. We manufacture balancing machines for every needs. Please contact us to get the best offer! 👇

Condition: new, workpiece weight (max.): 3 kg, rotor diameter: 400 mm, rotor length: 300 mm, High-Precision Rotor Balancing for Small Batch Production. The 9A710 balancing machine excels at balancing various rotor designs up to 3 kg. Its exceptional accuracy and high sensitivity allow you to detect and correct even the slightest imbalances. This makes it ideal for single-piece and small-batch production, ensuring smooth operation of your rotors. Key benefits: • High precision: Detects minute imbalances for optimal performance.   • Wide application: Handles diverse rotor designs within the weight limit.   • Simple & reliable: User-friendly design ensures long-term operation. • Increased productivity: Streamlines balancing processes in small-scale settings. Originally designed for small-batch production, the 9A710's versatility makes it a valuable asset in repair shops as well. Iedpju Urwgsfx Ad Dstp This machine is perfect for balancing: • Small motors & generators • Shafts for various mechanisms • Impeller fans & pumps • Precision machine tool components • Rotating drive elements ! Upgrade your balancing capabilities and achieve exceptional results with the 9A710. SPECIFICATIONS Weight range of balanced rotors 0.03 - 3 (5) kg Maximum rotor diameter (above the bedding) 400 mm Distance between centres of rotor supports 4 – 300 mm Support type Prisms Transmission element for rotor rotation Belt Minimum achievable residual specific unbalance 0.1 g*mm/kg Rotor speed range 600 – 3000 rpm Electric motor power 0.09 kW Parameters of the supply network 220V, 3 Ph, 50Hz Do you need a machine for a different load capacity, diameter or length? We manufacture balancing machines for every needs. Please contact us to get the best offer! 👇

Condition: new, workpiece weight (max.): 30 kg, rotor diameter: 700 mm, The BALANCING MACHINE 9A713 is a universal horizontal-axis balancing machine designed for light rotors up to 30 kg in various configurations. This series incorporates innovative technical solutions, ensuring that balancing is straightforward and accessible. With high performance and functionality, the 9A713 is popular in manufacturing across multiple industries. Originally designed for small series and individual production, its versatility and productivity have also made it a favorite in various repair shops. HIGHLIGHTS • High balancing accuracy 0,4 gmm/kg = 0,4 µm • Advanced Rollers: Specially designed rollers with advanced grinding technology mounted on precision bearings. • Bearing Design Options: Hard-bearing design suitable for small rotors, with optional soft bearing support available. • Belt Drive System: High degree of belt tensioning repeatability with a micro-tuning function for precise belt tension adjustment. • Quick Changeovers: Easy access to support rollers for quick rotor reinstallation and rapid replacement of roller units with prism units, significantly reducing changeover time. • Versatile Rotor Balancing: Capable of balancing rotors with small distances between bearing journals, limited only by the drive belt width. • Variable Speed Control: Frequency inverter asynchronous electric drive with a powerful motor for infinitely variable speed control and smooth acceleration/deceleration. • Height-Adjustable Supports: Adjustable supports to accommodate different bearing journal diameters, aiding in centering the workpiece. • Easy Installation: Requires no special foundation and can be installed on a standard concrete floor. MEASUREMENT AND CONTROL • We make balancing easier - the main advantage of our balancing systems. • The balancing process is displayed in real time and the unbalance behaviour of the rotor is monitored on the screen to achieve the best possible result. • The maximum sensitivity of the machine at any moment of operation, the set-up and calibration of the machine is carried out by the operator himself. • Free from the influence of external vibration factors on the measurement result, it has a high degree of protection against various types of interference. • Easy to learn working skills and maintenance for any employee. Itjdpfx Astu Ukaod Dsp SPECIFICATIONS Weight range of balanced rotors 0.3 - 30 kg (60 kg) Maximum rotor diameter (above the bedding) 700 mm Distance between centres of rotor supports 10 – 700 mm Support type Rollers + Prisms Transmission element for rotor rotation Belt Minimum achievable residual specific unbalance 0.4 g*mm/kg Rotor speed range 300 – 2000 rpm Electric motor power 0.75 kW Parameters of the supply network 380V, 3 Ph, 50Hz Do you need a machine for a different load capacity, diameter or length? We manufacture balancing machines for every needs. Please contact us to get the best offer! 👇

Condition: new, Year of construction: 2025, Technical Specifications Max Weight 3000 kg Itedpfor Dd Avjx Ad Dop

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, workpiece weight (max.): 30 kg, input voltage: 400 V, rotor diameter: 600 mm, year of last overhaul: 2023, power: 1.1 kW (1.50 HP), Balancing machine upgraded in 2009. 1 Machine base, welded construction 1 Balancing unit Vertical, single plane, permanently calibrated, 1 special spindle with centric flange 1 piezo-electric vibration sensor 1 3-phase drive motor of 1.5 kW, driven by a belt 1 Protractor disk 300 mm diameter, with 360 °, mounted on the spindle 1 Safety guard For diameters up to 600 mm and heights of 420 mm 1 SCHENCK CAB 803 measuring device - With direct data entry system via touch screen Ijdpfoq Umcrex Ad Dotp - Industrial PC with active TFT color monitor - Visualization of results via vector meters - Network capability - Polish dialogue - Modular, easy-to-use system design - Optimized signal processing system via digital Schenck MMD filter - Intelligent, self-diagnosing measurement electronics system - Operation using standard Windows routines - Programs for: - Straight compensation, keyway, compensation index - Tolerance calculation according to ISO 1940 - Log report in PDF format Balancing speeds from 0 to 720 RPM - Smooth Max residual unbalance 5 - 10 gmm (DIN 1319)

Condition: new, Year of construction: 2025, or Weight ----- 20 kg Isdpfx Adjq T Riwj Dstp or Weight ----- 500 g or Diameter ----- 450 mm ft Diameter ----- 5 mm ft Diameter ----- 50 mm Motor power ----- 750 W Bed Length ----- 600 mm Drive Unit ----- Belt

Condition: new, Year of construction: 2025, or Weight ----- 1000 kg or Weight ----- 10 kg or Diameter ----- 1400 mm ft Diameter ----- 10 mm ft Diameter ----- 240 mm Bed Length ----- 3000 mm Iodpfeq T Ikljx Ad Dotp Motor power ----- 11 kW Drive Unit ----- Belt

Condition: new, PAK-1 Unbalance Measuring Unit is designed to modernize your balancing machine. A balancing machine has a long mechanical life, but prolonged use leads to gradual failure of electronics and measuring instruments, causing problems with spare parts and lack of technical support. Minimize downtime and ensure the reliability of your balancing machine by upgrading it with a new advanced measuring unit. The PAK-1 unbalance measuring unit works in all balancing machines of most existing designs and manufacturers. Confidence in results and ease of use: Easy to set up and work with, our devices do not require any special theoretical knowledge. Wide range of functions for your balancing machine: The use of modern microprocessor technology and many years of experience of our developers allows us to implement functions that were previously unavailable to other manufacturers. Your machine complies with ISO 21940: Balancing machines equipped with the PAK-1 unbalance measuring unit fully meet the precision requirements of modern standards. HIGHLIGHTS • We make balancing easier - the main advantage of our balancing systems. • The balancing process is displayed in real time and the unbalance behaviour of the rotor is monitored on the screen to achieve the best possible result. Isdsq Ttn Djpfx Ad Detp • The maximum sensitivity of the machine at any moment of operation, the set-up and calibration of the machine is carried out by the operator himself. • Free from the influence of external vibration factors on the measurement result, it has a high degree of protection against various types of interference. • Easy to learn working skills and maintenance for any employee. INCLUDES: 1) vibration sensor signal processing unit, 2) fanless industrial computer with touch screen, 3) new vibration and speed sensors, 4) metal protected cable set. SEQUENCE OF WORKS for modernization of the measuring unit - Replacement of the existing measuring system with the balancing complex PAK-1 based on an industrial computer; - Installation of new vibration sensors and rotor speed sensor - Replacement of all connecting cables; - Adjustment of the measuring unit on the balancing machine; - Training of personnel with skills to operate the machine. VTM GROUP offers to upgrade your balancing machine. We repair and modernise various old balancing machines of all types from all manufacturers. It's cost effective. An alternative to buying a new balancing machine in 95% of cases. Urgent. Work can be done at customer site within 1-2 days. New components for modernization of your machine: • Installation of new measuring system and vibration and speed sensors. • Installation of new electrical equipment • Manufacturing or repair of the rotation drive • Manufacturing of new rollers Every business is different. Let's discuss your task. We can offer a solution for any balancing machine. Please contact us to get the best offer! 👇

Condition: new, Year of construction: 2025, Our most advanced software delivers incredibly sensitive measurements. Only 1.5 seconds to measure. Validation world-wide. Balancing speed - up to 300,000 revolutions per minute. Long lasting mechanical quality. 7/24 online support. 10 pieces of nozzles (28 - 65mm). 25 pieces of flanges. Five-stage oil filtration system. A core oil leak test. Automatic air flow control valve. Prevent turbo from running dry by controlling oil pressure and temperature. Energy-saving and cost-saving adapter system. Adapter changeover time is less than 15 seconds. Free online technical support during the warranty period and after the warranty period. Isdoq Tr R Sepfx Ad Dotp Support for spare parts. Required capacity of the air tank 1/2 m³. Colour printer. (Ops) Dremel for grinding. (Ops)

Condition: new, Year of construction: 2025, FEATURES BENEFITS Compact design Integrated air supply Utilises your existing workshop air supply, 7 bar, clean dry air requirement It has the ability to measure digital and analogue wastegates on all vehicle models. With its 23.5-inch full touch screen and simple interface, it is very easy to use. Can be used without an internet connection Built-in database of more than 1900 references Flow adjustment possible for all types of turbochargers up to 200 kg/h Calibration test plates provided to easily verify machine accuracy All types of turbochargers can be easily connected with 6 adapters included as standard. G3 REA-Master (USB) Controller Built-in complete with 14 cables 12 volt and 4 cables for 24 volt It displays and adjusts the current, voltage and position values of the Turbo VGT turbochargers. Itedpfxoq Trzfj Ad Djp It can test all types of turbos with electronic, vacuum and vacuum sensor. Operates on 200 volts of electricity Calibration test plates supplied for easy verification of machine accuracy Supports PWM, FDCan, Can 2.0, Linbust, j1939 automatic communication protocols You can assign programmes to activators Quick-release mounting flange with adapters Machine weight 150kg Full CE Accreditation INCLUDING 1 x FX1 Flowbench Machine 1 x Touch Screen Monitor 14 x R.E.A. Cables 4 x 24 v Cables (OPTIONAL) 3 x C-Clamps 1 x Magnetic Stand

Condition: excellent (used), Year of construction: 2014, workpiece weight (max.): 16 kg, input voltage: 230 V, year of last overhaul: 2025, SCHENCK TBsonio High Speed Balancing machine for turbocharger core assemblies Ijdpfx Adeq Nin Us Detp

Condition: excellent (used), Year of construction: 2011, functionality: fully functional, workpiece weight (max.): 10 kg, input voltage: 230 V, year of last overhaul: 2023, SCHENCK Highspeed Special Balancing Machine Type 110 MBRS for turbocharger core assemblies a for service, repair shops as well as research and development departments. The correction of the static unbalance can be performed inside the balancing machine on the compressor wheel side directly on the machine. Max balancing speed 250,000 rpm Itodpjq I Rz Rofx Ad Dsp

Condition: used, Scale with maximum capacity 6 tons, minimum 40 kg, overall dimensions 610 x 110 cm, h. 90 Itjdpfx Aepfp Dvsd Djp

Condition: new, The 9D717 balancing machine is a versatile and reliable tool for balancing a wide range of rotors from 15 to 1500 kg. This machine is capable of balancing different types of rotors, including inboard and outboard cantilever rotors, rotors on special mandrels and rotors in their own bearings. The machine's design is simple yet functional, allowing it to easily balance armatures, generator rotors, impellers and fan wheels, even with large initial imbalances. In addition, the machine can balance rotors in their own bearings, saving repair time and preventing damage to the rotor trunnions. Itsdpfxepdpn Uo Ad Dep It is suitable for determining and eliminating unbalance on rotors of electric motors, metallurgical gears, screws and printing equipment. The 9D717 balancing machine is also capable of balancing disc-type parts such as impellers and smoke pump impellers, as well as correcting unbalance on shaft-type parts such as threshing drums and combine rotors. Overall, this machine is highly versatile and effective in balancing various types of rotors, making it ideal for repair and production shops. HIGHLIGHTS • The specially designed rollers use advanced patented “Exact Barrel” grinding technology and are mounted on precision bearings. • The monolithic design of the supports and base eliminates vibration losses during balancing by reducing the number of "oscillating system" elements. • Allows large initial unbalances to be measured without destroying the machine, and rotor unbalance to be corrected directly on the machine. • The low natural resonance frequency of the supports allows the rotor to be balanced at low speeds. • The width of the support rollers and roller block allows the installation of rotors with very short rotor bearing journals. The modular design allows rotors with unusual configurations to be mounted using spacers or tools. • The height of the roller block is adjustable, allowing rotors with different journal diameters to be balanced. • The belt drive has a patented "Long stroke" design that allows any rotor to be rotated using only two drive belts. • The frequency converter drive provides smooth acceleration and deceleration of the electric motor and infinitely variable speed control of the rotor. MEASUREMENT AND CONTROL • We make balancing easier - the main advantage of our balancing systems. • The balancing process is displayed in real time and the unbalance behaviour of the rotor is monitored on the screen to achieve the best possible result. • The maximum sensitivity of the machine at any moment of operation, the set-up and calibration of the machine is carried out by the operator himself. • Free from the influence of external vibration factors on the measurement result, it has a high degree of protection against various types of interference. • Easy to learn working skills and maintenance for any employee. SPECIFICATIONS Weight range of balanced rotors 15 - 1500 kg Maximum rotor diameter (above the bedding) 1800 mm Distance between centres of rotor supports 360 – 3000 mm Support type Rollers Transmission element for rotor rotation Belt / Cardan Minimum achievable residual specific unbalance 0.4 g*mm/kg Rotor speed range 300 – 1500 rpm Electric motor power 7.5 kW Parameters of the supply network 380V, 3 Ph, 50Hz Do you need a machine for a different load capacity, diameter or length? We manufacture balancing machines for every needs. Please contact us to get the best offer! 👇

Condition: new, Turbocharger core balancing machine DBST-20 Low-speed turbocharger core balancing machine meets the needs of turbocharger repair workshops. Machine is used for balancing common truck and passenger car turbos. It is multi-functional and universal, so it is suitable for many large turbochargers of special vehicles, railroad and marine turbines, and even for industrial turbochargers of gas and diesel power plants. The DBST-20 is used for balancing common truck and car turbochargers. It is multifunctional and universal, so it is suitable for many large turbochargers of special vehicles, railway and marine turbines, and even industrial turbochargers of gas and diesel power plants. This stand allows for the final balancing of cartridges due to the specific design features of large turbines. The stand is used for balancing turbocharger cartridges at low speeds, as well as for checking turbocharger cartridge oil leaks. This is a larger version of the DBST-10 model that our company has developed specifically for large turbochargers weighing up to 30 kg. HIGHLIGHTS High accuracy of determining the unbalance of the rotor (0.4 g ∙ mm / kg). Reinforced torsional vibration suspension - high accuracy of vibration transmission, quality balancing results. Mounting the cartridges on their standard surfaces (as on the engine) allows the installation of almost all turbochargers. Wide range of accessories and adapters for installing any kind of turbos. Includes adapters for installing turbochargers with lower oil inlet. Itsdpfjn Nxcfox Ad Dep Oil system with oil heating allows to recreate similar conditions to the real one during balancing. 3-stage system of oil filtration allows to eliminate an unbalance directly on the machine by portable grinders. The measuring system displays the balancing process in real time and monitors the rotor unbalance behaviour on the screen to achieve the best possible result. Rotor adjustment and machine calibration are performed by the operator, ensuring maximum machine sensitivity at all times. Safe turbo shaft speed allows risk-free quality running-in of assembled cartridges, which significantly increases cartridge reliability after repair. KEY FEATURES • High accuracy 2 plane balancing • Truck and car turbocharger balancing • Any turbocharger can be installed • All type turbocharger adapters included • Quick and easy turbo core installation • Balancing speed up to 10 000 rpm • Fast oil heater and temperature regulation • 3-stage oil filtration • Real-time unbalance measurement • Calibration of the machine by the operator • Industrial fanless touch screen PC control system • Creation and printing of reports on turbocharger balancing SPECIFICATIONS Maximum turbocharger weight 30 kg Maximum turbocharger diameter 300 mm Maximum turbocharger length 300 mm Maximum rotation speed 10 000 rpm Minimum achievable residual specific imbalance, 0,4 g mm/kg Pneumatic system operating pressure 0,6 – 0,8 MPa Power supply 220V, 1Ph, 50Hz Power input 1,5 kW Dimensions 1120 х 780 х 1350 mm Weight 285 kg

Condition: new, Dynamic Hard-bearing Balancing Machines of the 9D716 series have originally been designed to meet the needs of a wide range of customers. They are undoubtedly the best solution if you need to balance a wide range of rotor types, weights and sizes. This has led to their use in a wide range of industries. The machines have many unique technical solutions that allow you to set up and balance complex rotors in the shortest possible time without losing the accuracy of the unbalance detection. MACHINE HIGHLIGHTS • The specially designed rollers use advanced patented Exact Barrel grinding technology and are mounted on precision bearings. • The monolithic design of the supports and base eliminates vibration losses during balancing by reducing the number of "oscillating system" elements. • Allows large initial unbalances to be measured without destroying the machine, and rotor unbalance to be corrected directly on the machine. • The low natural resonance frequency of the supports allows the rotor to be balanced at low speeds. • The width of the support rollers and roller block allows the installation of rotors with very short rotor bearing journals. The modular design allows rotors with unusual configurations to be mounted using spacers or tools. • The height of the roller block is adjustable, allowing rotors with different journal diameters to be balanced and the rotor to be centred during machine set-up. • The unique "Micro-Tuning" technology eliminates the effects of axial slippage during rotation. • The belt drive has a patented "long stroke" design that allows any rotor to be rotated using only two drive belts. • The frequency converter drive provides smooth acceleration and deceleration of the electric motor and infinitely variable speed control of the rotor. MACHINE DESIGN OPTIONS Isdpfx Aen Hwqved Djtp • Axial drive that uses a cardan shaft. Capable of transmitting high torque from the electric motor to the rotor. This type of drive is used for parts with high aerodynamic resistance or special design features (e.g. augers). • Drilling module for unbalance correction of the rotor without removing it from the machine. Convenient to use to increase the productivity of the operation. • Extended machine bed. The base of the machine can be made for any length of rotor. In our practice we have had machines for rotors of 12 metres in length. MEASUREMENT AND CONTROL • We make balancing easier - the main advantage of our balancing systems. • The balancing process is displayed in real time and the unbalance behaviour of the rotor is monitored on the screen to achieve the best possible result. • The maximum sensitivity of the machine at any moment of operation, the set-up and calibration of the machine is carried out by the operator himself. • Free from the influence of external vibration factors on the measurement result, it has a high degree of protection against various types of interference. • World-leading functionality and accuracy. SPECIFICATIONS Weight range of balanced rotors 5 - 500 kg Maximum rotor diameter (above the bedding) 1300 mm Diameter of rotor support journals 30 - 180 mm Distance between centres of rotor support journals 200 – 2000 mm Support type Rollers Transmission element for rotor rotation Belt / Cardan Minimum achievable residual specific unbalance 0.4 g.mm/kg Rotor speed range 300 – 1500 rpm Electric motor power 4.0 kW Parameters of the supply network 380V, 3 Ph, 50Hz

Condition: new, DRIVESHAFT BALANCING MACHINE BVI-03-88 Balancing machine for professional repair of cardan shafts up to 200 kg. The hard-bearing machine is adapted for heavy cardan shafts of trucks and special machinery. The high sensitivity of the supports allows also high-quality balancing of cardan shafts of passenger cars. The machine is designed for balancing cardan shafts in the facilities of cardan repair workshops. The machine can be quickly reconfigured for balancing a large amount of single cardan shafts of various designs, as well as for the production of small batches of shafts. . . . TWO TIMES faster then your machine. This balancing machine is majored to balance the shaft not only qualitatively, but also quickly. If you can balance in 2-2.5 times faster, then this is your real competitive advantage. . .. ... HIGH PERFORMANCE ACCESSORIES The machine is equipped with three main types of adapters: 1. Fast clamping universal adapters. It has two main advantages: The first is that due to the special design the driveshaft flange is clamped within 5 seconds. This advantage is due to the fact that the driveshaft flange does not need to be fixed with bolts. THE SHAFT CAN BE CLAMPED 4 TIMES FASTER WITHOUT BOLTS. The second advantage is the centering rings. The driveshaft is mounted in the adapters with centering rings that can be made on an ordinary lathe to fit most common driveshafts. 2. KV Flange adapters. Used for balancing shafts with cross-tooth flanges. Applies to four flange sizes: 120, 150, 180, 205 mm. Usually used on truck driveshafts. 3. Adapter with slots. Used to mount various flanges with holes. Mounting the driveshaft is the same as on universal adapters, with the help of centering rings. Isdpfsn E Skwex Ad Dotp KEY FEATURES • Balancing of 2, 3 and 4-support cardan shafts • Shaft length up to 5200mm, weight up to 200kg • Cardan installation in 1 minute • Standard set of adapters - Installation of 80% of cardan shafts; • Three ways of fixing the center bearing • Hard-bearing type machine - safe balancing of shafts with large initial unbalance • Machine is operated by one worker • Sliding tailstock spindle - quick changeover, comfortable operation • Safety bracket with clamp for quick installation • Measurement in all planes at one time • Calibration of the machine by the operator • Displays imbalance in real time • Create and print reports SPECIFICATIONS Maximum cardan shaft weight 200 kg Maximum flange diameter 300 mm Maximum length of cardan shaft 5200 mm Number of machine supports 4 Number of simultaneously measured planes 2, 3, 4 Minimum achievable residual specific imbalance, 10 g mm/kg Rotor speed range 1000-2500 rpm Parameters of the supply network 380V, 3 Ph, 50Hz Power consumption, minimum, 3 kW Dimensions (length x width x height) 6000 х 1100 х 1450 mm Weight 1100 kg

Condition: new, VSR turbocharger high-speed balancing machine SBR-10 SBR-10 professional specialised equipment for high-speed balancing of assembled turbo cartridges. Equally useful for car and truck turbocharger. The machine was designed for entry level turbocharger repair workshop, including medium re-manufacturers. It solves a wide range of tasks that repair centres face on a daily basis. The SBR-10 simulates the same testing and balancing conditions as the turbocharger on the vehicle, this allows the quality of the repair to be guaranteed. It also allows checking turbocharger for oil leakage. A well-balanced turbocharger has a long service life which reduces the return rate of turbochargers and helps to build up your reputation. HIGHLIGHTS Mounting the cartridges on their standard surfaces (as on the engine) allows the installation of almost all turbochargers. Wide range of accessories and adapters for installing any kind of turbos Includes adapters for installing turbochargers with lower oil inlet and reverse rotation turbines Oil system with oil heating allows to recreate similar conditions to the real one during balancing. The turbocharger rotation and measurement is automatic. The cycle includes acceleration to maximum speed, measurement during the cycle, and air shutdown. Emergency shutdown is provided in case of extreme vibration increase, which prevents cartridge destruction even in case of assembly errors Automatic cycle allows to carry out vibration measurement in a short and sufficient period of time. Vibration measurement of the turbocharger housing - up to a value of 10G, which 2 times better than other analogs. KEY FEATURES • car and truck turbocharger balancing • Any turbocharger installation • All type turbocharger adapters • Reverse rotation adapters • Balancing speed up to 300 000 rpm • Fast oil heater and temperature regulation • 3-stage oil filtration • Real-time unbalance measurement • Automatic cycle turbocharger balancing • An industrial fanless touch screen pc control system • Access to self-editing of the data base • Creation and printing of reports on turbocharger balancing SPECIFICATIONS Maximum compressor wheel diameter 120 mm Maximum rotation speed 300 000 rpm Pneumatic system operating pressure 0,8 – 1,0 MPa Minimum air receiver volume 1000 L Power supply 220V, 1Ph, 50Hz Power input 1,5 kW Dimensions 1120 х 780 х 1274 mm Isdpfenfvmhex Ad Dotp Weight 285 kg We manufacture fuul range turbo repair equipment. Please contact us to get more info! 👇

Condition: refurbished (used), Year of construction: 2025, functionality: fully functional, workpiece weight (max.): 50 kg, total width: 400 mm, total length: 1,200 mm, total height: 1,800 mm, overall weight: 850 kg, Equipment: documentation/manual, The KKT Universal BA & KA balancing machine is a horizontally operating industrial balancing machine for precision balancing with belt drive and cardan shaft drive. It is suitable for balancing motor armatures of various sizes, as well as shafts, fan impellers, grinding wheels, cardan shafts, and similar rotors. We offer this machine in various versions, both as a used machine and as a new machine built to meet customer requirements. Please feel free to contact us - we will be happy to provide you with comprehensive advice and support. Isdjf Sqiqjpfx Ad Dotp
