Condition: ready for operation (used), Year of construction: 2012, operating hours: 6,542 h, spindle motor power: 24,000 W, spindle speed (max.): 5,000 rpm, overall weight: 9,500 kg, number of axes: 11, This 11s TRAUB TNX 65/42 was manufactured in 2012. It features a maximum turning diameter of 175 mm and a turning length of 650 mm. The machine is equipped with a powerful main spindle speed of up to 5,000 rpm and a counter spindle speed of up to 7,000 rpm. If you are looking to get high-quality turning and milling capabilities, consider the TRAUB TNX 65/42 turn-mill centre we have for sale. Contact us for further details. • Working hours: 26,946 h • Max. turning diameter: 175 mm • Max. turning length: 650 mm • Main spindle bar capacity / bore: 65 mm • Max. spindle torque: 275 Nm • Counter spindle speed: up to 7,000 rpm • Counter spindle bar capacity: 42 mm • Tool turrets: 3 × 10 positions • Rapid traverse X-axis: 30 m/min • Rapid traverse Z-axis: 40 m/min Iodez Dk Riepfx Aqcstl • Rated power: 83 kW • Connected load: 68 kVA • Power supply: 400 V, 3~, N, PE, 50 Hz • Rated current: 134 A Technical Specification Counter Spindle Yes Driven Tools Yes

Condition: good (used), Year of construction: 2012, CNC Turning / Millingcenter Machine type: DMG CTX beta 500 V6 Control: Siemens 840 D Year: 2012 Working hours: 42.067 h Spindle running time: 20.209 h SPECIFICATIONS Max. turning length: 500 mm Turningdiameter: 410 mm Max. swing over bed: 700 mm Spindle bore: 87 mm Bar capacity: 77 mm C-Axis: 0,01° Main Spindle: ISM 76 Spindle speeds: 25 - 5.000 rpm Spindle power: 25 / 34 kW Torque: 280 Nm Subspindle: ISM 52 Travel Y-Axis: mm Amount of turrets: 1 Tool: VDI 40 Driven Tools: 12 revolution driven tools: 4.000 drive power driven tools : 11,3 kW Itsdpfsz Dkuhsx Aqcol Equipment Chip conveyor Short Bar Loader: LNS QLS 80 S2

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, Turning / milling center with counter spindle with 10 CNC axes (X1, X2, Z1, Z2, Y1, Y2, B1, B2, C1, C2) Control: FANUC 31:iA Main Spindle Power: 15/11 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Counter Spindle Power: 11/7,5 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Turning and milling spindle Power: 7,5/3,7 kW Turning and milling spindle speed: 12.000 min-1 max. rotation length turret bottom: 1.005 mm Slide cross X1 / X2 / Z1 / Z2 / B2: 455 / 222,5 /1.090 / 1.005 / 1.008 mm Slide cross Y1 / Y2: +/- 70 / +20, -50 mm Swivel range B1 axis: +/- 95 ° Linear rack magazine incl. support robot CNC support steady rest Coolant cyclone filter system incl. 2 pcs. coolant pumping spindle oil cooler Itodpfx Aez Digvoqcel

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, Niles N 40 MC - 6000 Turning/Milling Center, year of manufacture 2019, Siemens SI 840 D SL control, X/Z 850/6820 mm, Y axis -200 / +400 mm, B axis 0.001°, B axis swivel range -105° / +95°, tool changer with 192 positions, C axis main spindle 0.001°, spindle speed up to 1750 rpm, 2 gear stages, max. workpiece weight between chuck and tailstock 6,000 kg, drive power 87 kW, HSK 100 interface, steady rest 70 - 425 mm, tailstock. Iedpfx Aqsz Dgw Sjcetl

Condition: good (used), Year of construction: 2008, functionality: fully functional, Weiler DZ 40, Year of manufacture: 2008, Siemens 840 D control, Travel X/Z: 200/350 mm, Turning diameter: 180 mm, Max. swing diameter: 560 mm, Y-axis: +/-25 mm, Q-axis / programmable tailstock, Q-axis travel: 360 mm, Q-axis measuring system: rotary, Tailstock: MK 4, Ijdpoz Dgvnjfx Aqcotl Main spindle max. bar capacity: 42 mm, Spindle bore: 52 mm, Rapid traverse X/Z/Q: 30/30/20 m/min, Turret: 16 stations – all driven, VDI 25, Shank diameter: 25 mm, Driven tools up to 4,500 rpm, Parts catcher, Accessories, Driven tool holders, Fixed holders,

Condition: good (used), Year of construction: 2004, functionality: fully functional, CNC turning and milling center with 9 CNC axes, Okuma MacTurn 350 W, Year of manufacture 2004, OSP-E 100L, Additional magazine, Magazine with 80 tool positions, Main spindle with C-axis, Counter spindle with C-axis, Y-axis slide at the top / milling spindle, HSK 63 tool holder, Stepless B-axis as milling spindle, Distance between centers 1500 mm, Spindle bore 80 mm, Max. turning diameter 550 mm, Turning diameter 350 mm, Turret at the bottom with 12 tool positions and driven tools, Interlite compact filter system 900 l, Extraction system, Spindle operating time approximately 18,300 hours, Chip conveyor, Tool changer gripper arm completely renewed, High-pressure coolant, Coordinate measuring machine (CMM) measuring arm, Tool changer overhauled, Iedsz Dgudepfx Aqcjtl Main spindle Kitagawa B - 210, Counter spindle Kitagawa B - 208.

Condition: used, Year of construction: 2012, turning diameter max. 356 mm turning length 1.255 mm control M 730 BM MAPPS IV greates pass round over bed 920 mm Swing dia. over traverse guideway 742 mm distance between spindles 1.511 mm turning speed range - main spindle 4.000 min/-1 power capacity - main spindel 18,5 / 15 kW spindle nose JIS A2-8 spindle bore 91 mm max. bar capacity 80 mm Spindle speed range subspindle 6.000 min/-1 power capacity - Sub spindle 11 / 7,5 kW spindle bore 43 mm x-travel 260 mm z-travel 1.345 mm Y - Axis +/-50 mm rapid traverse ( X / Y / Z ) 30 / 10 / 30 m/min number of toolpositions 12 pos. Schank height for square tool 25 mm Drill shank diameter 50 mm Itedpfx Asz Dbqtjqcol turret change time 0,27 sec. Spindle speed - driven tools max. 6.000 min -1 power capacity - driven tools 5,5 / 3,7 kW total power requirement 50 kVA weight of the machine ca. 7,8 t dimensions of the machine ca. 6,0 x 3,0 x 2,3 m CNC - Turning- and MillingCenter DMG MORI SEIKI - NLX 2500 SY / 1250 - Subspindle

Condition: ready for operation (used), Year of construction: 2006, travel distance X-axis: 260 mm, travel distance Z-axis: 795 mm, overall weight: 6,100 kg, number of axes: 4, This 4-axis DMG Mori Seiki NL2500Y/700 was manufactured in 2006. It features a robust control unit, MORI SEIKI MSX-850, and includes an integrated mist extraction unit, chip conveyor, tailstock, turret, and tool setter. With a mass of 6100 kg, this turn-mill centre is designed for high-performance machining. If you are looking to get high-quality turning and milling capabilities, consider the DMG Mori Seiki NL2500Y/700 machine we have for sale. Contact us for further details. Itodpfx Aoz A Uz Noqcjl - Phase: 3- Frequency: 50 Hz- Voltage: AC 200 V- Full Load Current: 113 A- Current Rating of the Spindle Motor: 140 A- Interrupting Capacity: 5 kA- Short Circuit Rating: 1 kA- Rated Power: 39 kVA- Mass of Machine: 6100 kg- Control Unit: MORI SEIKI MSX-850- Additional Equipment / Attachments: Integrated mist extraction unit (SARA UC1 SDIV), chip conveyor / chute integration, tailstock, turret, tool setter / probe arm Technical Specification Counter Spindle No Driven Tools Yes

Condition: ready for operation (used), Year of construction: 2000, travel distance X-axis: 260 mm, travel distance Z-axis: 600 mm, controller manufacturer: SIEMENS, controller model: SINUMERIK, number of axes: 5, This 5-axis Monforts DNC 5 was manufactured in 2000. It features a twin-spindle configuration with dual tool turrets, enhancing productivity and efficiency. The machine includes an integrated chip conveyor for effective chip management and a mounted top extraction system for optimal air filtration. If you are looking to get high-quality turning capabilities, consider the Monforts DNC 5 turn-mill centre we have for sale. Contact us for further details. Itedpjz A Utlsfx Aqcol - Control Unit: SIEMENS SINUMERIK- Machine Configuration: Twin-spindle / Dual-chuck CNC Lathe with dual tool turrets and central partition wall Technical Specification Counter Spindle Yes Driven Tools Yes

Condition: good (used), Year of construction: 2023, functionality: fully functional, The machine is in good technical condition, testing can be arranged by prior agreement. Ijdpsz A T Hkofx Aqcstl

Condition: used, Year of construction: 2011, functionality: fully functional, turning length: 810 mm, turning diameter: 320 mm, spindle speed (max.): 5,000 rpm, spindle bore: 73 mm, rotational speed (max.): 5,000 rpm, bar passage: 65 mm, bar diameter (max.): 65 mm, We offer this used Mori Seiki NZ2000 CNC turning and milling center, manufactured in 2011. Fully automated twin-spindle production cell with FANUC robot, PROMOT Automation, and TOP XF380 bar feeder. Year of manufacture: 2011 For sale is a MORI SEIKI NZ2000 T2 CNC turning machine as a complete, automated production cell with PROMOT Automation, FANUC industrial robot, and TOP Automazioni XF380 bar feeder. This system is particularly notable for its exceptional automation concept, of which there are only two in Europe. The combination of main spindle, counter-spindle, two turrets, bar feeder, and robot automation allows different machining and material flow processes to be automated within a single system. The main spindle is supplied with bar material via the TOP Automazioni XF380 bar feeder. The bar capacity of the machine is 65 mm. Finished parts can be ejected on this side via the existing parts ejector. Simultaneously, the FANUC industrial robot with PROMOT Automation handles the automated workpiece handling on the counter-spindle side. The workpieces are placed on or removed from a rotary table with multiple workpiece holders. This enables highly productive simultaneous machining on the main and counter-spindle. The system thus combines practically two automated machining processes within a single production cell. Equipment / Highlights  MORI SEIKI NZ2000 T2  Year of manufacture 2011  Main and counter-spindle  2 turrets  Simultaneous machining capabilities  Driven tools Itjdpfxoz A S Uyj Aqcjl  TOP Automazioni XF380 bar feeder, year of manufacture 2011  Bar capacity MORI SEIKI NZ2000 T2: 65 mm  Automatic material feed via bar material  Parts ejector on the main spindle side  PROMOT Automation robot cell, year of manufacture 2011  FANUC industrial robot  Automatic loading and unloading on the counter-spindle side  Rotary table / workpiece storage with multiple workpiece holders  Integrated safety device and protective enclosure  Fully integrated and coordinated production cell Technical data  Max. turning diameter: approx. 320 mm  Max. turning length: approx. 810 mm  Bar capacity MORI SEIKI NZ2000 T2: 65 mm  Spindle bore: approx. 73 mm  Max. spindle speed main and counter-spindle: up to 5,000 rpm  2 tool turrets  Driven tools  C-axis on main and counter-spindle  Design without Y-axis  Simultaneous machining on main and counter-spindle  TOP Automazioni XF380 bar feeder, year of manufacture 03/2011  Bar capacity of the entire system: up to 65 mm round material, limited by the particularity of the system. In contrast to a conventional NZ2000 T2, this is not simply a CNC turning machine with a robot added later. The system was designed as a complete, automated manufacturing cell. Bar machining and robot handling can be combined within the same machine. While one side performs machining of bar material via the main spindle, the counter-spindle side can be automatically loaded and unloaded via the FANUC robot. This concept enables high machine utilization and is particularly suitable for series production and low-manned or automated production operations. If you have any questions or require further information, please feel free to send us a message or call us.

Condition: used, Year of construction: 1989, functionality: fully functional, overall weight: 5,000 kg, We offer this used Mazak ST 35 ATC MC CNC turning and milling center, manufactured in 1989. CNC lathe, brand MAZAK, model ST 35, manufactured in 1989, self-weight of 5 tons, equipped with a MAZATROL model T32-3 control, a KITAGAWA brand chuck, model B-12A0815 with a maximum pressure of 327 PSI, a KITAGAWA brand hydraulic cylinder, model F2078HS15A with a maximum speed of 3,000 rpm, as well as an automatic chip removal system, all accompanied by various manuals. Voltage: 220 V Frequency: 60 Hz Spindle power (rated): 26 hp Spindle power (continuous): 30 hp Machine serial number: 83298 Electrical diagram number: 112AAWA Main motor current: 102 A Full load current: 44 A Main switch current: 13/10 A Model: ST 35 ATC MC Serial number: 83496 Date of manufacture: June 1989 Weight: 5000 kg Isdpfx Aqsz A Incscotl If you have any questions or need more information, please do not hesitate to send us a message or call us.

Condition: ready for operation (used), Year of construction: 2009, operating hours: 15,600 h, functionality: fully functional, machine/vehicle number: 216615, turning length: 995 mm, turning diameter over cross slide: 660 mm, turning diameter: 660 mm, spindle motor power: 22 W, spindle speed (max.): 12,000 rpm, travel distance X-axis: 580 mm, travel distance Y-axis: 160 mm, travel distance Z-axis: 1,045 mm, milling spindle length: 30 mm, rotational speed (max.): 5,000 rpm, rotational speed (min.): 35 rpm, feed length X-axis: 580 mm, feed length Y-axis: 160 mm, feed length Z-axis: 1,045 mm, torque: 468 Nm, bar passage: 76 mm, total height: 2,500 mm, total length: 7,000 mm, total width: 2,000 mm, distance table center to spindle nose: 1,234 mm, overall weight: 9,760 kg, spindle diameter: 76 mm, feed force X-axis: 38 N, feed force Y-axis: 26 N, feed force Z-axis: 38 N, Equipment: documentation/manual, rotational speed infinitely variable, MAZAK INTEGREX 200-IV / 200-IVS Chuck size: 8 inches Max. swing diameter: Ø 660 mm Max. machining diameter: Ø 660 mm Max. machining length: 995 mm Max. bar capacity: up to Ø 65 mm Main spindle: Spindle speed: 35–5,000 rpm Main spindle motor power: 22 kW Spindle bore diameter: Ø 76 mm Iodpfxoz A Huhs Aqcetl Milling spindle: Spindle speed: 15–12,000 rpm Milling spindle motor power: 18.5 kW Max. torque of the milling spindle: 119 Nm Max. milling tool size: Ø 125 × 300 mm Travel ranges: X-axis: 580 mm Z-axis: 1,045 mm Y-axis: 160 mm

Condition: like new (used), Year of construction: 2026, functionality: fully functional, We offer you: CNC turning and milling center with robotic automation Ijdpfxez A Ay Ts Aqcotl Manufacturer: DMG MORI Type: CLX 450 TC Year of construction: 2026 Control system: Celos X with Siemens Sinumerik One Technical data: Max. turning diameter: 400 mm Turning length: 1100 mm Bar capacity: max. 65 mm Travel paths: X-axis travel: 276 mm Z1-axis travel: 755 mm Z3-axis travel: 775 mm Y-axis travel: +/- 100 mm B-axis travel: +/- 120° Main spindle: Speed: 5,000 rpm Drive power: 14/17 kW Max. torque: 275/345 Nm Counter spindle: Speed: 5,000 rpm Drive power: 14/17 kW Max. torque: 275/345 Nm Milling spindle: Speed: 0 – 12,000 rpm Drive power: 8.8/10.5 kW Tool interface: HSK-T 63 Tool changer: 60 positions Max. torque: 73/90 Nm Internal clamping device: Ø 67 mm Operating hours: approx. 1,130 h Spindle hours: approx. 280 h Technical features & accessories: - Absolute, direct linear scales in the X and Y axes - Double-circuit filter - Counter spindle ISM 65, A2-8, C-axis and hydraulic spindle brake - Hinged belt chip conveyor, incl. coolant tank - Chuck flushing device on the outside for the main and counter spindle - Coolant supply through the counter spindle - Coolant spray gun - Screen cleaning for the safety shield - Electronic handwheel (if available) - Alternating speed - Signal light, 4-color - Automatic work area door, electric - Electrical interface Robo2Go - Workpiece measuring probe, manufacturer Renishaw RMP40 (if available) - Tool measuring device, manufacturer Renishaw RP1 (if available) - Function for drill breakage detection for Renishaw RP1 - Linear scale for Z1-axis - Differential pressure monitoring 2.0 on the main and counter spindle - Tailstock function for the counter spindle, incl. foot switch - Coolant system 8/40 bar, consisting of: - Coolant tank 600 l - Pump pressure variable 8 – 40 bar - Belt filter system - Lifting pump with level monitoring - Mechanical oil mist separator - Protection Package - Technology cycle with dialogue-guided programming - Technology cycle for parting off the workpiece - 2x 3-jaw chuck, manufacturer Schunk ROTA THW3 265-81 - Loading and unloading system Robo2Go, consisting of: - Module 35 kg - Drawer storage incl. additional drawer - Accessories on request Accessories, tools and clamping devices shown in the pictures are only included in the scope of delivery if this is stated in the additional information. Changes and errors in the technical data and specifications, as well as prior sale, are reserved!

Condition: used, Year of construction: 1999, Technical details: turning diameter: 200 mm turning length: 600 mm capacity X-axis: 190 mm capacity Z-axis: 555 mm double spindle units: spindle distance: 800 mm spindle drive: Links (40/100%ED): 18/14 kW spindle turning speed range: 31-6300 U/min Itedpfxjz A Ands Aqcel spindle drive: Rechts (40/100%ED): 18/14 kW spindle turning speed range: 31-6300 U/min speeds of tool: 2x12 Werkzeuge: 7/5 KW, 40-4200 U/min dimensions of the machine ca.: 5,032 x 3,048 x 2,445 m weight of the machine ca.: 6500 Kg Gildemeister MF Twin 65-II lathe with loading automation. This machine is suitable as a counter spindle machine for 4-axis machining on the main and counter spindles, complete machining (turning, drilling, milling, Y-axis, B-axis) of bar and shaft parts. *

Condition: good (used), Year of construction: 2011, turning length: 225 mm, turning diameter: 260 mm, travel distance X-axis: 170 mm, travel distance Z-axis: 335 mm, There are 2 more machines of the same design with identical equipment. Machine type: CNC lathe Manufacturer: Hwacheon Type: Cutex-160A MC Year of construction: 11/2011 Control: Fanuc 0i-TD Country of origin: Korea Delivery time: ex-stock >>Powered tools >>Turning and milling spindle >>Including tailstock >>Including bar loader magazine >>High productivity This CNC lathe is in good condition. Thanks to the basic and additional equipment, the machine has short indexing times for the turret and a high rapid traverse speed. The 3-axis machining and the additional turning and milling spindle allow workpieces to be processed in a versatile and efficient manner. The additional tailstock and the associated short bar loader magazine increase the productivity of the manufacturing process. An economically effective used machine for series production. Machine equipment Chip conveyor for side mounting and chip bucket Short bar loader magazine Interface for bar feeding device Workpiece collection tray (parts catcher) Ijdpfx Asz Azxwjqcetl Turning and milling spindle Confirmation switch for chuck (open/close) C-axis indexing Powered tools Tailstock, adjustable Linear guides Technical data Performance Swinging diameter over bed: 550 mm Max. turning diameter: 260 mm Max. turning length: 225 mm Chuck size: 6" Spindle Spindle nose (ASA): A2-5 Max. spindle speed: 6000 rpm Spindle bore Ø: 56 mm Max. bar diameter: 45 mm Spindle motor: 15/7.5 kW Turret Turret number of stations: 12 positions Turret indexing time (s/stations): 0.15 Feed rates Rapid traverse X-axis: 36 m/min Rapid traverse Z-axis: 36 m/min Max. travel X-axis: 170 mm Max. travel Z-axis: 335 mm Feed motor X/Z: 3.0/1.8 kW Tailstock Arbor diameter: 60 mm Arbor stroke: 80 mm Taper bore/tailstock mounting: 4 MK Turning-milling spindle Spindle motor 3.7/2.2 kW Max. spindle speed: 5000 rpm Bar loader magazine Manufacturer: Fedek Machine Co. Type: DH-65 Min./max. bar length: 280/1200 mm Bar diameter: 5-65 mm Dimensions L x W x H: approx. 1620 x 620 (1200) x 1400 mm

Condition: used, Year of construction: 2008, turning diameter 600 mm turning length 1.045 mm control MSX - 711 III MAPPS III swing diameter over support 600 mm distance between spindles 1.255 mm max. bar capacity 65 mm turning speed range - main spindle max. 5.000 min/-1 power capacity - main spindel 25 / 22 kW no. of turning speeds 2 spindle nose JIS A2-6 spindle bore 73 mm Itedpfx Aqoz At T Hjcol C-Axis 0,0001 ° internal diameter 120 mm chucking diameter 200 mm Speed range Tool Spindle max. 12.000 min/-1 Power rating Tool Spindle 5,5 / 3,7 kW tool taper Capto C5 internal diameter 65 mm B - Axis 0,0001 ° swivellable +/- 120 ° x-axis 685 (610 + 75) mm y-axis +/- 125 mm z-axis 1 mm number of toolpositions 12 pos. Shank height for square tool 20 mm Drill shank diameter max. 32 mm tools in tool magazin 40 pos. max. tool diameter 70 mm max. tool-dia with free toolbox 125 mm max. tool length 300 mm max. tool weight 4 kg change-time tool to tool 1,25 sec Rapid traverse X / Z: 50 m/min Rapid traverse Y: 30 m/min Rapid traverse X2 / Z2: 30 m/min total power requirement 88 kVA weight of the machine ca. 16,5 t dimensions of the machine ca. 6,0 x 4,0 x 3,0 m High-Precision 5 Achsen CNC-Turning- and Millingcenter MORI SEIKI - NT 3200 DCG / 1000 SZ - 5 Axis - Swivable Milling-Head (B-Axis) - Subspindle - lower turret - approx. 11,300 power-on hours - approx. 9,200 spindle hours

Condition: good (used), Year of construction: 2005, operating hours: 4,630 h, turning length: 1,585 mm, spindle motor power: 30,000 W, spindle speed (max.): 3,300 rpm, spindle bore: 102 mm, travel distance X-axis: 630 mm, travel distance Y-axis: 115 mm, travel distance Z-axis: 1,585 mm, total height: 2,800 mm, total length: 7,000 mm, total width: 2,700 mm, overall weight: 14,500 kg, Multi-tasking lathe MAZAK - INTEGREX 400 III-S MACH-ID 9809 Make: MAZAK Type: INTEGREX 400 III-S Control: MAZATROL 640 MT PRO Year: 2005 Only 4630 Cutting hours Automatic door 40 CAPTCO C6-Tool magazin Robot interface 5 Axis simulteneous package Sub spindel with C-Axis and 0,0001 Degree Internal Grundfos 15 Bar coolant Chip conveyor Optional tooling package with 40 holders Max. turning Ø: 850mm Itsdpoz Ata Hsfx Aqcol X-Axis: 630mm Y-Axis: -115 to + 115mm Z-Axis: 1585mm B Axis: -30 to +195° Spindle bore: 102mm Speedrange: 3300Rpm Spindle power: 30kW Subspindle speeds:3300Rpm Subspindle bore: 102mm Subspindle power: 26kW ATC / revolver: 40 B-Axis Toolsystem:Capto C6 B-Axis Speedranges:12000Rpm B-Axis power: 19kW Chip conveyor: Yes Tool eye: Yes Hours: 4630H Length: 7000mm Width: 2700mm Height: 2800mm Weight: 14500kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: excellent (used), Year of construction: 2010, functionality: fully functional, turning length: 1,045 mm, spindle motor power: 18,500 W, spindle speed (max.): 6,000 rpm, spindle bore: 82 mm, travel distance X-axis: 580 mm, travel distance Y-axis: 580 mm, travel distance Z-axis: 1,045 mm, total height: 2,900 mm, total length: 4,500 mm, total width: 2,400 mm, overall weight: 9,200 kg, Multi-tasking lathe MAZAK - INTEGREX 200-4 S MACH-ID 9810 Make: MAZAK Type: INTEGREX 200-4 S Control: MAZATROL MATRIX Year: 2010 The Mazak INTEGREX 200-IV S is a multi-tasking CNC turning and milling center with a second/sub-spindle. The “S” indicates the sub-spindle, allowing complete machining of both sides of a workpiece in a single setup. Typical specifications include a maximum machining diameter of approximately 660 mm, a machining length of around 995 mm, and X/Y/Z travels of approximately 580 / 160 / 1,045 mm. The machine features a B-axis milling head, a main spindle and sub-spindle up to approximately 5,000 rpm, and a milling spindle typically capable of 12,000 rpm. It normally uses Capto C6 tooling and is often equipped with a 40-position automatic tool changer. Machines manufactured around 2006–2010 are commonly equipped with the Mazatrol Matrix CNC control. The INTEGREX 200-IV S is designed for complete machining of complex components, combining turning, milling, drilling, tapping and 5-axis positioning in one machine. This significantly reduces the number of setups and eliminates the need to move components between separate turning and milling machines. Max. turning Ø: 660mm X-Axis: 580mm Y-Axis: 160mm Z-Axis: 1045mm B Axis: 225° Spindle bore: 82mm Speedrange: 5000Rpm Iodpfsz Ar Ucox Aqcjtl Spindle power: 18.5kW Subspindle speeds:6000Rpm Subspindle bore: 82mm Subspindle power:18.5kW ATC / revolver: 80 Speed live tools:12.000Rpm Length: 4500mm Width: 2400mm Height: 2900mm Weight: 9200kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: excellent (used), Year of construction: 2007, operating hours: 5,500 h, functionality: fully functional, turning length: 1,545 mm, spindle motor power: 22,000 W, spindle speed (max.): 5,000 rpm, spindle bore: 65 mm, travel distance X-axis: 580 mm, travel distance Y-axis: 160 mm, travel distance Z-axis: 1,545 mm, total height: 2,600 mm, total length: 5,200 mm, total width: 2,550 mm, overall weight: 14,000 kg, Equipment: documentation/manual, Multi-Tasking Machining in a Single Machine Setup Sub spindle for overtaking with full C-Axis 0,001 Degrees Iedsz Ar R Dspfx Aqcetl 5500 Cutting hours ! The INTEGREX IV series can finish all machining processes. High speed, advanced milling spindle that can tilt up to 240 degrees swiveling. Lower turret with rotary tool spindle so livew tooling Chip conveyor with coolant and 15 Bar iKZ Double chuck KNCS-N 210-53 SMW Autoblock MAZAK Flex -GL150F Gantry Loader Gripping range 200 x 120 length x 15 Kg Max. turning Ø: 660mm X-Axis: 580mm Y-Axis: 160mm Z-Axis: 1545mm B Axis: 270° Spindle bore: 65mm Speedrange: 5000Rpm Spindle power: 22kW Subspindle speeds:5000Rpm Subspindle bore: 65mm Subspindle power: 18.5kW ATC / revolver: 40 B-Axis Toolsystem:Capto C6 B-Axis Speedranges:12000Rpm Length: 5200mm Width: 2550mm Height: 2600mm Weight: 14000kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: excellent (used), Year of construction: 2007, functionality: fully functional, Swing over bed 755mm, swing over crosslide 740mm, max turning diam 366mm, max turning lenght 785mm.Live tooling, C-axis. X 260mm, Y 100mm, Z 795mm Y , Control MXS 850 III. Itjdpjz Arxujfx Aqcol

Condition: used, Year of construction: 2011, Citizen Miyano ABX-64SY Fixed Headstock Lathe 9 Axis Machine with Fanuc Series 31i Model A CNC Control, Twin Spindle Hainbuch Collet Chucks, Twin 12 Position Tool Turrets All Driven, Max Work Piece Diameter 64mm, Main Spindle 40 - 4000rpm, Sub Spindle 50 - 5000rpm, Parts Catcher & Conveyor, Yoshida Swarf Conveyor. S/No. 4SSY0135 (2011) 9,300kg, Iemca Master 865 Verso 5 Meter Barfeed. S/No. 02111465A03 (2011). Country of Origin: Japan, (2) x Boxes of Driven & Static Tooling for ABX64. Country of Origin: Italy Itedpfx Aqoz Arp Hocjl Location: These lots are located in Biggleswade, UK. Unfortunately, there are no loading facilities on-site, dismantling and loading will be at the cost of the purchaser

Condition: used, Year of construction: 2017, Citizen Miyano BNA-42MSY2 Fixed Headstock Lathe 7 Axis Machine with Cincom/Citizen CNC Control, Twin Spindle Collet Chucks, 8 Position Tool Turret all Driven, Max Work Piece Diameter 42mm, Main Spindle Speed 50 - 5000rpm, Sub Spindle 50 - 5000rpm, Parts Catcher & Conveyor, LNS Turbo MH500 Swarf Conveyor. S/No. DL0110 (08/2017) 3000kg, Iemca Boss 552-HD 5 meter Barfeed. S/No. 021805GA03 (2018). Selection of Driven & Static Tooling for BNA42. Country of Origin: Japan Itjdpjz Arncsfx Aqcsl Location: These lots are located in Biggleswade, UK. Unfortunately, there are no loading facilities on-site, dismantling and loading will be at the cost of the purchaser.

Condition: excellent (used), functionality: fully functional, X = 1020 mm Itodpfez Ap R Ujx Aqcjl Y = 510 mm Z = 460 mm ATC 30 Table size: 1200 x 500 mm Machine dimensions: 3000 x 2800 x 2800 mm Machine weight: 7,300 kg

Condition: good (used), MAZAK Lathe Model: QTN 350 MY X 1500 Year: 2008 Control Unit: MATRIX Isdpfjz Apkbox Aqcotl Maximum Turning Diameter (capacity): 720 Machinable Diameter / Standard Machinable Diameter (capacity): 420 Maximum Machinable Length*1 (capacity): 1500 mm Bar Capacity (capacity): 102 Centering Dimensions (main spindle): 315 Spindle Speed (main spindle): 3300 Spindle Nose (main spindle): ASA 11 Spindle Bore (main spindle): 112 Spindle Speed (powered tool spindle): 4000 Travel (tailstock): 1550 Taper (tailstock): CM 5 Main Spindle Motor (continuous / 40% duty) (motors): 37 Kw Coolant Tank (coolant): 400 l
