Condition: like new (used), Year of construction: 2012, functionality: fully functional, measuring range X-axis: 400 mm, measuring range Y-axis: 400 mm, measuring range Z-axis: 300 mm, workpiece weight (max.): 180 kg, total height: 1,967 mm, type of input current: AC, total width: 981 mm, total length: 1,047 mm, travel distance X-axis: 410 mm, travel distance Y-axis: 410 mm, travel distance Z-axis: 310 mm, overall weight: 410 kg, input voltage: 230 V, table width: 624 mm, table length: 805 mm, table load: 180 kg, compressed air connection: 4 bar, ambient temperature (max.): 30 °C, ambient temperature (min.): 15 °C, Equipment: documentation/manual, type plate available, Coordinate Measuring Machine Mitutoyo Crysta-Plus with HP Workstation and Monitor Year of manufacture: 2012 Very little used, excellent condition X-axis: 400 mm Y-axis: 400 mm Z-axis: 300 mm Accuracy according to ISO 10360: E = 3 + 0.4 L/100 µm Within a temperature range of 15 to 30 °C Resolution: 0.0005 mm Fgjdpjxmhw Iofx Afpsh Probe head: Renishaw MH 20i+PS12R Measuring table: Granite 624 mm x 805 mm Pneumatic axis clamping for each axis, additionally operable via foot switch Workpiece clamping: Threaded insert M8, 13 positions Distance between columns: 625 mm Maximum workpiece height: 400 mm Maximum weight: 180 kg Machine weight: 480 kg Recommended installation area (incl. PC): 2.5 x 2.5 m Comprehensive accessories, e.g. probe heads, master ball

Condition: like new (used), Year of construction: 2013, operating hours: 400 h, functionality: fully functional, measuring range X-axis: 300 mm, measuring range Y-axis: 200 mm, measuring range Z-axis: 150 mm, workpiece weight (max.): 20 kg, total height: 890 mm, total width: 986 mm, total length: 705 mm, overall weight: 170 kg, input voltage: 230 V, Equipment: documentation/manual, lighting, type plate available, SPECIAL OFFER with optional full service (delivery, commissioning) Technical Specifications of the HEXAGON OPTIV CLASSIC 321 GL tp Measuring Machine Year of manufacture: 2013 Maximum traverse speed in X, Y, Z axes: 160 mm/s Maximum workpiece weight: 20 kg Measurement resolution: 0.05 µm Measurement accuracy in X, Y axes (optical sensor): Ex, Ey = (1.6 + L/250) µm Measurement accuracy in XY axes (optical sensor): Exy = (2.0 + L/250) µm Measurement accuracy in Z axis (optical sensor): Exy = (3.9 + L/200) µm Measurement accuracy in X, Y axes (touch-trigger probe): Ex, Ey = (2.0 + L/250) µm Measurement accuracy in XY axes (touch-trigger probe): Exy = (2.5 + L/250) µm Measurement accuracy in Z axis (touch-trigger probe): Ez = (2.9 + L/200) µm Measuring volume Optical Sensor: X 300mm Y 200mm Z 150mm Measuring volume tactile sensor: X 230mm Y 200mm Z 150mm Dimensions (L x W x H): 705 x 986 x 890 mm Machine weight: 170 kg Measuring machine features: 3-axis microprocessor CNC with vector path control Metrology software: PC-DMIS Vision Vision sensor for non-contact measurement of the smallest and most precise components Fsdpfx Afsxmgvpopogh CCD camera with 6.5x motorized CNC zoom DC servo motors TESA touch probe system (1 body and 1 module) Modular probe changer: TESASTAR with 4 slots and 4 modules Linear guides on all axes Coaxial LED incident light (white LED) LED backlight (green LED + diffuser) Multi-segment LED ring light Including evaluation computer by Dell Optional services: Delivery (extra charge) Commissioning (extra charge)

Condition: excellent (used), Year of construction: 2006, 1 x Profile Projector Tesa Scope 300 V Year of manufacture: 2006 Technical Data: Screen diameter: 300 mm Magnification: 10x + 20x Travel paths: X: 200 mm Y: 100 mm Resolution: 0.001 mm Fgodpsxl Ulijfx Afpeh Further technical data to follow. The projector can be inspected under power at any time.

Condition: excellent (used), Projector make: Baty Model: SM 20 E 220 volts 3 objectives: 10x, 20x, and 50x magnification Coordinate stage with Werth Digimy ZV 5 Digital readout, 2 axes Glass disc diameter: 510 mm Transport dimensions: Length: 1000 mm Width: 600 mm Fedoxlzxiepfx Afpogh

Condition: used, Measuring machine Hexagon Type: DEA Pioneer 05-06-04 Travel path: x/y/z = 500x600x400 Last calibration: 07/2022 Fjdexlcazspfx Afpsgh

Condition: ready for operation (used), Year of construction: 2016, Hexagon Tigo SF measuring machine (2016) Manufacturer: Hexagon Model: Tigo SF Fgedpoxlafbofx Afpsh Condition: used, very good. In production Maintenance and calibration before handover optional.

Condition: excellent (used), Year of construction: 2008, Faro Gage Plus measuring arm with 6 axes Measuring arm length: 4ft (approx. 1.2m) Accuracy: 5+8L/1000µm With trolley, accessories, and corresponding transport case Incl. software and operating manual Never used/Unused – Like new Fgsdpoxk U U Uefx Afpeh

Condition: used, Dr. Heinrich SKM 1000p – 3D Multi-Sensor Measuring Machine For sale is a 3D multi-sensor measuring machine from the manufacturer Dr. Heinrich, model SKM 1000p. The machine is in excellent condition, available immediately, and ready for operation. — Technical Data • Measuring range X/Y/Z: 1,000 × 400 × 300 mm • Max. workpiece weight: 100 kg • Voltage: 220–240 V, 50–60 Hz • Software: 3D measurement and analysis software SAPHIR • CAD import • Graphical display • Teach-in programming • Target/actual comparison — The machine is highly precise and in perfect technical condition. • Functional video available via WhatsApp on request • Shipping by freight forwarder possible at short notice throughout Germany — Contact Maschinenhandel Nord Gerstenstraße 2 17034 Neubrandenburg 📞 All prices net plus VAT. Subject to change and errors excepted. Fgsdpexk T Dbefx Afpsh

Condition: ready for operation (used), ZEISS Rondcom 54 Form Measuring Instrument – Surface and Contour Measuring Device Max. Measuring Diameter (OD): approx. 300 mm Max. Workpiece Diameter: approx. 580 mm (depending on configuration) Max. Workpiece Load: approx. 30 kg Rotational Axis (C-axis) – Radial Roundness: 0.020 + 6 H / 10,000 µm (tolerance) Axial Runout: 0.020 + 4 R / 10,000 µm Measuring Speed (Rotation): approx. 2 – 10 rpm Centering Range: ± 2 mm Leveling / Tilting Range: ± 1° Resolution (Rotary Axis): 0.025° Z-Axis (Vertical Travel): 300 mm (optionally expandable to 500 mm) Straightness Deviation Z-Axis: 0.12 µm / 100 mm, 0.20 µm / 300 mm Parallelism Deviation (relative to rotary axis): 0.8 µm / 300 mm R-Axis (Radial Movement) – Travel: 170 mm Straightness Deviation R-Axis: 0.8 µm / 150 mm Parallelism Deviation (C vs. R): 1 µm / 150 mm Linear Scale (on R-Axis): Yes, available as standard (for higher accuracy) Measuring Force (stylus / probe): adjustable, 30 – 100 mN Measuring Range (probe): ± 1000 µm (adjustable) Detector Resolution: up to 0.001 µm (1 nm) Standard Stylus: Length L = 54 mm, Ball Ø = 1.6 mm carbide Power Supply: 100 – 240 V AC, 50/60 Hz Fjdpfxoxhd E Ds Afpogh Power Consumption: approx. 600 VA Compressed Air Requirement: 0.3 – 0.7 MPa Weight (approx.): approx. 170 kg You are welcome to arrange a viewing appointment. We are happy to organize cost-effective shipping for you! You will receive a proper invoice. Export customers can be issued a net invoice, provided a valid VAT ID number is supplied. Sale subject to prior sale. Visit our shop to view our other offers as well. All company names and trademarks are property of their respective owners and are used for identification and description purposes only. Technical data may vary and errors in item descriptions are subject to change.

Condition: as good as new (ex-display), Year of construction: 2025, functionality: fully functional, measuring range X-axis: 100 mm, measuring range Y-axis: 100 mm, measuring range Z-axis: 35 mm, warranty duration: 12 months, total height: 670 mm, total width: 500 mm, total length: 280 mm, overall weight: 25 kg, repeat accuracy: 0.001 mm, From €239 per month (84 months) | DAkkS calibration included | Book a free online demo | Available immediately VX1100D – High-precision digital measuring projector with 100 mm field of view The VX1100D sets the standard for uncompromising precision and efficiency in optical measurement technology. As a state-of-the-art digital metrology system, it delivers top-tier accuracy, repeatability, and user-friendly operation—ideal for first article inspection, series production, and quality assurance in demanding manufacturing environments. Highlights Fsdpfjxg R Ddox Afpegh - 20-megapixel CMOS image sensor for razor-sharp, highly detailed measurement results - Dual telecentric lens for distortion-free imaging and utmost precision - Ring light and transmitted light illumination for optimal lighting on every measurement task - Large 100 mm field of view—perfect for larger components and complex geometries - Repeatability ±1 µm—maximum process reliability for series measurements - Measurement accuracy ±3 µm—reliable even with the tightest tolerances - Intuitive Vision X software with automated measuring sequences and evaluation functions - (Optional touch monitor installation) Technical Data - Resolution: 0.1 µm - Z-axis travel: 35 mm - Maximum table load: 3 kg - Operating environment: Temperature 10–35 °C, humidity 20–80 %, vibration < 0.002 g The VX1100D combines advanced optics, intelligent software, and superior manufacturing quality. It is the ideal solution for companies aiming to optimize their measurement processes while ensuring the highest levels of precision and reliability. Contact us for more information or a customized quote.

Condition: used, Year of construction: 2011, measuring range X-axis: 600 mm, measuring range Y-axis: 500 mm, measuring range Z-axis: 400 mm, Coordinate measuring machine with 5-axis head Manufacturer: Hexagon Model: DEA Pioneer 5-6-4 Year of manufacture: 2011 Measuring range: X-axis = 500 mm Y-axis = 600 mm Z-axis = 400 mm E (0,MPE) = 2.8 µm + L/285 P (FTU,MPE) = 3 µm Last calibration: 7 – 2022 Measuring head (refurbished in 2022): Type: HH-A-T5 Angular rotation steps = 5° A-axis = +90° / -115° B-axis = ±180° Equipment: - TESA probe head Tesa-Star Mp Fgodpjxg I Dnefx Afpjh - Handheld control unit NJB 001 (new in 2019) - 2 x extensions - Various styluses - Calibration sphere - PC - Measurement software PC-DMIS (license expired)

Condition: excellent (used), Year of construction: 2020, Very well-maintained measurement system from Keyence. Type: XM-T1200 with PC XM-1500 Year of manufacture: approx. 2020 Fgsdpfxjxgq Amo Afpoh #8385

Condition: used, Year of construction: 2014, with PC, software (software has no extra dongle, it is installed on the PC) to include various measuring probes Fodexgpv Espfx Afpjgh

Condition: used, Year of construction: 2005, with PC, software & dongle to include various measuring probes Fgjdpfx Afexgpubspeh

Condition: used, Year of construction: 1995, operating hours: 38,000 h, functionality: limited functionality, machine/vehicle number: PNC 35 / Serien-Nr.: B5307, Software version: Klingelnberg / V3.2.3 Fgsdpexgm Tbefx Afpsh Software options: Gina spur gear (Win) + da/df extension + cylindrical worms (Basic) + Gina hobbing option (Win) + spur gear (Basic) + Gina hobbing option (Win) PC equipment: XP_64bit system / 1x 19" monitor Probing system: Rigid probing system / probe sensor M43m The machine has not been in operation since 2021 and can be inspected at our facility upon request. The machine has been stored with transport securing measures in place.

Condition: like new (used), Year of construction: 2015, operating hours: 230 h, functionality: fully functional, measuring range X-axis: 300 mm, measuring range Y-axis: 200 mm, measuring range Z-axis: 150 mm, workpiece weight (max.): 20 kg, total height: 890 mm, total width: 986 mm, total length: 705 mm, overall weight: 170 kg, input voltage: 230 V, Equipment: documentation/manual, lighting, type plate available, SPECIAL OFFER with optional full service (delivery, commissioning) Technical data of the HEXAGON OPTIV CLASSIC 321 GL tp measuring machine Year of manufacture: 2015 Maximum traverse speed in X, Y, Z axes: 160 mm/s Maximum workpiece weight: 20 kg Measuring resolution: 0.05 µm Measuring accuracy in X, Y axes (optical sensor): Ex, Ey = (1.6 + L/250) µm Measuring accuracy in XY axes (optical sensor): Exy = (2.0 + L/250) µm Measuring accuracy in Z axis (optical sensor): Exy = (3.9 + L/200) µm Fgsdjxfzzqjpfx Afpjh Measuring accuracy in X, Y axes (touch-trigger probe): Ex, Ey = (2.0 + L/250) µm Measuring accuracy in XY axes (touch-trigger probe): Exy = (2.5 + L/250) µm Measuring accuracy in Z axis (touch-trigger probe): Ez = (2.9 + L/200) µm Measuring volume (optical sensor): X 300 mm / Y 200 mm / Z 150 mm Measuring volume (tactile sensor): X 230 mm / Y 200 mm / Z 150 mm Dimensions (L x W x H): 705 x 986 x 890 mm Machine weight: 170 kg Equipment of the measuring machine: • 3-axis microprocessor CNC with vector path control • Metrology software: PC-DMIS Vision • Vision sensor for non-contact measurement of the smallest and most precise components • CCD camera with 6.5x motorized CNC zoom • DC servomotors • TESA probe system (1 body and 1 module) • Modular probe changer: TESASTAR with 4 slots and 4 modules • Linear guides on all axes • Coaxial LED top light (white LED) • LED backlight (green LED + diffuser) • Multi-segment LED ring light • Evaluation computer from Dell included Optional services: Delivery (surcharge) Commissioning (surcharge)

Condition: used, Year of construction: 2015, functionality: fully functional, HEXAGON METROLOGY – ROMER Absolute Arm Portable Coordinate Measuring System The ROMER Absolute Arm from HEXAGON METROLOGY is a high-precision, portable coordinate measuring system designed for flexible 3D measurement directly at the point of use. With its rugged construction, intuitive operation, and absolute encoded rotary encoders, it delivers maximum accuracy with no prior referencing required. Description: • Manufacturer: HEXAGON METROLOGY • Model: ROMER Absolute Arm • Measuring Arm Technology: Portable 3D coordinate measuring system • Measuring range: (depending on model, e.g. up to 4.5 m reach) • Accuracy: High-precision 3D measurement for industrial applications • Kinematics: Smooth-running 7-axis design for ergonomic operation • Absolute encoders: No warm-up phase or referencing necessary • Material: High-quality, durable lightweight construction • Software compatibility: Supports various 3D measuring and evaluation programs (e.g., PC-DMIS, PolyWorks, etc.) • Areas of application: Production metrology, quality assurance, tool and jig construction, reverse engineering • Rapid commissioning with no presetting required • Portable and easy to transport – ideal for measurements directly at the machine or in the field • Simple operation, even for non-specialist measurement technicians • Expandable with laser scanners for non-contact measurement • 10 years old • No current software package (as of...) • Last calibration • On-site inspection with tests • Sale without guarantee/warranty Fgjdpfxsxfzdrs Afpsh

Condition: good (used), Year of construction: 2010, Technical Specifications Manufacturer: Werth Messtechnik GmbH Model: Video-Check 800x400x200 3D Year of manufacture: 2010 Measuring range: 800x400x200 mm Control system: Operator console with joystick and function buttons Voltage: 230 V AC Frequency: 50 Hz Current consumption: max. 10 A Fsdpfx Afoxfly Depogh Camera: High-resolution video technology Probes: Renishaw measuring probe Multi-sensor technology: Combined optical and tactile measurement Construction: Solid granite base SCOPE OF DELIVERY Includes, among others (list not exhaustive): • 3D measuring machine Werth Video-Check 800x400x200 • Operator console with joystick and function buttons • Probes Exact scope of delivery as per photo documentation The Werth Video-Check 800x400x200 is a high-precision 3D measuring machine for versatile applications in quality assurance. With its large measuring range of 800x400x200 mm, it is suitable for small to medium-sized components. The machine features multi-sensor technology that allows both optical and tactile measurements, offering maximum flexibility. The robust granite construction ensures the highest measurement accuracy and long-term stability. Thanks to the Renishaw probe, video camera, and convenient control via operator console, complex measuring tasks can be performed efficiently and reliably. No guarantee is given for the accuracy, completeness, or timeliness of the information provided.

Condition: good (used), Year of construction: 2010, 3D Coordinate Measuring Machine Werth Video-Check-IP 400×200 3D CNC TECHNICAL DATA Manufacturer: Werth Model: Video-Check-IP 400×200 3D CNC Function: 3D Coordinate Measuring Machine Year of manufacture: 2010 Measuring range X-axis: 400 mm Measuring range Y-axis: 200 mm Measuring range Z-axis: 250 mm Max. workpiece weight: 30 kg Drives: Ball screw drives with servo motors Measuring systems: Incremental scales with 0.1 µm resolution Guides: Precision ball guides on all axes Illumination: Transmitted light, bright field and dark field reflected light with LED Fsdpfoxfluujx Afpjgh Optics: Zoom optics with zoom factor 0.2x–100x Camera: High-resolution CCD black-and-white camera Electrical connection: 230 V AC, 50 Hz Current consumption: max. 10 A Power: max. 1.5 kVA Noise level: < 70 dB(A) SCOPE OF DELIVERY Including (not limited to): 3D Coordinate Measuring Machine Werth Video-Check-IP 400×200 3D CNC Control panel Probes Fiber optic and reference standard sets Exact scope of delivery according to photo documentation The Werth Video-Check-IP 400×200 3D CNC is a high-precision coordinate measuring machine for optical and tactile metrology. With a measuring range of 400 x 200 x 250 mm, it offers versatile application options for quality assurance of a wide variety of components. The combination of high-resolution CCD black-and-white camera, powerful zoom optics and LED lighting ensures precise image capture and reliable results. Precision ball guides and servo drives guarantee high repeatability. The device comes with extensive accessories and is ideally suited for precise 3D measuring tasks in industrial and manufacturing environments. No guarantee is given for the correctness, completeness or currentness of the information provided.

Condition: good (used), functionality: fully functional, measuring range X-axis: 300 mm, measuring range Y-axis: 200 mm, measuring range Z-axis: 150 mm, workpiece weight (max.): 20 kg, Optical Multisensor Measuring Machine HEXAGON OPTIV CLASSIC 321 GL tp Excellent condition, available for inspection at a specialist company for industrial metrology – commissioning, calibration etc. can be arranged upon request! - Year of manufacture: According to Hexagon, likely 2015 - Machine number: 7F001-7 - Condition: Good - Delivery terms: Loaded free on truck (unpacked) - Location: 66127 Saarbrücken - Availability: Immediately (subject to agreement) - Payment terms: Advance payment by bank transfer - Internal No.: OCU Available for inspection under power: YES Technical data: - Metrology software: PC-DMIS Vision - Vision sensor for non-contact measurement of very small and precise components - CCD camera with 6.5x motorized CNC zoom - DC servo motors - Modular probe changer: TESASTAR - Linear guides on all axes - Coaxial LED top light (white LED) Fsdoxfagrjpfx Afpsgh - LED backlight (green LED + diffuser disc) - Multi-segment LED ring light - Maximum feed rate in X, Y, Z axes: 160 mm/s - Maximum workpiece weight: 20 kg - Measuring resolution: 0.05 µm - Measuring accuracy in X, Y axis (optical sensor): Ex, Ey = (1.6 + L/250) µm - Measuring accuracy in XY axis (optical sensor): Exy = (2.0 + L/250) µm - Measuring accuracy in Z axis (optical sensor): Exy = (3.9 + L/200) µm - Measuring accuracy in X, Y axis (tactile probe system): Ex, Ey = (2.0 + L/250) µm - Measuring accuracy in XY axis (tactile probe system): Exy = (2.5 + L/250) µm - Measuring accuracy in Z axis (tactile probe system): Ez = (2.9 + L/200) µm - Measuring range (optical sensor) X 300mm Y 200mm Z 150mm - Measuring range (tactile sensor) X 230mm Y 200mm Z 150mm Scope of delivery: - PC including measurement software PC-DMIS Vision - Documentation / manuals - Clamping devices / stops for workpieces to be measured Probes: - 3 x stylus holder HP-TM-SF - 1 x stylus holder HP-TM LF - 2 x stylus Ø1 x 10 - 2 x stylus Ø2 x 12 - 1 x stylus Ø3 x 20 - 2 x stylus Ø1.5 x 20 - 1 x stylus Ø2 x 20 - 1 x stylus Ø2 x 10 - 1 x stylus Ø3 x 10 - 1 x disc stylus Ø6 x 1.2 x 10 - 3 x extension Ø3 x 10 - 1 x extension Ø3 x 20 - 1 x angle piece (individually adjustable) - 1 x stylus rack for holding 4 styli Dimensions & weight: - Installation dimensions (L x W x H) approx.: 705 x 986 x 890 mm - Weight approx.: 170 kg ℹ️ If you have any questions or wish to arrange an inspection, please contact us. ⚠️ Additional notes: ► The goods are sold under exclusion of any warranty ► Technical data subject to change ► Prior sale reserved ❗ Sale to businesses only ❗

Condition: used, Year of construction: 2006, functionality: fully functional, measuring range X-axis: 900 mm, measuring range Y-axis: 1,600 mm, measuring range Z-axis: 800 mm, Immediately available. Delivery (nationwide) within a maximum of 7 days after order. General machine data: Machine type: Crysta Apex C9168 Year of manufacture: Mid-2006 Manufacturer: Mitutoyo Measuring range: 900 x 1600 x 800 mm Control unit: UC-200H Fjdpfjxc Ia Uex Afpsgh Operating manual: Included Hardware and software equipment: Computer/CPU: Demo unit/new Monitor: Demo unit Printer: Demo unit Software: Latest Mitutoyo software MCosmos-1 Geopak-WIN Accessories: Probe head mount: Renishaw PH10MQ Probe head: Renishaw TP200 Additional accessories: Ceramic calibration sphere, various probe styli and extensions, Renishaw change rack 1 x SCR-200 incl. 5 x TP-200 modules This Mitutoyo Crysta-Apex C9168 from mid-2006 is designed for a wide range of measuring applications. Equipped with modern hardware and the latest software from Mitutoyo, it offers high precision and reliability. The comprehensive accessories, including the Renishaw probe head and calibration sphere, enable diverse measurement tasks. Kneissl Messtechnik GmbH is a trusted partner of Mitutoyo. Thanks to our close collaboration, we can respond individually to customer requirements and make specific adaptations to the Mitutoyo Crysta-Apex C9168.

Condition: used, For sale is a high-quality 3D CNC coordinate measuring machine from the renowned manufacturer Werth Messtechnik – model Scope-Check 650×750×500/MB/Z. This device stands out for its precision, reliability, and versatility in industrial metrology. Features & Equipment: - CNC-controlled 3D coordinate measuring machine - Multi-sensor capable (optical and tactile measurements possible) - Moving-bridge design (MB/Z) for high stability and flexibility - High precision measurement of complex workpieces - Robust construction, designed for continuous industrial use - Suitable for quality control, production monitoring, and R&D applications Additional Equipment – Renishaw TP200 Probe System: The high-precision, touch-trigger Renishaw TP200 probe is ideal for workpieces with tight tolerances and complex geometries. It allows for quick probe change-outs and precise measurements even with long probe styli. Key Features: - Strain gauge technology: Minimizes deflections are registered with high accuracy; typical errors such as “lobing” are avoided - High precision: Repeatability up to 0.4 μm, 2D probing uncertainty ±0.8 μm - Fast changeover: Automatic probe change with SCR200 rack, no recalibration required - Durability: Probe module lifetime exceeds 10 million triggerings - Flexibility: Standard- (SF) and low-force (LF) modules for sensitive materials - Compatibility: Usable with Renishaw PH10 probe heads and extensions up to 300 mm Fgodpfxsxcwxgj Afpjh Technical Specifications (excerpt): - Connection: M8 connector, PI200 interface - Probing directions: 6-way (+X, -X, +Y, -Y, +Z, -Z) - Probing force XY: 0.02 N, Z: 0.07 N - Overtravel force XY: up to 0.4 N, Z: up to 4.9 N - Weight (sensor + module): 22 g - Stylus threads: M2 Technical Data: - Manufacturer: Werth Messtechnik - Model: Scope-Check 650×750×500/MB/Z - Measuring range: X = 650 mm, Y = 750 mm, Z = 500 mm - Supply voltage: 115–230 V AC - Power consumption: max. 10 A Scope of Supply: - Werth Scope-Check 650×750×500/MB/Z - Renishaw TP200 probe system including probe modules - Accessories as shown in the attached images Important note: "The table shown in the photos is not included in the sale." (Specifications and technical details subject to change and errors!) We are happy to answer further questions by phone.

Condition: like new (used), Year of construction: 2024, Equipment: type plate available, The device is less than one year old. Sale is from the current location, transportation must be arranged by the buyer. Sale excludes any form of warranty and is only to commercial buyers. The purchasing company must sign a purchase contract and provide proof of its beneficial owners; the authorized signatory must complete Postident verification. Fjdpfoxckv Sex Afpsgh

Condition: like new (used), Year of construction: 2025, operating hours: 30 h, functionality: fully functional, measuring range X-axis: 800 mm, measuring range Y-axis: 800 mm, measuring range Z-axis: 500 mm, workpiece weight (max.): 100 kg, warranty duration: 12 months, type of input current: AC, input voltage: 230 V, compressed air connection: 6 bar, Equipment: documentation/manual, type plate available, High-Precision Reference Measuring Center – Mahr OMS 800/500 HA Multisensor Coordinate Measuring Center with Extended Z-Axis Measuring Range Factory overhauled and modernized in 2025 – ready for immediate use. Fgedpfoxbyxyex Afpsh Technical Data Measuring range: 800 × 800 × 500 mm Sensors: - Optical sensor: Camera & laser (active measurement) - Renishaw TP200 touch probe (other options: TP20, SP25, etc.) - Camera system with 10x objective (optional: 1x, 5x, 20x) - 3D multisensor head MSH with transmitted light, incident light, laser & probe mount Software: OptiCheck3D 2025 – user-friendly, interactive programming Evaluation station: High-performance PC with Windows 11 Professional (64bit) Accuracy: - Length measurement uncertainty: E1 = 0.9 + L/600 µm - E3 = 1.9 + L/400 µm (L in mm) - Scale resolution: 0.1 µm Dimensions / Weight: - Size: 2360 × 1940 × 3300 mm - Weight: approx. 8090 kg - Max. workpiece weight: 50 kg (glass), 100 kg (granite), extendable - Traverse speed: max. 200 mm/s Device Details Model: Mahr MarVision OMS 800/500 HA CNC Design: High-precision, air-bearing multisensor measuring center Special feature: Active vibration damping (BILZ Bi Air) Condition: From laboratory use in precision measurement room, factory-refurbished in 2024 New price of comparable equipment: from approx. €650,000 Delivery time: approx. 4 weeks from order Highlights - Leasing option: 0% interest, without bank transaction - Factory overhaul 01/2024 with warranty & guarantee - Live demo: Available online or on-site - Optional service package: Worldwide transport, commissioning, calibration/certification, training, user instruction - 18 months free: Software update service & hotline support - Software: Full license OptiCheck3D (no subscription fees) - Remote service: Online board support directly at the measuring device - Custom modifications & retrofits on request - Latest 64-bit CNC controller & evaluation station (Windows 10/11) Supply & Environment - Compressed air: 6 bar ±0.1 bar (filtered, ISO 8573-1, consumption approx. 160 Nl/min) - Voltage: 115/230 V ±10%, 50/60 Hz ±5%, 2500 VA Environment: - Temperature: 20 °C ±1 K - Humidity: 40–70% RH - Vibrations: < 5 µm amplitude at < 5 Hz Service & Demo - Online demos available at short notice - Optional on-site demonstration at customer location

Condition: used, Year of construction: 2003, functionality: fully functional, measuring range X-axis: 500 mm, measuring range Y-axis: 500 mm, measuring range Z-axis: 400 mm, Reliability at the highest level – for precise measurement results from day one. This used 3D coordinate measuring machine from Mitutoyo impresses with proven technology, a compact design, and exceptional precision – ideal for small to medium-sized measurement tasks in industrial and quality assurance applications. With the Kneissl Approved Guarantee, you receive a machine that has been thoroughly tested, documented, and supplied with a 6-month warranty – allowing you to measure worry-free from the very first day. ✅ Kneissl Approved – Your Guarantee of Certified Quality • Officially recommended by Mitutoyo Only machines with documented maintenance and known service history • Inspected by former Mitutoyo technicians Over 35 years of experience – each machine is inspected more thoroughly than any standard requires • 6 months warranty included On all inspected components and functions – for maximum investment security 🔍 Technical Data General Information: • Manufacturer: Mitutoyo • Model: Crysta-Apex C544 • Year: 2003 Measuring Range: • X-axis: 500 mm • Y-axis: 400 mm • Z-axis: 400 mm Control & Software: • Control unit: UC-200 • Software: MCOSMOS-1 V4.1 (latest version installed) Probing System: • Probe mount: PH-6M (upgradeable to PH-10M) • Probe: TP-200 • Change rack: SCR-200 including 1x TP-200 module 🛠 Condition & Delivery As part of the Kneissl Approved inspection, this machine has been tested and refurbished according to the following criteria: Electronics & boards – tested for thermal stress and functionality Air bearings & guideways – checked and, if necessary, relapped Mechanics, control unit & software – in technically flawless condition 📦 Scope of Supply Fgjdpfx Afoxbr Nqspjh • Mitutoyo Crysta-Apex C544 • UC-200 control unit • MCOSMOS-1 Software (V4.1) • PH-6M probing system with TP-200 & SCR-200 (including 1 module) • Test report & Kneissl Approved certificate • 6-month warranty 💡 Your Advantage with Kneissl: Don’t just buy any used machine – rely on certified precision with documented provenance and expert inspection. → Enquire now and measure worry-free.
