Condition: good (used), Year of construction: 2005, Pusher Furnace System (PUS1), Manufacturer: Ipsen International GmbH, Type: PP-2-65x65x65-18-G, Serial No.: AN 10.1595-01, Year of manufacture: 2005, Fuel: Gas/Natural Gas/Nitrogen/Methanol, 414 kW, 296 kVA comprising: Two-Chamber Pre-Washing Machine, Type: WPSSB-65x65x65-E, 302 A, 199 kVA, electric, Washing tank 2 m³, rinsing tank 2 m³, 60-80°C Pusher Preheating Furnace, Type: DL 65x65x65 4-G, 25 A, 9.5 kVA, natural gas heated, 80-100 mbar, 350-500°C Pusher Gas Carburizing Furnace (Double Line), Type: PP-2 65x65x65-18-G, natural gas heated, 86 A, 29.6 kVA, 10 kWh/m³, 80-100 mbar, 860-950°C, 140 pieces per batch, 695 kg/h Oil Quenching Bath (Hardening Oil), Type: QO-65x65x65-E, 161.5 A, 93.1 kVA, electric, air cooling, 6 m³ tank volume, 120°C max., 60-80°C working temperature Two-Chamber Post-Washing Machine, Type: WPSSB-65x65x65-E, 302 A, 199 kVA, electric, washing tank 2 m³, rinsing tank 2 m³, 60-80°C Pusher Tempering Furnace, Type: DL-65x65x65-6-E, Iedpfxeyabxye Ahusal 126.8 A, 84 kVA, electric, 300°C max. furnace temperature, 150-240°C working temperature Batch Transport System, Measuring, Control, and Switch Cabinet with Conti-Control System, Type: CO/CO2-2 Batch Data: Case hardening for transmission parts 650 mm x 650 mm x 650 mm, max. 280 kg, batch transport height 800/2,200 mm

Condition: good (used), Year of construction: 2017, functionality: fully functional, Technical details core drilling diameter max. 3 - 28 mm bore depth 1000 mm control Heidenhain TNC 640 x-axis 1000 mm y-axis 800 mm z-axis 800 mm spindle head - swivable (W) +15°/-30° deg B-axis (table) 360.000° deg table surface area 1000 x 1000 mm table load 5,0 t tool taper SK 40 Iajdjx Ux Dkepfx Ahuel spindle turning speed range 60 - 6000 U/min spindle motor 12 kW total power requirement 58 kW weight of the machine ca. 14 t dimensions of the machine ca. 6,35 x 4,75 x 3,80 m Additional information 5 axes Deep Drilling-Milling-Machine A current geometry measurement report is available. Equipped with: HEIDENHAIN TNC 640 control 5 CNC AXES X – Y – Z – W – B NC rotary table 360.000 deg. Milling performance 150 cm3/min. Direct linear position measuring system Digital AC drives Table design with Hirschmann zero-point clamping system NC-controlled tilting of the deep hole drilling/milling unit (W) +15/-30 deg. Automatic tool changer for 24 tools Internal coolant supply High-pressure coolant system 1200 liters for deep hole drilling oil up to 140 bar Paper belt filter system SIEMENS extinguishing system Fire protection system Spindle cooling Oil temperature control 3D HEXAGON probe RENISHAW tool measurement Electronic handwheel OPT kinematics Chip conveyor Coolant pressure and flow control Collision and vibration monitoring Feed control Coolant gun MONTRONIX machine airbag Oil mist extraction 2 clamping plates Walk-in full enclosure with roof and opening for crane loading Included in delivery: Operating manual Documentation Machine parameters on USB stick

Condition: used, Year of construction: 2007, functionality: fully functional, 3 axe machine Siemens Sinumerik 840 D 1000 rpm Table 3300 x 950 mm X axe 950 mm Z axe 1750 mm Isdpjx Uqp Sjfx Ahueal Table loading 4000 kg

Condition: excellent (used), Deep hole drilling machine tools DEGEN - UTB Iedpox Tp Ahsfx Ahusal MACH-ID 9188 Make: DEGEN Type: UTB Year: 2005

Condition: good (used), Year of construction: 2008, IXION TL 1001 CNC Deep Hole Drilling Machine with Equipment Year of manufacture: 2008 Control system: MITSUBISHI M530 Machine number: 950521 Drilling depth (Z), CNC controlled: 1,000 mm Iodpfex Tdwajx Ahueal Drilling unit (Y), vertically traversable: 800 mm Table size: 1,200 mm x 700 mm Table load: 3,000 kg Table longitudinal travel (X): 1,000 mm Table displacement (W): 1,000 mm Table rotatable by 360° Spindle: SK 40 Spindle speed: 100 – 4,000 rpm Max. drilling capacity in steel: 25 mm Max. thread cutting in steel: M20 Milling in steel possible Weight: approx. 3,500 kg Equipment: Compact belt filter KBF Electronic handwheel Coolant system Chip conveyor KBF 270 P50 Included in delivery: Deep hole drilling tools Workplace with: Holders / mounting brackets / supports / sealing discs Operating manual/documentation Machine parameters on storage medium For equipment, technical data, installation & transport – see PDF. Image, content, and details are provided without guarantee and therefore not binding. All additional accessories visible in the photos and video are not included in the scope of delivery and are therefore not part of this sale. The scope of delivery includes only the accessories explicitly listed here, in the order confirmation and invoice. FCA (Free Carrier, loaded on truck) D-04643 Geithain packaging only Lead time: immediately Subject to prior sale / Payment due immediately upon purchase

Condition: ready for operation (used), Year of construction: 1983, operating hours: 6,348 h, functionality: fully functional, drilling depth: 1,500 mm, travel distance X-axis: 1,250 mm, travel distance Y-axis: 900 mm, travel distance Z-axis: 900 mm, drill diameter: 50 mm, The machine was overhauled in 2009! TECHNICAL DETAILS Drilling depth: 1,500 mm Drill diameter: 5 - 50 mm Travel X-axis: 1,250 mm Travel Y-axis: 900 mm Travel Z-axis: 900 mm Table length: 1,000 mm Table width: 1,000 mm Max. table load: 3,000 kg Spindle speed: 100 - 6,000 rpm Spindle taper: SK 40 MACHINE DETAILS Control: Siemens 802 D Dimensions & Weight Dimensions (L x W x H): 5,000 x 2,600 x 2,000 mm Weight: 6,000 kg Operating hours: 6,348 h Iasdsx Ngxrspfx Ahuol

Condition: refurbished (used), 2-spindle deep hole drilling machine under reconstruction Iaodpex E U S Eofx Ahuel

Condition: repair required (used), Year of construction: 1991, functionality: limited functionality, machine/vehicle number: 950082, drilling depth: 1,000 mm, travel distance X-axis: 1,500 mm, type of input current: three-phase, This machine is equipped with a Bosch CC100 M control system and has a defect. All motors and the drive are in working condition. The machine can be used for retrofit or as a source of spare parts. Ijdox Afbpopfx Ahueal

Condition: excellent (used), Year of construction: 2003, Deep Hole Drilling and Milling Machine TBFZ 1600 CNC Year of manufacture: 2003 Iodpfjxz Aygex Ahuoal X-AXIS TRAVEL: 1600 MM Y-AXIS TRAVEL: 1200 MM Z-AXIS TRAVEL: 500 MM W-AXIS TRAVEL: 1200 MM B-AXIS TRAVEL: 360° (Rotary table) * Table size (LxW): 1500x1500 mm * T-slots: 5x DIN 650-22 h12, 150 mm spacing * Tool clamping: hydraulic * Electrical connection: 400 V, 50 Hz * Compressed air connection: rated flow rate 7000 l/min, operating pressure: 6 bar * Botek driller optionally available * Feed drive: brushless AC servo motors * Feed rate: 0-20000 mm/min * Rapid traverse: X 20000 mm/min, Y+Z 20000 mm/min * Manual mode: 20000 mm/min * Setup operation: 0-2000 mm/min

Condition: like new (used), Year of construction: 2019, operating hours: 454 h, functionality: fully functional, machine/vehicle number: 7438, drilling depth: 3,000 mm, total length: 11,515 mm, total width: 5,415 mm, total height: 2,350 mm, overall weight: 14,450 kg, spindle speed (min.): 13 rpm, spindle speed (max.): 1,800 rpm, rapid traverse Z-axis: 6,000 m/min, type of input current: AC, input voltage: 400 V, Deep drilling machine, in excellent conditions due to very limited usage - 454 hours. Tooling of different diameters available and included in the price. Selling because of business change. Iodpfx Ajxzq Ryohusal

Condition: like new (used), Ryazan Model PT295106 Deep Hole Borer x 4000mm Manufacturer Ryazan Model PT295106 Iedsxzp Rlepfx Ahujal Year 1985 Condition Used Stock Number 2850 Centre Height 550mm Solid Boring Capacity 200mm Max Boring Length 4000mm Headstock Hollow spindle 500mm Headstock Spindle speeds 16-250 rpm Headstock drive 50/75kw Max boring length in front of headstock 3500mm Max boring length if using the 500mm hollow spindle 4000mm

Condition: excellent (used), Year of construction: 2012, operating hours: 79,000 h, functionality: fully functional, machine/vehicle number: 106648-11, Please provide your offer price. Sales only within Europe, including Turkey. Price excluding packaging; delivery condition: FCA (machine location). Iasdpfxjxzgrae Ahuol Available machines: 5 units, identical process. Year of manufacture: 2001 - 2012 ===== For technical data, please refer to the handout. All warranty rights are excluded. We do not guarantee the accuracy of the technical data and year of manufacture, the completeness of accessories and tooling, or compliance with all safety and environmental protection requirements specified in accident prevention regulations. No sale to private individuals.

Condition: excellent (used), Year of construction: 2018, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,600 mm, travel distance Z-axis: 1,800 mm, Table 1,500 x 1,500 mm X 2,000 mm Y 1,600 mm Z 1,800 mm B-axis, A-axis swiveling +/- 19 degrees Machine features full enclosure Chip conveyor and high-pressure coolant system Tool holder SK 50 Control Heidenhain iTNC 640 Iaodpsxyic Sofx Ahusl Table load capacity 20 tons Spindle speeds up to 4,000 rpm Rapid traverse 20 m/min Tool changer with 40 stations

Condition: excellent (used), Year of construction: 2007, • Maximum possible drilling depth: 1200 mm • Maximum hole diameter: 32 mm • Minimum drilling diameter: 6 mm • Longitudinal travel (X-axis) table: 1800 mm • Cross travel (Z-axis) column: 1700 mm • Cross travel (W-axis) drilling head: 1150 mm • Vertical travel (Y-axis) drilling head: 1200 mm • Clamping surface NC table: 1500 x 1000 mm • Maximum table load: 10 t • Rotary axis (B-axis) rotary table: 360° • Rotary axis (A-axis) drilling head: -25°/+15° • Feed rate: 1-15 m/min (Y-axis: 1-10 m/min) • Rapid traverse speed in all axes: 15 m/min (Y-axis: 10 m/min) • Maximum spindle speed: 6000 rpm • Minimum spindle speed: 60 rpm • Tool holder: SK 40 • Tool clamping: OTT • Rated power main drive (100% ED, S1/40% ED, S6): 9/13 kW Iasdexyf E Nopfx Ahuel • Coolant tank capacity: 1000 l • Maximum coolant pressure: 100 bar • Low-pressure external and high-pressure internal coolant supply • Power supply: 3x 400 V; 50 Hz • Required installation space (L x W x H): 6550 x 5350 x 4130 mm • Machine weight: 12,000 kg Deep Hole Drilling Machine Equipment • CNC control: HEIDENHAIN iTNC 530 • Interpolated rotary table with minimal backlash, dimensions 1500 x 1000 mm • Swiveling drilling head +15°/-25° • Shank drilling head • Handwheel HR520 • Fixed supports (2 units) • Tool magazine: ELB tools: 12 pcs (max. diameter: 32 mm / max. length: 1550 mm) Standard tools: 12 pcs (max. diameter: 140 mm / max. length: 400 mm) • Direct measurement and positioning system in X, Y, and Z axes • Collision monitoring system for supports and drill sleeves • Oil cooler • Coolant flow control system • Adjustable coolant nozzles • Cooling unit for electrical cabinet • Enclosed upper cover (roof) • Drip tray for machine and tank facility (tray height 30 mm) • Extraction system • Infrared touch probe • Drilling depth extension 1200 mm (retrofit) • Chip conveyor

Condition: excellent (used), Year of construction: 2016, operating hours: 40,000 h, functionality: fully functional, Technical data: Iajdpfoxyarwox Ahuel 3 x drilling spindles Boring method: BTA Minimum drilling diameter: 18 mm Maximum drilling diameter: 30 mm Maximum drilling depth: 1800 mm Rotating tailstock, hydraulic with counter-rotation, stroke 45-50 mm Spindle distance: 210 mm Feed rate: 1-4000 mm/min Position display with 1-axis PLC deep hole drilling control and monitoring Gear motor with holding brake for counter-rotation of workpieces, 160 rpm Chip conveyor Oil trough with extraction pump

Condition: excellent (used), bore depth 500 mm Isdpoxx A D Tefx Ahueal spindle speed: 1

Condition: excellent (used), Year of construction: 2001, drilling depth: 700 mm, travel distance X-axis: 1,600 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,600 mm, spindle speed (min.): 6,000 rpm, drill diameter: 40 mm, table length: 1,500 mm, table width: 1,250 mm, table load: 10,000 kg, Year of manufacture: 2001 Iajdpoxu Dkgofx Ahusl Control: Heidenhain TNC 430 X: 1600 mm Y: 1200 mm Z: 1600 mm W: 500 mm Table: 1500*1250 mm, 10T B-axis, A-axis swiveling +/- 19 degrees Machine features full enclosure Chip conveyor with coolant system Tool holder: SK50 Tool changer: 20 positions

Condition: excellent (used), functionality: fully functional, drilling depth: 1,000 mm, feed length X-axis: 1,650 mm, feed length Y-axis: 1,000 mm, travel distance Z-axis: 360 mm, spindle speed (max.): 4,200 rpm, drill diameter: 40 mm, rapid traverse X-axis: 10 m/min, rapid traverse Y-axis: 10 m/min, rapid traverse Z-axis: 10 m/min, spindle motor power: 10,000 W, table length: 700 mm, table width: 1,400 mm, table load: 4,000 kg, feed length W-axis: 500 mm, Selca S4040D CNC Control Drilling depth, transverse movement V axis: 1,000 mm Column, longitudinal movement X axis: 1,650 mm Ijdpfjxpwf Tox Ahusal Drilling slide, vertical movement Y axis: 1,000 mm Drilling slide, workpiece support movement W axis: 500 mm Drilling slide, maximum vertical "swivel" - A axis: +20° / –20° Rapid traverse, adjustable speed up to 10,000 mm/min Drilling diameter in solid material min/max: 5 – 40 mm Drilling spindle, rotational speed, adjustable: 1 – 4,200 rpm Drilling spindle motor power: 10 kW Fixed clamping table, dimensions: 700 x 1,400 mm Standard clamping slots: 18 mm Hydraulic pump motor power: 7.5 kW Gun drill holder; shank for drills > 6 mm: 10 x 40 mm Gun drill holder; shank for drills < 6 mm: 25 x 70 mm Clamping table ROTARY & "BARRASENO" axis B Dimensions mm: 800 x 1,000 Standard clamping slots: 18 mm Maximum axial load (rotary): 4,000 kg Continuous rotary axis B resolution: 360,000 steps/rev Maximum vertical resolution "BARRASENO" axis B1: +20° / –20° Small milling head – threading, etc. Maximum horizontal working stroke Z axis (830): 360 mm Spindle speed, adjustable up to 2,200 rpm Threading spindle motor power: 10 kW ISO40 tool changer with 10 rotary-translating stations USED MACHINE

Condition: refurbished (used), Year of construction: 2000, functionality: fully functional, drilling depth: 600 mm, rotational speed (max.): 6,000 rpm, center height: 250 mm, controller model: SIEMENS Sinumerik 840 D, workpiece diameter (max.): 25 mm, No reserve price – guaranteed sale to the highest bidder! The machine has been completely overhauled! TECHNICAL DETAILS Working depth: 600 mm Working diameter: 4 – 25 mm Number of spindles: 2 Centre height: 250 mm Centre distance: 203.2 mm Speed range: 1,000 – 6,000 rpm Feed rate: 0 – 300 mm/min Rapid traverse: 6,000 mm/min MACHINE DETAILS Control system: SIEMENS Sinumerik 840 D (Retrofit) Drilling system: Single-lip deep hole drilling Main drive: 2 x 5.5 kW EQUIPMENT - Single functions for machine setup - Semi-automatic operation for manual loading - Robust spindle carriage - Machine monitoring with spindle speed display - Table plate in special cast design - Safety guard with sliding door - Machine bed with hardened and ground linear guides - Internal coolant supply through drilling spindle - Electrical equipment according to IEC standards - Separate control cabinet with safety devices Iedoxpvbtepfx Ahusal - Control panel in working area

Condition: ready for operation (used), Year of construction: 1979, functionality: fully functional, machine/vehicle number: 419.324.012, drilling depth: 1,200 mm, spindle speed (max.): 3,000 rpm, table length: 1,050 mm, table width: 1,050 mm, center height: 1,040 mm, No minimum price – guaranteed sale to the highest bidder! The payment deadline for the machine is 20/11/2025! Placing a bid obligates you to collect the machine on time between 01/12/2025 and 05/12/2025! TECHNICAL DETAILS Drilling depth: 1,200 mm Spindle speed (min): 50 rpm Spindle speed (max): 3,000 rpm Feed rate (Row 1): 18 – 160 mm/min Feed rate (Row 2): 35 – 320 mm/min Rapid traverse speed: 3.5 m/min Rated motor speed: 1,400 rpm Table length: 1,050 mm Table width: 1,050 mm Centre height above table: 240 – 1,040 mm Iaedpexm S Idofx Ahusl MACHINE DETAILS Dimensions (L x W x H): 6,500 x 3,500 x 2,900 mm Electrical data Operating voltage: 380 V Frequency: 50 Hz Connected load: 25 kW EQUIPMENT 3-axis Heidenhain digital readout Coolant system

Condition: ready for operation (used), Year of construction: 2011, functionality: fully functional, machine/vehicle number: 35114, feed length X-axis: 600 mm, feed length Y-axis: 300 mm, feed length Z-axis: 600 mm, spindle speed (max.): 4,000 rpm, drill diameter: 16 mm, No reserve price – guaranteed sale to the highest bidder! The payment deadline for the machine is 20/11/2025! Placing a bid obligates you to collect the machine on time between 01/12/2025 and 05/12/2025! TECHNICAL DETAILS Feed travel X-axis: 600 mm Feed travel Y-axis: 300 mm Feed travel Z-axis: 600 mm Feed travel W-axis: 650 mm Spindle speed (max.): 4,000 rpm Drilling diameter, twist drill: max. 16 mm Single-lip drill: 4 to 16 mm Ijdsxm S Hyopfx Ahuoal Tapping: max. M12 Table length: 1,000 mm Table width: 680 mm MACHINE DETAILS Control model: HEIDENHAIN TNC 124 DIMENSIONS & WEIGHT Dimensions (L x W x H): 3,500 x 1,500 x 2,100 mm Total weight: 2,000 kg

Condition: good (used), Bench drill, pillar drill, column drill, column drill -Manufacturer: WMW Heckert, bench drilling machine type BT 2 -Clamping table: 340 x 280 mm -Travel: 350 mm -Spindle holder: MK2 -Projection: 215 mm -Speeds: 355/710/1400/2800 rpm -Column: diameter 93 mm -Spindle stroke: 100 mm / depth stop with fine adjustment -Motor: VEM 0.8/1.0 kW with brake Iasdpsxm Rzisfx Ahujl -Voltage: 380 V -Number: 2x drill available -Price: per piece -Dimensions: 550/480/H1270 mm -Weight:157 kg/piece

Condition: used, Year of construction: 2006, Solid drill diameter / mm bore depth / mm number of spindles / Froriep CNC deep hole drilling machine – the prefabrication specialist Year of manufacture: 2006 Control system: Siemens Sinumerik 840D Max. drilling depth: 8,850 mm Workpiece diameter: 150 – 900 mm Speed range: 1 – 300 rpm Feed rate: 0.5 – 4,500 mm/min Drive power: 129 kW Swing diameter over bed: 1,000 mm Clamping diameter faceplate: 900 mm Iaodpfexgu R Iex Ahuol Weight: approx. 47,000 kg Ideal for precise pre-drilling of deep holes – including faceplate, steering ring

Condition: good (used), Year of construction: 2009, operating hours: 20,709 h, functionality: fully functional, machine/vehicle number: 106516-11, drilling depth: 1,200 mm, overall weight: 7,500 kg, For sale: A very well-equipped deep hole drilling machine from TBT, including various accessories. Drilling specifications: - Spindle 1: 5–18 mm; Spindle 2: 1–4 mm - Drilling depth: approx. 1200 mm with Ø8 mm using 3 steadies - Number of spindles: 2 - Spindle drive: Spindle 1: 1 x 4 kW; Spindle 2: 1 x 1.2 kW - Spindle speed: Spindle 1: 600–6000 rpm; Spindle 2: 2000–24000 rpm - Rapid traverse: 15,000 mm/min - Saddle stroke (nominal): 1800 mm - Coolant: Deep hole drilling oil Iedpexgnhaofx Ahusal - Tank capacity: 1,100 liters - Operating voltage: 3AC 400V, 50Hz (Total connected load: 25 kW) Condition: Good, appropriate for its age Accessories: Includes drip tray and various drills On-site inspection is recommended!

Condition: used, Year of construction: 2004, Solid drill diameter 200 mm bore depth / mm number of spindles / Technical data Power: 129 kW Control: Siemens NC control Speed range (stepless): 2 - 300 rpm Feed range (in steps): 3 - 4500 mm/min Oil system capacity: 20,000 litres Maximum delivery rate: 1500 l/min Circular diameter in steady rest: 1100 mm Circular diameter over bed: 1250 mm Centre distance: 11000 mm Clamping diameter face plate: up to 1100 mm Max. workpiece weight with one tailstock: 10 t Clamping range of the two steady rests: 150 - 1100 mm Clamping range BOZA: 1 = 200 - 400 mm 2 = 400 - 800 mm Dimensions Min. outer diameter: 406 mm Max. outer diameter: 850 mm Wall thickness: 10–150 mm Max. workpiece length: 11,000 mm Max. workpiece weight: 10 t Max. strength: 800 N/mm² Specific cutting resistance (Ks): 2000–2100 N/mm² Machine data Machine length: 28,800 mm Centre height: 560 mm Swing diameter over bed: 1120 mm Full drilling diameter: 200 mm Core drilling diameter: 350 mm Iajdpfx Ahexgic Ejujl Reaming diameter without drilling: 350 mm Reaming diameter with drilling: 350 mm Headstock: Main drive motor: Siemens Type: 1 PH 7228 Performance data at 1,000 min: 113 kW / 1,079 Nm Performance data at 1,150 min: 129 kW / 1,017 Nm Main gearbox: Z-F manual gearbox Type: 2 K210 Switchable gear ratios: i = 1:1 i = 1:4 Fixed gear ratio for spindle: i = 11.68 Max. torque: 50,000 Nm Speed range I: 2...300 min Speed range II: 2 ...75 min
