K+S Rotationstechnik GbR

Condition: good (used), Year of construction: 2010, Bar capacity 50.8mm, maximum cutting diameter 279mm, maximum cutting length 274mm, Spindle power 11Kw, Spindle speed 6,000rpm, 12 station turret, Dcodpjxlch Ssfx Acwen fitted with collet chuck, tool setter and magazine barfeed unit.

Condition: good (used), Year of construction: 2005, The machine is connected and in operation. The gantry loader is connected but not in operation. Control system: FANUC Series 21i-TB. The machine is supplied with tool holders on the turret head, including all accessories available with the machine. The machine does not have a tailstock; it has a main spindle and one turret head. Machine dimensions approx.: Length: 1600 mm, Width: 1280 mm, Height: 1890 mm, Weight: 2800 kg. Djdpfx Aoxiv E Secwocn

Condition: excellent (used), functionality: fully functional, CNC lathe Mori Seiki CL203, year 2000, with tailstock and conveyor, including tooling and documentation Dedpfx Acsxhdzlswecn

Condition: used, functionality: fully functional, Swing diameter over bed: Ø 450 mm Swing diameter over carriage: Ø 280 mm Max. swing diameter: Ø 280 mm Turning length: 450 mm Distance between centers: 450 mm Speed range: stepless variable, approx. 50 – 5000 rpm Turret: 1x 8 tool positions Dcedpfjxg Itvsx Acwsn 1x 12 tool positions Tool system: VDI-30 Travels: X-axis travel: 120 + 25 mm Z-axis travel: 450 mm Rapid traverse: 12 m/min Motors & Electrical: Spindle motor: approx. 5.5 / 7.5 kW (continuous / 30 min) Total connected load: 29 kVA Power supply: 380V, 3-phase, 50 Hz Full load current: 44 A Weight & Dimensions: Machine weight: approx. 4,800 kg Dimensions (L×W×H): 2,985 × 1,720 × 1,850 mm

Condition: used, Year of construction: 2008, Mazak QTN 100IIM CNC Lathe Year of manufacture: 2008 C axis, driven tools Chuck: 170 mm Spindle bore: 51 mm Max turning diameter: 280 mm Max turning length: 334 mm Spindle: 35–6,000 RPM Travels: X - 185 mm Z - 385 mm Main spindle motor: 11 kW Max. torque: 184 Nm Spindle nose: A2–5'' Spindle indexing increments: 0.001° - Tailstock - Parts catcher - Measuring probe - Bar feeder interface - Chip tray with pump - Machine documentation - 10 standard tool holders Dcsdpfx Acexg Iffjwon - 2 driven tool holders 1/1 Weight: 3,800 kg Dimensions (L x W x H): 2.10 x 1.70 x 2.00 m

Condition: used, Year of construction: 1996, functionality: fully functional, machine/vehicle number: 6-030, turning diameter over cross slide: 254 mm, turning length: 500 mm, spindle bore: 70 mm, travel distance X-axis: 180 mm, travel distance Z-axis: 510 mm, overall weight: 4,300 kg, - Year of manufacture: 1996 - First commissioning: 1998 - Single owner, used in our own operation - Fully functional, powered and ready for demonstration - X-axis travel: 180 mm - Z-axis travel: 510 mm - Turning diameter: 254 mm - Turning length: 500 mm - Spindle speed: 3,600 rpm - Spindle bore: 70 mm - Spindle motor power: 15 kW - Control: Siemens 840 C - Chip conveyor - 8-position turret - 3-jaw chuck with hollow clamping cylinder - Fully automatic tool presetter - Dimensions: 2,600 x 1,650 x 1,830 mm – 4,300 kg Dedsxgtvcopfx Acwjcn Net price ex-works Luckenwalde (Germany), excluding transport

Condition: refurbished (used), functionality: fully functional, The machine has been completely overhauled by us, meaning it was fully dismantled and rebuilt. The spindle bearings have been replaced, the geometry has been checked and adjusted, and the accuracy is comparable to a new machine. Technical Data: - DMT KERN CD282 CNC cycle lathe (Made in Germany) - Year of manufacture: 2007 - CNC control: Sinumerik 840Dsl with ShopTurn Accessories / Options: - Frequency-controlled coolant system (electronically adjustable) - USB interface - Workspace extraction system (programmable on/off) - Manual Turn (in addition to CNC capabilities, the machine can also be operated in conventional mode) - Spindle positioning (C-axis) 1x Fixed steady rest 1x Travelling steady rest 1x Tailstock 1x Tool clamping system: Multifix B with one holder 1x 3-jaw chuck 1 set of machine feet Horizontal bed - Hardened and ground prismatic/flat guideways Dodpsxfmptsfx Acwscn Working area - Swing over bed with Multifix B (front): 280 mm - Swing over cross slide: 140 mm - Cross slide travel (facing): 200 mm Main spindle drive - Digital AC motor – 40% duty cycle, 11.5 kW Spindle headstock - Spindle nose: DIN 55027, size 5 - Spindle diameter in front bearing: 75 mm - Spindle bore: 45 mm - Speed range: 1–5000 rpm Cross slide - Transverse feed range: 0.001–1000 mm/rev - Longitudinal feed range: 0.001–2000 mm/rev - Thread pitches: 0.01–999.9 mm - Rapid traverse (transverse/longitudinal): 7/13 m/min - Central automatic lubrication - Digital AC servo motors, transverse and longitudinal Tailstock - Quill diameter: 50 mm - Quill travel: 120 mm - Quill taper: MK 3 - Clamping screw for bed mounting - Eccentric lever for quill clamping Machine weight approx. 1,600 kg Shipping condition: EXW Assistance with loading can be provided. A suitable forklift is available. As is customary with used machines, any warranty (liability for defects) is excluded. All information is provided to the best of our knowledge and belief. Subject to prior sale and errors excepted.

Condition: good (used), Year of construction: 1996, functionality: fully functional, The used TAKISAWA TW 30 CNC 2-axis lathe is a robust and fast numerically controlled lathe with an inclined bed and flat guides, medium-sized and equipped with a FANUC 21-T CNC, year of manufacture 1996 (installed in 1999), CE-compliant. Djdexfinxjpfx Acwjcn Main features: - Max turning diameter over bed: 540 mm - Max machining diameter: 330 mm - Max turning length: 510 mm - Max bar capacity: 75 mm - Spindle nose: ASA 8" - Spindle: max rotational speed 3,250 rpm - Spindle motor power: 15 kW - Turret: 10 stations - Machine weight: 3,800 kg The equipment is completed by a tailstock with programmable quill movement, a 250 mm 3-jaw self-centering chuck, and operation and maintenance manuals.

Condition: used, Year of construction: 2017, operating hours: 1,200 h, functionality: fully functional, turning diameter over cross slide: 256 mm, turning length: 527 mm, spindle bore: 52 mm, spindle speed (max.): 4,800 rpm, Equipment: rotational speed infinitely variable, Description: For sale is a HURCO TM8i VDI CNC lathe with MAX5 single control, year of manufacture 2017, with only approx. 1,200 operating hours. The machine is in excellent condition, has been regularly serviced, and is immediately ready for operation. Ideal for precise turning applications in small and medium-sized batch production. Accessories / Equipment: Dcodpfxoxfgkks Acwsn • Tool presetter • Chip conveyor • Coolant system • Three-jaw chuck • Collet chuck with various collets • Mist extraction unit Condition: • Lightly used (only 1,200 hours) • Regularly serviced • Immediately available • Inspection by appointment possible

Condition: good (used), Year of construction: 2008, functionality: fully functional, Machine type: CNC Turning Machine Manufacturer: Hwacheon Model: Hi-Tech 300 Year of manufacture: 2008 Control: Fanuc 18i-TB Country of origin: Korea Availability: ex-stock Machine Equipment ▪ Chip conveyor ▪ Bar feeder magazine ▪ 3 spindle reduction sleeves ▪ Turning and milling spindle ▪ Driven tools (4 holders installed) ▪ Tailstock with quill ▪ Box guideways ▪ 3-jaw power chuck, 250 mm (Seoam ACE CAH-10) ▪ Full-featured C-axis ▪ Tool setter Technical Specifications Performance ▪ Swing diameter over bed: 600 mm Dsdpsxfbm Hjfx Acwecn ▪ Max. turning diameter: 380 mm ▪ Max. turning length: 1240 mm Spindle ▪ Main spindle power: 22 kW ▪ Main spindle torque: 1030 Nm ▪ Main spindle speed: 3200 rpm ▪ Main spindle chuck diameter: 254 mm ▪ Bar capacity: 76 mm Rapid Traverse ▪ Travel paths X- / Z-axis: 20/--/20 m/min Turret ▪ Tool turret - number of stations: 12 positions ▪ Driven tool speed: 3000 rpm ▪ Drive power: 3.7 kW ▪ Tool system (type): BMT ▪ Direct mount: 6 driven stations ▪ C-axis: 0.001° Tailstock ▪ Quill diameter: 100 mm ▪ Quill stroke: 120 mm ▪ Taper: 5 MT Bar Feeder Magazine ▪ Type: Samsys Multisam 2000 ▪ Bar length: max. 1550 mm Machine dimensions without accessories (LxW): approx. 3300 x 1960 mm Overall machine length (machine + chip conveyor + bar feeder): approx. 7000 mm Machine height: approx. 2150 mm Weight: approx. 10,500 kg

Condition: good (used), Year of construction: 2011, functionality: fully functional, Machine Type: CNC Lathe Manufacturer: Hwacheon Model: Cutex-160A MC Year of Manufacture: 11/2011 Control: Fanuc 0i-TD Country of Origin: Korea Delivery: from stock • Driven tools • Turning and milling spindle • Including tailstock • Including bar loading magazine • High productivity This horizontal CNC lathe is in very good condition. Thanks to its standard and additional features, the machine offers short turret indexing times and high rapid traverse speeds. Three-axis machining and the additional turning and milling spindle enable versatile and efficient processing of workpieces. The additional tailstock and accompanying short bar feeder further increase production productivity. This is a cost-effective used machine for series production. Equipment • Chip conveyor for lateral installation with chip tray • Short bar loading magazine • Interface for bar feeder unit • Workpiece catcher (parts catcher) • Turning and milling spindle • Chuck confirmation switch (open/close) • C-axis indexing • Driven tools • Drag-along tailstock • Linear guideways Technical Data Performance • Swing diameter over bed: 550 mm • Max. turning diameter: 260 mm • Max. turning length: 225 mm • Chuck size: 6" Spindle • Spindle nose (ASA): A2-5 • Max. spindle speed: 6000 rpm • Spindle bore diameter: 56 mm • Max. bar capacity diameter: 45 mm • Spindle motor: 15/7.5 kW Turret • Number of turret stations: 12 positions • Turret indexing time (s/position): 0.15 Feed Rates • Rapid traverse X-axis: 36 m/min • Rapid traverse Z-axis: 36 m/min • Max. travel X-axis: 170 mm • Max. travel Z-axis: 335 mm • Feed motor X/Z: 3.0/1.8 kW Tailstock • Quill diameter: 60 mm • Quill stroke: 80 mm • Taper/mounting: MT4 Turn-mill spindle • Spindle motor: 3.7/2.2 kW • Max. spindle speed: 5000 rpm Bar loading magazine • Manufacturer: Fedek Machine Co. • Model: DH-65 • Min./max. bar length: 280/1200 mm • Bar diameter: 5-65 mm Dsdpexcpllofx Acwocn • Dimensions (LxWxH): approx. 1620×620(1200)x1400 mm

Condition: used, Year of construction: 2014, Very good condition! Available immediately! Control: Fanuc Oi - TD Travel: X-195 mm, Z-660 mm Dcodpfx Acexca U Dowsn programmable tailstock: via M function turning diameter: 254 mm tool turret: 12x coolant tank : 180L, 6 bar pump pressure electric handwheel: ,

Condition: good (used), Year of construction: 2001, turning diameter over cross slide: 410 mm, turning length: 550 mm, turning diameter: 250 mm, spindle bore: 73 mm, spindle speed (max.): 3,500 rpm, spindle speed (min.): 35 rpm, travel distance X-axis: 190 mm, travel distance Z-axis: 370 mm, spindle motor power: 11,000 W, rotational speed (min.): 35 rpm, rotational speed (max.): 3,500 rpm, overall weight: 3,000 kg, swing diameter over bed slide: 515 mm, bar passage: 65 mm, We offer a reliable Mori Seiki CL-203B/500 CNC lathe with MSG-803 control. Technical data: Control: Mori Seiki MSG-803 Centre distance: approx. 500 mm Max. turning diameter: approx. 200 mm Spindle bore: 65 mm Spindle speed: 3,500 rpm Spindle mount: A2-6 Drive power: approx. 11 kW Dodpfx Acjxb Uf Iswecn Travel paths: X ≈ 235 mm / Z ≈ 310 mm Rapid traverse X/Z: 30 m/min Turret: 12 stations Machine weight: approx. 3,000 kg Year of manufacture: 2001 Equipped with tailstock.

Condition: good (used), Year of construction: 2002, Machine is in good working condition. Parts shown by hand not come. Dcodsxbqnxspfx Acwon

Condition: used, Year of construction: 2003, turning diameter 0240 mm turning length 525 mm control 840 D Siemens centre height 120 mm turning diameter over bed 450 mm Dcjdpsw U Eifjfx Acwsn turning dia. over face-slide 300 mm turning speed range - main spindle max. 5.000 min/-1 power capacity - main spindel 21,5 kW usable bar diameter 42 mm travel -x axis 210 mm travel -y axis 80 mm travel -z axis 525 mm number of toolpositions 16 pos. tool taper VDI 30 Shank diameter 20 x 20 mm rapid traverse X: 24 / Z: 30 m/min Feed force 4,5 kN total power requirement 30 kVA weight of the machine ca. 5 t dimensions of the machine ca. 5,0 x 2,2 x 1,8 m CNC - Lathe with sub spindle. Control Siemens 840 D. Machine has Y- axe and live tooling. We supply an IEMCA VIP 80 bar loader along with the machine and many accessories.

Condition: refurbished (used), Year of construction: 2000, functionality: fully functional, machine/vehicle number: 341966, Country of manufacture: Switzerland Voltage: 400/50/3 Net weight: 2640 kg Customs tariff number: 8458.1120 Dimensions: 2301 x 1438 x 1676 mm TECHNICAL SPECIFICATIONS Capacities: Maximum turning diameter: 330 mm Maximum diameter admitted over cross slide: 160 mm Center height over cross slide: 83 mm Maximum diameter admitted over bed: 430 mm Turning length (depending on equipment): 650 mm Headstock: Standardized spindle nose, suitable for use with various collets and chucks using adaptation accessories. Collet accessories (SCHAUBLIN): B45/F48 Maximum bar capacity, diameter: 36 mm / 42 mm Automatic chuck, standard diameter: 170 mm Direct drive via AC motor, power at 100% / 50% duty: 15 / 18.5 kW Maximum torque at 100% / 50% duty: 135 / 165 Nm Maximum spindle speed: 5000 rpm C axis: Pneumatic clamping cylinder: 2700 daN Cross slide: Transverse travel, X axis: 240 mm Radial resolution: 0.0005 mm AC motor drive, nominal torque: 3 Nm Ball screw, diameter x pitch: 32 x 5 mm Longitudinal travel, Z axis: 720 mm Resolution: 0.001 mm AC motor drive, nominal torque: 6 Nm Ball screw, diameter x pitch: 32 x 10 mm Dedpfx Aew T Smhscwecn Feeds: Stepless working feeds, X/Z axes: 0–5000 mm/min Rapid traverse feeds, X/Z axes: 8 / 10 m/min Feed force, X/Z axes: 420 / 670 daN Turret tool system: Number of tool stations: 8 Standardized tool holder mounting: VDI 30 Max. tool shank size: 20 x 20 mm Integrated coolant Indexing in both rotation directions Coolant system: Tank capacity: 120 liters Pump flow rate: 10 l/min Pressure: 5 bar Unless otherwise specified, the above technical details are provided without commitment or liability.

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, Takisawa EX 310 with C-axis, driven tools including accessories Dodpfxjw Th Hko Acwecn Control: Fanuc

Condition: good (used), Year of construction: 2000, Machine come without tool holders and any additional equipement. Parts shown by hand not come. Technical details are shown on picture. Dodpfx Acow Tc S Uswscn

Condition: used, Year of construction: 2006, functionality: fully functional, Equipment: rotational speed infinitely variable, For sale: CNC lathe CUTEX 240 - Year of manufacture: 2006 Dcsdjw Skuujpfx Acwon - Siemens control - Max. diameter: 350 mm - Max. distance between centers: 700 mm - Includes various live centers Further information available upon request

Condition: new, Year of construction: 2025, Horizontal CNC Lathe HTC200 II x 560 C2023030141 Working Area: Max. swing diameter over bed: Ø620 mm Max. swing diameter over carriage: Ø410 mm Max. turning diameter: Ø400 mm Max. turning length: 560 mm Spindle center height: 1035 mm X-axis travel: 215 mm Z-axis travel: 615 mm Motorized High-Speed Spindle Max. spindle speed: 4,500 rpm Spindle power (continuous/30 min overload): 11/15 kW Spindle torque: 158/211 Nm Spindle nose taper: DIN55026 A2 6 Spindle bore: Ø66 mm Spindle bearing diameter: Ø100 mm Chuck size: 8 inches Turret Turret type: Servo V12 OD tool size: 25x25 mm ID tool size: Ø40 mm Indexing time (tool to tool): 0.2 s Tailstock: Tailstock type: Hydraulic Quill diameter: Ø100 mm Quill taper: MT No.5 Quill stroke: 122 mm Tailstock travel: 550 mm Feed Shaft X/Z-axis travel: 215/615 mm Rapid traverse X/Z-axis: 24/30 m/min Type of guideway: Linear guideway X/Z-axis drive power: 1.8/1.8 kW Control System: FANUC 0i-TF Power supply: 35 kVA Coolant capacity: 240 l Machine weight: 4.8 t Dcsdsw Rpchepfx Acwsn Machine dimensions (LxWxH, without chip conveyor): 3097x1855x1755 mm Components Control: FANUC X/Z-axis ball screw: PMI (TW) Spindle bearings: NTN/NSK (JP) Spindle ball bearings: FAG (GE) Chuck and cylinder: STRONG (TW) Servo turret: HISION (CN) Main components of pump and valves: NACHI (JP) Main lubrication system components: LIUBIAN (CN) Main electronic components: Schneider

Condition: new, Year of construction: 2025, Horizontal CNC Turning Machine HTC200 II x 560 C2023030332 Working Area: Max. swing over bed: Ø620 mm Max. swing over carriage: Ø410 mm Max. turning diameter: Ø400 mm Max. turning length: 560 mm Spindle center height: 1035 mm X-axis travel: 215 mm Z-axis travel: 615 mm Motorized High-Speed Spindle Max. spindle speed: 4,500 rpm Spindle power (continuous/30 min. overload): 11/15 kW Spindle torque: 157/211 Nm Spindle nose taper: DIN55026 A2 6 Spindle bore: Ø66 mm Spindle bearing diameter: Ø100 mm Chuck size: 8 inch Turret Turret type: Servo V12 OD tool size: 25x25 mm ID tool size: Ø40 mm Indexing time (tool-to-tool): 0.2 s Tailstock Tailstock type: Hydraulic Quill diameter: Ø100 mm Center type: MT 04 Quill stroke: 122 mm Tailstock travel: 550 mm Feed Shaft Dodpow Rpa Tefx Acwscn X/Z axis travel: 215/615 mm Rapid traverse X/Z axis: 24/30 m/min Guideway type: Linear guideways X/Z axis drive power: 1.8/1.8 kW Control System: FANUC 0i-TF Power supply: 35 kVA Coolant tank capacity: 240 l Machine weight: 4.8 t Machine dimensions (LxWxH, without chip conveyor): 3,097 x 1,855 x 1,755 mm Components Control system: FANUC X/Z-axis ball screws: PMI (TW) Spindle bearings: NTN/NSK (JP) Spindle angular contact bearings: FAG (GE) Chuck and cylinder: STRONG (TW) Servo turret: HISION (CN) Main hydraulic pump and valves: NACHI (JP) Primary lubrication system components: LIUBIAN (CN) Main electronic components: Schneider

Condition: good (used), Year of construction: 2000, functionality: fully functional, turning diameter over cross slide: 420 mm, turning length: 640 mm, turning diameter: 250 mm, spindle bore: 51 mm, spindle speed (max.): 4,000 rpm, spindle speed (min.): 40 rpm, Equipment: chip conveyor, TAKISAWA TC-20 CNC Turning Center S/N: TLMZ6628 Swing: 16.5″ (419 mm) Max Turning Length: 25.19″ (640 mm) Max Turning Diameter: 9.84″ (250 mm) Chuck Size: 8″ (203 mm) Bar Capacity: 2″ (51 mm) Spindle Speed: 4,000 RPM Spindle Motor: 15 HP (11.2 kW) Turrets: 1 Dsdow Na Daepfx Acwscn Tool Stations: 12 Box Ways Construction Floor Space: 75″ × 50″ × 76″ (1,905 × 1,270 × 1,930 mm) Weight: ~5,600 lbs (2,540 kg)

Condition: ready for operation (used), Year of construction: 2022, operating hours: 2,800 h, functionality: fully functional, machine/vehicle number: AU1190, turning diameter: 280 mm, spindle bore: 52 mm, spindle speed (max.): 5,000 rpm, travel distance X-axis: 200 mm, travel distance Z-axis: 510 mm, CNC lathe from 2022 with only 2,800 operating hours! The machine is being auctioned with a comprehensive tooling package! Placing a bid obligates you to collect the machine on time in calendar week 39 or 40! The seller will specify a fixed pick-up date, which must be adhered to! TECHNICAL DETAILS Max. turning diameter: 280 mm Spindle data Spindle bore: 52 mm Spindle speed: max. 5,000 rpm Spindle motor power: 23,500 W Dedpfsw Iy Txox Acwocn Axis data X-axis travel: 200 mm Z-axis travel: 510 mm X-axis rapid traverse: 15 m/min Z-axis rapid traverse: 24 m/min Tooling Tool rotation speed: max. 4,500 rpm Tool stations: 12 (all driven) Tool holder: VDI 30 Tailstock Quill diameter: 60 mm / MT 4 Quill stroke: 125 mm Tailstock longitudinal travel: 500 mm MACHINE DETAILS Control: Siemens 840DE Dimensions & Weight Footprint (L x W x H): 3,500 x 2,200 x 1,900 mm Total weight: 4,000 kg Operating hours: 2,800 EQUIPMENT SPINNER SPIOS 24" touch panel 14.0 SHOPTURN process step programming Additional chuck jaws Spinner Multicontrol Wheel Power chuck SMW 210 mm C-axis Chip conveyor High-pressure pump 15 bar Measuring probe (tool measurement) Incl. tool holder and tooling package

Condition: excellent (used), Year of construction: 1988, functionality: fully functional, turning length: 420 mm, turning diameter: 250 mm, spindle bore: 42 mm, spindle speed (max.): 4,000 rpm, chuck outer diameter: 200 mm, controller manufacturer: Fanuc, number of slots in tool magazine: 12, • Year of Manufacture: 1988 • Country of Origin: Japan • Controller: FANUC • Number of Turret Tools: 12 Dodpfx Asw Hnwqecwjcn • Tailstock: Available • Machine Weight: 3000 kg

Condition: used, Year of construction: 2018, Lathes Travel distance X: 221 mm Travel distance Y :100 mm Travel distance Z: 400 mm turning length: 380 mm max. circulation diameter: 280 mm spindle boring: 65 mm input Power: 11 kW max. turning moment: 80 NM range of revolution from: 100 rpm range of revolutions till: 4500 rpm Djdow Ekimopfx Acwocn Control: Fanuc 0i-TF Powered tools: 12 working hours approx: 813 h control Fanuc Scrapper chip conveyor
